FOLIO
TEOH HOOI YING
MAY - NOV 2022
PORT-
Name StudentID DateofBirth Hometown Education SecondarySchool 2013-2017SMKTunkuAbdulRahman DiplomainArchitecturalStudies May2018-May2020UCSIUniversity BachelorofScience(Hons)inArchitecture Jan2021-Nov2022UCSIUniversity :TeohHooiYing :1001849879 :22/08/2000 :NibongTebal,PulauPinang :
02
02
Chang Qing Nature School Assignment 1 Project 1 Site Analysis & Site Reaction Assignment 2 Project 2 Literature Review Towards Architectural Spatial Concepts Assignment 3 Project 3 Design Development CONTENT
Task 01 A - Site Analysis of The Confluence Area (Group) Task 01 B - A 'Warm Up' Design-Thinking Proposal (Group) Task
A - Speculative: Literature Review towards Architectural Spatial Concepts Task
B - Micro Site Analysis & Site Strategies
Project 1a SiteAnalysis&SiteReaction
Assignment1-Task01A SiteAnalysisofTheConfluenceArea(Group)
THE CONFLUENCE
The confluence of Gombak River & Klang River forms the centralpointofthethreeparcels.Itisaplaceofthevivacityof atop-classmetropolis,whichyetfindsaplaceforitsdeepest of cultural roots, which grow from an array of seeds from places far and wide. It truly js, as the name suggests, a confluenceofcultures.
ThisprojectwillallowustounderstandmoreaboutTheConfluence Areathroughtheinspectionandfeasibilitystudiesonsite.UnitC focusesonthethemeof'KLFlashFlood'-'KLUrbanTraffic'-'City Making'.Eachgroupwillconductasiteanalysisandwillbecompiled intoaSiteReportincatalogformat.
The following groups are:
Group 1 Catalogue of Unit C Sites
Group 2 Catalogue of Buildings & Landscapes
Group 3 Catalogue of History & Crises
Group 4 Catalogue of People & Culture
Group 3: Catalogue of History & Crises within the Confluence of Kuala Lumpurt
History of Kuala Lumpur - the rural and urban liminality (past, present, future)
Identification of disaster events & its challenges (past, present, future)
Kuala Lumpur's architectural manifesto and proposals
Project 1b
A'WarmUp'Design-ThinkingProposal
(Downtown Kuala Lumpur's Laneway Improvement)
DOWNTOWN KL'S LANEWAY IMPROVEMENT
LORONG BANDAR 13
PRESENTED BY GROUP 4
DESIGN STATEMENT
Attempt to connect with the public communityandstreetfriendsbyusingthe same alleyway in balance, creating a friendlyfeelingforthepublic,andforming acloserrelationshipwiththepublicwho sharetheirculturalbeliefs.Spreadmore resourceknowledgetothestreetfriends and teach them how to use the area appropriately, providing them with the necessary survival resources. And to attractmorepeopletosocialisearound TheLorongBandar13,createapeaceful andcleanurbanalley.
SAMA - SAMA KONGSI
SAMA - SAMA KONGSI SHELTER
SAMA - SAMA KONGSI WASHROOM
MOCK-UP MODEL ON SITE MODEL
FOLDABLE SHELTER
Project 2a
Speculative:LiteratureReviewtowards ArchitecturalSpatialConcepts (Conceptual Model / Conceptual Poster)
Task 02 A - Speculative: Literature Review towards Architectural Spatial Concepts
In an effort to expand the students' understanding of design in space, this project now challenges specific architectural concepts.
NARRATIVE THINKING
Concrete vs Greens
This model aims to capture the contrast between the natural forest and the concrete jungle. The past of the city is on the right, surrounded by greenery and nature, whereas the current state of the city is on the left, with many high-rise structures. giving off a dense, depressing, and anxious mood. Once the left part putting onto the right part, the greens can only see in the fragmented holes and this is the issue that we are facing right now, which is Lack of Greens.
Escaping
This physical poster aims to convey the sense that the greenery is eagerly attempting to escape the extremely high dense concrete city.
Project 2b
MicroSiteAnalysis&SiteStrategies
Mockup Model
Understanding the site, implementing the strategies to the building form.
Project 3
DesignDevelopment
Project 3 - Design Development
Chang Qing Nature School
Green Culture . Cultivating . Experiencing
SITE 01
Master Plan
Observation
Site 01 was surrounded by high-rise buildings, with the majority of the buildings being mixed-use. The site's accessibility by public transportation is a strength. There are also a few Art & Culture establishments nearby, such as the National Textile Museum, which is just next to Site 01, and the Central Market, which is direct across the Klang River. The lack of greenery and vegetation at the site, as well as the way the main road isolated the greenery, are its weakness.
Master Plan
Observation
Alargeportionofthegreenspaceswas situated on the west side of Site 01. There are extremely few green spaces for public usage on the east side, and those that do exist are mainly used for private purposes. While the east is a concreteforestcity,thewestismainlya naturalgreenforest.
(Do refer the Google Earth Master Plan as well)
LACK OF GREENS
According to the WHO, every city is recommended to provide a minimumof9squaremetresofurbangreenspaceforeachpersonand that UGS must be accessible, safe and functional. But in KL, it has around 8 square metres per capita of urban green space only. ComparedwithMalaysia'scloser'neighbour',Singapore,acity-statewith the third highest population density in the world, provides 66 square metresofgreenspaceperhabitant
PROPOSED PROGRAMME
Education
Nature School Experiencing
Environment Education Community Garden Sport Activities Music Date
CASE STUDY
Reference Building form design
EL TERRENO COMMUNAL GARDEN / VERTEBRAL
Reference Program introducing
OLIVE OIL MILL TREBBIO - OFFICE 264
Chang Qing Nature School
In nature school, children can enjoy learning in unique environments that emphasizes on practical experience activities and environmental education.
Design Intention
To cultivate the spirit of appreciate the nature To create a green culture
常青学院
NORTH ELEVATION
EAST ELEVATION
SOUTH ELEVATION WEST ELEVATION
SECTION
SECTION B-B
A-A
URBS Graduation Exhibition
urbs_exhibition
ThankYou
