APRIL 20232023 MAY/JUNE MAY/JUNE 2023
If you are reading this advert, so are over 62,000+ others Digitally.
Special summer rate @ £525.00 To take ADVANTAGE of this special offer and book this advert please email: power@wipmagazines.com or call Tel. +44 (0) 1403 888019 HEAT PUMPS FOR THE UK MAN ES heat pumps have it all: heat production, storage, and reconversion into electricity for industrial & domestic use. Page 16-17 Prysmian Group, world leader in the energy and telecom cable systems industry, has received the notification from SSEN Transmission and National Grid Electricity Transmission plc, the GB electricity transmission network owners. The company been selected as the exclusive preferred bidder for the Eastern Green Link 2 (EGL2) cable connection. Prysmian Group continues the contract negotiations with the aim of concluding the contract in a timely manner. Eastern Green Link 2 is a planned high voltage direct current (HVDC) submarine and underground cable link of around 500 km route length between Peterhead in Scotland and Drax in the North of England. With a power transmission capacity of 2 GW the connection is expected to be one of the first cable systems in the UK to utilise 525 kV technology with extruded XLPE insulation. EGL2 forms part of a series of planned system reinforcements required to increase the capability of the existing UK transmission network and facilitate the growth in flows of renewable generation in the North to
GAS ENGINES IN IMMINGHAM VPI’s new energy hub on the South Humber bank has reached a milestone with contracts awarded for nearly 350MW of gas engines.
COGEN AT A TEXTILE PLANT MWM reveals how the TCG 2032 genset has proven to be one of the most reliable onsite gas engines for more than 20 years.
Page 18
Page 23
UFR1001E G99/98 compliant Loss of Mains Relay
PREFERRED BIDDER HAS BEEN SELECTED FOR UK’S EGL2 HVDC CABLE PROJECT demand centres to the South, supporting the target of enabling 50 GW offshore wind generation by 2030 and achieving a Net Zero economy by 2050. At an estimated cost of £3.4 billion for the two links, the Eastern HVDC projects form the largest electricity transmission investment project in the UK’s recent history. The Scotland-England Green Link 1, SEGL1, will run from Torness in southeast Scotland to
UK POWER NEWS MAY/JUNE 2023
Hawthorn Pit substation in county Durham, northeast England. The subsea portion of the cable will be 440 km (270 mi) long. In December 2022, the project was in the ‘early development’ stage. Work begins in 2024, with the main construction phase starting in 2025, and a completion date of 2029.
The UFR1001E system-disconnection relay monitors voltage and frequency in single or three-phase networks. • Presetting per G99/98, values as per the standard pre programmed • Under and overvoltage monitoring 40…520 V • Under and over frequency monitoring 45…65 Hz • Monitoring of Rate of Change of Frequency (ROCOF, df/dt) • Monitoring the voltage quality (10 minute average value) • Response time adjustable 0.05 … 130.0 s, individual setting for each limit • Fail-safe, with monitoring of the connected section switch (can be switched off) 2 automatic restarts on error • Supports the mains synchronisation when using generators • Measurement 3 phase 3 or 4 wire systems or single phase • Self-test • Third Part Independently tested Compliant to G99/98 by Bureau Veritas
Tel: +44 (0) 1206 575755
Email: sales@tvri.co.uk www.tvri.co.uk TVR Instruments Limited 143 Butt Road, Colchester CO3 3DP Essex, United Kingdom
1
