Cable Pathway, Racks and Accessories
Supporting IT and network infrastructure
Quality. Value. Delivered.
Durable and reliable open architecture racks, rack-mount accessories and cable pathway to support IT infrastructure.
• Wide variety of standard sizes
• Custom orders available
• Access to expert support
RACKS & CABINETS
L130016-60B
RACK MOUNT SHELVES
TELESCOPING ADJUSTABLE RACK MOUNT SHELF
L130014-126 19" EIA (483 mm) 16"-26" (406 -660 mm)
L130014-244 19" EIA (483 mm) 27"-44" (685-1118 mm)
DOUBLE-SIDED SOLID RACK MOUNT SHELF
L130123-D4U 23" (584 mm) 30" (762 mm)
RACK MOUNT SHELVES (continued)
DOUBLE-SIDED VENTED RACK MOUNT SHELF
L130012-20V 19" EIA (483 mm)
L130012-30V 19" EIA (483 mm)
L130013-20V 23" (584 mm)
L130015-219 19" EIA (483 mm) 19" (483 mm)
CABLE
MANAGERS
DUAL SIDE VERTICAL CABLE MANAGER
L140002-400 4" (101 mm) N 84" (2134 mm) Y Black
L140002-600 6" (152 mm) N 84" (2134 mm) Y Black
L140002-800 8" (203 mm) N 84" (2134 mm) Y Black
L140002-100 10" (254 mm) N 84" (2134 mm) Y Black
L140002-40G 4" (101 mm) Y 84" (2134 mm) Y Black
L140002-60G 6" (152 mm) Y 84" (2134 mm) Y Black
L140002-80G 8" (203 mm) Y 84" (2134 mm) Y Black
L140002-10G 10" (254 mm) Y 84" (2134 mm) Y Black
VERTICAL CABLE MANAGER
L140003-40R 4" (101 mm) N 84" (2134 mm) Y Black
L140003-60R 6" (152 mm) N 84" (2134 mm) Y Black
L140003-80R 8" (203 mm) N 84" (2134 mm) Y Black
L140003-10R 10" (254 mm) N 84" (2134 mm) Y Black
L140200-04G 4" (101 mm) Y 84" (2134 mm) Y Black
L140200-06G 6" (152 mm) Y 84" (2134 mm) Y Black
L140200-08G 8" (203 mm) Y 84" (2134 mm) Y Black
L140200-10G 10" (254 mm) Y 84" (2134 mm) Y Black
MANAGERS
(continued)
HORIZONTAL RACK MOUNT CABLE MANAGER
L140001-100 19" EIA (483 mm) 1U D-Ring N Black
L140001-200 19" EIA (483 mm) 2U D-Ring N Black
L140001-10C 19" EIA (483 mm) 1U D-Ring Y Black
L140001-20C 19" EIA (483 mm) 2U D-Ring Y Black
L140001-10F 19" EIA (483 mm) 1U Finger Style Y Black
L140001-20F 19" EIA (483 mm) 2U Finger Style Y Black
Rack-Mount Accessories
BLANK FILLER PLATES
RACK HARDWARE
CABLE RUNWAY SECTIONS
STRAIGHT RUNWAY SECTIONS
L022200-06B 6" (152 mm) 10' (3.05 m) Black 12" (305 mm)
L022200-12B 12" (305 mm) 10' (3.05 m) Black 12" (305 mm)
L022200-18B 18" (457 mm) 10' (3.05 m) Black 12" (305 mm)
L022200-24B 24" (609 mm) 10' (3.05 m) Black 12" (305 mm)
HORIZONTAL BEND RUNWAY SECTIONS
L021011-06B 6" (152 mm) Black
L021011-12B 12" (305 mm) Black
L021011-18B 18" (457 mm) Black
L021011-24B 24" (609 mm) Black
VERTICAL BEND RUNWAY SECTIONS PART NUMBER
L021012-06B 6" (152 mm) Black
L021012-12B 12" (305 mm) Black
L021012-18B 18" (457 mm) Black
L021012-24B 24" (609 mm) Black
CABLE RUNWAY COMPONENTS & ACCESSORIES
END CLOSING KIT PART
L021013-06B 6" (152 mm) Black
L021013-12B 12" (305 mm) Black
L021013-18B 18" (457 mm) Black
L021013-24B 24" (609 mm) Black
J-BOLT HARDWARE KIT
L021140-00Z 5/16 x 3" One Pair 5/16" Hex Nuts, Flat Washers, and Lock Washers Zinc Plate
JUNCTION SPLICE KIT
L021105-00B One Pair Black
VERTICAL WALL BRACKET KIT
L021307-00B One Pair Black
CABLE RUNWAY COMPONENTS & ACCESSORIES (continued)
ANGLED BUTT SPLICE KIT
PART NUMBER ANGLE QUANTITY COLOR
L021130-00B 45 Degrees Pair Black
SWIVEL BUTT SPLICE KIT
PART
L021125-00B Adjustable Pair Black
TRIANGLE WALL SUPPORT BRACKET
PART NUMBER WIDTH COLOR
L021303-12B 12" (305 mm) Black
L021303-18B 18" (457 mm) Black
L021303-24B 24" (609 mm) Black
RACK-TO-RUNWAY MOUNTING PLATE
PART NUMBER WIDTH COLOR
L021302-12B 12" (305 mm) Black
L021302-18B 18" (457 mm) Black
CABLE RETAINING POST KIT
PART NUMBER HEIGHT COLOR
L021205-06B 6" (152 mm) Black
END CAPS
PART NUMBER QUANTITY COLOR
L021200-00B Pair Black
L021200-20B 20 Black
ELEVATION KIT
PART
L021304-06B Single
Adjustable 4", 5" or 6" (102 mm, 127 mm or 152 mm) Pair Black
CABLE RUNWAY COMPONENTS & ACCESSORIES (continued)
FOOT KIT
PART NUMBER COLOR
L021014-00B Black
RADIUS DROP
L021310-06B Cross Member 6" (152 mm) Each Black
L021310-12B Cross Member 12" (305 mm) Each Black
L021310-18B Cross Member 18" (457 mm) Each Black
L021310-24B Cross Member 24" (610 mm) Each Black
L021315-10B Stringer 10" (254 mm) Each Black
SLOTTED SUPPORT BRACKET KIT
PART NUMBER QUANTITY COLOR
L021305-00B Pair Black
WALL ANGLE SUPPORT BRACKET KIT
PART NUMBER WIDTH COLOR
L021301-06B 6" (152 mm) Black
L021301-12B 12" (305 mm) Black
L021301-18B 18" (457 mm) Black
L021301-24B 24" (609 mm) Black
L021100-00B Pair Black
MOVABLE CROSS MEMBER KIT
PART NUMBER WIDTH QUANTITY COLOR
L022123-01B Adjustable 12" (305 mm) - 24" (610 mm) Each Black
L022123-02B 6" (152 mm) Each Black
ELECTRICAL BONDING JUMPER PART
L160010-00G 12" (305 mm) Each Green
L160010-10G 12" (305 mm) 10 Green
ANTIOXIDANT COMPOUND
PART NUMBER SIZE COLOR
L160099-008 0.5 ounces Gray
TOUCH UP PAINT
PART NUMBER TYPE COLOR
L029999-01B Aerosol Can Black (RAL 9005)
WIRE MESH CABLE TRAY
L022000-21Z 4”x2” (100x60) EZ
L022000-22Z 6”x2” (150x60) EZ
L022000-23Z 8”x2” (200x60) EZ
L022000-24Z 12”x2” (300x60) EZ
L022000-25Z 16”x2” (400x60) EZ
L022000-26Z 18”x2” (450x60) EZ
L022000-27Z 20”x2” (500x60) EZ
L022000-28Z 24”x2” (600x60) EZ
L022000-31Z 4”x4” (100x100) EZ
L022000-32Z 6”x4” (150x100) EZ
L022000-33Z 8”x4” (200x100) EZ
L022000-34Z 12”x4” (300x100) EZ
L022000-35Z 16”x4” (400x100) EZ
L022000-36Z 18”x4” (450x100) EZ
L022000-37Z 20”x4” (500x100) EZ
L022000-38Z 24”x4” (600x100) EZ
L022056-63Z 4”x2” (100x60) EZ
L022056-64Z 6”x2” (150x60) EZ
L022056-65Z 8”x2” (200x60) EZ
L022056-66Z 12”x2” (300x60) EZ
L022056-67Z 16”x2” (400x60) EZ
L022056-68Z 18”x2” (450x60) EZ
EZ - Electrozinc Plate
Part Number Size Finish
L022000-21B 4”x2” (100x60) C8
L022000-22B 6”x2” (150x60) C8
L022000-23B 8”x2” (200x60) C8
L022000-24B 12”x2” (300x60) C8
L022000-25B 16”x2” (400x60) C8
L022000-26B 18”x2” (450x60) C8
L022000-27B 20”x2” (500x60) C8
L022000-28B 24”x2” (600x60) C8
L022000-31B 4”x4” (100x100) C8
L022000-32B 6”x4” (150x100) C8
L022000-33B 8”x4” (200x100) C8
L022000-34B 12”x4” (300x100) C8
L022000-35B 16”x4” (400x100) C8
L022000-36B 18”x4” (450x100) C8
L022000-37B 20”x4” (500x100) C8
L022000-38B 24”x4” (600x100) C8
L022056-63B 4”x2” (100x60) C8
L022000-22B 6”x2” (150x60) C8
L022056-65B 8”x2” (200x60) C8
L022056-66B 12”x2” (300x60) C8
L022056-67B 16”x2” (400x60) C8
L022056-68B 18”x2” (450x60) C8
C8 - High Resistance Coating (Black)
WIRE MESH CABLE TRAY COMPONENTS
& ACCESSORIES
Splice Clamp Hardware
L022001-50Z 50 EZ
L022001-50B 50 C8
Horizontal Bend Clip
Part Clamp Hardware
L022005-50Z 50 EZ
L022005-50B 50 C8
Adjustable Splice Plate
L022002-50Z 50 EZ
L022002-50B 50 C8 Heavy Duty Side Joint Plate
Central Hanging Plate Click Central Hanging Plate
WIRE MESH CABLE TRAY COMPONENTS & ACCESSORIES (continued)
Light and Box Support Base Rapid Splice Channel Strut Clip
Rapid Splice
Universal Bracket
Radius Support
Small Wall Mount Bracket Side Support
L022054-00B
L022009-00B 100 Plastic Black RAL 9005
WIRE MESH CABLE TRAY SUPPORT SYSTEM
Ceiling Support Bracket
L022041-01B For 3.9" (100 mm) Width
L022041-04B For 11.8" (300 mm) Width
L022041-05B For 15.8" (400 mm) Width 4 EZ
L022041-01G For 3.9" (100 mm) Width 4 C8
L022041-02G
L022041-03G For 7.8" (200 mm) Width
L022041-04G
L022041-05G For 15.8" (400 mm) Width 4 C8
Stand Off Bracket
L022036-01G 3.9" (100 mm) 10 PG
L022036-03G 7.9" (200 mm) 10 PG
L022036-04G 11.8" (300 mm) 10 C8
Channel Strut Cantilever Support Bracket
L022035-01G For 3.9" (100 mm) Width
L022035-02G For 5.9" (150 mm) Width
L022035-03G For 7.8" (200 mm) Width 4
L022035-04-G For 11.8" (300 mm) Width
L022035-05G For 15.8" (400 mm) Width
L022035-06G For 19.6" (500 mm) Width
L022035-07G For 23.6" (600 mm) Width
For 3.9" (100 mm) Width
L022035-02B For 5.9" (150 mm) Width 4
L022035-03B For 7.8" (200 mm) Width
L022035-05B For 15.8" (400 mm) Width
L022035-06B For 19.6" (500 mm) Width
L022035-07B For 23.6" (600 mm) Width
WIRE MESH CABLE TRAY SUPPORT SYSTEM (continued)
Trapeze Support (Standard)
L022030-01G For 3.9" (100 mm) Width
L022030-02G For 5.9" (150 mm) Width 10 PG
L022030-03G For 7.8" (200 mm) Width 10 PG
L022030-04G For 11.8" (300 mm) Width
L022030-05G For 15.8" (400 mm) Width
L022030-06G For 19.6" (500 mm) Width
L022030-07G For 23.6" (600 mm) Width
L022030-01B For 3.9" (100 mm) Width
L022030-02B For 5.9" (150 mm) Width 10 C8
L022030-03B For 7.8" (200 mm) Width
L022030-04B For 11.8" (300 mm) Width
L022030-05B For 15.8" (400 mm) Width
L022030-06B For 19.6" (500 mm) Width
L022030-07B For 23.6" (600 mm) Width 10 C8
Trapeze Support (Long)
L022030-10G For 39.4" (1000 mm) Width
Pendant Support
Liberty has a complete technology system of adaptable, advanced infrastructure systems across Audio/Visual, Security and Surveillance, Cable and Connectivity, Metals, Racks and Enclosures, Wireless and Distributed Antenna Systems, and Software and Services — all backed by the support of knowledgeable in-house, customer service teams. With an ever-growing portfolio of products, Liberty has maintained both quality and personal connection to the installer, delivering products that are dependable, affordable, cutting edge, yet easy to install and user-friendly that support the toughest of technical requirements.
