Construction
The base of the Vipp V2 Kitchen is a steel frame with adjustable levelling feet.
The cabinets are placed on top of the frame, followed by the installation of the side panels. Finally, the worktop is mounted. Pipes and cables are concealed by a steel collar on the floor.
*All dimensions are originally in centimeters and then converted to inches.
Make sure to double‑check measurements in inches to be certain.
Installation tunnel
Sidepanel
Steel frame
Levelling feet
Steel collar for hiding pipes and cables
Rubber spacer tape
Stainless steel 1mm folded
22mm veneered door and drawer fronts
Modules
There are three different modules.
Plan plumbing and electricity according to module chosen
ISLAND
48124‑608cm 13/16‑2393/8in
±92cm ±361/4in
47120cm 1/4in
3795cm 3/8in
2565cm 5/8in
NARROW
WALL
Wall installations
Plumbing and electrical installations from the wall.
Recommended for the Wall module.
Installation zone
The Wall cabinets are 60cm deep and the sidepanels are 65cm giving 5cm free space behind the cabinets
60cm 235/8in
65cm 255/8in 5cm 2in
Sink cabinets
The sink cabinet comes with drawers or doors, as single or double cabinets.
It is recommended to have all installations in the sink cabinet, including electricity, for easy access.
Sink cabinet with door
Large sink cabinet with doors (US)
7
60,4cm 233/4in
120,8cm 479/16in
Page 8
Page 9
Sink cabinet with drawers
Large sink cabinet with drawers
Page 10
Sink cabinet with door
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
Installation zone
22cm 85/8in
Cover panel hiding installations
Large sink cabinet with doors (US)
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
Cover panels hiding installations
Sink cabinet with drawers
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
Installation zone
22cm 85/8in
Cover panel hiding installations
Large sink cabinet with drawers
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
Cover panel only on the left side
22cm 85/8in
Floor installations
Plumbing and electrical installations from the floor.
Recommended for the Narrow and Island modules.
*Be aware that the frame might cause slight interference to the installation zone.
Narrow island module
Sink cabinets
The sink cabinet comes with drawers or doors, as single or double cabinets.
It is recommended to have all installations in the sink cabinet, including electricity, for easy access.
*Narrow cabinets are shown here. Same recommendations apply for Island modules.
Large sink cabinet with doors (US) Sink cabinet with door
Page 13
Page 14
60,4cm 233/4in
Page 15
Sink cabinet with drawers
120,8cm 479/16in
Large sink cabinet with drawers
Page 16
Sink cabinet with door
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
See ”Section cuts” page 18 for cabinet details
Sidepanel 1,3cm 1/2in
Narrow module Island module
Large sink cabinet with doors (US)
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
Installation zone
See ”Section cuts” page 18 for cabinet details
Sink cabinet with drawers
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
25cm 97/8in
36,3cm 145/16in
Installation zone
20cm 77/8in
38,7cm 151/4in
See ”Section cuts” page 18 for cabinet details
Large sink cabinet with drawers
Plan for your water, drainage, and electrical installations to be placed within the hatched area.
Installation zone
See ”Section cuts” page 18 for cabinet details
Narrow module
module
Dishwasher cabinet
The dishwasher is placed on top of a low drawer cabinet.
The drawer cabinet is slightly shorter than standard cabinets to provide extra space for hoses and cables.
10cm / 4in space behind low drawer cabinet
5cm / 2in space between low drawer cabinet and the single narrow cabinet behind
5cm / 2in space between low drawer cabinet and the wall cabinet behind
See ”Section cuts” page 18 for DW cabinet details
Section cuts
Wall modules
Sink door
Sink drawers
51/2in 13,4cm 51/4in
2 drawers
3 drawers Storage Dishwasher
Narrow modules
Narrow modules always has storage on the short side can be with wood or aluminum doors.
Sink door/ storage
19cm 71/2in
Ø5,5cm Ø23/16in
71,9cm 285/16in
52,5cm 205/8in
11,9cm 411/16in
32cm 129/16in
33,5cm 133/16in
22,5cm 87/8in
31,5cm 123/8in
Sink drawers/ storage
33,5cm 133/16in
22,5cm 87/8in
2 Drawer / storage
31cm 121/4in
32cm 129/16in
Narrow modules
3 Drawer / storage
Storage / storage
Island modules
Island modules can be configured in multiple ways.
Sink door
19cm 71/2in
52,5cm 205/8in
11,9cm 411/16in
32cm 129/16in
33,5cm 133/16in
22,5cm 87/8in
Sink drawers
Ø5,5cm Ø23/16in
31cm 121/4in
32cm 129/16in
33,5cm 133/16in
2 Drawer
22,5cm 87/8in
57cm 227/16in
71,9cm 285/16in
Island modules
3 Drawer
13,4cm 51/4in
14cm 51/2in
32cm 129/16in
47cm 181/2in
Storage
71,9cm 285/16in
56,8cm 223/8in
7cm 23/4in
Power outlet
The power outlets are placed in the end panels of the kitchen module. It is recommended to keep all installations inside the sink cabinet and run cables through the installation tunnel. The cable is 3 meters long.
See installation manual for installation guide.
