EVO MIG 250 PFC Synergic Compact
EVO
ORDER CODE EM-250CT
The EVO MIG 250CT combines advanced PFC inverter technology with a dual-roll wire feed motor, delivering exceptional welding performance, smooth wire feeding, and a superior user experience. Built for durability and versatility, it supports synergic MIG/ MAG, MMA, and smart DC Lift TIG, making it ideal for a wide range of welding applications in demanding environments. Its unique compartmented electrical design further enhances reliability. With full synergic control, the ClearVision display allows precise, effortless parameter adjustments and clear readouts in any lighting conditions. Supplied with a custom low-profile trolley designed to hold a size Y gas cylinder, this compact unit ensures excellent mobility and convenience in the workshop. Auto-sleep mode provides market-leading energy efficiency while extending the lifespan of the equipment.
TECHNICAL DATA KEY FEATURES • Rugged, ergonomic design • ClearVision technology • Intelligent synergic control • Adaptable wide voltage range • Welding engineer mode • Smart Lift TIG • Consistent and efficient MIG spot welding performance • Dual roll wire feed motor • Flexible remote control solutions (optional) • Power factor correction (PFC), generator friendly • Quick factory reset; auto sleep mode • Compatible with MIG digital torch and spool gun • LED inside wire feeder cabinet; handy accessory storage slot • Fan on demand • Trolley with cylinder holder • Voltage Reduction Device (VRD) • Key power electronic component protection • Overcurrent and overheat protection
STANDARD ACCESSORIES MIG Welding Torch (JE250-4), Earth Clamp, Gas Hose and Argon Regulator (SSARG2G), Trolley * Generator must have AVR
Input voltage No load voltage Ieff Rated input power Current range MIG Rated duty cycle @ 40ºC Wire feed speed Wire spool size Ieff Rated input power MMA Current range Rated duty cycle @ 40ºC Ieff Rated input power TIG Current range Rated duty cycle @ 40ºC Efficiency Power factor Idle state power Protection class Insulation class Dimensions LxWxH Weight Recommended generator size
AC 95-265V, 50/60 Hz AC 115V AC 230V 70V 19A 18.5A 6.1kVA 10.3kVA 30-160A 30-250A 30% 2-14m/min 2-18m/min D300 18.1A 17.6A 3.8kVA 6.9kVA 20-125A 20-220A 30% 15.9A 14.5A 3.3kVA 6.1kVA 5-160A 5-250A 30% >80% 0.99 <50W IP23S H 920 x 480 x 755mm 43.5Kg 9kVA 15.5kVA
OPTIONAL ACCESSORIES Wireless Remote Control (HRC-02), Wired Remote Control (HRC-01), Wireless Foot Pedal (FRC-02), Wired Foot Pedal (FRC-01), Wireless Transceiver (TS4)
