ROOFING
CUSTOM ORB®
CORRUGATED
Corrugated roofing offers the timeless elegance and matchless adaptability of the traditional corrugate profile.
Produced in Whangarei, Auckland, Hamilton, Tauranga, Wellington and Christchurch.
RESIDENTIAL AND COMMERCIAL PROFILES
TRAPEZOIDAL
Trapezoidal, or rib, profiles have sloping-sided ribs and are fastened through the profile. They are available in a number of configurations to suit a vast range of performance and appearance criteria.
They can be categorised by common application into Residential/Commercial and Commercial/Industrial groups.
Steel & Tube offer four Trapezoidal rib products with rib heights varying between 20mm and 30mm. These are typically utilised in domestic roofing, or for commercial roofing and cladding applications where spanning ability is not a prime requirement.
SIX RIB
Produced in Tauranga
Six Rib has a more subtle rib and wider pan, for an attractive, economical solution to most domestic roofing applications.
Because both Plumbdek® and Trimform® profiles feature a strong rib design, they are equally at home in residential applications or at work in commercial situations.
PLUMBDEK®
Produced in Auckland, Tauranga & Christchurch
TRIMFORM®
Produced in Hamilton
TRIMLINE®
Produced in Auckland, Whangarei & Wellington
Trimline has six bold ribs making it an exceptionally attractive roofing and cladding profile.
* Note: Regional variances can occur with different base materials and thicknesses. If cover is crucial, please discuss with Steel & Tube prior to ordering.
COMMERCIAL/INDUSTRIAL PROFILES
Where larger spans or greater robustness is required, the higher-ribbed trapezoidals make their mark. ST7® and ST900® have medium height ribs, giving a bolder look for residential applications and for commercial and industrial work.
ST7®
Produced in Wellington
ST900®
Produced in Auckland and Christchurch
ST963
Produced in Auckland & Christchurch
ST963 is a profiled metal roofing and cladding profile with four trapezoidal ribs of 46mm in height and a 230mm wide pan.
KLIPLOK
Produced in Wellington
TROUGH SECTION
Steel & Tube’s trough section profiles are designed to meet a variety of needs from low pitch and long lengths to steep pitches where the clean lines are enhanced by the secret fixings.
In some cases indentations from the clips may be noticeable although this should become less noticeable with weathering over time.
HI RIB
Produced in Auckland
LEGACY®
LEGACY® has been specifically introduced to complement our EuroLine range of roofing products, with their unmistakable eighteenth century standing seam roofing style.
It incorporates modern high strength roll forming technology and is available in continuous lengths.
It is important to note that an architectural feature of this product is the undulation of the wide flat pan of the profile. In some situations, indentations caused by fixing clips or purlins may be noticeable although this should become less apparent with weathering over time.
LEGACY®
Produced in Auckland
QBT450
This innovative system combines the timeless elegance of tray roofing with modern features that make it fully ventilated, selfsupporting and easier to install.
QBT450 is the only BRANZ Appraised Tray Roofing System in New Zealand.
Available across New Zealand
Drainage Mat or Purlin Tape Purlin
QBT450 Concealed Extruded Clip and Fixings
COMMON FLASHINGS
For corrugate barges, your supplying branch may have dimensions standard for their area. Dimensions for other profiles dimensions should be specified by the installer. Internal angles on soft edge or notched barge or apron also need to be specified.
WALL CLADDING
* 200mm wide cover ridge is also available.
TRIMKLAD®
Produced in Hamilton
Trimklad® has an unobtrusive rib and a very wide swaged pan for any installation where a neat appearance and lower labour costs are an essential design criteria.
STC900®
Produced in Auckland
STC900® is specially designed for pan-out wall cladding or canopies where the normal underside of the profile is exposed to view. Fine flutes in the face highlight the surface and accentuate the negative detail, while modifications to the side lap detail means that weatherproofness and good looks are maintained on both sides of the profile.
RAINWATER SOLUTIONS
Note:
TRADITIONAL
CUSTOMLINE®
Produced in Tauranga
• Customline® is a larger, long run version of the classic quarter round, and is deeper than other designs, for greater water carrying capacity and enhanced aesthetic appeal.
• Customline® can be fitted with fully concealed brackets to enhance the clean smooth lines or with external brackets, for a timeless classic look.
CONTEMPORARY
PLUMBLINE®
Produced in Auckland
• Plumbline® provides a large capacity domestic spouting which is also at home on smaller commercial work.
• Plumbline® has a strong profile with a double swaged face and swaged base.
• Plumbline® is fixed using concealed clips for emphasis of its bold lines.
COMMERCIAL GUTTERS
CROSS SECTIONAL AREA 7100mm2
10000mm2
Produced in Whangarei, Auckland, Hamilton, Tauranga, Wellington and Christchurch
The most commonly specified commercial gutters are 175mm and 300mm, however, as each is specifically folded, the dimensions can be varied greatly to suit any application, provided appropriate fixing brackets are sourced.
Standard pressed internal brackets are available for the 175 gutter, however for extra strength, specially fabricated steel external brackets are recommended (colour matched if required).
Steel & Tube provides details regarding industrial gutter bracket design and placement, available from our website www.steelandtube.co.nz.
COMMERCIAL GUTTERS TYPICALLY AVAILABLE IN 175mm AND 280mm-300mm WIDTHS
CROSS SECTIONAL AREA
21,000mm2
CROSS SECTIONAL AREA
31,350mm2 (285mm width)
33,000mm2 (300mm width)
Dimensions are indicative only. There may be differences in dimensions between regions. Please contact your local Steel & Tube branch for more information. • Whangarei, Auckland and Wellington, x = 300mm
FASCIA SYSTEMS
MULTI-LINE® FASCIA
• An attractive and economical advance over timber fascias, Multi-line® Fascia can be fitted with a range of spoutings for contemporary or traditional appearances.
Steel & Tube’s fascia systems are available exclusively through qualified installers.
MULTI-LINE®
FASCIA 150
Produced in Tauranga
MULTI-LINE®
FASCIA 185
Produced in Wellington and Christchurch
BIM-spec™ is a one stop portal for all Steel & Tube’s specification and technical content. It provides access to a large library of 2D and 3D CAD content and building information models (BIM) across a wide range of Steel & Tube product categories. This includes manufacturer-specific and generic libraries suitable for all specifiers, consulting and fabrication engineers and specialist consultants/contractors. The BIM-spec portal can be accessed through our website www.steelandtube.co.nz
Trademark Note:
CUSTOM ORB is a registered trademark of BlueScope Steel Limited. Multi-line, ST7, ST900, Trimklad, STC900, Plumbdek, Trimform, Trimline, Euroline, Plumbline, Legacy are registered trademarks of Steel & Tube Holdings Limited. The ST963 profile is a registered patent - New Zealand Patent Number: 605058.
