Manufactory Wholesale Caster-T315 4 Ch HDSDI IPTV
Encoder for Multiscreen HD Broadcasting
Struggling to deliver high-quality video across multiple devices? The Caster-T315 is a real-time multi-channel IP-based encoder designed to streamline HD-SDI content delivery for Broadcast, IPTV, and Terrestrial Networks. With support for H.264, MPEG-4 encoding, and multiple protocols like RTMP, HLS, and UDP, it ensures seamless multiscreen streaming. Optimized for 1080p HD at 5 Mbps, this compact 1RU solution is perfect for Cable, Satellite, and IPTV applications.
Certified for 24/7 operation, it’s the ultimate tool for content repurposing.
• 4-Channel HD-SDI Input | • H.264/MPEG-4 Encoding | • RTMP/HLS/UDP
Protocols | • 1080p at 5 Mbps | • 24/7 Operation
1.Multiscreen hd iptv encoder support 4/8 HD inputs
2.Any-to-Any configuration
3.Compact modular design
4.Multiple Codec, Protocol, Bitrate, Resolution, Profile per channel Description
Overview
Caster-T315 high-performance High definition solution allows content owners and service providers to significantly increase the content hours delivered while adhering to processing timetables and video quality targets in a cost-effective and scalable manner. A real-time multi-channel, codec, format IP-based encoder for multi- screen delivery. With the support for various encapsulation formats base on embedded Linux operating system appliances.
Caster-T315 can push/pull 4Channels H.264, MPEG-4 encoding video streams deliver to various servers, such as Adobe Flash Server, Wowza Server, Windows Media Server, Apples HTTP Live Streaming, and some other servers base on UDP/RTSP/RTMP/ HTTP/RTP/HLS protocols.The all HD-SDI live content delivery by enabling to repurpose content over numerous devices such as TV, tablets, PCs or web players while maintaining uncompression video quality. It is a answer for all market requirements and is a suitable solution to Terrestrial, Satellite, Cable, IPTV networks.
Features
◆Up to 4Channels HD-SDI or HD per chassis(1RU)
◆Highly Reliable, High density 1-RU platform can process up to 4*1080P Full HD profiles
◆Optimized for 1500 Kbps for SD, 2.5 Mbps for HD 720p, 5 Mbps for HD 1080p.
◆Multiple output streams per input service to support Broadcast, IPTV, Set top box applications
◆Mulltiple Codec, Protocol,Bitrate, Resolution, Profile per channel
◆GbE IP outputs –UDP, RTSP, RTMP, Pull/Push HTTP,HTTP Live Smooth(HLS), FTP M3u8 playlist files
◆Picture-in-picture (PIP) operation supported
◆Flexible GOP structures with Reference-frame and B-frame edit
◆Broadcast-grade HD/SD up and down converter
◆Frame rate down- and up-conversion
◆Up to 2 audio channels Per embeded SDI inputs, Option Provides up to 8 audio channels for customization
◆High quality pre-processing including filtering, Deinterlacing, cross scaling
◆Support for Variable Bit Rate (VBR) encoding maximizes adaptive streaming video quality and bandwidth efficiency
◆Based on embedded Ubuntu Linux
◆The preview interface adds color control adjustment (CCATM) function (video output brightness, contrast, saturation, aberration).
◆TS parameter configuration: The output stream can be edited to change the program number, program name, supplier (for video output part), easy to identify end device.
◆DVB Subtitle and Logo insertion
◆High contrast LCD display
◆Parameter template settings and imports
Contact:Tomleequan Email：sales@fmuser.com whatsapp: +8613922702227
Contact:Tomleequan Email：
◆Real time preview of input video stream in encoding and parameter configuration
◆Selectable any resolution from QSIF to 1080P
◆Designed for 24*365 uninterrupted working
◆Easy-to-Use System Management via Web
