Advanced, Long-Range Strike
Innovative Weapon System to Dominate the Modern Battlefield
ICE BREAKERTM is a long-range, Standoff, autonomous, precision-guided weapon system enabling significant attack performance against a variety of high-value targets. The system is resilient to electronic countermeasures and fully operational in GNSS-denied arenas.
ICE BREAKER is one of RAFAEL’s cuttingedge precision-strike solutions, based on operational experience and up-to-date technologies.
DESIGNED TO MEET THE NEEDS OF THE NEW ERA
Benefits
• Highly effective and lethal against a variety of targets
• Compact, lightweight, and compatible with jet fighters, light attack aircraft, and helicopters as well as small maritime vessels and ground vehicles
• Multi-service capability: air, land, and sea launch
• Synchronized attack capability
• Fully autonomous with man-in-the-loop capability
• Low and controlled collateral damage
• Advanced ATA & ATR capabilities
• Affordable
• Designed to operate in an A2/AD environment
• Transforms light platforms into dominating fighting machines
• Cross-platform launch: air, land & sea
Mission Effectiveness
Main Capabilities
ICE BREAKER is a complete, full-sphere solution countering various threats on land and at sea. It effectively strikes high-value targets with controlled and low collateral damage.
The missile utilizes an advanced, all-weather, electrooptical IIR seeker based on RAFAEL's innovative legacy of products and operationally-proven capabilities including scene-matching algorithms and ATR – Automatic Target Recognition.
The system complies with strict Rules of Engagement (ROE), allowing its autonomous capability to identify and engage only hostile targets.
The system can counter modern Integrated Air Defense System (IADS) deployments, relying on late detection due to its passive seeker, low-level terrain -following flight pattern, sea-skimming, and the VLO (Very Low Observable) of the missile.
A salvo attack capability enhances missile penetration against well-defended targets. The effective warhead, combined with selective and precise aimpoints, ensures the desired damage to the target from neutralization to destruction with reduced risk to uninvolved civilians in close proximity.
• Optimized for deep strike scenarios
• GNSS-independent
• All-weather operations
• VLO (Very Low Observable)
• Advanced mission planning
• Man-in-the-loop for decision backup and BDA
• Long-range (300 Km), low-level terrainfollowing, sea-skimming
Technical Specifications
Length 4 m
Weight < 400 kg
Range 300 km at low flight
Velocity High subsonic
Warhead 250 lb
Seeker Advanced IIR with AI Fused
Navigation INS + anti-jam GPS + TERCOM
Solution
Control & Advanced mission planning & C2
Planning systems
Two-Way
Long-Range Updates mission on flight & BDA
Data link
Tel: +(972)73-336-8503 HQ Tel: +(972)73-335-4714
Fax: +(972)73-336-6257
AIR & C4ISR DIVISION Email: c4isr_mkt@rafael.co.il
ICE BREAKERTM is a Trademark of RAFAEL Advanced Defense Systems Ltd. UNC. 67403-06/22/K1 V1 ENG/ Studio | MSS
Fax: +(972)73-335-4657
Email: Intl-mkt@rafael.co.il www.rafael.co.il
ICE BREAKER
