Product:TRACKLOADER
Model:953DTRACKLOADERLBP Configuration:953DTRACK-TYPELOADERLBP00001-UP(MACHINE)POWEREDBYC6.6Engine OperationandMaintenanceManual
SafetySignsandLabels
Donotoperateorworkonthismachineunlessyouhaveread andunderstandtheinstructionsandwarningsintheOperation andMaintenanceManuals.Failuretofollowtheinstructionsor heedthewarningscouldresultininjuryordeath.Contactyour Catdealerforreplacementmanuals.Propercareisyour responsibility.
SafetyMessages
ThewarningfilminIllustration1canbefoundinalocationsuchasthedash.Thewarningfilm willbeclearlyvisibletotheoperatorduringthenormaloperationofthemachine.
ThismachineisequippedwithaCaterpillarProductLink communicationdevice.Whenelectricdetonatorsareused,this communicationdeviceshouldbedeactivatedwithin12m(40ft) ofablastsite,orwithinthedistancemandatedunderapplicable legalrequirements.Failuretodosocouldcauseinterference withblastingoperationsandresultinseriousinjuryordeath.
