High strength chains for hoists
Content Intelligent profile cross section pewag, as an innovation leader, is the world‘s first supplier of a chain with an intelligent and stiff cross profile for lifting devices. pewag offers a variety of high class and innovative chain types in the category of hoist chains as well as the support for the design of chain drives.
pewag group Welcome to the pewag group Production and sales locations History, quality management Business areas, environment
4-5 6 7 8
Advantages Advantages of pewag hoist chains Profile steel chain Mechanical properties
12 12 13
Hoist chains – types Chain dimensions according to EN 818-7 Chain dimensions according to JIS B8812 Case hardened chains Stainless steel chains Through hardened chains
16 17 18-20 21-23 24-26
Finishing Surface finishing Types of packaging
30 31
Chain drives Chain wheel design Hub type
34-35 35
Technical changes and misprints are subject to alteration. High strength chains for hoists
