Level
Submersible pressure sensor For general applications Model LS-10 WIKA data sheet PE 81.55 for further approvals, see page 4
Applications ■ Level measurement in rivers and lakes
■ Level measurement in vessel and storage systems ■ Control of sewage lift and pumping stations
■ Monitoring of sewage, settling and rainwater retention
basins
Special features ■ Robust
■ Reliable
■ Economical
Submersible pressure sensor model LS-10
Description For simple measuring requirements The model LS-10 submersible pressure sensor has been optimised for simple measuring requirements in level measurement. It offers excellent quality, is cost-effective and reliable.
Reliable and durable The submersible pressure sensor features a hermetically sealed and exceptionally robust stainless steel case. The proven, all-welded construction ensures a long service life and permanent leak tightness.
It has been designed to the current demands of the industry and features a 4 ... 20 mA output signal, an accuracy of 0.5 % and a cable from PUR as standard. With IP68 ingress protection, it is suitable for permanent level measurement up to 100 m water column.
WIKA data sheet PE 81.55 ∙ 10/2021 Data sheets showing similar products: High-performance submersible pressure sensor; model LH-20; see data sheet PE 81.56 Intrinsically safe submersible pressure sensor; model IL-10; see data sheet PE 81.23
Page 1 of 5
