ARCHITECTURE PORTFOLIO
* total area of the site : 10 acres
* plot coverage : 50% - 20234.3sqm
* fsi : 5
* built-up-area (bua) : 202343sqm
* height - 60m
* setbacks : front - 7.5m, side - 7m
* osr : 10% of the total land - 4046.86sqm
* parking : residencey - 740 cars
* club house :
5% of total built-up-area - 2023.43sqm
* flat count : low income group20% of total bua - 40468.6sqm area of 1bhk - 50sqm no of units - 270, average people - 1080 medium income group : 2bhkbua - 32374.88sqm area of single unit - 120sqm no of units - 90, average people - 360
3bhkbua - 56656.04sqm area of single unit - 160sqm no of units - 118, average people- 708 high income group :
4bhkbua - 56656.04sqm area of single unit - 200sqm no of units - 94, average people - 564
villabua - 16187.44sqm area of single unit - 260sqm no of units - 21, average people - 126
* total number of units - 593
SITE DETAILS :
Location - Istanbul
Total area - 2 Acres
OBJECTIVE :
Golden horn has impeersonated an essential role in the evolution of Istan Istanbul as a natural and remarkably guarded harbor. Figure ground maps of two different cities were combined using AI tools like Ostagram, Mid-Journey, Rhino, and Grasshopper. The combined output was then combined with a black and white graphic in ostagram, which transformed it into a hypothetical realistic city map which was further developed into 3d buildings, greenscapes, transportation network, water bodies, open spaces, building typologies and land use in Grasshopper AI tools considering the existing scenario along with topography.
Considering a futuristic hypothetical city in the next 30 years, with an approach to city design that is accessible and 15 minutes walkable for all users, while concentrating on the places that practically need to be redeveloped due to outdated infrastructure and earthquake-prone zones.
