catalogue chalet laminate

laminate flooring: sahara oak

laminate flooring: vanilla blackbutt 2 | Chalet Laminate

chalet 12mm premium collection Transform your space with the beauty and durability of our premium Chalet Laminate range. Whether you’re refreshing a cosy bedroom or revamping a busy living area, this flooring is designed to keep up with life while looking stunning every step of the way. With 14 gorgeous colours to choose from and the choice of a sleek smooth finish or a natural matte texture, creating the home you’ve always dreamed of has never been easier.

features & benefits

easy to clean & maintain

steam mop friendly

super matt finish

water resistant

pet friendly

Chalet Laminate | 3

available colours

Vanilla Blackbutt 2240x195x12mm

Clay Spotted Gum 2240x195x12mm

Umber Brushbox 2240x195x12mm

Almond Blackbutt 2240x195x12mm

Chai Spotted Gum 2240x195x12mm

Toasted Walnut 2240x195x12mm

Marina Oak 2240x195x12mm

Alba Oak 2240x195x12mm

Linen Oak 2240x195x12mm

Sahara Oak 2240x195x12mm

Bisque Oak 2240x195x12mm

Oyster Oak 2240x195x12mm

Fossil Oak 2240x195x12mm

Nordic Hickory 2240x195x12mm

4 | Chalet Laminate

laminate flooring: vanilla blackbutt Chalet Laminate | 5

laminate flooring: chai spotted gum 6 | Chalet Laminate

Chalet Laminate | 7

Vanilla Blackbutt 2240 x 195 x 12mm

Colour disclaimer: Due to monitor settings, we cannot guarantee that the colour you see on your screen as an exact colour of the product. We strive to make our colours as accurate as possible, but screen images are intended as a guide only and should not be regarded as absolutely correct. All colours are approximations of actual colours. For more accurate consideration of your tile choices, we recommend taking advantage of our sample service.

8 | Chalet Laminate

Clay Spotted Gum 2240 x 195 x 12mm

Chalet Laminate | 9

Umber Brushbox 2240 x 195 x 12mm

10 | Chalet Laminate

Almond Blackbutt 2240 x 195 x 12mm

Chalet Laminate | 11

Chai Spotted Gum 2240 x 195 x 12mm

12 | Chalet Laminate

Toasted Walnut 2240 x 195 x 12mm

Chalet Laminate | 13

Marina Oak 2240 x 195 x 12mm

14 | Chalet Laminate

Alba Oak 2240 x 195 x 12mm

Chalet Laminate | 15

Linen Oak 2240 x 195 x 12mm

16 | Chalet Laminate

Sahara Oak 2240 x 195 x 12mm

Chalet Laminate | 17

Bisque Oak 2240 x 195 x 12mm

18 | Chalet Laminate

Oyster Oak 2240 x 195 x 12mm

Chalet Laminate | 19

Fossil Oak 2240 x 195 x 12mm

20 | Chalet Laminate

Nordic Hickory 2240 x 195 x 12mm

Chalet Laminate | 21

Product Specifications Type of floor covering Classification (Use Area)

Laminate flooring

Domestic: 23 (Heavy) Commercial: 32 (General Commercial) Residential 30 years Warranty* Commercial 8 years *All warranties are in addition to any rights consumers may have under Australian consumer laws. Terms and conditions apply - for full information in respect to the scope of the residential warranty, please see nationaltiles.com.au or contact our head office. ISO 10874

Physical Properties Surface treatment

Super matt finish

Colour (Standard)

Overall thickness (mm) ISO 24346

Edge

Micro Bevel

Core type

GenCore + Moisture Guard

Locking system

Angle/Angle

Dimensions (mm)

ISO 24342

2240 x 195mm

Planks/carton

m /carton

2.184

m /pallet

163.8

kg/carton

2 2

Installation Please refer to National Tiles Chalet Laminate Flooring Installation Guide

Sustainability Compliant with Green Building Council low emitting VOC emission rates

TVOC Emissions

Technical Performance Slip resistance Fire resistance (floor) Acoustic

AS 4586 Wet Pendulum (Appendix A) AS ISO 9239-1 Critical Radiant Flux (CRF Value) Smoke Development Rate ISO 10140-3 & ISO 717-2 Impact sound insulation

P3 ≥ 8.6W/m2 ≤ 750%. min L’nT, w1 = 44dB (5 Star - AAAC Star Rating)

All specifications are current as at date of publication and may be changed without notice.

22 | Chalet Laminate

laminate flooring: sahara oak

Chalet Laminate | 23

Installation Guide scan to view the installation guide

24 | Chalet Laminate

Care and Maintenance Guide Looking after your Chalet Laminate Flooring is easy with the right care and maintenance. By following the recommended guidelines, you can help keep your floor looking great and performing at its best for years to come.

Preventative Maintenance • Installing good-quality mats inside and outside of external doors to trap grit and remove moisture from shoes is a sensible precaution and will reduce the possibility of scratches. • In high-traffic areas, or areas where spillages may occur, the use of mats is recommended for added protection. • All furniture should have felt pads fitted to the base of its legs or to any other areas in contact with the floor, to help prevent scratches. • Avoid using wheeled chairs (i.e. office furniture), or ensure that a large, goodquality office mat is used to prevent indentation of the laminate flooring. • Rubber-based items (e.g. the underside of some mats, castors under furniture, and rubber-tipped furniture feet) should not come into direct contact with the floor. • Any liquids spilt on the floor must be wiped up immediately.

Curtains, blinds, or UV-resistant window films should be used. These precautions will help reduce exposure to direect sunlight and protect the flooring. Furniture and rugs should be move occasionally so that the effects of sunlight are distributed evenly across the floor. • Maintaining the temperature and humidity within a reasonably consistent range will help keep the floor stable. The humidity level in the home should be maintained between 45%-60% RH (relative humidity) year-round, using humidifiers or dehumidifiers as required. Weatherstrips can be installed on all external doors to help maintain the indoor environment. This will also help reduce extreme fluctuations in temperature and moisture within the building.

General Cleaning • The use of wet and dry vacuum cleaners, including robotic models, is not permitted on laminate floor.

• Keep pets’ nails trimmed to protect the floor from scratches.

• Sweep the floor regularly to remove loose dirt, grit and dust using a microfibre cleaning pad or a soft broom.

• All laminate flooring reacts when exposed to direct sunlight, which may cause colour changes or fading.

• If vacuum cleaning, the vacuum head must be fitted with a soft brush to avoid damage to the floor.

Chalet Laminate | 25

• Use a suitable spray mop (with a microfibre cleaning head attached) and spray the surface sparingly with a pH-neutral floor cleaner when required. This will remove stains, dirt, footprints and other marks that may be present. Rinse the microfibre cleaning head regularly in clean water and replace it when dirty. • Pull the mop back towards you and wipe lengthways across the floor using a zigzag motion. • Ensure the floor is wiped dry with a microfibre cloth and that no moisture remains on the surface after cleaning. • If spills occur, they must be wiped up as quickly as possible and cleaned with a pH-neutral cleaner. The use of a lightly damp or ‘well wrung out’ mop is appropriate for larger spills. • DO NOT wet mop the floor at any time, as excessive amounts of water may cause damage. • DO NOT USE scouring products and/or any wax or varnish coating on the floor.

Steam Mop Cleaning • If necessary, a suitable steam mop can be used on the 12mm laminate flooring. The use of a steam mop should not exceed once per fortnight. • Before using a steam mop, ensure the floor is free from any sand, stones or grit that could be dragged across the surface and caused damage.

26 | Chalet Laminate

• Using a suitable steam mop pad and cloth is essential to ensure that moisture and heat are distributed evenly across the floor. • IMPORTANT: Always use the steam mop on a lower power setting. Never allow your steam mop to remain in one spot for more than 30 seconds while in use, as this may result in damage to the laminate flooring. Always follow the steam mop manufacturer’s user instructions/guidelines and contact the manufacturer for further information if required.

96 Hour Moisture Guard Thanks to its unique core design, Chalet laminate flooring is proudly engineered to withstand exposure to moisture for up to 96 hours in household settings. It is important to note that even though this laminate is more resistant to moisture than others, it is vital to promptly clean up spills and moisture to prevent damage to the surface. As with all HDF-based products, Chalet laminate flooring is not waterproof. The flooring will therefore react to moisture in the environment, causing it to expand or contract. Excessive wetting of the floor is not permitted at any time. This flooring cannot be installed in any wet areas including bathrooms, laundries, toilets or areas subject to regular moisture or water.

Avoid the following • Indentation from stilettos or spiked heels. • Pulling or pushing furniture or other objects across the floor. • Using abrasive cleaning materials, or harsh detergents/household cleaners on the floor. These cleaning methods/ materials will harm the surface of the floor and may cause physical damage to the boards. • The use of solvents of any kind to clean the floor. Methylated spirits, turpentine, bleach, ammonia, eucalyptus, citrus, vinegar and/or similar solutions will damage the floor surface. All spillages and stains must be cleaned immediately with a pH neutral cleaner. • Urine spillages must be avoided at all times, as it will damage the flooring surface. • Exposure to direct sunlight through sliding doors and/or windows. Hybrid flooring needs to be protected from direct sunlight by blinds or curtains. • Excessive water, wet and dry vacuum cleaners, including robotic model, should not be used.

Chalet Laminate | 27

Flooring Warranty Chalet Laminate Flooring comes with a 30 Year Residential Warranty and 8 Year Commercial Warranty from the date of purchase. The original purchaser is covered by this warranty and may not be assigned or transferred. These warranties, which begin from the date of purchase, apply to products used in dry residential applications. Installation must be carried out in strict accordance with current written installation instructions. Wet Areas: This flooring is not suitable for installation in bathrooms, saunas, laundries, or any other areas where high levels of steam and moisture are present. Care and Maintenance Guidelines must be adhered to. Non-Assignment: the warranty is limited to the original purchaser and may not be assigned or transferred. Important: The floorboards must be inspected prior to use and any planks deemed unfit for service, should not be installed and will not be covered by warranty provisions. The installation instructions must be followed strictly when installing your floors and the manufacturer’s care and maintenance guidelines should be followed at all times after installation. All installation instructions can be found inside each pack of flooring and the manufacturer’s care and maintenance guidelines can be obtained by contacting your local retailers. Please make sure you fully understand the manufacturer’s care and maintenance guidelines before commencing any cleaning and maintenance schedules. Post-installation cupping and gapping issues could be considered site-related

28 | Chalet Laminate

installation or performance issues and may not be covered by the warranty and other consumer-related product purchase laws.

30 Year Residential & 8 Year Commercial Warranty Chalet Laminate Flooring provides for a 30 Year Limited Residential and 8 Year Limited Commercial Warranty. From the date of purchase, the manufacturer warrants to the original purchaser only, that under normal domestic conditions of use, the surface will not wear through during the period warranted. With proper maintenance, the goods will perform under normal household conditions. Scratches, dents, reduction of gloss (appearance reduction), damage caused by negligence, urine, animals, or high-heeled shoes are not considered a defect and therefore are not covered by this warranty. Felt pads must be adhered to the underside of all furniture to protect the surface of your floor. From time to time this will need to be maintained and checked for wear. Please note: All warranty claims must be lodged by contacting the retailer where the product was originally purchased within 30 days of the problem being noticed. Proof of purchase (date), identity of the wholesaler or retailer, and the location of installation must be provided.

All assessments for replacement or rectification work that may need to occur for faulty planks or floor installation must be formally inspected and approved by the supplier prior to any repair.

8 Year Commercial Warranty Exclusions •

All industrial food areas, such as, but not limited to, intensively frequented restaurants and cafeterias, pubs, dance halls.

•

All institutional applications, such as, but not limited to hospitals and government buildings.

•

Heavy commercial areas, such as, but not limited to airports, lobbies, schools, or barber shops.

•

Other areas that have heavy traffic and immediate access to street traffic.

Major Failure Chalet Laminate Flooring is highly resistant to chips, scratches, stains, wear, moisture and heat, but still not “proof” in any respect (i.e. scratch proof and waterproof). Slight colour and/or pattern variation from batch to batch may occur, minor gaps between the joins of each board might be caused by temperature or relative humidity changes. Please note these minor gaps, batch colour and/or pattern variation, chips, scratches are

not considered to be major failures. Once floor has been installed, it is considered that the product has been accepted by the installer/contractor.

Acceptable Quality and User Guidelines Chalet Laminate Flooring is designed for use in internal environments, including floors and walls, and should not be used externally. Furthermore, Chalet Laminate Flooring should not be directly adhered to a subfloor and must be installed as a floating floor. The flooring should be installed in a “laminate flooring-friendly environment” where the area is occupied, protected from direct heat and sunlight, and where heating and cooling systems are in place and used to control internal temperature and humidity. Maintain the internal relative humidity level between 45% and 60% throughout the year, using humidifiers or dehumidifiers if necessary. Chalet Laminate Flooring should not be installed in wet areas, including bathrooms, toilets, or rooms where a floor waste (water drain) is present or required. Residential kitchens are not considered wet areas. In areas where spills may occur frequently, such as kitchens and living areas, ensure spills are wiped up and dried as soon as possible to avoid moisture ingress and possible plank deformation. Excessive wetting of the floor and exposure to pet urine are not permitted at any time. This flooring cannot be installed in wet areas, including bathrooms, laundries, toilets, or areas subject to regular moisture or water.

Chalet Laminate | 29

96 Hour Moisture Guard Thanks to its unique core design, Chalet Laminate Flooring is proudly engineered to withstand exposure to moisture for up to 96 hours in household settings.

installed in strict accordance with the manufacturer’s current written installation instructions. In addition, the care and maintenance guidelines must be adhered to. •

It is important to note that even though this laminate is more resistant to moisture than others, it is still vital to promptly clean up spills and moisture to prevent damage to the surface. As with all HDF-based products, Chalet Laminate Flooring is not waterproof. The flooring will therefore react to moisture in the environment, causing it to expand or contract.

Boards that are visibly faulty or deemed visually or structurally inappropriate prior to installation should not be installed, and are therefore also not covered by this warranty.

•

Surface coating damage caused by using duct tape, masking tape and/or other industry tapes.

•

Australian Consumer Law

Any damages incurred by direct exposure to excessive heat and/or sunlight.

•

Scratches, surface marks/stains, chipping or indentations of any type are also not covered by this warranty.

•

Damage caused by use of cleaning products other than pH-neutral cleaners is not covered by this warranty. Solvents include (but are not limited to) Methylated Spirits, Turpentine, Bleach, Ammonia, Eucalyptus, Citrus and Vinegar, and/or similar solutions.

•

Damage, intentional or accidental, caused by water, urine, abuse, misuse, stiletto heels, dragged objects, heavy furniture, sand stones, castor wheels, dropped items, etc.

•

Direct or indirect result of moisture ingress and damage along with the incorrect use of cleaning will not be covered by this warranty. Wet and dry vacuum cleaners, including robotic models, are not allowed for Chalet Laminate Flooring under any circumstances.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

Warranty Exclusions •

The manufacturer for the purpose of this warranty will be referred to as ‘the supplier’. Breach of Warranty Conditions - any breach of warranty conditions will void the warranty.

•

Any issues directly associated with improper installation, care and maintenance will void the warranty. Chalet Laminate Flooring must be

30 | Chalet Laminate

•

Wear that may be directly associated with water or liquid damage from any source, moisture ingress from any source into the floorboards. Floor performance issues that may arise as a direct or indirect result of moisture ingress along with the incorrect use of heating and cooling systems will not be covered by warranty provisions. Please note evaporative cooling systems need to be operated as per the manufacturer’s guidelines. Please consult the manufacturer to better understand the operating methods.

•

Misuse of the warranty does not extend to damage caused by moisture penetration through the subfloor, other flooding, leaking, plumbing, overflowing, hydrostatic pressure, or any other water damage.

•

Installation over any floor heating systems is not covered by this warranty.

•

Direct or indirect result of incorrect use of heating or cooling systems will not be covered by this warranty.

•

Extreme Conditions: The humidity level in the home must be in the 45%-60% range throughout the year, using humidifiers or dehumidifiers as appropriate.

•

Alterations where floor or subflooring has been altered, repaired, resurfaced, or replaced, no warranty will apply except to the extent implied by law.

•

Any costs associated with any rectification work required other than the supply of the new flooring and scotia beading if necessary. Re-painting, removal of fixtures or

furniture, accommodation, and any other cost is specifically excluded from this warranty. •

Directly associated with improper installation or care and maintenance.

•

Labour charges associated with any rectification work may apply. In some cases, reasonable labour costs may be considered, at the sole discretion of the distributor’s authorised representative.

Chalet Laminate | 31
