TECHNICAL DATA SHEET
DESCRIPTION
The AZTEC® Straddle Chair is molded using high quality composite plastic that easily endures the large temperature extremes found on the jobsite without sagging or breaking, while Dayton Superior’s unique geometry provides excellent load capacity.
APPLICATION
PSC is designed to straddle the lower mat of rebar, simplifying placement of upper reinforcement mat.
PRODUCT SPECIFICATION
■ Fits rebar sizes #3 to #11
■ Cover Heights available from 3” to 7-3/4” in ¼” increments
PSC - AZTEC® STRADDLE CHAIR™
Rebar Supports
FEATURES
■ Minimal footprint
■ Staple down feature incorporated into feet
■ Each chair provides 2 cover heights
BENEFITS
■ Reduces inventory
■ Fewer part numbers required
APPROVALS / COMPLIANCE
■ Conforms to CRSI specifications
■ ACI-315, AC-315R compliance
ORDERING INFORMATION
STRADDLE CHAIR™
MANUFACTURER
Dayton Superior Corporation 1125 Byers Road Miamisburg, OH 45342
Customer Service: 888-977-9600
Technical Services: 877-266-7732
Website: www.daytonsuperior.com
TECHNICAL DATA SHEET
WARRANTY (ACCESSORIES)
Limited Warranty. Dayton warrants, for a period of 60 days from the date of shipment (three years from the date of shipment in the case of formwork, excluding any consumable Products included with such formwork), that Products and any associated application drawings and engineering services provided by Dayton (“Ancillary Services”) will be free from defects in material and workmanship and, in the case of custom designed formwork, that the formwork will meet the specifications set forth in the design drawings approved by Dayton and Customer. Any claim under this warranty must be made in writing within such warranty period. If any Product and/or Ancillary Service covered by a timely claim are found to be defective, Dayton will, within a reasonable time, make any necessary repairs or corrections or, at Dayton’s option, replace the Product. Unless pre-authorized by Dayton in writing, Dayton will not accept any charges for correcting defects or accept the return of any Product. This warranty will not apply to any Products that have been subjected to misuse, neglect, storage damage, misapplication, accident or any other damage caused by any person other than Dayton, or that have not been maintained in accordance with Dayton’s specifications. THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES AS TO THE PRODUCTS AND ANCILLARY SERVICES. DAYTON MAKES NO OTHER WARRANTIES OR GUARANTEES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE. THE REMEDIES SET FORTH IN THIS SECTION ARE CUSTOMER’S EXCLUSIVE REMEDY FOR BREACH OF WARRANTY.
