Paragon Products PP35/45 - Spacer Wheels Precast & Infrastructure
TECHNICAL DATA SHEET DESCRIPTION
ORDERING INFORMATION
Spacer wheels are designed to easily clip over rebar, providing proper cover spacing between the formwork and rebar.
INFRASTRUCTURE - SPACER WHEELS Product Code Description
Weight
1202-4002
PP35 - 3/4" MESH
0.0059 LB
1202-4003
PP35 - 5/8" MESH
0.0059 LB
APPLICATION
1202-4000
P35 - 1" MESH - #2
0.0176 LB
Intended for drill shafts, caissons, precast, or other applications utilizing formwork.
1202-4010
PP35 - 1" #3-#6
0.0242 LB
1202-4001
PP35 - 3/4" #1-#2
0.0077 LB
1202-4011
PP35 - 1" #3-#6 BULK
0.0242 LB
1202-4015
PP35 - 1-1/2" #1-#2
0.0264 LB
1202-4025
PP35 - 1-1/2" #3-#6
0.0374 LB
1202-4030
PP35 - 2" MESH
0.0400 LB
1202-4040
PP35 - 2" #3-#6
0.0617 LB
1202-4045
PP35 - 2-3/8" #4-#8
0.0463 LB
1202-4050
PP35 - 3" #3-#6
0.0749 LB
1202-4055
PP45 - 3" #4 -#6 LOCKING
0.2621 LB
MANUFACTURER Dayton Superior Corporation 1125 Byers Road Miamisburg, OH 45342 Customer Service: 888-977-9600 Technical Services: 877-266-7732 Website: www.daytonsuperior.com
FEATURES ■ Multiple cover ranges from 5/8” to 3” – concrete cover is defined as the distance from where the reinforcement sits in the hub of the wheel to outside of the wheel where it contacts the form ■ Designed to fit a various range of mesh and rebar sizes ■ Lightweight ■ Locking wheel available in 3” size only
BENEFITS ■ Quick and easy installation ■ Concrete gray color to match concrete
APPROVALS / COMPLIANCE ■ ACI 315-99 ■ CRSI requirements for Class 1 compliance
WARRANTY (ACCESSORIES) Limited Warranty. Dayton warrants, for a period of 60 days from the date of shipment (three years from the date of shipment in the case of formwork, excluding any consumable Products included with such formwork), that Products and any associated application drawings and engineering services provided by Dayton (“Ancillary Services”) will be free from defects in material and workmanship and, in the case of custom designed formwork, that the formwork will meet the specifications set forth in the design drawings approved by Dayton and Customer. Any claim under this warranty must be made in writing within such warranty period. If any Product and/or Ancillary Service covered by a timely claim are found to be defective, Dayton will, within a reasonable time, make any necessary repairs or corrections or, at Dayton’s option, replace the Product. Unless pre-authorized by Dayton in writing, Dayton will not accept any charges for correcting defects or accept the return of any Product. This warranty will not apply to any Products that have been subjected to misuse, neglect, storage damage, misapplication, accident or any other damage caused by any person other than Dayton, or that have not been maintained in accordance with Dayton’s specifications. THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES AS TO THE PRODUCTS AND ANCILLARY SERVICES. DAYTON MAKES NO OTHER WARRANTIES OR GUARANTEES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE. THE REMEDIES SET FORTH IN THIS SECTION ARE CUSTOMER’S EXCLUSIVE REMEDY FOR BREACH OF WARRANTY.
Page 1 of 1
File Date: 5/8/2024
