Pro-Poxy™ 300 Fast Epoxy Gel Anchor
TECHNICAL DATA SHEET DESCRIPTION
Pro-Poxy 300 Fast is two component, moisture tolerant, 100% solids, high modulus epoxy gel adhesive that meets ASTM C881 and AASHTO M235.
USE
Tension Loads ASTM E488 pull out tests in 6000 psi concrete at 7days with threaded rod and rebar. Average of 5 specimens embedded into dry, drilled holes. Threaded Rod Size
Pro-Poxy 300 Fast is ideal for anchoring bolts, dowels, and reinforcing steel in concrete. It is also ideal for vertical and horizontal structural bonding and patching. Pro-Poxy 300 Fast may also be used to seal cracks and set injection ports prior to injection grouting.
Hole Diameter
Hole Depth
1/2" (1.3 cm)
9/16" (1.4 cm)
3-1/2" (8.9 cm)
11000 lbs
48.9 kN
5/8" (1.6 cm)
3/4" (1.9 cm)
4-3/8" (11.1 cm)
14000 lbs
62.2 kN
3/4" (1.9 cm)
7/8" (2.2 cm)
5-1/4" (13.3 cm)
15100 lbs
67.1 kN
1" (2.5 cm)
1-1/8" (2.8 cm)
7" (17.7 cm)
17000 lbs
75.6 kN
FEATURES
■ High-strength structural adhesive ■ Ideal for anchoring dowels, bolts, reinforcing steel and threaded rod ■ Moisture tolerant ■ Fast-setting ■ Non-sag gel consistency ■ Tested and compliant per CDPH V1.2
Pull Out Strength
Steel Rebar Size
Hole Diameter
Hole Depth
#4
9/16" (1.4 cm)
3-1/2" (8.9 cm)
Pull Out Strength 11500 lbs
51.1 kN
#5
3/4" (1.9 cm)
4-3/8" (11.1 cm)
15800 lbs
70.2 kN
#6
7/8" (2.2 cm)
5-1/4" (13.3 cm)
16200 lbs
72.0 kN
#8
1-1/8" (2.8 cm)
7" (17.7 cm)
19000 lbs
84.5 kN
Note:
PROPERTIES
ASTM C881, AASHTO M235, Types I, II, IV, V Grade 3, Classes B & C, Except for gel time due to fast set Mix ratio 1 part A to 1 part B by volume Gel Time 60 gm mass 12 minutes at 73°F (23°C), 32 minutes at 50°F (10°C) Compressive Strength ASTM D695 7 days at 40°F (4°C)- 11,500 psi (79.28 MPa) 7 days at 60°F (15°C)- 12,500 psi (86.18 MPa) Concrete Bond Strength ASTM C882 2 days at 40°F (4°C)- 2,950 psi (20.33 MPa) 2 days at 60°F (15°C)- 3,000 psi (20.68 MPa) 14 days at 40°F (4°C)- 2,960 psi (20.40 MPa) 14 days at 60°F (15°C)- 3,160 psi (21.78 MPa) Water Absorption ASTM D570 - 0.1% Tensile Strength ASTM D638 7 days 7,000 psi (48.2 MPa)
The data shown is typical for controlled laboratory conditions. Reasonable variation from these results can be expected due to interlaboratory precision and bias. When field testing the material, other factors such as variations in installation, temperature, and application conditions should be considered.
voc
Pro-Poxy 300 Fast has a VOC content of 0 g/L . Compliant with all Canadian and U.S. VOC regulations including Federal EPA, OTC, LADCO, SCAQMD & CARB
Visit www.daytonsuperior.com for the most up to date technical information Page 1 of 4
File Date: 11/22/2023
