HOJA DE DATOS TÉCNICOS
DESCRIPCIÓN
ProAnchor Elite es de dos componentes, tolerante a la humedad, 100% sólidos, adhesivo de gel epóxico de alto módulo, aprobado para su uso en cartuchos y a granel para el anclaje en hormigón agrietado y sin agrietar e inserciones roscadas internamente en hormigón sin agrietar. Cumple con los requisitos de ACI 355.4 e ICC-ES AC308 por IAPMO ER-690.
USO
ProAnchor Elite es ideal para anclar pernos, pasadores y acero de refuerzo en hormigón. También es ideal para la unión estructural vertical y horizontal y parcheo. También se puede utilizar para sellar grietas y establecer puertos de inyección antes de la lechada de inyección.
CARACTERÍSTICAS
■ Adhesivo estructural de alta resistencia
■ Ideal para anclaje de pasadores, pernos, acero de refuerzo y varilla roscado
■ Configuración fija
■ Adecuado para agujeros secos, saturados de agua y llenos de agua
■ Calificado para las categorías de diseño sísmico
A a F.
■ Fabricado en los EE.UU. de acuerdo con CFR 49 sección 50101.
PROPIEDADES
Véase el Apéndice A.
Para obtener una lista completa de propiedades, herramientas y accesorios, consulte IAPMO ER -690
APPLICABLE STANDARDS
ASTM C881, AASHTO M235: Tipos I, II, IV y V; Grado 3; Clases A, B y C*
*Excepto por el tiempo de gel debido al conjunto rápido
Aprobaciones de DOT de varios estados IBC/IRC
Certificado UL – Componentes del sistema de agua potable a NSF /ANSI / CAN 61 Aceptable para su uso en instalaciones inspeccionadas por el USDA
COV
ProAnchor Elite tiene un contenido de COV de 0 g/L. Cumple con todas las regulaciones VOC canadienses y estadounidenses, incluidas las federales EPA, OTC, LADCO, SCAQMD y CARB
Embalaje
Código de producto
ProAnchor
ALMACENAMIENTO
El material debe almacenarse a 40°-95°F (5°-35°C). Usar antes de la "fecha de caducidad" en la etiqueta del producto.
No exponga el producto almacenado a temperaturas frías o de congelación por debajo de 35 °F (2 °C) durante ningún período de tiempo.
Preparación de la superficie: Condiciones ambientales y de temperatura del sustrato: 43° y 110°F (6° y 43°C) para aplicaciones estructurales por UES 690.
38° y 125°F (3° y 52°C) para aplicaciones de infraestructura de transporte a AASHTO M235 & ASTM C881.
La superficie a unir debe estar limpia y sana. Elimine el polvo, la suciedad, la grasa, la laitance, los compuestos de curado y otras materias extrañas mediante chorro de arena, abrasión mecánica o hidroarración. Para agujeros perforados, limpie con un cepillo de cerdas.
Retire toda el agua y el polvo con aire comprimido limpio antes de la instalación. La temperatura del aire y la superficie debe ser de 38 °F (3 °C) o más.
Mezclado:
Acondicione el material a 65°- 85°F (18°- 29°C) antes de usarlo.
Cartuchos:
Retire la tapa protectora y "pre-purgue" el cartucho antes de poner el mezclador estático para asegurar una mezcla uniforme. Atornille la boquilla de mezcla estática y dispense epoxi hasta que el producto sea un gris uniforme sin rayas.
Bulto:
Premezcle cada componente, luego mezcle volúmenes iguales de la Parte A y la Parte B durante 3 minutos con un taladro de baja velocidad, un mezclador o paleta. Mezcle solo lo que se puede usar durante la vida útil de la olla. Para equipos de dispensación a gra nel para
HOJA DE DATOS TÉCNICOS
aplicaciones estructurales, consulte UES 690 Tabla 5. En condiciones normales de funcionamiento, la bomba a granel debe ser capaz de dispensar los componentes individuales a una relación de mezcla 1:1 por volumen con una tolerancia de ± 2%.
Colocación:
Paso 1: Taladro en concreto usando un taladro de potencia de percusión rotativa (taladro de martillo rotativo) y una broca de tipo SDS o SDS-Plus con punta de carburo que cumpla con ANSI B212.151994, al diámetro y la profundidad de incrustación que se adhieren al espaciado mínimo, la distancia mínima del borde y el espesor mínimo del miembro de concreto.
Precaución: Use una protección adecuada para los ojos y la piel. Evite la inhalación de polvo durante la perforación y la eliminación de escombros.
Paso 2: Soplar el agujero usando aire comprimido exento de aceite a un mínimo de 70 psi con una boquilla. Mientras sopla aire, inserte la boquilla en el agujero hasta que esté en contacto con la parte inferior durante no menos de un segundo, y luego retírmela.
Paso 3: Inserte un cepillo de limpieza para el diámetro adecuado del orificio de perforación. Empuje el cepillo a la parte inferior del pozo mientras se tuerce. Una vez que el cepillo esté en contacto con la parte inferior del agujero, gire el cepillo a media revolución y luego retire rápidamente el cepillo con un tirón vigoroso y retorcido. Repetir.
Paso 4: Repita el golpe fuera del agujero con aire según el paso 2 anterior. El hormigón deberá estar seco antes de la inyección del adhesivo.
Paso 5: Cuando utilice el cartucho, inserte el cartucho en la herramienta de extrusión y conecte la boquilla de mezcla suministrada al cartucho. No modifique la boquilla de mezcla. Antes de la inyección, dispense el material a través de la boquilla de mezcla en una cuenta continua hasta que se logre un color gris claro uniforme. El material dispensado inicial será de color gris más oscuro y no debe usarse para la instalación. Después de lograr un color gris claro uniforme, inserte el extremo de la boquilla de mezcla en el pozo hasta que esté en contacto con la parte inferior. Luego, dispense el adhesivo mientras retira lentamente la boquilla hasta que el orificio esté aproximadamente 1/2 - 2/3 lleno, y luego retire la boquilla de mezcla. Mantenga la boquilla conectada en cartuchos parcialmente usados. Se debe utilizar
ProAnchor Elite
una nueva boquilla de mezcla si el tiempo de gel se ha excedido entre inyecciones.
Paso 6: Marque la varilla de anclaje con la profundidad de incrustación requerida. Inserte la varilla de anclaje limpia y libre de aceite en el adhesivo en el pozo, volteándolo lentamente a medida que se empuja hacia abajo hasta el contacto con el fondo del pozo. Asegúrese de que el agujero esté completamente lleno de adhesivo y que no aparezcan huecos entre la varilla de anclaje y el pozo.
Paso 7: Ajuste la alineación del ancla en el agujero inmediatamente. No lo moleste entre el Tiempo de Gel y el Tiempo mínimo de curación. No apriete ni aplique carga al ancla hasta el tiempo de curado recomendado.
Tiempo de curación
Tiempo de trabajo y tiempo de curación completo por UES 690. Base la temperatura del material y del aire ambiente será de 43° a 110° F (6° a 43° C) durante la instalación. Cuando ambiente o el material de base cae por debajo de 70 ° F (21 ° C) el el adhesivo se acondicionará a 70° a 75° F (21° a 24° C) antes de su uso.
Temperaturas del hormigón
Accesorios
Cepillos de acero inoxidable
Véase el apéndice B.
LIMPIEZA
Herramientas y Equipos: Limpie antes de que el epoxi se establezca. Use xileno o citrus cleaner J48.
LIMITACIONES SOLO PARA USO PROFESIONAL
Los requisitos del código de construcción para hormigón estructural (ACI 318-11 / ACI 318-14) requieren que el instalador esté certificado cuando se
HOJA DE DATOS TÉCNICOS
instalen anclajes adhesivos en instalaciones horizontales o aéreas. No adelgazar con disolventes La temperatura de la superficie y del ambiente debe ser de 38 °F (3 °C) o más No exponga el producto almacenado a temperaturas frías o de congelación por debajo de 35 °F (2 °C) durante ningún período de tiempo
PRECAUCIONES
LEA LA HOJA DE SDS ANTES DE USAR EL PRODUCTO
■ Componente A – Irritante
■ Componente B – Corrosivo
■ El producto es un fuerte sensibilizador
■ Uso con ventilación adecuada
■ Mantener fuera del alcance de los niños
■ Use ropa protectora, guantes y protección ocular (gafas, gafas de seguridad y/o protector facial)
■ No tomar internamente
■ En caso de ingestión, busque ayuda médica inmediatamente
■ Puede causar irritación de la piel al contacto, especialmente prolongada o repetida. Si se produce contacto con la piel, lávese inmediatamente con agua y jabón y busque ayuda médica según sea necesario.
■ Si se produce contacto visual, enjuague inmediatamente con agua limpia y busque ayuda médica según sea necesario
■ Deseche el material de desecho de acuerdo con los requisitos federales, estatales y locales
■ Las resinas epoxi curadas son inocuas
FABRICANTE
Dayton Superior Corporation
1125 Byers Road
Miamisburg, OH 45342
Servicio al Cliente: 888-977-9600
Servicios Técnicos: 866-329-8724
Sitio Web: www.daytonsuperior.com
GARANTÍA
Dayton Superior Corporation (“Dayton”) garantiza por 12 meses a partir de la fecha de fabricación o por la duración de la vida útil publicada del producto, lo que sea menor, que al momento del envío por parte de Dayton, el producto está libre de defectos de fabricación y satisface las
propiedades del producto de Dayton en v igor en la fecha de aceptación del pedido por parte de Dayton. Dayton solo será responsable bajo esta garantía si el producto se ha aplicado, utilizado y almacenado conforme a las instrucciones de Dayton, en especial la preparación e instalación de superfi cies, en vigor en la fecha de aceptación del pedido por parte de Dayton. El comprador deberá examinar el producto al recibirlo y notificar rápidamente a Dayton por escrito de cualquier no conformidad antes de que el producto se utilice y, a más tardar 30 días después de que se haya descubierto dicha no conformidad por primera vez. Si Dayton, a su exclusiva discreción, determina que el producto ha violado esta garantía, a su exclusiva discreción reemplazará el producto no conforme, rembolsará el precio de co mpra o expedirá un crédito por la suma del precio de compra. Este es el único y exclusivo remedio en caso de incumplimiento de esta garantía. Solo un funcionario de Dayton está autorizado para modificar esta garantía. La información de esta hoja técnica re emplaza toda la demás información de ventas recibida por el cliente durante el proceso de venta. LA GARANTÍA ANTERIOR SERÁ EXCLUSIVA Y EN LUGAR DE CUALQUIER OTRA GARANTÍA, EXPRESA O IMPLÍCITA, INCLUIDAS LAS GARANTÍAS DE COMERCIALIZACIÓN E IDONEIDAD PARA UN PROPÓSITO PARTICULAR, Y TODAS LAS DEMÁS GARANTÍAS QUE SURJAN POR APLICACIÓN DE LA LEY, TRANSACCIÓN, COSTUMBRE, COMERCIO O POR OTRO MOTIVO.
Dayton no se hace responsable por contrato o por agravio (incluyendo, sin limitación, negligencia, responsabilidad estricta o de otro tipo) por la pérdida de ventas, ingresos o utilidades, costo de capital o fondos, interrupción del negocio o costo del tiempo de inactividad, pérdida de uso, daños o pérdida del uso de otros bienes (muebles o inmuebles), no obtención de ahorros previstos, frustración de expectativas económicas o comerciales, reclamos de terceros (que no sean por lesiones corporales), o pérdidas económicas de cualquier tipo, o por ningún daño especial , incidental, indirecto, emergente, punitivo o ejemplar que surja de cualquier manera del cumplimiento o del incumplimiento de sus obligaciones en virtud de cualquier contrato de venta de producto , incluso si Dayton hubiera podido prever o hubiera sido advertido de la posibilidad de tales daños. Las partes acuerdan expresamente que estas limitaciones sobre los daños son asignaciones de riesgo que constituyen, en parte, el pago de este contrato, y que dichas limitaciones sobrevivirán a la determinación de cualquier tribunal de jurisdicción competente en el sentido de que cualquier recurso previsto en estos términos o disponible por ley no cumple su propósito esencial.
HOJA DE DATOS TÉCNICOS
Apéndice A
TABLA 1: ProAnchor Elite Performance a ASTM C881-151,2,3
Propiedad Tiempo de curación ASTM Norma Unidad
Tiempo de gel – 60
Gramo Masa4 C881 Min 14 13 10 24 24
Consistencia o Viscosidad No hundimiento
Resistencia al rendimiento compresivo 7 día D695
compresivo
Resistencia de unión endurecida a hormigón endurecido 2 día
Resistencia de unión fresca a hormigón endurecido
Resistencia a la tracción5 7 día
Temperatura de desviación de calor
Absorción de agua 14 día
Coeficiente lineal de contracción
(MPa)
D648 °F
1. Resultados de las pruebas del producto basadas en lotes representativos. Los resultados medios variarán según las tolerancias de la propiedad dada.
2. El tiempo de curado completo se enumera anteriormente para obtener las propiedades dadas para cada característica del producto.
3. Los resultados pueden variar debido a factores ambientales como la temperatura, la humedad y el tipo de sustrato.
4. El tiempo de gel puede ser inferior al mínimo requerido para astm C881.
5. Pruebas opcionales para ASTM C881 Grado 3.
Apéndice B
Herramientas
Cepillos
HOJA DE DATOS TÉCNICOS
100865
100866
100867
100868
100869
100871
100872
100873
100874
100875
100876
100877
100878
100879
100881
100882
100883
141293
141487
140952
100216
140954
Cepillo - 6 IN - Drill Size 7/16"
Cepillo - 6 IN - Drill Size 1/2"
Cepillo - 6 IN - Drill Size 9/16"
Cepillo - 6 IN - Drill Size 5/8"
Cepillo - 6 IN - Drill Size 3/4"
Cepillo - 6 IN - Drill Size 7/8"
Cepillo - 9 IN - Drill Size 1"
Cepillo - 9 IN - Drill Size 1-1/8"
Cepillo - 9 IN - Drill Size 1-3/8"
Cepillo - 9 IN - Drill Size 1-1/2"
Adaptador de pincel SDS
Extensión de pincel
Misceláneo
Boquilla de mezcla cuadrada con percha – 10"x1/2"x7/16"
Boquilla de mezcla HF con tubo ext de 8MM - 15.75"
Tubo de extensión de 8 MM para boquilla de mezcla HF de 15,75"
Extensión de boquilla de 9/16" de diámetro - 36"
Cuña de retención
Herramientas de dispensación
Herramienta manual de dispensación de servicio pesado – 8.6 oz
Herramienta manual de dispensación de servicio pesado – 21.2 oz
Herramienta de dosificación neumática – 21.2 oz
Herramienta de dosificación de batería – 21.2/16 oz con cargador de 18V
Herramienta de dosificación neumática - 53 oz
HOJA DE DATOS TÉCNICOS
100895
100896
100897
100898
100899
100901
100902
100903
100904
100905
Enchufes de pistón
Enchufe de pistón 7/16" - Negro con tubo de polipropileno de 8" (10 pk)
Enchufe de pistón 7/16" - Negro (10 pk)
Enchufe de pistón 9/16" - Azul (10 pk)
Enchufe de pistón 5/8" - Rojo (10 pk)
Enchufe de pistón 3/4" - Amarillo (10 pk)
Enchufe de pistón 7/8" - Verde (10 pk)
Enchufe de pistón 1-1/8" - Naranja (5 pk)
Piston Plug 1-1/8" - Orange (5 pk)
Enchufe de pistón 1-3/8" - Marrón (5 pk)
Enchufe de pistón 1-1/2" - Gris (5 pk)
Printing date 04/25/2023
1 Identification
· Product identifier
· Trade name:ProAnchor Elite - Part A
· Article number: 100862A
· Application of the substance / the mixture
· Details of the supplier of the safety data sheet
· Manufacturer/Supplier: Dayton® Superior 4226 Kansas Avenue
acc. to OSHA HCS
Reviewed on 04/25/2023
Tel.: (866) 329-8724 Kansas City, KS 66106
Emergency Telephone Number: Use only in the event of an emergency involving a spill, leak, fire, exposure, or accident involving chemicals. Within the U.S., Canada, or the U.S. Virgin Islands, call ChemTrec at (800) 424-9300, 24 hours a day. Or, outside these areas, call international number, +1 703 741-5970. Collect calls are accepted.
· Information department: Environmental, Health, and Safety department.
2 Hazard(s) identification
· Classification of the substance or mixture
Skin Irrit. 2H315Causes skin irritation.
Eye Dam. 1H318Causes serious eye damage.
Skin Sens. 1H317May cause an allergic skin reaction.
Repr. 1BH360May damage fertility or the unborn child.
Aquatic Chronic 2H411Toxic to aquatic life with long lasting effects.
· Label elements
· GHS label elements The product is classified and labeled according to the Globally Harmonized System (GHS).
· Hazard pictograms
GHS05 GHS07 GHS08 GHS09
· Signal word Danger
· Hazard statements
Causes skin irritation. Causes serious eye damage. May cause an allergic skin reaction. May damage fertility or the unborn child. Toxic to aquatic life with long lasting effects.
· Precautionary statements
If in eyes: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a poison center/doctor. Specific treatment (see on this label).
Take off contaminated clothing and wash it before reuse. Store locked up.
Dispose of contents/container in accordance with local/regional/national/international regulations.
(Contd. on page 2) US
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
· Classification system:
· NFPA ratings (scale 0 - 4)
0 0 Health = 3 Fire = 0 Reactivity = 0
· HMIS-ratings (scale 0 - 4)
3 0 0
= 3 Fire = 0 Reactivity = 0
· Other hazards
· Results of PBT and vPvB assessment
· PBT: Not applicable.
· vPvB: Not applicable.
3 Composition/information on ingredients
· Chemical characterization: Mixtures
· Description: Mixture of the substances listed below with nonhazardous additions.
· Dangerous components:
25085-99-8Diglycidyl ether of bisphenol A homopolymer
· Additional information: For the wording of the listed hazard phrases refer to section 16.
4 First-aid measures
· Description of first aid measures
· General information:
Immediately remove any clothing soiled by the product.
In the event of persistent symptoms recieve medical treatment.
Reviewed on 04/25/2023
(Contd. of page 1)
Symptoms of poisoning may even occur after several hours; therefore medical observation for at least 48 hours after the accident.
· After inhalation:
Immediately move exposed person to fresh air. If breathing difficulty persists or develops get prompt medical attention.
· After skin contact:
Immediately wash with water and soap and rinse thoroughly. If skin irritation continues, consult a doctor.
· After eye contact: Rinse opened eye for several minutes under running water. Then consult a doctor.
· After swallowing: Seek medical treatment.
· Information for doctor:
· Most important symptoms and effects, both acute and delayed No further relevant information available.
· Indication of any immediate medical attention and special treatment needed No further relevant information available.
5 Fire-fighting measures
· Extinguishing media
· Suitable extinguishing agents: Use fire fighting measures that suit the environment.
· Special hazards arising from the substance or mixture No further relevant information available. (Contd. on page 3)
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
· Advice for firefighters
· Protective equipment:
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 2)
Because fire may produce thermal decomposition products, wear a self-contained breathing apparatus (SCBA) with a full face piece operated in pressure-demand or positive-pressure mode.
6 Accidental release measures
· Personal precautions, protective equipment and emergency procedures
Wear protective equipment. Keep unprotected persons away.
· Environmental precautions: Do not allow product to reach sewage system or any water course.
· Methods and material for containment and cleaning up:
Absorb with liquid-binding material (sand, diatomite, acid binders, universal binders, sawdust).
Dispose contaminated material as waste according to item 13.
Ensure adequate ventilation.
· Reference to other sections
See Section 7 for information on safe handling.
See Section 8 for information on personal protection equipment.
See Section 13 for disposal information.
7 Handling and storage
· Handling:
· Precautions for safe handling
Wear appropriate personal protective clothing to prevent eye and skin contact. Avoid breathing vapors or mists of this product. Use with adequate ventilation. Do not take internally.
· Information about protection against explosions and fires: No special measures required.
· Conditions for safe storage, including any incompatibilities
· Storage: cool and dry
· Requirements to be met by storerooms and receptacles: No special requirements.
· Information about storage in one common storage facility: Not required.
· Further information about storage conditions: Keep receptacle tightly sealed.
· Specific end use(s) No further relevant information available.
8 Exposure controls/personal protection
· Additional information about design of technical systems: No further data; see item 7.
· Control parameters
· Components with limit values that require monitoring at the workplace: The product does not contain any relevant quantities of materials with critical values that have to be monitored at the workplace.
· Additional information: The lists that were valid during the creation were used as basis.
· Exposure controls
· Personal protective equipment:
· General protective and hygienic measures: Keep away from foodstuffs, beverages and feed. Immediately remove all soiled and contaminated clothing. Wash hands before breaks and at the end of work.
Avoid contact with the eyes.
Avoid contact with the eyes and skin. (Contd.
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
· Breathing equipment:
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 3)
In case of brief exposure or low pollution use respiratory filter device. In case of intensive or longer exposure use respiratory protective device that is independent of circulating air.
· Protection of hands:
Protective gloves
The glove material has to be impermeable and resistant to the product/ the substance/ the preparation.
· Eye protection: Wear appropriate eye protection to prevent eye contact.
9 Physical and chemical properties
· Information on basic physical and chemical properties
· General Information
· Appearance: Form: Viscous Color: White
· Odor: Characteristic
· Odor threshold: Not determined.
· pH-value: Not determined.
· Change in condition
Melting point/Melting range: Undetermined. Boiling point/Boiling range: Undetermined.
· Flash point: Not applicable.
· Flammability (solid, gaseous): Not applicable.
· Decomposition temperature: Not determined.
· Auto igniting: Product is not selfigniting.
· Danger of explosion: Product does not present an explosion hazard.
· Explosion limits: Lower: Not determined. Upper: Not determined.
· Vapor pressure: Not determined.
· Density: Not determined.
· Relative density Not determined.
· Vapor density Not determined.
· Evaporation rate Not determined.
· Solubility in / Miscibility with Water: Not miscible or difficult to mix.
· Partition coefficient (n-octanol/water): Not determined.
· Viscosity: Dynamic: Not determined. Kinematic: Not determined.
(Contd. on page 5)
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
· Solvent content:
Solids content:
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 4)
100.0 %
· Other information No further relevant information available.
10Stability and reactivity
· Reactivity No decomposition if stored and applied as directed.
· Chemical stability No decomposition if stored and applied as directed
· Thermal decomposition / conditions to be avoided: No decomposition if used according to specifications.
· Possibility of hazardous reactions No dangerous reactions known.
· Conditions to avoid Keep away from heat and sources of ignition.
· Incompatible materials: No further relevant information available.
· Hazardous decomposition products: No dangerous decomposition products known.
11Toxicological information
· Information on toxicological effects
· Acute toxicity:
· LD/LC50 values that are relevant for classification: 25085-99-8Diglycidyl ether of bisphenol A homopolymer
OralLD505,000 mg/kg (rat)
DermalLD5020,000 mg/kg (rabbit)
· Primary irritant effect:
· on the skin: May cause skin irritation.
· on the eye: Irritating effect.
· Sensitization: No sensitizing effects known.
· Additional toxicological information: The product shows the following dangers according to internally approved calculation methods for preparations: Harmful Irritant
· Carcinogenic categories
· IARC (International Agency for Research on Cancer) None of the ingredients is listed.
· NTP (National Toxicology Program)
None of the ingredients is listed.
· OSHA-Ca (Occupational Safety & Health Administration)
None of the ingredients is listed.
12Ecological information
· Toxicity
· Aquatic toxicity: No further relevant information available.
· Persistence and degradability No further relevant information available.
· Behavior in environmental systems:
· Bioaccumulative potential No further relevant information available.
· Mobility in soil No further relevant information available.
(Contd. on page 6)
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
· Additional ecological information:
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 5)
· General notes: Water hazard class 1 (Self-assessment): slightly hazardous for water
· Results of PBT and vPvB assessment
· PBT: Not applicable.
· vPvB: Not applicable.
· Other adverse effects No further relevant information available.
13Disposal considerations
· Waste treatment methods
· Recommendation: It is the generator's responsibility to determine if the waste meets applicable definitions of hazardous waste. State and local regulations may differ from federal disposal regulations. Dispose of waste material according to local, state, federal, and provincial environmental regulations.
· Uncleaned packagings:
· Recommendation: Disposal must be made according to Federal, State, and Local regulations.
14Transport information
· UN-Number
· DOT, ADR, ADN Not Regulated
· IMDG, IATA UN3077
· UN proper shipping name
· DOT, ADR, ADN Not Regulated
· IMDG
ENVIRONMENTALLY HAZARDOUS SUBSTANCE, SOLID, N.O.S. (Diglycidyl ether of bisphenol A homopolymer), MARINE POLLUTANT
· IATA ENVIRONMENTALLY HAZARDOUS SUBSTANCE, SOLID, N.O.S. (Diglycidyl ether of bisphenol A homopolymer)
· Transport hazard class(es)
· DOT, ADR, ADN
· Class Not Regulated
· IMDG, IATA
· Class 9 Miscellaneous dangerous substances and articles
· Label 9
· Packing group
· DOT, ADR Not Regulated
· IMDG, IATA III
· Environmental hazards:
· Marine pollutant: Symbol (fish and tree)
· Special marking (IATA): Symbol (fish and tree)
(Contd. on page 7) US
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 6)
· Transport in bulk according to Annex II of MARPOL73/78 and the IBC Code Not applicable.
· Transport/Additional information:
· ADR
· U.S. Domestic Ground Shipments:
· U.S. Domestic Ground Non-Bulk (119 gal or less per container) Shipments:
Same as listed for Standard Shipments above.
Same as listed for Standard Shipments above.
· Emergency Response Guide (ERG) Number: Not determine
· IMDG
· Limited quantities (LQ) 5L
· UN "Model Regulation": Not Regulated
15Regulatory information
· Safety, health and environmental regulations/legislation specific for the substance or mixture
· Sara
· Section 355 (extremely hazardous substances):
None of the ingredient is listed.
· Section 313 (Specific toxic chemical listings): This product may contain 1 or more toxic chemicals subject to the reporting requirements of Section 313 of Title III of the Superfund Amendments and Reauthorization Act (SARA) of 1986 and 40 CFR part 372. If so, the chemicals are listed below. None of the ingredients is listed.
· TSCA (Toxic Substances Control Act):
25085-99-8Diglycidyl ether of bisphenol A homopolymer ACTIVE 30499-70-81,3-propanediol, 2-ethyl-2-(hydroxymethyl)-, polymer with 2-(chloromethyl)oxirane ACTIVE
· Hazardous Air Pollutants
None of the ingredients is listed.
· Proposition 65
· Chemicals known to the State of California (Prop. 65) to cause cancer: None of the ingredients is listed.
· Chemicals known to cause reproductive toxicity for females: None of the ingredients is listed.
· Chemicals known to cause reproductive toxicity for males: None of the ingredients is listed.
· Chemicals known to cause developmental toxicity: None of the ingredients is listed.
· Cancerogenity categories
· EPA (Environmental Protection Agency) None of the ingredients is listed.
· TLV (Threshold Limit Value established by ACGIH) None of the ingredients is listed.
(Contd. on page 8)
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
acc. to OSHA HCS
· MAK (German Maximum Workplace Concentration)
None of the ingredients is listed.
· NIOSH-Ca (National Institute for Occupational Safety and Health)
None of the ingredients is listed.
Reviewed on 04/25/2023
· GHS label elements The product is classified and labeled according to the Globally Harmonized System (GHS).
· Hazard pictograms GHS05 GHS07 GHS08 GHS09
· Signal word Danger
· Hazard statements
Causes skin irritation. Causes serious eye damage. May cause an allergic skin reaction. May damage fertility or the unborn child.
Toxic to aquatic life with long lasting effects.
· Precautionary statements
(Contd. of page 7)
If in eyes: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a poison center/doctor.
Specific treatment (see on this label).
Take off contaminated clothing and wash it before reuse.
Store locked up.
Dispose of contents/container in accordance with local/regional/national/international regulations.
· Chemical safety assessment: A Chemical Safety Assessment has not been carried out.
16Other information
This information is based on our present knowledge. However, this shall not constitute a guarantee for any specific product features and shall not establish a legally valid contractual relationship.
· Department issuing SDS: Environmental, Health & Safety Department
· Contact: Environmental, Health & Safety Manager
· Date of preparation / last revision 04/25/2023 / 1
· Abbreviations and acronyms:
ADR: Accord européen sur le transport des marchandises dangereuses par Route (European Agreement concerning the International Carriage of Dangerous Goods by Road)
IMDG: International Maritime Code for Dangerous Goods
DOT: US Department of Transportation
IATA: International Air Transport Association
ACGIH: American Conference of Governmental Industrial Hygienists
EINECS: European Inventory of Existing Commercial Chemical Substances
ELINCS: European List of Notified Chemical Substances
CAS: Chemical Abstracts Service (division of the American Chemical Society)
NFPA: National Fire Protection Association (USA)
HMIS: Hazardous Materials Identification System (USA)
LC50: Lethal concentration, 50 percent
LD50: Lethal dose, 50 percent
PBT: Persistent, Bioaccumulative and Toxic
vPvB: very Persistent and very Bioaccumulative
NIOSH: National Institute for Occupational Safety
OSHA: Occupational Safety & Health
TLV: Threshold Limit Value
PEL: Permissible Exposure Limit
REL: Recommended Exposure Limit
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part A
Skin Irrit. 2: Skin corrosion/irritation – Category 2
Eye Dam. 1: Serious eye damage/eye irritation – Category 1
Skin Sens. 1: Skin sensitisation – Category 1
Repr. 1B: Reproductive toxicity – Category 1B
Aquatic Chronic 2: Hazardous to the aquatic environment - long-term aquatic hazard – Category 2
Reviewed on 04/25/2023
(Contd. of page 8)
Printing date 04/25/2023
1 Identification
· Product identifier
· Trade name:ProAnchor Elite - Part B
· Article number: 100862B
· Application of the substance / the mixture
· Details of the supplier of the safety data sheet
· Manufacturer/Supplier: Dayton® Superior 4226 Kansas Avenue
acc. to OSHA HCS
Reviewed on 04/25/2023
Tel.: (866) 329-8724 Kansas City, KS 66106
Emergency Telephone Number: Use only in the event of an emergency involving a spill, leak, fire, exposure, or accident involving chemicals. Within the U.S., Canada, or the U.S. Virgin Islands, call ChemTrec at (800) 424-9300, 24 hours a day. Or, outside these areas, call international number, +1 703 741-5970. Collect calls are accepted.
· Information department: Environmental, Health, and Safety department.
2 Hazard(s) identification
· Classification of the substance or mixture
Acute Tox. 4H302Harmful if swallowed.
Skin Corr. 1BH314Causes severe skin burns and eye damage.
Skin Sens. 1H317May cause an allergic skin reaction.
Carc. 1AH350May cause cancer.
Repr. 2H361Suspected of damaging fertility or the unborn child.
STOT RE 1H372Causes damage to organs through prolonged or repeated exposure.
Aquatic Chronic 3H412Harmful to aquatic life with long lasting effects.
· Label elements
· GHS label elements The product is classified and labeled according to the Globally Harmonized System (GHS).
· Hazard pictograms
· Signal word Danger
· Hazard-determining components of labeling:
Quartz (SiO2)
1,3-Cyclohexanedimethanamine
2-piperazin-1-ylethylamine
titanium dioxide
· Hazard statements
Harmful if swallowed.
Causes severe skin burns and eye damage. May cause an allergic skin reaction.
May cause cancer.
Suspected of damaging fertility or the unborn child.
Causes damage to organs through prolonged or repeated exposure.
Harmful to aquatic life with long lasting effects.
· Precautionary statements
If on skin (or hair): Take off immediately all contaminated clothing. Rinse skin with water/shower.
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 1)
If in eyes: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a poison center/doctor.
Specific treatment (see on this label).
Store locked up.
Dispose of contents/container in accordance with local/regional/national/international regulations.
· Classification system:
· NFPA ratings (scale 0 - 4)
3 0 0
Health = 3
Fire = 0
Reactivity = 0
· HMIS-ratings (scale 0 - 4) HEALTH
PHYSICAL HAZARD *3 0 0 Health = *3 Fire = 0 Reactivity = 0
· Other hazards
· Results of PBT and vPvB assessment
· PBT: Not applicable.
· vPvB: Not applicable.
3 Composition/information on ingredients
· Chemical characterization: Mixtures
· Description: Mixture of the substances listed below with nonhazardous additions.
· Dangerous components:
· Additional information: For the wording of the listed hazard phrases refer to section 16.
4 First-aid measures
· Description of first aid measures
· General information:
Immediately remove any clothing soiled by the product. In the event of persistent symptoms recieve medical treatment. Symptoms of poisoning may even occur after several hours; therefore medical observation for at least 48 hours after the accident.
· After inhalation:
Supply fresh air and to be sure call for a doctor.
In case of unconsciousness place patient stably in side position for transportation. Immediately move exposed person to fresh air. If breathing difficulty persists or develops get prompt medical attention.
· After skin contact:
Immediately wash with water and soap and rinse thoroughly. Immediately rinse with water. If skin irritation continues, consult a doctor.
· After eye contact: Rinse opened eye for several minutes under running water. Then consult a doctor.
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 2)
· After swallowing: Immediately call a doctor. Drink copious amounts of water and provide fresh air. Immediately call a doctor. Seek medical treatment.
· Information for doctor:
· Most important symptoms and effects, both acute and delayed No further relevant information available.
· Indication of any immediate medical attention and special treatment needed No further relevant information available.
5 Fire-fighting measures
· Extinguishing media
· Suitable extinguishing agents: Use fire fighting measures that suit the environment.
· Special hazards arising from the substance or mixture No further relevant information available.
· Advice for firefighters
· Protective equipment:
Because fire may produce thermal decomposition products, wear a self-contained breathing apparatus (SCBA) with a full face piece operated in pressure-demand or positive-pressure mode.
6 Accidental release measures
· Personal precautions, protective equipment and emergency procedures
Wear protective equipment. Keep unprotected persons away.
· Environmental precautions: Do not allow product to reach sewage system or any water course.
· Methods and material for containment and cleaning up:
Absorb with liquid-binding material (sand, diatomite, acid binders, universal binders, sawdust).
Use neutralizing agent.
Dispose contaminated material as waste according to item 13.
Ensure adequate ventilation.
· Reference to other sections
See Section 7 for information on safe handling.
See Section 8 for information on personal protection equipment.
See Section 13 for disposal information.
7 Handling and storage
· Handling:
· Precautions for safe handling
Wear appropriate personal protective clothing to prevent eye and skin contact. Avoid breathing vapors or mists of this product. Use with adequate ventilation. Do not take internally.
· Information about protection against explosions and fires: No special measures required.
· Conditions for safe storage, including any incompatibilities
· Storage:
· Requirements to be met by storerooms and receptacles: No special requirements.
· Information about storage in one common storage facility: Not required.
· Further information about storage conditions: Keep receptacle tightly sealed.
· Specific end use(s) No further relevant information available.
8 Exposure controls/personal protection
· Additional information about design of technical systems: No further data; see item 7.
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
· Control parameters
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 3)
· Components with limit values that require monitoring at the workplace: The following constituent is the only constituent of the product which has a PEL, TLV or other recommended exposure limit. At this time, the other constituents have no known exposure limits. 14808-60-7Quartz (SiO2)
PELLong-term value: 0.05* mg/m³
*resp. dust; 30mg/m3/%SiO2+2
RELLong-term value: 0.05* mg/m³
*respirable dust; See Pocket Guide App. A
TLVLong-term value: 0.025* mg/m³
*as respirable fraction
· Additional information: The lists that were valid during the creation were used as basis.
· Exposure controls
· Personal protective equipment:
· General protective and hygienic measures: Keep away from foodstuffs, beverages and feed. Immediately remove all soiled and contaminated clothing. Wash hands before breaks and at the end of work. Avoid contact with the eyes and skin.
· Breathing equipment: In case of brief exposure or low pollution use respiratory filter device. In case of intensive or longer exposure use respiratory protective device that is independent of circulating air.
· Protection of hands:
The glove material has to be impermeable and resistant to the product/ the substance/ the preparation.
· Eye protection: Wear appropriate eye protection to prevent eye contact.
9 Physical and chemical properties
· Information on basic physical and chemical properties
· General Information
· Appearance: Form: Viscous Color: Gray
· Odor: Amine-like
· Odor threshold: Not determined.
· pH-value: Not determined.
· Change in condition
Melting point/Melting range: Undetermined. Boiling point/Boiling range: Undetermined.
· Flash point: Not applicable.
· Flammability (solid, gaseous): Not applicable.
· Decomposition temperature: Not determined.
(Contd. on page 5)
Protective gloves
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
acc. to OSHA HCS
· Auto igniting: Product is not selfigniting.
· Danger of explosion: Product does not present an explosion hazard.
· Explosion limits: Lower: Not determined. Upper: Not determined.
· Vapor pressure: Not determined.
· Density at 20 °C (68 °F): 1.12637 g/cm³ (9.39956 lbs/gal)
· Relative density Not determined.
· Vapor density Not determined.
· Evaporation rate Not determined.
· Solubility in / Miscibility with Water: Not miscible or difficult to mix.
· Partition coefficient (n-octanol/water): Not determined.
· Viscosity: Dynamic: Not determined. Kinematic: Not determined.
· Other information No further relevant information available.
10Stability and reactivity
· Reactivity No decomposition if stored and applied as directed.
· Chemical stability No decomposition if stored and applied as directed
Reviewed on 04/25/2023
(Contd. of page 4)
· Thermal decomposition / conditions to be avoided: No decomposition if used according to specifications.
· Possibility of hazardous reactions No dangerous reactions known.
· Conditions to avoid Keep away from heat and sources of ignition.
· Incompatible materials: No further relevant information available.
· Hazardous decomposition products: No dangerous decomposition products known.
11Toxicological information
· Information on toxicological effects
· Acute toxicity:
· LD/LC50 values that are relevant for classification: 140-31-82-piperazin-1-ylethylamine
OralLD502,140 mg/kg (rat)
DermalLD50880 mg/kg (rabbit)
· Primary irritant effect:
· on the skin: May cause skin irritation.
· on the eye: Strong caustic effect.
· Sensitization: Sensitization possible through skin contact.
· Additional toxicological information: The product shows the following dangers according to internally approved calculation methods for preparations: Harmful
Corrosive Irritant
(Contd. on page 6)
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 5)
Swallowing will lead to a strong caustic effect on mouth and throat and to the danger of perforation of esophagus and stomach.
· Carcinogenic categories
· IARC (International Agency for Research on Cancer)
14808-60-7Quartz (SiO2)
13463-67-7titanium dioxide
· NTP (National Toxicology Program)
14808-60-7Quartz (SiO2)
· OSHA-Ca (Occupational Safety & Health Administration)
None of the ingredients is listed.
12Ecological information
· Toxicity
· Aquatic toxicity: No further relevant information available.
· Persistence and degradability No further relevant information available.
· Behavior in environmental systems:
· Bioaccumulative potential No further relevant information available.
· Mobility in soil No further relevant information available.
· Additional ecological information:
· General notes:
Water hazard class 1 (Self-assessment): slightly hazardous for water
Water hazard class 2 (Self-assessment): hazardous for water
Do not allow product to reach ground water, water course or sewage system.
Must not reach bodies of water or drainage ditch undiluted or unneutralized. Danger to drinking water if even small quantities leak into the ground.
· Results of PBT and vPvB assessment
· PBT: Not applicable.
· vPvB: Not applicable.
· Other adverse effects No further relevant information available.
13Disposal considerations
· Waste treatment methods
· Recommendation:
It is the generator's responsibility to determine if the waste meets applicable definitions of hazardous waste. State and local regulations may differ from federal disposal regulations. Dispose of waste material according to local, state, federal, and provincial environmental regulations.
· Uncleaned packagings:
· Recommendation: Disposal must be made according to Federal, State, and Local regulations.
14Transport information
· UN-Number
· DOT, ADR, IMDG, IATA UN2735
(Contd. on page 7)
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
· UN proper shipping name
acc. to OSHA HCS
Reviewed on 04/25/2023
(Contd. of page 6)
· DOT Amines, liquid, corrosive, n.o.s. (N-Aminoethylpiperazine, 1,3Cyclohexanedimethanamine)
· ADR 2735 AMINES, LIQUID, CORROSIVE, N.O.S. (NAMINOETHYLPIPERAZINE, 1,3-Cyclohexanedimethanamine)
· IMDG, IATA AMINES, LIQUID, CORROSIVE, N.O.S. (NAMINOETHYLPIPERAZINE, 1,3-Cyclohexanedimethanamine)
· Transport hazard class(es)
· DOT · Class
· Class
· IMDG, IATA
· Class
· Label
· Packing group
· DOT, ADR, IMDG, IATA III
· Environmental hazards:
· Special marking (ADR): Symbol (fish and tree)
· Special precautions for user Warning: Corrosive substances
· EMS Number: F-A,S-B
· Segregation groups Alkalis
· Stowage Category A
· Stowage Code SW2 Clear of living quarters.
· Transport in bulk according to Annex II of MARPOL73/78 and the IBC Code Not applicable.
· Transport/Additional information:
· ADR
· Excepted quantities (EQ)
Code: E1
Maximum net quantity per inner packaging: 30 ml
Maximum net quantity per outer packaging: 1000 ml
(Contd. on page 8)
Safety Data Sheet
acc. to OSHA HCS
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
· U.S. Domestic Ground Shipments:
· U.S. Domestic Ground Non-Bulk (119 gal or less per container) Shipments:
· Emergency Response Guide (ERG) Number:
· IMDG
· Limited quantities (LQ)
· Excepted quantities (EQ)
· UN "Model Regulation":
15Regulatory information
Reviewed on 04/25/2023
Same as listed for Standard Shipments above.
Same as listed for Standard Shipments above.
Not determine
5L
Code: E1
Maximum net quantity per inner packaging: 30 ml
(Contd. of page 7)
Maximum net quantity per outer packaging: 1000 ml
UN 2735 AMINES, LIQUID, CORROSIVE, N.O.S. (NAMINOETHYLPIPERAZINE, 1,3CYCLOHEXANEDIMETHANAMINE), 8, III
· Safety, health and environmental regulations/legislation specific for the substance or mixture
· Sara
· Section 355 (extremely hazardous substances):
None of the ingredient is listed.
· Section 313 (Specific toxic chemical listings):
This product may contain 1 or more toxic chemicals subject to the reporting requirements of Section 313 of Title III of the Superfund Amendments and Reauthorization Act (SARA) of 1986 and 40 CFR part 372. If so, the chemicals are listed below. None of the ingredients is listed.
· TSCA (Toxic Substances Control Act):
14808-60-7Quartz (SiO2) ACTIVE
2579-20-61,3-Cyclohexanedimethanamine ACTIVE 140-31-82-piperazin-1-ylethylamine ACTIVE 13463-67-7titanium dioxide ACTIVE
· Hazardous Air Pollutants
None of the ingredients is listed.
· Proposition 65
· Chemicals known to the State of California (Prop. 65) to cause cancer: 14808-60-7Quartz (SiO2) 13463-67-7titanium dioxide
· Chemicals known to cause reproductive toxicity for females: None of the ingredients is listed.
· Chemicals known to cause reproductive toxicity for males: None of the ingredients is listed.
· Chemicals known to cause developmental toxicity: None of the ingredients is listed.
· Cancerogenity categories
· EPA (Environmental Protection Agency) None of the ingredients is listed.
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
acc. to OSHA HCS
· TLV (Threshold Limit Value established by ACGIH)
14808-60-7Quartz (SiO2)
13463-67-7titanium dioxide
· MAK (German Maximum Workplace Concentration)
14808-60-7Quartz (SiO2)
13463-67-7titanium dioxide
· NIOSH-Ca (National Institute for Occupational Safety and Health)
14808-60-7Quartz (SiO2)
13463-67-7titanium dioxide
Reviewed on 04/25/2023
(Contd. of page 8)
· GHS label elements The product is classified and labeled according to the Globally Harmonized System (GHS).
· Hazard pictograms
GHS05 GHS07 GHS08
· Signal word Danger
· Hazard-determining components of labeling:
Quartz (SiO2)
1,3-Cyclohexanedimethanamine
2-piperazin-1-ylethylamine titanium dioxide
· Hazard statements
Harmful if swallowed.
Causes severe skin burns and eye damage. May cause an allergic skin reaction.
May cause cancer.
Suspected of damaging fertility or the unborn child.
Causes damage to organs through prolonged or repeated exposure.
Harmful to aquatic life with long lasting effects.
· Precautionary statements
If on skin (or hair): Take off immediately all contaminated clothing. Rinse skin with water/shower. If in eyes: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing. Immediately call a poison center/doctor.
Specific treatment (see on this label).
Store locked up.
Dispose of contents/container in accordance with local/regional/national/international regulations.
· National regulations:
· Water hazard class: Water hazard class 2 (Self-assessment): hazardous for water.
· Chemical safety assessment: A Chemical Safety Assessment has not been carried out.
16Other information
This information is based on our present knowledge. However, this shall not constitute a guarantee for any specific product features and shall not establish a legally valid contractual relationship.
· Department issuing SDS: Environmental, Health & Safety Department
· Contact: Environmental, Health & Safety Manager
· Date of preparation / last revision 04/25/2023 / 1
Printing date 04/25/2023
Trade name:ProAnchor Elite - Part B
· Abbreviations and acronyms:
Reviewed on 04/25/2023
(Contd. of page 9)
ADR: Accord européen sur le transport des marchandises dangereuses par Route (European Agreement concerning the International Carriage of Dangerous Goods by Road)
IMDG: International Maritime Code for Dangerous Goods
DOT: US Department of Transportation
IATA: International Air Transport Association
ACGIH: American Conference of Governmental Industrial Hygienists
EINECS: European Inventory of Existing Commercial Chemical Substances
ELINCS: European List of Notified Chemical Substances
CAS: Chemical Abstracts Service (division of the American Chemical Society)
NFPA: National Fire Protection Association (USA)
HMIS: Hazardous Materials Identification System (USA)
LC50: Lethal concentration, 50 percent
LD50: Lethal dose, 50 percent
PBT: Persistent, Bioaccumulative and Toxic
vPvB: very Persistent and very Bioaccumulative
NIOSH: National Institute for Occupational Safety
OSHA: Occupational Safety & Health
TLV: Threshold Limit Value
PEL: Permissible Exposure Limit
REL: Recommended Exposure Limit
Acute Tox. 4: Acute toxicity – Category 4
Skin Corr. 1B: Skin corrosion/irritation – Category 1B
Skin Sens. 1: Skin sensitisation – Category 1
Carc. 1A: Carcinogenicity – Category 1A
Repr. 2: Reproductive toxicity – Category 2
STOT RE 1: Specific target organ toxicity (repeated exposure) – Category 1
Aquatic Chronic 3: Hazardous to the aquatic environment - long-term aquatic hazard – Category 3
