SCHNITTPLAN TEMPLATE
Datenformat Data format 20 mm Überfüller 20 mm bleed
Endformat/Rahmenformat Final format/Frame format Sicherheitsabstand Safety distance 70 mm Sicherheitsabstand zum Endformat 70 mm safety distance from the final format
Bei durchgehenden Sujets über mehrere Rahmen die Grafikdatei unbedingt im Ganzen anlegen. In the case of continuous graphics over several frames, it is essential to create the graphic file as a whole.
Hinweis zur Konfektionierung der Gummilippe: Bei der Konfektion ist unbedingt darauf zu achten, dass die Gummilippe auf der Seite des Druckmotivs angenäht wird. Note on the finishing of the rubber lip: During finishing, it is essential to ensure that the rubber lip is sewn on the side of the printed image.
Rahmenformat Breite: 1000 mm Frame format width: 1000 mm Endformat/Rahmenformat Datenformat inkl. 20 mm Überfüller Final format/Frame format Data format incl. 20 mm bleed 1000 x 2000 mm 1000 x 2500 mm 1000 x 3000 mm
1040 x 2040 mm 1040 x 2540 mm 1040 x 3040 mm
