Exam Control Room Smart Security System using Arduino K. SRIHARI RAO1, M.RAVI2, U.HEMA LATHA3,T.BHANU KRISHNAVENI4 , S.NAGA MASTAN SRIHARSHA5, N.MANIKYA RAO6 1 Associate professor, Department of Electronics and Communication Engineering, Nri institute of technology,
Perecherla, Andhra Pradesh,India
2 Associate professor, Department of Electronics and Communication Engineering, Nri institute of technology,
Perecherla, Andhra Pradesh,India Department of Electronics and Communication Engineering, Nri institute of technology, Perecherla, Andhra Pradesh,India ---------------------------------------------------------------------***--------------------------------------------------------------------2. LITERATURE REVIEW Abstract - The implementation of a smart security system 3 UG Students,
using the RC522 RFID module in an exam control room offers a technologically advanced solution for ensuring the integrity and confidentiality of examination processes. This paper presents the design, development, and deployment of such a system, which leverages RFID technology for secure access control and monitoring within the exam control room. By integrating the RC522 RFID module with a comprehensive security infrastructure, including cameras, alarms, and centralized monitoring software, the system enables efficient management of exam-related activities while preventing unauthorized access and malpractice. This paper discusses the key components, functionalities, and benefits of the smart security system, as well as its potential applications in educational institutions and examination centers.
This document provides detailed information on the "Door Lock System," which allows us to unlock the door using a predetermined password. This solution allows the user to reset or modify their password in the event that they forget both of them. An infrared sensor has been employed in this proposed study to raise the security level. This study presents a password-protected door lock with an LEDbased resistive screen input panel that senses changes in light intensity reflected by the finger and emitted by surrounding red LEDs. The photo diode records this variation in light intensity. Because Arduino is easier to interface with, it has been used in this suggested article. After working on a component of the project that involved using ARDUINO and ultrasonic sensors, it was discovered that this concept is widely searched for and considered to be cutting edge. The innovations that were used were not only reliable and fruitful, but also financially feasible. Not only that, but additional really helpful uses for ultrasonic sensors were also noted here. This project describes a monitoring system that uses an Arduino microcontroller to measure the height of a river and the pace of its waves through the use of an ultrasonic sensor. The event known as a flood or surge occurs when all of the water submerges beneath land due to a waterway's inability to handle the volume of water. By measuring the water's height beforehand and keeping an eye on its velocity, we can solve the flooding issue. We can solve an issue before it becomes a crisis if we recognize it early.
Key Words: Arduino , RC522, Leds, Lock, ID cards, LCD
1.INTRODUCTION Exam control rooms are crucial spaces where strict adherence to the security and integrity of examination procedures is required. The efficiency and effectiveness of traditional security measures, including physical locks and surveillance cameras, in preventing illegal entry and malpractice are limited. As a result, creative solutions that make use of cutting-edge technology are becoming more and more necessary to improve test security and reduce administrative load. The RC522 RFID module is the primary component used by the proposed smart security system for monitoring and access control in the exam control room. Contactless operation, excellent security, and simplicity of connection with current infrastructure are just a few benefits of RFID technology. The method minimizes the danger of malpractice and security breaches by limiting access to the control room to only authorized staff, such as exam invigilators and administrators, who are issued RFID-enabled identity cards.
