Women And Child Security System Hanish Kandoi1, Harsh Anand2, Kanishk Aswal3, Mrs. Supriya Sharma4 1,2,3Electrical & Electronics Engg., Maharaja Agrasen Institute of Technology, Delhi-110086
4Professor, Electrical & Electronics Engg., Maharaja Agrasen Institute of Technology, Delhi-110086
---------------------------------------------------------------------***---------------------------------------------------------------------
Abstract - Despite the cultural norms of deification and
this project. The development of satellite technology helped in the locations of an object primarily used in automobiles and vehicles. The GPS used in the cars and public services helps to eliminate so may accidents. The GPS/GSM technology is a versatile system in today’s world it has wide range of applications in the land construction and transport business and so more. We have created a system using the Arduino based GPS and GSM module. Which work as the GPS trace the current location while GSM send message to the numbers saved in the receiver or to the system, as it acts as the emergency number saved in it. The notion behind this to be the user friendly for both children and women, its use case in children scenario is just like if the children of age around (5-6 years) roaming in the area somewhat a distant more than range prescribed in the given invention than it will send the message to their parents which will notify by the coordinates send by the GPS to that particular number. This evolving world has created so many threats to the women on and offline world, the sheer threat to their life in online world through cyberbullying, cyberstalking and body shaming. The technology we have if anyone try to harass a women and children then they can press the button which also the panic button attached to the device that there it generates a signal in the form of 0 and 1 and then it goes to the microcontroller and it’s connected to pins of that and then it gives you latitude and longitude. It also uses a programming language to code the locations and interfacing the components with each other, this gives the slight contribution to protect the women and child from the crimes taking place in the world.
religious tolerance towards women, children are still at risk in India's 21st century due to the prevalence of violent crimes against women. As violence against women and children is on the rise, technology and the safety of women and children must be a priority in society. Many crimes like murder, rape, assault, and sexual assault in the workplace or anywhere in the world have come to light and some of the incidents in India are not recorded or suppressed, some of the witnesses have been politically motivated or forced. Seeing this abuse of women and children disturbs us and compels us to do something to save their safety. Therefore, in this project, we are changing the concept of empowering women and children with the help of technical tools that use Arduino, GPS, and GSM to ensure their safety. The system's features include an emergency button, buzzer, GPS location tracking, GSM communication, and LCD visual aids. Users can press the panic button when an accident or emergency arises and create a quick response mechanism. The system has a buzzer that sends alerts and GPS coordinates via SMS using your smart emergency contacts' GPS and GSM functions, set to the latitude and longitude of that location. This tool is used for self-defense and can reduce crime rates by providing real and adequate safety for women and children. This project aims to save women and children. Key Words: Arduino, GPS, GSM, Buzzer, Women and Child Security System
1. INTRODUCTION In today’s era, women continue to grapple with the feelings of insecurity when stepping out of their homes due to alarming increase in crimes such as harassment, abuse and violence in our country. India in last few decades progressing to be the superpower in the world. With the IT advancements thriving the huge workforce is molding the country. The women are the essential part of it, but there remains the fear of unknown in women’s mind those who particularly works in night shifts. India’s superpower is their youth and so the children is the future. And many crimes take place against children too like kidnapping and the child labor and trafficking of them. According to the annual reports of National Crime Record Bureau (NCRB) there was a spike of over 4.45 lakh crime atrocities takes place against women which is around one in every 51 minutes. The Delhi “Nirbhaya” case that triggered the whole nation was the greatest motivation for
© 2024, IRJET
|
Impact Factor value: 8.226
2. LITERATURE SURVEY In this project we are addressing the crisis confronting by the women and child. The security system comprises of the microcontroller ATmega328P, GPS and GSM technology and the Arduino here is easily accessible to the different components used in this project and it is compatible with the different components. The Arduino AT mega 328P is a general-purpose microcontroller that is at the heart of electronics projects due to its simplicity, flexibility, and reliability. By using this Arduino, it helps the developers to program for this project By Arduino IDE. It requires the knowledge of C programming to implement those functions and the microcontroller must be connected to some sort of hardware for programming. We can use a USB serial port there, it provides an interface
|
