DOWNLOAD PDF Volkswagen Jetta 2014 onward to 2022 Wiring Diagrams Manual

Jetta Rusia

Basic equipment, Low (AW0)

From June 2011

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen AGdoesnotguaranteeoracceptanyliabilitywith respect

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Fuse 1 in fuse holder A, Fuse 4 in fuse holder A, Fuse holder B

A Battery

C Alternator

J519 Onboard supply control unit

SA1 Fuse 1 in fuse holder A

SA4 Fuse 4 in fuse holder A

SB Fuse holder B

SB10 Fuse 10 on fuse holder B

SB19 Fuse 19 on fuse holder B

SB20 Fuse 20 on fuse holder B

SB25 Fuse 25 on fuse holder B

SB30 Fuse 30 on fuse holder B

T73a 73-pin connector

T73b 73-pin connector

508 Threaded connection (30) on E-box

B111 Positive connection 1 (30a), in interior wiring harness

B218 Positive connection 6 (30), in interior wiring harness

* Up to May 2013

*2 Cross section depends on equipment

*3 According to equipment

= white

= red

= brown

= green

= blue

= grey

purple

= purple

= yellow

= orange

= pink

Jetta Rusia Current Flow Diagram

Ignition/starter switch, Onboard supply control unit, Terminal 50 voltage supply relay, Converter box

B Starter

D Ignition/starter switch

J519 Onboard supply control unit

J682 Terminal 50 voltage supply relay

J935 Converter box

T9c 9-pin connector

T10 10-pin connector

T10i 10-pin connector

T73a 73-pin connector

T73b 73-pin connector

A15 Positive connection (15), in instrument wiring harness

A33 Connection (75), in dash panel wiring harness

A41 Positive connection (50), in dash panel wiring harness

B218 Positive connection 6 (30), in interior wiring harness

B239 Positive connection 1 (50), in interior wiring harness

B346 Connection 1 (75), in main wiring harness

* Up to May 2013

*2 From June 2013

*3 Wiring colour depends on equipment

Jetta Rusia Current Flow Diagram

Terminal 15 voltage supply relay, Onboard supply control unit, Fuse holder C

J329 Terminal 15 voltage supply relay

J519 Onboard supply control unit

J681 Terminal 15 voltage supply relay 2

SC Fuse holder C

SC1 Fuse 1 on fuse holder C

SC10 Fuse 10 on fuse holder C

SC13 Fuse 13 on fuse holder C

SC14 Fuse 14 on fuse holder C

SC15 Fuse 15 on fuse holder C

SC16 Fuse 16 on fuse holder C

SC27 Fuse 27 on fuse holder C

T9f 9-pin connector

T9g 9-pin connector

A201 Positive connection 6 (15a) in dash panel wiring harness

B149 Positive connection 2 (15a), in interior wiring harness

B163 Positive connection 1 (15), in interior wiring harness

B218 Positive connection 6 (30), in interior wiring harness

B346 Connection 1 (75), in main wiring harness

* From June 2013

*2 Cross section depends on equipment

*3 Only models with manual gearbox

*4 Up to May 2013

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Fuse holder C

J519 Onboard supply control unit

SC Fuse holder C

SC3 Fuse 3 on fuse holder C

SC6 Fuse 6 on fuse holder C

SC7 Fuse 7 on fuse holder C

SC8 Fuse 8 on fuse holder C

SC21 Fuse 21 on fuse holder C

SC22 Fuse 22 on fuse holder C

SC23 Fuse 23 on fuse holder C

SC24 Fuse 24 on fuse holder C

SC36 Fuse 36 on fuse holder C

SC39 Fuse 39 on fuse holder C

SC44 Fuse 44 on fuse holder C

SC55 Fuse 55 on fuse holder C T73a 73-pin connector

A1 Positive connection (30a), in dash panel wiring harness

A32 Positive connection (30), in dash panel wiring harness

A167 Positive connection 3 (30a) in dash panel wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

B171 Positive connection 3 (30), in interior wiring harness

B172 Positive connection 4 (30), in interior wiring harness

B219 Positive connection 4 (30a), in interior wiring harness

* From June 2013

*2 Cross section depends on equipment

*3 Wiring colour depends on equipment

Jetta Rusia

Onboard supply control unit, Terminal 75 voltage supply relay 1, Fuse holder C

J519 Onboard supply control unit

J680 Terminal 75 voltage supply relay 1

SC Fuse holder C

SC5 Fuse 5 on fuse holder C

SC18 Fuse 18 on fuse holder C

SC19 Fuse 19 on fuse holder C

SC30 Fuse 30 on fuse holder C

SC31 Fuse 31 on fuse holder C

SC32 Fuse 32 on fuse holder C

SC33 Fuse 33 on fuse holder C

SC34 Fuse 34 on fuse holder C

SC37 Fuse 37 on fuse holder C

SC38 Fuse 38 on fuse holder C

SC54 Fuse 54 on fuse holder C

T9x 9-pin connector

A83 Connection(daytimerunninglights),indashpanelwiringharness

B167 Connection (56b), in interior wiring harness

* Up to June 2012

*2 Only models with daytime running lights

*3 Wiring colour depends on equipment

*4 According to equipment

*5 Only for American markets

*6 Cross section depends on equipment

*7 Only models with rear fog light

*8 From July 2012

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Left fog light bulb, Right fog light bulb, Left side light bulb, Front left headlight, Front left turn signal bulb

J519 Onboard supply control unit

L22 Left fog light bulb

L23 Right fog light bulb

L174 Left daytime running light bulb

M1 Left side light bulb

MX1 Front left headlight

M5 Front left turn signal bulb

M29 Left headlight dipped beam bulb

M30 Left headlight main beam bulb

T2dg 2-pin connector

T2dh 2-pin connector

T10l 10-pin connector

121 Earth connection 2, in front right wiring harness

179 Earth connection, in left headlight wiring harness

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

B142 Positive connection 2 (56a), in interior wiring harness

B522 Connection (FL), in main wiring harness

* According to equipment

*2 Cross section depends on equipment

*3 Only models with daytime running lights

*4 Wiring colour depends on equipment

*5 Only for American markets

Jetta Rusia

Switch and instrument illumination regulator, Onboard supply control unit, Front right headlight, Right side light bulb, Front right turn signal bulb

E20 Switch and instrument illumination regulator

J519 Onboard supply control unit

L76 Button illumination bulb

L175 Right daytime running light bulb

MX2 Front right headlight

M3 Right side light bulb

M7 Front right turn signal bulb

M31 Right headlight dipped beam bulb

M32 Right headlight main beam bulb

T3i 3-pin connector

T10r 10-pin connector

A3 Positive connection (58), in dash panel wiring harness

* Cross section depends on equipment

*2 Only models with daytime running lights

*3 Only for American markets

Jetta Rusia Current Flow Diagram

Lightswitch,Foglightswitch,Rearfoglightswitch,Onboard supply control unit, Fog light warning lamp, Automatic control of lights warning lamp

E1 Light switch

E7 Fog light switch

E18 Rear fog light switch

J519 Onboard supply control unit

K17 Fog light warning lamp

K209 Automatic control of lights warning lamp

L9 Light switch illumination bulb

T17 17-pin connector

T73a 73-pin connector

T73b 73-pin connector

388 Earth connection 23, in main wiring harness

A170 Connection 2 (58R), in dash panel wiring harness

B10 Positive connection (30), in light switch wiring harness

B340 Connection 1 (58d), in main wiring harness

* If fitted

*2 According to equipment

*3 Cross section depends on equipment

*4 Only models with rear fog light

Jetta Rusia

Onboard supply control unit, Rear left fog light bulb, Left tail light, Rear left turn signal bulb, Left brake light bulb, Left reversing light bulb, Right reversing light bulb

J519 Onboard supply control unit

L46 Rear left fog light bulb

M2 Right tail light bulb

MX3 Left tail light

M4 Left tail light bulb

MX5 Left tail light 2

M6 Rear left turn signal bulb

MX6 Right tail light 2

M9 Left brake light bulb

M16 Left reversing light bulb

M17 Right reversing light bulb

T4a 4-pin connector

T4c 4-pin connector

T4d 4-pin connector

T73a 73-pin connector

T73b 73-pin connector

86 Earth connection 1, in rear wiring harness

A6 Positiveconnection(leftturnsignal),indashpanelwiringharness

A84 Connection (58L), in dash panel wiring harness

A88 Connection (RFL), in dash panel wiring harness

* Only models with rear fog light

*2 Only models with no US equipment

Jetta Rusia Current Flow Diagram

Rear lid handle release button, Rear lid lock unit, Onboard supply control unit, Rear lid central locking motor, Number plate light

E234 Rear lid handle release button

F256 Rear lid lock unit

J519 Onboard supply control unit

T2dx 2-pin connector

T2dy 2-pin connector

T2t 2-pin connector

T4u 4-pin connector

T73a 73-pin connector

V53 Rear lid central locking motor

X Number plate light

86 Earth connection 1, in rear wiring harness

437 Earth connection, in number plate wiring harness

662 Earth point, rear left side panel

A126 Connection(rearlidcontactswitch),indashpanelwiringharness

B128 Connection (luggage compartment light), in interior wiring harness

W41 Positive connection (58), in number plate lights wiring harness

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Right tail light, Rear right turn signal bulb, Right brake light bulb, Additional brake light bulb, Tank filler flap locking motor

J519 Onboard supply control unit

M2 Right tail light bulb

MX4 Right tail light

M8 Rear right turn signal bulb

M10 Right brake light bulb

M25 Additional brake light bulb

T2dn 2-pin connector

T2x 2-pin connector

T4b 4-pin connector

T8f 8-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32 32-pin connector

T73a 73-pin connector

T73b 73-pin connector

V56 Driver door central locking motor

V155 Tank filler flap locking motor

87 Earth connection 2, in rear wiring harness

682 Earth point 2, in rear right side panel

A5 Positive connection (right turn signal), in dash panel wiring harness

A85 Connection (58R), in dash panel wiring harness

A89 Connection 2 (54) in dash panel wiring harness

ypocybdetcetorP

B214 Connection 1 (central locking), in interior wiring harness

B216 Connection 3 (central locking), in interior wiring harness

* According to equipment

Jetta Rusia Current Flow Diagram

Reversing light switch, Onboard supply control unit, Driver side turn signal repeater bulb, Front passenger side turn signal repeater bulb

F4 Reversing light switch

J519 Onboard supply control unit

L131 Driver side turn signal repeater bulb

L132 Front passenger side turn signal repeater bulb

T2fi 2-pin connector

T2sl 2-pin connector, in driver side exterior mirror housing

T2sr 2-pin connector

T12b 12-pin connector, in driver door

T12c 12-pin connector, in front passenger door

T28 28-pin connector, lower part of A-pillar, driver side

T28a 28-pin connector, lower part of A-pillar, front passenger side

T32 32-pin connector

T73b 73-pin connector 107 Earth connection, in external mirror wiring harness 205 Earth connection, in driver door wiring harness 206 Earth connection, in front passenger door wiring harness 801 Earth connection 2, in external mirror wiring harness

A217 Positive connection 8 (15a) in dash panel wiring harness

B182 Connection (RL), in interior wiring harness

* According to equipment

*2 Only models with manual gearbox

*3 Up to May 2013

*4 Only models with automatic gearbox

*5 Wiring colour depends on equipment

Jetta Rusia Current Flow Diagram

Turn signal switch, Headlight dipper and flasher switch, Left steering column switch, Cruise control system switch, Cruise control system (CCS) SET button, Onboard supply control unit

E2 Turn signal switch

E4 Headlight dipper and flasher switch

EX19 Left steering column switch

E45 Cruise control system switch

E227 Cruise control system (CCS) SET button

J5 Fog light relay

J331 Dipped beam relay

J519 Onboard supply control unit

J623 Engine control unit

T9h 9-pin connector

T9n 9-pin connector

T16ls 16-pin connector

T73a 73-pin connector

T73b 73-pin connector

A9 Positive connection (56b), in instruments wiring harness

A51 Connection (56), in dash panel wiring harness

B441 Connection (CCS), in main wiring harness

* Only models with cruise control system (CCS)

*2 Only for American markets

*3 According to equipment

*4 Cross section depends on equipment

Jetta Rusia

Intermittent wiper switch, Washer pump switch (automatic wash/wipe and headlight washer system), Airbag coil connector and return ring with slip ring, Onboard supply control unit

EX20 Right steering column switch

E22 Intermittent wiper switch

E38 Intermittent wiper regulator

E44 Washer pump switch (automatic wash/wipe and headlight washer system)

F138 Airbag coil connector and return ring with slip ring

H Horn plate

J234 Airbag control unit

J519 Onboard supply control unit

N95 Driver side airbag igniter

T2bv 2-pin connector

T4k 4-pin connector

T10ls 10-pin connector

T12k 12-pin connector

T16k 16-pin connector

T73a 73-pin connector

T73b 73-pin connector

V5 Washer pump

A156 Connection (53c), in dash panel wiring harness

* According to equipment

*2 Cross section depends on equipment

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia

= red

Airbag coil connector and return ring with slip ring, Steering angle sender, Onboard supply control unit

F138 Airbag coil connector and return ring with slip ring

G85 Steering angle sender

J519 Onboard supply control unit

T16k 16-pin connector

T73a 73-pin connector

T73b 73-pin connector

44 Earth point, lower part of left A-pillar

= pink

367 Earth connection 2, in main wiring harness

368 Earth connection 3, in main wiring harness

386 Earth connection 21, in main wiring harness

605 Earth point, on top end of steering column

B528 Connection 1 (LIN bus) in main wiring harness

* According to equipment

*2 Up to May 2013

*3 From June 2013

Jetta Rusia

Hazard warning lights button, Onboard supply control unit, Indicator lamp for hazard warning light, Windscreen wiper motor, Left washer jet heater element, Right washer jet heater element

E229 Hazard warning lights button

J519 Onboard supply control unit

K6 Indicator lamp for hazard warning light

T2bt 2-pin connector

T2bu 2-pin connector

T4p 4-pin connector

T6c 6-pin connector

T73a 73-pin connector

T73b 73-pin connector

V Windscreen wiper motor

Z20 Left washer jet heater element

Z21 Right washer jet heater element

43 Earth point, lower part of right A-pillar

80 Earth connection 1, in dash panel wiring harness

124 Earth connection, in right side engine compartment wiring harness

366 Earth connection 1, in main wiring harness

C53 Positive connection (x), in heated washer jets wiring harness

* Cross section depends on equipment

*2 Up to May 2013

*3 From June 2013

Jetta Rusia Current Flow Diagram

Bonnet contact switch, Horn or dual tone horn, Onboard supply control unit, Heated rear window

F266 Bonnet contact switch

H1 Horn or dual tone horn

J519 Onboard supply control unit

R178 Frequency modulation (FM) frequency filter in negative wire

R179 Frequency modulation (FM) frequency filter in positive wire

T2di 2-pin connector

T2dj 2-pin connector

T2n 2-pin connector, near headlight

T73a 73-pin connector

T73b 73-pin connector

Z1 Heated rear window

12 Earth point, on left in engine compartment

13 Earth point, on right in engine compartment

108 Earth connection 2, in front left wiring harness

124 Earth connection, in right side engine compartment wiring harness

681 Earth point 1, in rear right side panel

A184 Connection(bonnetcontactswitch),indashpanelwiringharness

B180 Connection (heated rear window), in interior wiring harness

C13 Positive connection in dual tone horn wiring harness

* Only models with dual tone horn

*2 Up to May 2013

*3 Cross section depends on equipment

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Front interior light, Luggage compartment light, Front passenger reading light, Interior light with switch-off delay, Driver side reading light, Left centre reading light, Right centre reading light

J519 Onboard supply control unit

T2aq 2-pin connector

T3am 3-pin connector

T6b 6-pin connector

T73a 73-pin connector

W1 Front interior light

W3 Luggage compartment light

W13 Front passenger reading light

W15 Interior light with switch-off delay

W19 Driver side reading light

W39 Left centre reading light

W40 Right centre reading light

347 Earth connection, in roof wiring harness

B154 Connection 1 (DCt), in interior wiring harness

B250 Positive connection, in roof wiring harness

B552 Positive connection 2, in roof wiring harness

* According to equipment

Jetta Rusia Current Flow Diagram

Glove compartment light switch, Onboard supply control unit, Glove compartment light, Rear left reading light, Rear right reading light, Front passenger side illuminated vanity mirror, Driver side illuminated vanity mirror, Rear interior light

E26 Glove compartment light switch

F147 Driver vanity mirror contact switch

F148 Front passenger vanity mirror contact switch

J519 Onboard supply control unit

T2bi 2-pin connector

T2bj 2-pin connector

T2bk 2-pin connector

T2bl 2-pin connector

T2bp 2-pin connector

T2br 2-pin connector

T3an 3-pin connector

W6 Glove compartment light

W11 Rear left reading light

W12 Rear right reading light

W14 Front passenger side illuminated vanity mirror

W20 Driver side illuminated vanity mirror

W43 Rear interior light

43 Earth point, lower part of right A-pillar

ihtninoitamrof

81 Earth connection 1, in dash panel wiring harness

347 Earth connection, in roof wiring harness

B250 Positive connection, in roof wiring harness

B552 Positive connection 2, in roof wiring harness

* Cross section depends on equipment

Jetta Rusia

Brake light switch, Blocking diode, Onboard supply control unit, Cigarette lighter illumination bulb, Cigarette lighter, 12 V socket

F Brake light switch

J29 Blocking diode, in interior wiring harness

J519 Onboard supply control unit

L28 Cigarette lighter illumination bulb

T3g 3-pin connector

T3h 3-pin connector

T3j 3-pin connector

T4al 4-pin connector

T73a 73-pin connector

U1 Cigarette lighter

U5 12 V socket

U18 12 V socket 2 43 Earth point, lower part of right A-pillar

374 Earth connection 9, in main wiring harness

B131 Connection (54), in interior wiring harness

B348 Connection 1 (75a), in main wiring harness

D196 Connection 2 (87a) in engine prewiring harness

* According to equipment

*2 Only models with dual clutch gearbox (DSG)

*3 Only models with manual gearbox

*4 Up to May 2013

Jetta Rusia

Freshairblowerswitch,Heatercontrolunit,Onboardsupply controlunit,Freshairblowerseriesresistorwithoverheating fuse, Fresh air blower, Fresh air and air recirculation flap control motor

E9 Fresh air blower switch

E16 Heater/heat output switch

E230 Heated rear window button

G143 Potentiometer for air recirculation flap control motor

J162 Heater control unit

J485 Auxiliary heater operation relay

J519 Onboard supply control unit

K10 Heated rear window warning lamp

K114 Fresh air and air recirculation warning lamp

L16 Fresh air regulator illumination bulb

N24 Fresh air blower series resistor with overheating fuse

T2v 2-pin connector

T4f 4-pin connector

T5aa 5-pin connector

T6s 6-pin connector

T10a 10-pin connector, on heater and air conditioner unit

T20c 20-pin connector

T73a 73-pin connector

T73b 73-pin connector

V2 Fresh air blower

V154 Fresh air and air recirculation flap control motor

602 Earth point, in front left footwell

L77 Connection, in fresh air blower wiring harness

L78 Connection 1, in fresh air blower wiring harness

* Only models with auxiliary coolant heater

*2 According to equipment

*3 From June 2013

*4 Up to May 2013

Jetta Rusia

Immobiliser reader coil, Handbrake warning switch, Brake fluid level warning contact, Immobiliser control unit, Onboard supply control unit, Dash panel insert

D2 Immobiliser reader coil

F9 Handbrake warning switch

F34 Brake fluid level warning contact

J285 Control unit in dash panel insert

J362 Immobiliser control unit

J519 Onboard supply control unit

K Dash panel insert

K75 Airbag warning lamp

K132 Electronic power control fault lamp

K155 ESP and TCS warning lamp

K169 Selector lever lock warning lamp

T2ap 2-pin connector

T2bm 2-pin connector

T2w 2-pin connector

T32 32-pin connector

132 Earth connection 3, in engine compartment wiring harness

A199 Positive connection 4 (15a) in dash panel wiring harness

* According to equipment

Jetta Rusia Current Flow Diagram

Front left brake pad wear sender, Onboard supply control unit,Fuelpumpcontrolunit,Dashpanelinsert,Rearfoglight warning lamp

G1 Fuel gauge

G6 Fuel system pressurisation pump

G34 Front left brake pad wear sender

J285 Control unit in dash panel insert

J519 Onboard supply control unit

J538 Fuel pump control unit

K Dash panel insert

K2 Alternator warning lamp

K13 Rear fog light warning lamp

K47 ABS warning lamp

K149 Engine electronics warning lamp

T2bb 2-pin connector

T5b 5-pin connector

T10n 10-pin connector

T32 32-pin connector

389 Earth connection 24, in main wiring harness

B379 Connection 1 (brake pad wear indicator), in main wiring harness

B380 Connection 2 (brake pad wear indicator), in main wiring harness

* see applicable current flow diagram for engine

*2 According to equipment

*3 Only models with no US equipment

Jetta Rusia Current Flow Diagram

Oil pressure switch, Ambient temperature sensor, Coolant shortage indicator sender, Windscreen washer fluid level sender, Onboard supply control unit, Dash panel insert

F1 Oil pressure switch

G17 Ambient temperature sensor

G32 Coolant shortage indicator sender

G33 Windscreen washer fluid level sender

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K Dash panel insert

K31 Cruise control system warning lamp

K65 Left turn signal warning lamp

K94 Right turn signal warning lamp

K161 Electromechanical power steering warning lamp

T2bw 2-pin connector

T2cw 2-pin connector

T2dk 2-pin connector

T14 14-pin connector

T32 32-pin connector

269 Earth connection (sender earth) 1, in dash panel wiring harness

* Cross section depends on equipment

Jetta Rusia

Onboard supply control unit, Dash panel insert

EX20 Right steering column switch

E86 Multifunction display call-up button

E109 Multifunction display memory switch

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K Dash panel insert

K3 Oil pressure warning lamp

K19 Seat belt warning system warning lamp

K28 Coolant temperature and coolant shortage warning lamp

K29 Glow period warning lamp

K32 Brake pad warning lamp

K37 Washer fluid level warning lamp

K38 Oil level warning lamp

K105 Reserve fuel warning lamp

K115 Immobilizer warning lamp

K118 Brake system warning lamp

T10ls 10-pin connector

T32 32-pin connector

* Only models with multifunction display

Jetta Rusia

Onboard supply control unit, Dash panel insert

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K Dash panel insert

K1 Main beam warning lamp

K83 Exhaust emissions warning lamp

K166 Door open warning lamp

K170 Bulb failure warning lamp

K171 Bonnet open warning lamp

K201 Fuel tank flap lock warning lamp

K205 Warning lamp for daytime running lights

K220 Tyre Pressure Loss Indicator warning lamp

T32 32-pin connector

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

Jetta Rusia Current Flow Diagram

Onboard supply control unit

J104 ABS control unit

J234 Airbag control unit

J503 Control unit with display for radio and navigation

J519 Onboard supply control unit

J533 Data bus diagnostic interface

J623 Engine control unit

J743 Mechatronic unit for dual clutch gearbox

T16 16-pin connector

T16d 16-pin connector

T26 26-pin connector

T47 47-pin connector

T73b 73-pin connector

T75 75-pin connector

A76 Connection (K-diagnosis wire), in dash panel wiring harness

B150 Positive connection 2 (30a), in interior wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

B397 Connection 1 (convenience CAN bus, high), in main wiring harness

B406 Connection 1 (convenience CAN bus, low), in main wiring harness

B590 K-diagnosis wire connection, in interior wiring harness

* Diagnostic connection

*2 Only models with automatic gearbox

*3 Only for American markets

Jetta Rusia

Convenience system, Low (AW0)

From June 2011

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG Volkswagen

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia

icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Battery, Fuse 4 in fuse holder A, Fuse holder B, Fuse 25 on fuse holder B, Fuse holder C

A Battery

SA4 Fuse 4 in fuse holder A

SB Fuse holder B

SB25 Fuse 25 on fuse holder B

SC Fuse holder C

SC17 Fuse 17 on fuse holder C

SC36 Fuse 36 on fuse holder C

508 Threaded connection (30) on E-box

B111 Positive connection 1 (30a), in interior wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

B171 Positive connection 3 (30), in interior wiring harness

B218 Positive connection 6 (30), in interior wiring harness

B236 Positive connection 6 (30a), in interior wiring harness

* gradual introduction

Jetta Rusia

Fuse holder C

SC Fuse holder C

SC21 Fuse 21 on fuse holder C

SC22 Fuse 22 on fuse holder C

SC24 Fuse 24 on fuse holder C

SC43 Fuse 43 on fuse holder C

SC45 Fuse 45 on fuse holder C

SC46 Fuse 46 on fuse holder C

SC48 Fuse 48 on fuse holder C

SC51 Fuse 51 on fuse holder C

A1 Positive connection (30a), in dash panel wiring harness

A62 Connection (window regulators), in dash panel wiring harness

A167 Positive connection 3 (30a) in dash panel wiring harness

* Gradually discontinued *2 gradual introduction

Jetta Rusia

Front left window regulator switch, Rear left window regulator switch, in driver door, Rear right window regulator switch, in driver door, Front right window regulator switch in driver door, Childproof lock button, Driver door control unit

E40 Front left window regulator switch

E53 Rear left window regulator switch, in driver door

E55 Rear right window regulator switch, in driver door

E81 Front right window regulator switch in driver door

E318 Childproof lock button

J386 Driver door control unit

K236 Warning light for activated childproof lock

L76 Button illumination bulb

T10f 10-pin connector

T16a 16-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32f 32-pin connector, lower part of A-pillar, driver side

V147 Driver side window regulator motor

89 Earth connection 1, in window regulator wiring harness

Q38 Positive connection 1 (58b), in window regulator wiring harness

* Only models with front and rear window regulators

*2 Only models with childproof locks

*3 According to equipment

Jetta Rusia

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Rear lid remote release button, Driver side interior locking button for central locking system, Driver door control unit, Onboard supply control unit, Button illumination bulb

E233 Rear lid remote release button

E308 Driver side interior locking button for central locking system

J386 Driver door control unit

J519 Onboard supply control unit

K133 Central locking SAFELOCK function warning lamp

L76 Button illumination bulb

T4am 4-pin connector

T4w 4-pin connector

T16a 16-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32f 32-pin connector, lower part of A-pillar, driver side

T73a 73-pin connector

T73b 73-pin connector

89 Earth connection 1, in window regulator wiring harness

B528 Connection 1 (LIN bus) in main wiring harness

Q38 Positive connection 1 (58b), in window regulator wiring harness

* According to equipment

Jetta Rusia Current Flow Diagram

Mirror adjustment switch, Mirror adjustment changeover switch, Exterior mirror heater button, Fold-in mirror switch, Driver door control unit, Onboard supply control unit, Mirror adjustment switch illumination bulb

E43 Mirror adjustment switch

E48 Mirror adjustment changeover switch

E231 Exterior mirror heater button

E263 Fold-in mirror switch

J386 Driver door control unit

J519 Onboard supply control unit

L78 Mirror adjustment switch illumination bulb

T10p 10-pin connector

T16a 16-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32f 32-pin connector, lower part of A-pillar, driver side

T73b 73-pin connector

205 Earth connection, in driver door wiring harness

B231 Positive connection 5 (30a), in interior wiring harness

Q38 Positive connection 1 (58b), in window regulator wiring harness

Z1 Connection 1, in mirror adjustment/heating wiring harness

* According to equipment

Jetta Rusia Current Flow Diagram

Driver door control unit, Onboard supply control unit, Driver side exterior mirror, Driver side mirror adjustment motor

J386 Driver door control unit

J519 Onboard supply control unit

L131 Driver side turn signal repeater bulb

M5 Front left turn signal bulb

T10l 10-pin connector

T12b 12-pin connector, in driver door wiring harness

T16a 16-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32f 32-pin connector, lower part of A-pillar, driver side

T73b 73-pin connector

VX4 Driver side exterior mirror

V17 Driver side mirror adjustment motor

V149 Driver side mirror adjustment motor

Z4 Heated exterior mirror on driver side

44 Earth point, lower part of left A-pillar

107 Earth connection, in external mirror wiring harness, in left door, near exterior mirror

205 Earth connection, in driver door wiring harness

386 Earth connection 21, in main wiring harness

A6 Positiveconnection(leftturnsignal),indashpanelwiringharness

* According to equipment

*2 Wiring colour depends on equipment

Jetta Rusia

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Driver door contact switch, Driver side central locking lock unit,Onboardsupplycontrolunit,Driverdoorcentrallocking motor

F2 Driver door contact switch

F220 Driver side central locking lock unit

J519 Onboard supply control unit

T8f 8-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32f 32-pin connector, lower part of A-pillar, driver side

T73a 73-pin connector

V56 Driver door central locking motor

205 Earth connection, in driver door wiring harness

* According to equipment

Jetta Rusia

Window regulator switch in front passenger door, Front passenger door contact switch, Front passenger side central locking lock unit, Front passenger door control unit, Onboard supply control unit, Front passenger seat central lockingmotor,Frontpassengersidewindowregulatormotor

E107 Window regulator switch in front passenger door

F3 Front passenger door contact switch

F221 Front passenger side central locking lock unit

J387 Front passenger door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4ak 4-pin connector

T8h 8-pin connector

T16b 16-pin connector

T28a 28-pin connector, lower part of A-pillar, front passenger side

T73a 73-pin connector

T73b 73-pin connector

V57 Front passenger seat central locking motor

V148 Front passenger side window regulator motor

206 Earth connection, in front passenger door wiring harness

Jetta Rusia

AGdoesnotguaranteeoracceptanyliabilitywi

icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Front passenger side interior locking button for central locking system, Onboard supply control unit, Front passenger side turn signal repeater bulb, Front passenger side exterior mirror

E309 Front passenger side interior locking button for central locking system

J519 Onboard supply control unit

L76 Button illumination bulb

L132 Front passenger side turn signal repeater bulb

M7 Front right turn signal bulb

T4an 4-pin connector

T10r 10-pin connector

T12c 12-pin connector, in front passenger door

T28a 28-pin connector, lower part of A-pillar, front passenger side

T73a 73-pin connector

T73b 73-pin connector

VX5 Front passenger side exterior mirror

V25 Front passenger side mirror adjustment motor

V150 Front passenger side mirror adjustment motor

Z5 Heated exterior mirror on front passenger side

206 Earth connection, in front passenger door wiring harness

801 Earth connection 2, in external mirror wiring harness, in right door, near exterior mirror

A5 Positive connection (right turn signal), in dash panel wiring harness

A63 Connection (mirror adjustment/heating), in dash panel wiring harness

B720 Connection 1 (central locking), in main wiring harness

B721 Connection 2 (central locking), in main wiring harness

Q39 Positive connection 2 (58b), in window regulator wiring harness

* Wiring colour depends on equipment

Jetta Rusia Current Flow Diagram

Rear lid handle release button, Rear central switch for interior locking, Rear lid lock unit, Onboard supply control unit, Rear lid central locking motor

E234 Rear lid handle release button

E286 Rear central switch for interior locking

F256 Rear lid lock unit

J519 Onboard supply control unit

L76 Button illumination bulb

T2t 2-pin connector

T4bz 4-pin connector

T4u 4-pin connector

T73a 73-pin connector

V53 Rear lid central locking motor

43 Earth point, lower part of right A-pillar 86 Earth connection 1, in rear wiring harness

366 Earth connection 1, in main wiring harness

388 Earth connection 23, in main wiring harness

662 Earth point, rear left side panel

A126 Connection(rearlidcontactswitch),indashpanelwiringharness

B128 Connection (luggage compartment light), in interior wiring harness

B720 Connection 1 (central locking), in main wiring harness

B721 Connection 2 (central locking), in main wiring harness

* Wiring colour depends on equipment

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Tank filler flap locking motor, Luggage compartment light

H18 Alarm system horn

J519 Onboard supply control unit

J641 Alarm horn relay

T2ah 2-pin connector

T2aq 2-pin connector

T2x 2-pin connector

T5ah 5-pin connector

T73a 73-pin connector

V155 Tank filler flap locking motor

W3 Luggage compartment light

Earth connection 2, in main wiring harness

Earth connection 24, in main wiring harness

605 Earth point, on top end of steering column

A32 Positive connection (30), in dash panel wiring harness

B128 Connection (luggage compartment light), in interior wiring harness

B216 Connection 3 (central locking), in interior wiring harness

B250 Positive connection, in roof wiring harness

* Gradually discontinued

*2 Wiring colour depends on equipment

*3 gradual introduction

Jetta Rusia

Rear left window regulator switch, in door, Rear left door control unit, Onboard supply control unit, Rear left window regulator motor

E52 Rear left window regulator switch, in door

J388 Rear left door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4aq 4-pin connector

T16h 16-pin connector

T28b 28-pin connector, on left B-pillar

V26 Rear left window regulator motor

207 Earth connection, in rear left door wiring harness

Jetta Rusia Current Flow Diagram

0.5

Rear left door contact switch, Rear left central locking lock unit, Onboard supply control unit, Rear left door central locking motor, lock

E1 Light switch

F10 Rear left door contact switch

F222 Rear left central locking lock unit

J519 Onboard supply control unit

T8s 8-pin connector

T10h 10-pin connector

T28b 28-pin connector, on left B-pillar

T73a 73-pin connector

T73b 73-pin connector

V214 Rear left door central locking motor, lock

207 Earth connection, in rear left door wiring harness

B340 Connection 1 (58d), in main wiring harness

Jetta Rusia

Rear right window regulator switch, in door, Rear right door control unit, Onboard supply control unit, Rear right window regulator motor

E54 Rear right window regulator switch, in door

J389 Rear right door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4ar 4-pin connector

T16i 16-pin connector

T28c 28-pin connector, on right B-pillar

V27 Rear right window regulator motor

grey

purple

purple

= yellow

orange

= pink

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia Current Flow Diagram

Rear right door contact switch, Rear right central locking lock unit, Rear right door control unit, Onboard supply control unit, Rear right door central locking motor, lock

F11 Rear right door contact switch

F223 Rear right central locking lock unit

J389 Rear right door control unit

J519 Onboard supply control unit

T8t 8-pin connector

T16i 16-pin connector

T28c 28-pin connector, on right B-pillar

T73a 73-pin connector

V215 Rear right door central locking motor, lock

43 Earth point, lower part of right A-pillar

81 Earth connection 1, in dash panel wiring harness

208 Earth connection, in rear right door wiring harness

B214 Connection 1 (central locking), in interior wiring harness

B215 Connection 2 (central locking), in interior wiring harness

orange

Jetta Rusia

Slidingsunroofadjustmentregulator,Button1fortiltingroof, Bonnet contact switch, Sliding sunroof adjustment control unit, Onboard supply control unit, Sliding sunroof motor

E139 Sliding sunroof adjustment regulator

E582 Button 1 for tilting roof

F34 Brake fluid level warning contact

F266 Bonnet contact switch

J245 Sliding sunroof adjustment control unit

J519 Onboard supply control unit

T2ap 2-pin connector

T2n 2-pin connector

T4ad 4-pin connector

T10e 10-pin connector

T73a 73-pin connector

T73b 73-pin connector

V1 Sliding sunroof motor 132 Earth connection 3, in engine compartment wiring harness

167 Earth connection 4, in engine compartment wiring harness

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

A184 Connection(bonnetcontactswitch),indashpanelwiringharness

Jetta Rusia Current Flow Diagram

Terminal 15 voltage supply relay, Onboard supply control unit, Data bus diagnostic interface, Terminal 15 voltage supply relay 2, Automatic anti-dazzle interior mirror

J329 Terminal 15 voltage supply relay

J519 Onboard supply control unit

J533 Data bus diagnostic interface

J681 Terminal 15 voltage supply relay 2

J935 Converter box

M17 Right reversing light bulb

SC13 Fuse 13 on fuse holder C

T4d 4-pin connector

T6d 6-pin connector

T9f 9-pin connector

T9g 9-pin connector

T10i 10-pin connector

T16 16-pin connector

T73b 73-pin connector

Y7 Automatic anti-dazzle interior mirror

347 Earth connection, in roof wiring harness

A87 Connection (RL), in dash panel wiring harness

A217 Positive connection 8 (15a) in dash panel wiring harness

B163 Positive connection 1 (15), in interior wiring harness

* Diagnostic connection

Basic equipment, High (AW1)

From June 2011

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Jetta Rusia

Wiper motor switch-over relay 1, Wiper motor switch-over relay 2, Onboard supply control unit, Fuse 1 in fuse holder A, Fuse 4 in fuse holder A, Fuse holder B

A Battery

C Alternator

J368 Wiper motor switch-over relay 1

J369 Wiper motor switch-over relay 2

J519 Onboard supply control unit

SA1 Fuse 1 in fuse holder A

SA4 Fuse 4 in fuse holder A

SB Fuse holder B

SB19 Fuse 19 on fuse holder B

SB28 Fuse 28 on fuse holder B

SB29 Fuse 29 on fuse holder B

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

12 Earth point, on left in engine compartment

108 Earth connection 2, in front left wiring harness

508 Threaded connection (30) on E-box

B111 Positive connection 1 (30a), in interior wiring harness

B316 Positive connection 2 (30a) in main wiring harness

B684 Positive connection 24 (30a) in main wiring harness

Jetta Rusia

Onboard supply control unit, Terminal 15 voltage supply relay 2, Fuse holder B, Fuse holder C

J234 Airbag control unit

J519 Onboard supply control unit

J681 Terminal 15 voltage supply relay 2

J682 Terminal 50 voltage supply relay

K145 Front passenger side airbag deactivated warning lamp

SB Fuse holder B

SB10 Fuse 10 on fuse holder B

SB20 Fuse 20 on fuse holder B

SB25 Fuse 25 on fuse holder B

SB30 Fuse 30 on fuse holder B

SC Fuse holder C

SC9 Fuse 9 on fuse holder C

SC14 Fuse 14 on fuse holder C

SC15 Fuse 15 on fuse holder C

SC16 Fuse 16 on fuse holder C

T9c 9-pin connector

T9f 9-pin connector

T52b 52-pin connector

T75 75-pin connector

A200 Positive connection 5 (15a) in dash panel wiring harness

A217 Positive connection 8 (15a) in dash panel wiring harness

B163 Positive connection 1 (15), in interior wiring harness

B316 Positive connection 2 (30a) in main wiring harness

Jetta Rusia

Onboard supply control unit, Fuse holder C

J519 Onboard supply control unit

SC Fuse holder C

SC1 Fuse 1 on fuse holder C

SC3 Fuse 3 on fuse holder C

SC13 Fuse 13 on fuse holder C

SC20 Fuse 20 on fuse holder C

SC21 Fuse 21 on fuse holder C

SC22 Fuse 22 on fuse holder C

SC23 Fuse 23 on fuse holder C

SC35 Fuse 35 on fuse holder C

SC36 Fuse 36 on fuse holder C

T52b 52-pin connector

T52c 52-pin connector

A32 Positive connection (30), in dash panel wiring harness

A189 Positive connection 5 (30a) in dash panel wiring harness

A217 Positive connection 8 (15a) in dash panel wiring harness

B163 Positive connection 1 (15), in interior wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

B171 Positive connection 3 (30), in interior wiring harness

B172 Positive connection 4 (30), in interior wiring harness

B315 Positive connection 1 (30a) in main wiring harness

* Up to May 2013

*2 Cross section depends on equipment

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Terminal 75 voltage supply

relay 1, Right fog light bulb, Right cornering light bulb, Fuse holder C

J245 Sliding sunroof adjustment control unit

J519 Onboard supply control unit

J680 Terminal 75 voltage supply relay 1

L23 Right fog light bulb

L149 Right cornering light bulb

SC Fuse holder C

SC30 Fuse 30 on fuse holder C

SC33 Fuse 33 on fuse holder C

SC44 Fuse 44 on fuse holder C

SC51 Fuse 51 on fuse holder C

SC58 Fuse 58 on fuse holder C

T2dh 2-pin connector

T9x 9-pin connector

T10e 10-pin connector

T52b 52-pin connector

T52c 52-pin connector

121 Earth connection 2, in front right wiring harness

B219 Positive connection 4 (30a), in interior wiring harness

B554 Connection (fog light), in main wiring harness

* Cross section depends on equipment

*2 Only models with dual tone horn

*3 Only models with dual clutch gearbox (DSG)

*4 Up to May 2013

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Left fog light bulb, Left corneringlightbulb,Leftdaytimerunninglightbulb,Leftside lightbulb,Frontleftheadlight,Frontleftturnsignalbulb,Left headlight range control motor

J519 Onboard supply control unit

L22 Left fog light bulb

L148 Left cornering light bulb

L174 Left daytime running light bulb

M1 Left side light bulb

MX1 Front left headlight

M5 Front left turn signal bulb

M29 Left headlight dipped beam bulb

M30 Left headlight main beam bulb

T2dg 2-pin connector

T10l 10-pin connector

T52a 52-pin connector

T52c 52-pin connector

V48 Left headlight range control motor

179 Earth connection, in left headlight wiring harness

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

B522 Connection (FL), in main wiring harness

* According to equipment

*2 Up to May 2013

*3 Cross section depends on equipment

*4 From June 2013

Jetta Rusia

icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Switch and instrument illumination regulator, Headlight range control regulator, Onboard supply control unit, Front right headlight, Right side light bulb, Front right turn signal bulb, Right headlight range control motor

E20 Switch and instrument illumination regulator

E102 Headlight range control regulator

J519 Onboard supply control unit

L76 Button illumination bulb

L175 Right daytime running light bulb

MX2 Front right headlight

M3 Right side light bulb

M7 Front right turn signal bulb

M31 Right headlight dipped beam bulb

M32 Right headlight main beam bulb

T8e 8-pin connector

T10r 10-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

V49 Right headlight range control motor

B149 Positive connection 2 (15a), in interior wiring harness

B457 Connection 1 (potentiometer), in main wiring harness

* According to equipment

*2 From July 2012

*3 Wiring colour depends on equipment

*4 Up to May 2013

*5 Cross section depends on equipment

*6 Only models with auxiliary coolant heater

*7 From June 2013

Jetta Rusia Current Flow Diagram

Lightswitch,Foglightswitch,Rearfoglightswitch,Onboard supply control unit, Fog light warning lamp, Automatic control of lights warning lamp

E1 Light switch

E7 Fog light switch

E18 Rear fog light switch

J519 Onboard supply control unit

K17 Fog light warning lamp

K209 Automatic control of lights warning lamp

L9 Light switch illumination bulb

T10h 10-pin connector

T52a 52-pin connector

T52b 52-pin connector

388 Earth connection 23, in main wiring harness

B150 Positive connection 2 (30a), in interior wiring harness

B340 Connection 1 (58d), in main wiring harness

* According to equipment

*2 If fitted

*3 From July 2012

*4 Cross section depends on equipment

*5 Up to June 2012

*6 Wiring colour depends on equipment

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Rear left fog light bulb, Right tail light bulb, Left tail light, Left tail light bulb, Rear left turn signal bulb, Left brake light bulb, Right reversing light bulb

J519 Onboard supply control unit

L46 Rear left fog light bulb

M2 Right tail light bulb

MX3 Left tail light

M4 Left tail light bulb

MX5 Left tail light 2

M6 Rear left turn signal bulb

MX6 Right tail light 2

M9 Left brake light bulb

M16 Left reversing light bulb

M17 Right reversing light bulb

T4a 4-pin connector

T4c 4-pin connector

T4d 4-pin connector

T52a 52-pin connector

T52c 52-pin connector

86 Earth connection 1, in rear wiring harness

A6 Positiveconnection(leftturnsignal),indashpanelwiringharness

A84 Connection (58L), in dash panel wiring harness

A87 Connection (RL), in dash panel wiring harness

Jetta Rusia Current Flow Diagram

Rear lid handle release button, Rear lid lock unit, Onboard supply control unit, Rear lid central locking motor, Number plate light

E234 Rear lid handle release button

F256 Rear lid lock unit

J519 Onboard supply control unit

T2dx 2-pin connector

T2dy 2-pin connector

T2t 2-pin connector

T4u 4-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

V53 Rear lid central locking motor

X Number plate light

86 Earth connection 1, in rear wiring harness

437 Earth connection, in number plate wiring harness

662 Earth point, rear left side panel

B128 Connection (luggage compartment light), in interior wiring harness

W41 Positive connection (58), in number plate lights wiring harness

* Cross section depends on equipment

*2 According to equipment

Jetta Rusia Current Flow Diagram

Brake light switch, Onboard supply control unit, Right tail light, Rear right turn signal bulb, Right brake light bulb, Additional brake light bulb

F Brake light switch

J519 Onboard supply control unit

M2 Right tail light bulb

MX4 Right tail light

M8 Rear right turn signal bulb

M10 Right brake light bulb

M25 Additional brake light bulb

T2bv 2-pin connector

T2dn 2-pin connector

T4al 4-pin connector

T4b 4-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

V5 Washer pump

87 Earth connection 2, in rear wiring harness

682 Earth point 2, in rear right side panel

A5 Positive connection (right turn signal), in dash panel wiring harness

A85 Connection (58R), in dash panel wiring harness

A201 Positive connection 6 (15a) in dash panel wiring harness

B131 Connection (54), in interior wiring harness

D196 Connection 2 (87a) in engine prewiring harness

* According to equipment

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia Current Flow Diagram

Reversing light switch, Driver door control unit, Front passenger door control unit, Onboard supply control unit, Driver side turn signal repeater bulb, Front passenger side turn signal repeater bulb, Tank filler flap locking motor

F4 Reversing light switch

J386 Driver door control unit

J387 Front passenger door control unit

J519 Onboard supply control unit

L131 Driver side turn signal repeater bulb

L132 Front passenger side turn signal repeater bulb

T2fi 2-pin connector

T2sl 2-pin connector, in driver side exterior mirror housing

T2sr 2-pin connector

T2x 2-pin connector

T16a 16-pin connector

T16d 16-pin connector

T20a 20-pin connector

T20b 20-pin connector

T28 28-pin connector

T28a 28-pin connector, near lower part of right A-pillar

T52a 52-pin connector

T52b 52-pin connector

V155 Tank filler flap locking motor

107 Earth connection, in external mirror wiring harness

801 Earth connection 2, in external mirror wiring harness

B182 Connection (RL), in interior wiring harness

* According to equipment

*2 Only models with no US equipment

Jetta Rusia

Right steering column switch, Intermittent wiper switch, Intermittent wiper regulator, Washer pump switch (automatic wash/wipe and headlight washer system), Onboard supply control unit, Steering column electronics control unit

EX20 Right steering column switch

E22 Intermittent wiper switch

E38 Intermittent wiper regulator

E44 Washer pump switch (automatic wash/wipe and headlight washer system)

F189 Tiptronic switch

J519 Onboard supply control unit

J527 Steering column electronics control unit

J623 Engine control unit

T10s 10-pin connector

T16l 16-pin connector

purple

orange

= pink

B114 Connection (inhibitor switch), in interior wiring harness

B441 Connection (CCS), in main wiring harness

Jetta Rusia

Ignition/starter switch, Turn signal switch, Headlight dipper and flasher switch, Left steering column switch, Cruise control system switch, Cruise control system (CCS) SET button, Onboard supply control unit, Steering column electronics control unit

D Ignition/starter switch

E2 Turn signal switch

E4 Headlight dipper and flasher switch

EX19 Left steering column switch

E45 Cruise control system switch

E227 Cruise control system (CCS) SET button

J519 Onboard supply control unit

J527 Steering column electronics control unit

N376 Ignition key withdrawal lock solenoid

T12j 12-pin connector

* Only models with cruise control system (CCS)

*2 Only models with dual clutch gearbox (DSG)

*3 Wiring colour depends on equipment

*4 Cross section depends on equipment

*5 According to equipment

*6 Up to May 2013

Jetta Rusia Current Flow Diagram

Airbag coil connector and return ring with slip ring, Onboard supply control unit, Steering column electronics control unit

F138 Airbag coil connector and return ring with slip ring

H Horn plate

J234 Airbag control unit

J453 Multifunction steering wheel control unit

J519 Onboard supply control unit

J527 Steering column electronics control unit

T4k 4-pin connector

T12k 12-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

T75 75-pin connector

44 Earth point, lower part of left A-pillar

367 Earth connection 2, in main wiring harness

605 Earth point, on top end of steering column

* see applicable current flow diagram for airbag

*2 see applicable current flow diagram for multifunction steering wheel

*3 Wiring colour depends on equipment

*4 Cross section depends on equipment

Jetta Rusia Current Flow Diagram

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Glove compartment light switch, Bonnet contact switch, Onboard supply control unit, Windscreen wiper motor, Glove compartment light, Left washer jet heater element, Right washer jet heater element

E26 Glove compartment light switch

F266 Bonnet contact switch

G397 Rain and light sensor

J519 Onboard supply control unit

T2bp 2-pin connector

T2br 2-pin connector

T2bt 2-pin connector

T2bu 2-pin connector

T2n 2-pin connector, near headlight

T3ae 3-pin connector

T4p 4-pin connector

T52a 52-pin connector

T52b 52-pin connector

V Windscreen wiper motor

W6 Glove compartment light

Z20 Left washer jet heater element

Z21 Right washer jet heater element

80 Earth connection 1, in dash panel wiring harness

124 Earth connection, in right side engine compartment wiring harness

A184 Connection(bonnetcontactswitch),indashpanelwiringharness

C53 Positive connection (x), in heated washer jets wiring harness

* Up to May 2013

Jetta Rusia

Horn or dual tone horn, Dual tone horn relay, Heated rear window relay, Onboard supply control unit, Frequency modulation(FM)frequencyfilterinnegativewire,Frequency modulation (FM) frequency filter in positive wire, Heated rear window

H1 Horn or dual tone horn

J4 Dual tone horn relay

J9 Heated rear window relay

J519 Onboard supply control unit

R178 Frequency modulation (FM) frequency filter in negative wire

R179 Frequency modulation (FM) frequency filter in positive wire

T2di 2-pin connector

T2dj 2-pin connector

T5c 5-pin connector

T5f 5-pin connector

T52b 52-pin connector

Z1 Heated rear window

13 Earth point, on right in engine compartment

124 Earth connection, in right side engine compartment wiring harness

681 Earth point 1, in rear right side panel

A198 Positive connection 6 (30a) in dash panel wiring harness

B180 Connection (heated rear window), in interior wiring harness

C13 Positive connection in dual tone horn wiring harness

* Only models with dual tone horn

*2 Only models with multifunction steering wheel

*3 Only models with dual clutch gearbox (DSG)

Jetta Rusia Current Flow Diagram

Onboard supply control unit, Front interior light, Luggage compartment light, Right centre reading light, Automatic anti-dazzle interior mirror

J519 Onboard supply control unit

T2aq 2-pin connector

T6b 6-pin connector

T6d 6-pin connector

T52b 52-pin connector

T52c 52-pin connector

W1 Front interior light

W3 Luggage compartment light

W39 Left centre reading light

W40 Right centre reading light Y7 Automatic anti-dazzle interior mirror

347 Earth connection, in roof wiring harness

B154 Connection 1 (DCt), in interior wiring harness

B250 Positive connection, in roof wiring harness

B552 Positive connection 2, in roof wiring harness

* Up to May 2013

*2 From June 2013

Jetta Rusia Current Flow Diagram

Hazard warning lights button, Onboard supply control unit, Front passenger side illuminated vanity mirror, Driver side illuminated vanity mirror, Rear interior light

E229 Hazard warning lights button

F147 Driver vanity mirror contact switch

F148 Front passenger vanity mirror contact switch

J519 Onboard supply control unit

K6 Indicator lamp for hazard warning light

T2bi 2-pin connector

T2bj 2-pin connector

T2bk 2-pin connector

T2bl 2-pin connector

T3an 3-pin connector

T6c 6-pin connector

T52b 52-pin connector

T52c 52-pin connector

W11 Rear left reading light

W12 Rear right reading light

W14 Front passenger side illuminated vanity mirror

W20 Driver side illuminated vanity mirror

W43 Rear interior light

43 Earth point, lower part of right A-pillar

81 Earth connection 1, in dash panel wiring harness

347 Earth connection, in roof wiring harness

366 Earth connection 1, in main wiring harness

B250 Positive connection, in roof wiring harness

B552 Positive connection 2, in roof wiring harness

* According to equipment

*2 Cross section depends on equipment

Jetta Rusia Current Flow Diagram

purple

yellow

Blocking diode, Onboard supply control unit, Cigarette lighter illumination bulb, Cigarette lighter, 12 V socket, DC/ AC converter with socket, 12 V - 230 V

J29 Blocking diode, in interior wiring harness

J519 Onboard supply control unit

L28 Cigarette lighter illumination bulb

T3g 3-pin connector

T3h 3-pin connector

T3j 3-pin connector

T3wr 3-pin connector

T52c 52-pin connector

U1 Cigarette lighter

U5 12 V socket

U13 DC/AC converter with socket, 12 V - 230 V

U18 12 V socket 2

43 Earth point, lower part of right A-pillar

374 Earth connection 9, in main wiring harness

602 Earth point, in front left footwell

B177 Connection (61), in interior wiring harness

B348 Connection 1 (75a), in main wiring harness

* Wiring colour depends on equipment

*2 Cross section depends on equipment

*3 Only models with dual tone horn

*4 Up to May 2013

*5 According to equipment

*6 From June 2013

Jetta Rusia

Freshairblowerswitch,Heatercontrolunit,Onboardsupply controlunit,Freshairblowerseriesresistorwithoverheating fuse, Fresh air blower, Fresh air and air recirculation flap control motor

E9 Fresh air blower switch

E16 Heater/heat output switch

E230 Heated rear window button

G143 Potentiometer for air recirculation flap control motor

J162 Heater control unit

J485 Auxiliary heater operation relay

J519 Onboard supply control unit

K10 Heated rear window warning lamp

K114 Fresh air and air recirculation warning lamp

L16 Fresh air regulator illumination bulb

N24 Fresh air blower series resistor with overheating fuse

T2v 2-pin connector

T4f 4-pin connector

T5 5-pin connector

T6s 6-pin connector

T9y 9-pin connector

T10a 10-pin connector

T10ag 10-pin connector

T10n 10-pin connector

T20c 20-pin connector

T52a 52-pin connector

T52b 52-pin connector

V2 Fresh air blower

V154 Fresh air and air recirculation flap control motor

602 Earth point, in front left footwell

L77 Connection, in fresh air blower wiring harness

L78 Connection 1, in fresh air blower wiring harness

* Cross section depends on equipment

Jetta Rusia

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Immobiliser reader coil, Handbrake warning switch, Brake fluid level warning contact, Immobiliser control unit, Onboard supply control unit, Dash panel insert

D2 Immobiliser reader coil

F9 Handbrake warning switch

F34 Brake fluid level warning contact

J285 Control unit in dash panel insert

J362 Immobiliser control unit

J519 Onboard supply control unit

K Dash panel insert

K75 Airbag warning lamp

K132 Electronic power control fault lamp

K155 ESP and TCS warning lamp

K169 Selector lever lock warning lamp

T2ap 2-pin connector

T2bm 2-pin connector

T2w 2-pin connector

T32 32-pin connector

132 Earth connection 3, in engine compartment wiring harness

A199 Positive connection 4 (15a) in dash panel wiring harness

* Cross section depends on equipment

Jetta Rusia Current Flow Diagram

thgirypocybdetcetorP

Fuel system pressurisation pump, Front left brake pad wear

sender,Onboardsupplycontrolunit,Fuelpumpcontrolunit, Dash panel insert

G1 Fuel gauge

G6 Fuel system pressurisation pump

G34 Front left brake pad wear sender

J285 Control unit in dash panel insert

J519 Onboard supply control unit

J538 Fuel pump control unit

K Dash panel insert

K2 Alternator warning lamp

K47 ABS warning lamp

K149 Engine electronics warning lamp

T2bb 2-pin connector

T5b 5-pin connector

T10a 10-pin connector

T10n 10-pin connector

T32 32-pin connector

389 Earth connection 24, in main wiring harness

B379 Connection 1 (brake pad wear indicator), in main wiring harness

B380 Connection 2 (brake pad wear indicator), in main wiring harness

* According to equipment

*2 see applicable current flow diagram for engine

*3 Only models with auxiliary coolant heater

*4 Only models with no start/stop system

*5 Only models with start/stop system

Jetta Rusia

Oil pressure switch, Ambient temperature sensor, Coolant shortage indicator sender, Windscreen washer fluid level sender, Onboard supply control unit, Dash panel insert

F1 Oil pressure switch

G17 Ambient temperature sensor

G32 Coolant shortage indicator sender

G33 Windscreen washer fluid level sender

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K Dash panel insert

K31 Cruise control system warning lamp

K65 Left turn signal warning lamp

K94 Right turn signal warning lamp

K161 Electromechanical power steering warning lamp

T2bw 2-pin connector

T2cw 2-pin connector

T2dk 2-pin connector

T14 14-pin connector

T32 32-pin connector

269 Earth connection (sender earth) 1, in dash panel wiring harness

* According to equipment

*2 Only models with auxiliary coolant heater

*3 Cross section depends on equipment

*4 Only models with start/stop system

Jetta Rusia

red

brown

green

blue

Onboard supply control unit, Dash panel insert

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K Dash panel insert

K3 Oil pressure warning lamp

K19 Seat belt warning system warning lamp

K28 Coolant temperature and coolant shortage warning lamp

K29 Glow period warning lamp

K32 Brake pad warning lamp

K37 Washer fluid level warning lamp

K38 Oil level warning lamp

K105 Reserve fuel warning lamp

K115 Immobilizer warning lamp

K118 Brake system warning lamp

* According to equipment

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia

Onboard supply control unit, Data bus diagnostic interface, Dash panel insert

J285 Control unit in dash panel insert

J519 Onboard supply control unit

J533 Data bus diagnostic interface

K Dash panel insert

K1 Main beam warning lamp

K83 Exhaust emissions warning lamp

K166 Door open warning lamp

K170 Bulb failure warning lamp

K171 Bonnet open warning lamp

K201 Fuel tank flap lock warning lamp

K205 Warning lamp for daytime running lights

K220 Tyre Pressure Loss Indicator warning lamp

T20 20-pin connector

T32 32-pin connector

B708 Connection 1 (dash panel insert CAN bus high) in main wiring harness

B709 Connection 1 (dash panel insert CAN bus low) in main wiring harness

* From June 2013

*2 According to equipment

Jetta Rusia

Onboard supply control unit, Data bus diagnostic interface

J104 ABS control unit

J234 Airbag control unit

J519 Onboard supply control unit

J533 Data bus diagnostic interface

J623 Engine control unit

J743 Mechatronic unit for dual clutch gearbox

T16 16-pin connector

T20 20-pin connector

T20e 20-pin connector

T47 47-pin connector

T75 75-pin connector

A76 Connection (K-diagnosis wire), in dash panel wiring harness

B383 Connection

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

* Diagnostic connection

*2 If fitted

Jetta Rusia

Onboard supply control unit, Data bus diagnostic interface

J519 Onboard supply control unit

J533 Data bus diagnostic interface

T20 20-pin connector

T52c 52-pin connector

B397 Connection 1 (convenience CAN bus, high), in main wiring harness

B406 Connection 1 (convenience CAN bus, low), in main wiring harness

Convenience system, High (AW1)

From June 2011

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

respect

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

Jetta Rusia Current Flow

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Battery, Fuse 1 in fuse holder A, Fuse 4 in fuse holder A, Fuse 25 on fuse holder B, Fuse holder C

A Battery

C Alternator

SA1 Fuse 1 in fuse holder A

SA4 Fuse 4 in fuse holder A

SB25 Fuse 25 on fuse holder B

SC Fuse holder C

SC22 Fuse 22 on fuse holder C

SC36 Fuse 36 on fuse holder C

SC45 Fuse 45 on fuse holder C

SC46 Fuse 46 on fuse holder C

SC48 Fuse 48 on fuse holder C

SC51 Fuse 51 on fuse holder C

508 Threaded connection (30) on E-box

B111 Positive connection 1 (30a), in interior wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

B171 Positive connection 3 (30), in interior wiring harness

* Only models with no hybrid drive system

*2 Cross section depends on equipment

*3 see applicable current flow diagram for high-voltage system

Jetta Rusia Current Flow Diagram

Front left window regulator switch, Rear left window regulator switch, in driver door, Rear right window regulator switch, in driver door, Front right window regulator switch in driver door, Childproof lock button, Driver door control unit

E40 Front left window regulator switch

E53 Rear left window regulator switch, in driver door

E55 Rear right window regulator switch, in driver door

E81 Front right window regulator switch in driver door

E318 Childproof lock button

J386 Driver door control unit

K236 Warning light for activated childproof lock

L76 Button illumination bulb

T10f 10-pin connector

T20a 20-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32a 32-pin connector

V147 Driver side window regulator motor

205 Earth connection, in driver door wiring harness

Q38 Positive connection 1 (58b), in window regulator wiring harness

R10 Positive connection 1 (30), in driver door wiring harness

S25 Positive connection (30a), in central locking wiring harness

* Gradually discontinued

Jetta Rusia

Rear lid remote release button, Driver side interior locking button for central locking system, Driver door control unit, Central locking SAFELOCK function warning lamp

E233 Rear lid remote release button

E308 Driver side interior locking button for central locking system

J386 Driver door control unit

K133 Central locking SAFELOCK function warning lamp

K174 Driver side interior locking warning lamp

L76 Button illumination bulb

T2z 2-pin connector

T4am 4-pin connector

T4w 4-pin connector

T20a 20-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

T32a 32-pin connector

205 Earth connection, in driver door wiring harness

Q38 Positive connection 1 (58b), in window regulator wiring harness

Jetta Rusia

Mirror adjustment switch, Mirror adjustment changeover switch, Exterior mirror heater button, Fold-in mirror switch, Fueltankflapreleasebutton,Driverdoorcontrolunit,Mirror adjustment switch illumination bulb

E43 Mirror adjustment switch

E48 Mirror adjustment changeover switch

E231 Exterior mirror heater button

E263 Fold-in mirror switch

E319 Fuel tank flap release button

J386 Driver door control unit

L76 Button illumination bulb

L78 Mirror adjustment switch illumination bulb

T4ac 4-pin connector

T6al 6-pin connector

T32a 32-pin connector

205 Earth connection, in driver door wiring harness

Q38 Positive connection 1 (58b), in window regulator wiring harness

* Only for American markets

Jetta Rusia

Driver door control unit, Driver side exterior mirror, Driver side fold-in mirror motor, Driver side mirror adjustment motor

J386 Driver door control unit

L131 Driver side turn signal repeater bulb

T2sk 2-pin connector, in driver side exterior mirror housing

T2sl 2-pin connector, in driver side exterior mirror housing

T16a 16-pin connector

T20a 20-pin connector

T28 28-pin connector, lower part of A-pillar, driver side

VX4 Driver side exterior mirror

V17 Driver side mirror adjustment motor

V121 Driver side fold-in mirror motor

V149 Driver side mirror adjustment motor

Z4 Heated exterior mirror on driver side

44 Earth point, lower part of left A-pillar

107 Earth connection, in external mirror wiring harness

205 Earth connection, in driver door wiring harness

386 Earth connection 21, in main wiring harness

* According to equipment

*2 Wiring colour depends on equipment

Jetta Rusia

purple

yellow

Driver door contact switch, Driver side central locking lock unit, Driver door control unit, Driver door central locking motor

F2 Driver door contact switch

F220 Driver side central locking lock unit

J386 Driver door control unit

T8f 8-pin connector

T20a 20-pin connector

V56 Driver door central locking motor

V161 Driver door central locking SAFELOCK function motor

44 Earth point, lower part of left A-pillar

367 Earth connection 2, in main wiring harness

605 Earth point, on top end of steering column

* Not for American markets

Jetta Rusia

Window regulator switch in front passenger door, Front passenger door contact switch, Front passenger side

central locking lock unit, Front passenger door control unit, Front passenger seat central locking motor, Front passenger side window regulator motor

E107 Window regulator switch in front passenger door

F3 Front passenger door contact switch

F221 Front passenger side central locking lock unit

J387 Front passenger door control unit

L76 Button illumination bulb

T4ak 4-pin connector

T8h 8-pin connector

T20b 20-pin connector

T28a 28-pin connector, lower part of A-pillar, front passenger side

T32b 32-pin connector

V57 Front passenger seat central locking motor

V148 Front passenger side window regulator motor

V162 Front passenger door central locking SAFELOCK function motor

206 Earth connection, in front passenger door wiring harness

R16 Positive connection 1 (30), in front passenger door wiring harness

* Not for American markets

Jetta Rusia

orange

Front passenger door control unit, Front passenger side exterior mirror, Front passenger side fold-in mirror motor, Front passenger side mirror adjustment motor

J387 Front passenger door control unit

L132 Front passenger side turn signal repeater bulb

T2sm 2-pin connector, in front passenger side exterior mirror housing

T2sr 2-pin connector, in front passenger side exterior mirror housing

T16b 16-pin connector

VX5 Front passenger side exterior mirror

V25 Front passenger side mirror adjustment motor

V122 Front passenger side fold-in mirror motor

V150 Front passenger side mirror adjustment motor

Z5 Heated exterior mirror on front passenger side

801 Earth connection 2, in external mirror wiring harness, in right door, near exterior mirror

* According to equipment

*2 Wiring colour depends on equipment

Jetta Rusia

GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

Interior monitoring deactivation switch, Front passenger side interior locking button for central locking system, Deactivation button for vehicle inclination sender, Front passenger door control unit, Onboard supply control unit, Front interior light

E267 Interior monitoring deactivation switch

E309 Front passenger side interior locking button for central locking system

E360 Deactivation button for vehicle inclination sender

J387 Front passenger door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4an 4-pin connector

T4br 4-pin connector

T6b 6-pin connector

T32b 32-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

W1 Front interior light

B154 Connection 1 (DCt), in interior wiring harness

B250 Positive connection, in roof wiring harness

* According to equipment

Jetta Rusia Current Flow Diagram

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen

AGdoesnotguaranteeoracceptanyliabilitywi

Rear lid handle release button, Luggage compartment light switch, Rear lid lock unit, Onboard supply control unit, Tank filler flap locking motor, Rear lid electric opener motor, Luggage compartment light

E234 Rear lid handle release button

F5 Luggage compartment light switch

F256 Rear lid lock unit

J519 Onboard supply control unit

T2aq 2-pin connector

T2t 2-pin connector

T2x 2-pin connector

T4u 4-pin connector

T52a 52-pin connector

T52b 52-pin connector

V155 Tank filler flap locking motor

V254 Rear lid electric opener motor

W3 Luggage compartment light

86 Earth connection 1, in rear wiring harness

391 Earth connection 26, in main wiring harness

662 Earth point, rear left side panel

B128 Connection (luggage compartment light), in interior wiring harness

B722 Connection 3 (central locking), in main wiring harness

* gradual introduction

*2 Gradually discontinued

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia Current Flow Diagram

Interiormonitoringsensor,Vehicleinclinationsender,Alarm horn, Onboard supply control unit

G273 Interior monitoring sensor

G384 Vehicle inclination sender

H12 Alarm horn

H18 Alarm system horn

J519 Onboard supply control unit

J682 Terminal 50 voltage supply relay

T2ah 2-pin connector

T3f 3-pin connector

T4j 4-pin connector

T9c 9-pin connector

T52b 52-pin connector

T52c 52-pin connector

347 Earth connection, in roof wiring harness

389 Earth connection 24, in main wiring harness

A32 Positive connection (30), in dash panel wiring harness

A57 Positive connection 3 (30), in dash panel wiring harness

B321 Positive connection 7 (30a) in main wiring harness

B549 Connection 2 (LIN bus) in main wiring harness

* Not for American markets

*2 Only for American markets

*3 Cross section depends on equipment

Jetta Rusia

Rear left window regulator switch, in door, Rear left door control unit, Onboard supply control unit, Rear left window regulator motor

E52 Rear left window regulator switch, in door

J388 Rear left door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4aq 4-pin connector

T20f 20-pin connector

T28b 28-pin connector, on left B-pillar

V26 Rear left window regulator motor

207 Earth connection, in rear left door wiring harness

A62 Connection (window regulators), in dash panel wiring harness

Q40 Positive connection 3 (58b), in window regulator wiring harness

R19 Positive connection 1 (30), in rear left door wiring harness

Jetta Rusia Current Flow Diagram

Rearcentralswitchforinteriorlocking,Rearleftdoorcontact switch, Rear left central locking lock unit, Rear left door control unit, Onboard supply control unit, Rear left door central locking motor, lock

E286 Rear central switch for interior locking

F10 Rear left door contact switch

F222 Rear left central locking lock unit

J388 Rear left door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4bz 4-pin connector

T8s 8-pin connector

T20f 20-pin connector

T28b 28-pin connector, on left B-pillar

V214 Rear left door central locking motor, lock

43 Earth point, lower part of right A-pillar

207 Earth connection, in rear left door wiring harness

366 Earth connection 1, in main wiring harness

388 Earth connection 23, in main wiring harness

* Not for American markets

Jetta Rusia Current Flow Diagram

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

= white

= red

= brown

= green

= blue

= purple

= purple

= yellow

= orange

= pink

Rear right window regulator switch, in door, Rear right door control unit, Onboard supply control unit, Rear right window regulator motor

E54 Rear right window regulator switch, in door

J389 Rear right door control unit

J519 Onboard supply control unit

L76 Button illumination bulb

T4ar 4-pin connector

T20g 20-pin connector

T28c 28-pin connector, on right B-pillar

V27 Rear right window regulator motor

208 Earth connection, in rear right door wiring harness

Q41 Positive connection 4 (58b), in window regulator wiring harness

R23 Positive connection 1 (30), in rear right door wiring harness

Jetta Rusia

Rear right door contact switch, Rear right central locking lock unit, Rear right door control unit, Onboard supply control unit, Rear right door central locking motor, lock

F11 Rear right door contact switch

F223 Rear right central locking lock unit

J389 Rear right door control unit

J519 Onboard supply control unit

T8t 8-pin connector

T20g 20-pin connector

T28c 28-pin connector, on right B-pillar

V215 Rear right door central locking motor, lock

43 Earth point, lower part of right A-pillar

81 Earth connection 1, in dash panel wiring harness

208 Earth connection, in rear right door wiring harness

* Not for American markets

Jetta Rusia

Slidingsunroofadjustmentregulator,Button1fortiltingroof, Sliding sunroof adjustment control unit, Onboard supply control unit, Sliding sunroof motor

E1 Light switch

E139 Sliding sunroof adjustment regulator

E582 Button 1 for tilting roof

J245 Sliding sunroof adjustment control unit

J519 Onboard supply control unit

J533 Data bus diagnostic interface

T4ad 4-pin connector

T10e 10-pin connector

T10h 10-pin connector

T20 20-pin connector

T52b 52-pin connector

V1 Sliding sunroof motor

B340 Connection 1 (58d), in main wiring harness

Jetta Rusia

Bonnet contact switch, Onboard supply control unit, Terminal 15 voltage supply relay 2, Automatic anti-dazzle interior mirror

F266 Bonnet contact switch

J519 Onboard supply control unit

J681 Terminal 15 voltage supply relay 2

SC13 Fuse 13 on fuse holder C

T2n 2-pin connector

T6b 6-pin connector

T6d 6-pin connector

T9f 9-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

W1 Front interior light

Earth connection 4, in engine compartment wiring

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

A87 Connection (RL), in dash panel wiring harness

A184 Connection(bonnetcontactswitch),indashpanelwiringharness

A217 Positive connection 8 (15a) in dash panel wiring harness

B163 Positive connection 1 (15), in interior wiring harness

* Gradually discontinued

Jetta Rusia

Onboard supply control unit

J519 Onboard supply control unit

J533 Data bus diagnostic interface

T20 20-pin connector

T52c 52-pin connector

B397

B406 Connection 1 (convenience CAN bus,

Jetta Rusia

Earthing concept

From October 2011

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen

Jetta Rusia Current Flow Diagram

Earth strap, battery - body, Earth point, in front left footwell

A Battery

A19 Voltage converter

F148 Front passenger vanity mirror contact switch

JX1 Power and control electronics for electric drive

J245 Sliding sunroof adjustment control unit

J367 Battery monitor control unit

T2bl 2-pin connector

T2v 2-pin connector

T3wr 3-pin connector

T10a 10-pin connector, behind glove compartment

T10e 10-pin connector, near front interior light

T28a 28-pin connector, lower part of A-pillar, front passenger side

U13 DC/AC converter with socket, 12 V - 230 V

U27 DC/AC converter with socket, 12 V - 115 V

V2 Fresh air blower

Z35 Auxiliary air heater element

1 Earth strap, battery - body

81 Earth connection 1, in dash panel wiring harness

206 Earth connection, in front passenger door wiring harness

602 Earth point, in front left footwell

624 Earth point, starter battery

* Not for American markets

*2 Only for American markets

*3 Only models with hybrid drive system

Jetta Rusia

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Earth connection, in rear right door wiring harness

E107 Window regulator switch in front passenger door

E309 Front passenger side interior locking button for central locking system

F221 Front passenger side central locking lock unit

F223 Rear right central locking lock unit

J387 Front passenger door control unit

J389 Rear right door control unit

L132 Front passenger side turn signal repeater bulb

T4ak 4-pin connector

T4an 4-pin connector

T8h 8-pin connector

T8t 8-pin connector

T12c 12-pin connector, in front passenger door

T16b 16-pin connector

T18c 18-pin connector

T20b 20-pin connector

T28c 28-pin connector, lower part of B-pillar, front passenger side

T32b 32-pin connector

Z5 Heated exterior mirror on front passenger side

81 Earth connection 1, in dash panel wiring harness

206 Earth connection, in front passenger door wiring harness

208 Earth connection, in rear right door wiring harness

801 Earth connection 2, in external mirror wiring harness, in left door, near exterior mirror

* Only models with "Low" equipment (AW0)

*2 Only models with "High" equipment (AW1)

Jetta Rusia

Earth point, lower part of right A-pillar, Earth connection 3, in seat heating wiring harness, Earth connection, in rear rightdoorwiringharness,Earthconnection1,inmainwiring harness, Earth connection 14, in main wiring harness

E54 Rear right window regulator switch, in door

T4ar 4-pin connector

T10d 10-pin connector, under front passenger seat

43 Earth point, lower part of right A-pillar

connection,

Earth connection 1, in main wiring harness 374 Earth connection 9, in main wiring harness

379 Earth connection 14, in main wiring harness

Jetta Rusia

Earth connection 3, in seat heating wiring harness, Earth connection 1, in main wiring harness, Earth connection 14, in main wiring harness

E508 Operating unit for preparation for mobile telephone

J29 Blocking diode, in interior wiring harness

R36 Telephone transmitter and receiver unit

R126 Telephone bracket

T3g 3-pin connector

T3h 3-pin connector

T3j 3-pin connector

T6av 6-pin connector

T10m 10-pin connector

T54 54-pin connector

U1 Cigarette lighter

U5 12 V socket

U18 12 V socket 2

145 Earth connection 3, in seat heating wiring harness

366 Earth connection 1, in main wiring harness

374 Earth connection 9, in main wiring harness

379 Earth connection 14, in main wiring harness

Jetta Rusia

Earth connection 3, in seat heating wiring harness, Earth connection 4, in seat heating wiring harness, Earth connection 1, in main wiring harness

E229 Hazard warning lights button

G60 Front passenger seat temperature sensor

J532 Voltage stabiliser

K6 Indicator lamp for hazard warning light

T2e 2-pin connector, in seat

T4m 4-pin connector, in seat

T6c 6-pin connector

T10w 10-pin connector

T12d 12-pin connector

Z8 Heated seat cushion for front passenger seat

Z9 Heated backrest for front passenger seat

Z33 Front passenger seat lateral support heater

145 Earth connection 3, in seat heating wiring harness

318 Earth connection 4, in seat heating wiring harness

366 Earth connection 1, in main wiring harness

* Gradually discontinued *2 gradual introduction

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia

Diagnostic connection, Earth connection 1, in main wiring harness

G238 Air quality sensor

J533 Data bus diagnostic interface

J745 Control unit for cornering light and headlight range control

MX1 Front left headlight

MX2 Front right headlight

T2br 2-pin connector

T2bt 2-pin connector

T2bu 2-pin connector

T3aw 3-pin connector

T10l 10-pin connector

T10r 10-pin connector

T14l 14-pin connector

T14r 14-pin connector

T16b 16-pin connector

T20a 20-pin connector

T26b 26-pin connector

U31 Diagnostic connection, near lower part of left A-pillar

V48 Left headlight range control motor

V49 Right headlight range control motor

W6 Glove compartment light

Z20 Left washer jet heater element

Z21 Right washer jet heater element

80 Earth connection 1, in dash panel wiring harness

366 Earth connection 1, in main wiring harness

* Diagnostic connection

*2 Headlight with gas discharge light

*3 From June 2013

Jetta Rusia

Earth connection 1, in main wiring harness, Earth connection 23, in main wiring harness

E1 Light switch

E2 Turn signal switch

E266 Parking aid button

F9 Handbrake warning switch

F319 Selector lever locked in position P switch

J301 Air conditioning system control unit

L9 Light switch illumination bulb

L76 Button illumination bulb

T2w 2-pin connector

T3i 3-pin connector

T6j 6-pin connector

T10s 10-pin connector

T16ls 16-pin connector

T17 17-pin connector

T20c 20-pin connector

366 Earth connection 1, in main wiring harness

387 Earth connection 22, in main wiring harness

388 Earth connection 23, in main wiring harness

* Not for models with dual clutch gearbox

*2 Only models with "Low" equipment (AW0)

Jetta Rusia Current Flow Diagram

Earth connection 23, in main wiring harness

E1 Light switch

E20 Switch and instrument illumination regulator

E102 Headlight range control regulator

E132 Traction control system switch

E262 Start/Stop operation switch

E286 Rear central switch for interior locking

E319 Fuel tank flap release button

E492 Tyre Pressure Loss Indicator button

F319 Selector lever locked in position P switch

J255 Climatronic control unit

J518 Entry and start authorisation control unit

L105 Illumination regulator illumination bulb

T3i 3-pin connector

T4bz 4-pin connector

T6ad 6-pin connector

T6ak 6-pin connector

T6be 6-pin connector

T6te 6-pin connector

T8e 8-pin connector

T10h 10-pin connector

T10s 10-pin connector

T20c 20-pin connector

T32e 32-pin connector

388 Earth connection 23, in main wiring harness

* Only models with "High" equipment (AW1)

*2 According to equipment

*3 Only models with start/stop system

*4 Only models with "Low" equipment (AW0)

*5 Only models with hybrid drive system

Jetta Rusia

Earth point, on right in engine compartment, Earth point, on right A-pillar

H1 Horn or dual tone horn

J104 ABS control unit

L23 Right fog light bulb

MX2 Front right headlight

T2bt 2-pin connector

T2bu 2-pin connector

T2by 2-pin connector

T2dh 2-pin connector

T2dj 2-pin connector

T10r 10-pin connector

T26b 26-pin connector

T47 47-pin connector

V11 Headlight washer system pump

V263 Fuel pump for cold start

Z20 Left washer jet heater element

Z21 Right washer jet heater element

13 Earth point, on right in engine compartment

121 Earth connection 2, in front right wiring harness

124 Earth connection, in right side engine compartment wiring harness

638 Earth point, on right A-pillar

* Only models with dual tone horn

*2 Up to May 2013

*3 see applicable current flow diagram for engine

Jetta Rusia

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Earth point (audio), front below centre console

J503 Control unit with display for radio and navigation

J650 Multimedia system control unit

R Radio

R12 Amplifier

R189 Reversing camera

T4cq 4-pin connector

T12h 12-pin connector

T16d 16-pin connector

T38 38-pin connector

370 Earth connection 5, in main wiring harness

371 Earth connection 6, in main wiring harness

610 Earth point (audio), front below centre console

Jetta Rusia

Earth connection 1, in engine compartment wiring harness, Earth connection 2, in engine compartment wiring harness, Earth point, on left headlight

J400 Wiper motor control unit

L22 Left fog light bulb

MX1 Front left headlight

T2dg 2-pin connector

T4p 4-pin connector

T10l 10-pin connector

connection

connection,

connection

179 Earth connection, in left headlight wiring harness

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

Jetta Rusia

Earth connection 1, in engine compartment wiring harness, Earth connection 2, in engine compartment wiring harness, Earth connection 3, in engine compartment wiring harness

F34 Brake fluid level warning contact

F266 Bonnet contact switch

G266 Oil level and oil temperature sender

J179 Automatic glow period control unit

J623 Engine control unit

J842 Control unit for air conditioning compressor

N280 Air conditioner compressor regulating valve

T2ap 2-pin connector

T2m 2-pin connector

T2n 2-pin connector, on left in engine compartment near headlight

T4t 4-pin connector, near starter

T6z 6-pin connector, near E-box

T8ay 8-pin connector

T11a 11-pin connector

T14ax 14-pin connector

T14hy 14-pin connector, black

T80 80-pin connector

T91 91-pin connector

T94 94-pin connector

85 Earth connection 1, in engine compartment wiring harness

114 Earth connection, in automatic gearbox wiring harness

131 Earth connection 2, in engine compartment wiring harness

132 Earth connection 3, in engine compartment wiring harness

167 Earth connection 4, in engine compartment wiring harness

* see applicable current flow diagram for engine

*2 Only models with hybrid drive system

Jetta Rusia

Earth connection 1, in engine compartment wiring harness, Earth connection 2, in engine compartment wiring harness

F125 Multifunction switch

G476 Clutch position sender

J217 Automatic gearbox control unit

J318 Vacuum pump relay

J743 Mechatronic unit for dual clutch gearbox

N79 Heater element for crankcase breather

T5m 5-pin connector

T10o 10-pin connector

T20e 20-pin connector

T25 25-pin connector

T52 52-pin connector

V192 Vacuum pump for brakes

Earth connection 1, in engine compartment wiring harness

114 Earth connection, in automatic gearbox wiring harness

131 Earth connection 2, in engine compartment wiring harness

* Only models with 1.6l engine

*2 Only models with diesel engine

*3 According to equipment

Jetta Rusia

Earth connection, in driver door wiring harness, Earth connection 21, in main wiring harness

E40 Front left window regulator switch

E43 Mirror adjustment switch

E233 Rear lid remote release button

E308 Driver side interior locking button for central locking system

E319 Fuel tank flap release button

F220 Driver side central locking lock unit

J386 Driver door control unit

K174 Driver side interior locking warning lamp

T2z 2-pin connector

T4ac 4-pin connector

T4am 4-pin connector

T4w 4-pin connector

T8f 8-pin connector

T10f 10-pin connector

T16a 16-pin connector

T28 28-pin connector, on lower section of left A-pillar

T32a 32-pin connector

T32f 32-pin connector, on lower section of left A-pillar

205 Earth connection, in driver door wiring harness

386 Earth connection 21, in main wiring harness

* Only models with "Low" equipment (AW0)

*2 Only models with "High" equipment (AW1)

*3 Only for American markets

Jetta Rusia

Earth point, lower part of left A-pillar, Earth connection 1, in seat heating wiring harness, Earth connection, in external mirrorwiringharness,Earthconnection,indriverdoorwiring harness, Earth connection 2, in main wiring harness, Earth connection 21, in main wiring harness, Earth point, on top end of steering column

J386 Driver door control unit

L131 Driver side turn signal repeater bulb

T10c 10-pin connector, under seat on front left

T12b 12-pin connector, in driver door

T20a 20-pin connector

Z4 Heated exterior mirror on driver side

44 Earth point, lower part of left A-pillar

96 Earth connection 1, in seat heating wiring harness

107 Earth connection, in external mirror wiring harness, in left door, near exterior mirror

205 Earth connection, in driver door wiring harness

367 Earth connection 2, in main wiring harness

386 Earth connection 21, in main wiring harness

605 Earth point, on top end of steering column

* Only models with "Low" equipment (AW0)

*2 Only models with "High" equipment (AW1)

Jetta Rusia

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

Earthconnection1,inseatadjustmentwiringharness,Earth connection 1, in seat heating wiring harness, Earth connection 2, in main wiring harness, Earth connection 21, in main wiring harness

E52 Rear left window regulator switch, in door

E418 Seat longitudinal adjustment button

E421 Rake adjustment button

E425 Backrest adjustment button

F222 Rear left central locking lock unit

J388 Rear left door control unit

T4aq 4-pin connector

T6g 6-pin connector

T8s 8-pin connector

T16h 16-pin connector

T28b 28-pin connector, on left B-pillar 95 Earth connection 1, in seat adjustment wiring harness

96 Earth connection 1, in seat heating wiring harness

207 Earth connection, in rear left door wiring harness

367 Earth connection 2, in main wiring harness

386 Earth connection 21, in main wiring harness

* Only models with "Low" equipment (AW0)

*2 Only models with "High" equipment (AW1)

Earth connection 1, in seat heating wiring harness, Earth connection 2, in main wiring harness

E176 Driver seat lumbar support adjustment switch

G59 Driver seat temperature sensor

J774 Heated front seats control unit

T2d 2-pin connector, in driver seat

T4l 4-pin connector, in driver seat

T6ah 6-pin connector

T8z 8-pin connector

Z6 Heated seat cushion for driver seat

Z7 Heated backrest for driver seat

Z31 Driver seat cushion lateral support heater

Earth connection 1, in seat heating wiring harness

136 Earth connection 2, in seat heating wiring harness

367 Earth connection 2, in main wiring harness

* Gradually discontinued

Jetta Rusia

Earth connection 2, in main wiring harness

EX20 Right steering column switch

J285 Control unit in dash panel insert

J329 Terminal 15 voltage supply relay

J519 Onboard supply control unit

J527 Steering column electronics control unit

J680 Terminal 75 voltage supply relay 1

J935 Converter box

T9x 9-pin connector

T10i 10-pin connector

T10ls 10-pin connector

T16l 16-pin connector

T32b 32-pin connector

T52a 52-pin connector

T52b 52-pin connector

T52c 52-pin connector

T73a 73-pin connector

T73b 73-pin connector

purple

yellow

orange

= pink

367 Earth connection 2, in main wiring harness

* Only models with "High" equipment (AW1)

*2 Only models with "Low" equipment (AW0)

*3 Cross section depends on equipment

Jetta Rusia

Earth connection 2, in main wiring harness, Earth connection 3, in main wiring harness, Earth connection 24, in main wiring harness

F138 Airbag coil connector and return ring with slip ring

G476 Clutch position sender

J162 Heater control unit

J331 Dipped beam relay

J519 Onboard supply control unit

J681 Terminal 15 voltage supply relay 2

T5m 5-pin connector

T9h 9-pin connector

T16k 16-pin connector

T20c 20-pin connector

T52c 52-pin connector

T73a 73-pin connector

367 Earth connection 2, in main wiring harness

368 Earth connection 3, in main wiring harness

389 Earth connection 24, in main wiring harness

* According to equipment

*2 Gradually discontinued

*3 Only models with "Low" equipment (AW0)

*4 Only models with "High" equipment (AW1)

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia

Earth connection 24, in main wiring harness

E378 Starter button

E656 Button for electric drive

F47 Brake pedal switch

G34 Front left brake pad wear sender

G65 High-pressure sender

H12 Alarm horn

H18 Alarm system horn

J13 Fresh air blower relay

J485 Auxiliary heater operation relay

J641 Alarm horn relay

J682 Terminal 50 voltage supply relay

J764 Control unit for electronic steering column lock

J869 Control unit for structure-borne sound

L76 Button illumination bulb

T2ah 2-pin connector

T2bb 2-pin connector

T3c 3-pin connector

T3f 3-pin connector

T4al 4-pin connector

T5ah 5-pin connector

T6ef 6-pin connector

T6st 6-pin connector

T16v 16-pin connector

389 Earth connection 24, in main wiring harness

B380 Connection 2 (brake pad wear indicator), in main wiring harness

* Only models with hybrid drive system

*2 Cross section depends on equipment

Jetta Rusia

in w ho

Earth connection, in roof wiring harness, Earth connection 24, in main wiring harness

F147 Driver vanity mirror contact switch

G273 Interior monitoring sensor

G384 Vehicle inclination sender

G397 Rain and light sensor

T2bk 2-pin connector

T3ae 3-pin connector

T3am 3-pin connector

T4j 4-pin connector

T6d 6-pin connector

T8a 8-pin connector

W1 Front interior light

W43 Rear interior light

Y7 Automatic anti-dazzle interior mirror

347 Earth connection, in roof wiring harness

389 Earth connection 24, in main wiring harness

Jetta Rusia

Earth point, on left in engine compartment

H1 Horn or dual tone horn

JX1 Power and control electronics for electric drive

J369 Wipermotorswitch-overrelay2,inE-boxinenginecompartment

N79 Heater element for crankcase breather

T2cf 2-pin connector

T2di 2-pin connector

T2fc 2-pin connector

T2fl 2-pin connector

T4x 4-pin connector, near radiator fan

V7 Radiator fan

V35 Right radiator fan

V51 Continued coolant circulation pump

V101 Secondary air pump motor

V177 Radiator fan 2

V277 Fuel pump 2

12 Earth point, on left in engine compartment

108 Earth connection 2, in front left wiring harness

* see applicable current flow diagram for engine

*2 Only models with "High" equipment (AW1)

*3 Only models with dual tone horn

*4 Only models with two radiator fans

*5 Only models with hybrid drive system

Jetta Rusia

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

Earth connection 1, in engine compartment wiring harness

F1 Oil pressure switch

N70 Ignition coil 1 with output stage

N127 Ignition coil 2 with output stage

N291 Ignition coil 3 with output stage

N323 Ignition coil 5 with output stage

N492 Solenoid for coolant circuit

T3bc 3-pin connector

T3ht 3-pin connector

T3nt 3-pin connector

T14l 14-pin connector

V178 Coolant circulation pump 2

V192 Vacuum pump for brakes

V467 Coolant pump for high-temperature circuit

V468 Coolant pump for low-temperature circuit 85 Earth connection 1, in engine compartment wiring harness

yellow

orange

108 Earth connection 2, in front left wiring harness

* Only models with 1.6l engine

*2 Only models with diesel engine

*3 Only models with hybrid drive system

Jetta Rusia

Earth connection 1, in rear wiring harness, Earth point, rear left side panel, Earth connection 1, in hybrid system wiring harness

AX1 Hybrid battery unit

G197 Magnetic field sender for compass

J345 Trailer detector control unit

J840 Battery regulation control unit

T4cx 4-pin connector

T4lh 4-pin connector

T6au 6-pin connector

T12a 12-pin connector

T13 13-pin connector

T14ax 14-pin connector

U10 Trailer socket

V457 Battery fan 1 86 Earth connection 1, in rear wiring harness

430 Earth connection, in towing bracket wiring harness

431 Earth connection 2, in roof wiring harness

662 Earth point, rear left side panel

701 Earth point in luggage compartment

816 Earth connection 1, in hybrid system wiring harness

* Only models with hybrid drive system

Jetta Rusia

Earth connection 1, in rear wiring harness, Earth connection, in number plate wiring harness, Earth point 2, left in engine compartment

E234 Rear lid handle release button

F5 Luggage compartment light switch

F256 Rear lid lock unit

J500 Power steering control unit

J895 Control unit for vehicle location system

MX3 Left tail light

MX5 Left tail light 2

MX6 Right tail light 2

R149 Remote control receiver for auxiliary coolant heater

T2a 2-pin connector

T2t 2-pin connector

T3an 3-pin connector

T4u 4-pin connector

T6j 6-pin connector

V254 Rear lid electric opener motor

W44 Rear centre reading light

X Number plate light

86 Earth connection 1, in rear wiring harness

437 Earth connection, in number plate wiring harness

640 Earth point 2, left in engine compartment

Jetta Rusia

yellow

Earth point 1, in rear right side panel, Earth point 2, in rear right side panel

F334 Fuel tank cap detection switch

G6 Fuel system pressurisation pump

J446 Parking aid control unit

J538 Fuel pump control unit

MX4 Right tail light

M25 Additional brake light bulb

R178 Frequency modulation (FM) frequency filter in negative wire

T2dn 2-pin connector

T4b 4-pin connector

T4te 4-pin connector

T5b 5-pin connector

T10n 10-pin connector

T16c 16-pin connector

V54 Metering pump

Z1 Heated rear window

87 Earth connection 2, in rear wiring harness

196 Earth connection 3, in rear wiring harness

681 Earth point 1, in rear right side panel

682 Earth point 2, in rear right side panel

* Only models with auxiliary coolant heater

*2 If fitted

*3 Only models with hybrid drive system

*4 Cross-section 1.5 possible

From September 2011

th respect t o t h e c o r r e c t n e ss o f ni.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof 1.6l petrol engine , CFNA,CFNB

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG Volkswagen

Jetta Rusia

Battery, Starter, Alternator, Fuse 1 in fuse holder A, Fuse 4 in fuse holder A, Fuse holder B

A Battery

B Starter

C Alternator

C1 Voltage regulator

SA1 Fuse 1 in fuse holder A

SA4 Fuse 4 in fuse holder A

SB Fuse holder B

T2 2-pin connector

T2i 2-pin connector, near starter

T4t 4-pin connector, near starter

1 Earth strap, battery - body

12 Earth point, on left in engine compartment

508 Threaded connection (30) on E-box

652 Earth point, engine and gearbox earth

B111 Positive connection 1 (30a), in interior wiring harness

B177 Connection (61), in interior wiring harness

* Only models with air conditioning system

*2 Only models with no air conditioning system

Jetta Rusia

Main relay, Onboard supply control unit, Fuse holder B

J271 Main relay

J519 Onboard supply control unit

SB Fuse holder B

SB2 Fuse 2 on fuse holder B

SB3 Fuse 3 on fuse holder B

SB4 Fuse 4 on fuse holder B

SB14 Fuse 14 on fuse holder B

purple

= yellow

orange

= pink

D78 Positive connection 1 (30a), in engine compartment wiring harness

Jetta Rusia Current Flow Diagram

= red

= brown

= green

= blue

= grey

= purple

= purple

= yellow

= orange

= pink

Onboard supply control unit, Fuse holder B

D Ignition/starter switch

J519 Onboard supply control unit

SB Fuse holder B

SB7 Fuse 7 on fuse holder B

SB8 Fuse 8 on fuse holder B

SB10 Fuse 10 on fuse holder B

SB25 Fuse 25 on fuse holder B

T10 10-pin connector

T14 14-pin connector, near battery

T52c 52-pin connector

T73b 73-pin connector

A41 Positive connection (50), in dash panel wiring harness

B218 Positive connection 6 (30), in interior wiring harness

B239 Positive connection 1 (50), in interior wiring harness

D196 Connection 2 (87a) in engine prewiring harness

Jetta Rusia Current Flow Diagram

AGdoesnotguaranteeoracceptanyliabilitywi

Onboard supply control unit, Terminal 15 voltage supply relay 2, Terminal 50 voltage supply relay

J329 Terminal 15 voltage supply relay

J519 Onboard supply control unit

J681 Terminal 15 voltage supply relay 2

J682 Terminal 50 voltage supply relay

J935 Converter box

T9c 9-pin connector

T9f 9-pin connector

T9g 9-pin connector

T9i 9-pin connector

T10i 10-pin connector

T52b 52-pin connector

T73a 73-pin connector

389 Earth connection 24, in main wiring harness

A41 Positive connection (50), in dash panel wiring harness

B163 Positive connection 1 (15), in interior wiring harness

B429 Connection (EFPR), in main wiring harness

* Only models with "Low" equipment (AW0)

*2 see applicable current flow diagram for basic equipment

Jetta Rusia Current Flow Diagram

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

= white

= red

= red

= brown gn = green

= blue

= grey li = purple vi = purple ge = yellow or = orange rs = pink

Fuse holder C

SC Fuse holder C

SC3 Fuse 3 on fuse holder C

SC14 Fuse 14 on fuse holder C

SC16 Fuse 16 on fuse holder C

SC35 Fuse 35 on fuse holder C

A199 Positive connection 4 (15a) in dash panel wiring harness

A201 Positive connection 6 (15a) in dash panel wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B172 Positive connection 4 (30), in interior wiring harness

B315 Positive connection 1 (30a) in main wiring harness

* gradual introduction

*2 Gradually discontinued

Jetta Rusia Current Flow Diagram

Fuel gauge sender, Fuel system pressurisation pump, Fuel pump relay, Fuel supply relay, Fuse holder C

G Fuel gauge sender

G6 Fuel system pressurisation pump

J17 Fuel pump relay

J643 Fuel supply relay

SC Fuse holder C

SC47 Fuse 47 on fuse holder C

T5am 5-pin connector

T5b 5-pin connector

196 Earth connection 3, in rear wiring harness

682 Earth point 2, in rear right side panel

A99 Connection 1 (87) in dash panel wiring harness

B156 Positive connection (30a), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia

Engine control unit

E45 Cruise control system switch

J527 Steering column electronics control unit

J623 Engine control unit

T16l 16-pin connector

T80 80-pin connector

131 Earth connection 2, in engine compartment wiring harness

655 Earth point, on left headlight

B441 Connection (CCS), in main wiring harness

D110 Connection 8 in engine compartment wiring harness

* Only models with cruise control system (CCS)

Jetta Rusia Current Flow Diagram

Engine control unit, Spark plug connector, Spark plugs

J623 Engine control unit

N70 Ignition coil 1 with output stage

N127 Ignition coil 2 with output stage

N291 Ignition coil 3 with output stage

N292 Ignition coil 4 with output stage

P Spark plug connector

Q Spark plugs

T4af 4-pin connector

T4ag 4-pin connector

T4ah 4-pin connector

T4ai 4-pin connector

T14 14-pin connector, near battery

T80 80-pin connector

12 Earth point, on left in engine compartment 15 Earth point, on cylinder head

85 Earth connection 1, in engine compartment wiring harness

108 Earth connection 2, in front left wiring harness

281 Earth point 1, engine prewiring harness

D206 Connection 4 (87a) in engine prewiring harness

Jetta Rusia

Accelerator position sender, Accelerator position sender 2, Throttle valve drive for electric throttle, Throttle valve module, Engine control unit

G69 Throttle valve potentiometer

G79 Accelerator position sender

G185 Accelerator position sender 2

G186 Throttle valve drive for electric throttle

G188 Throttle valve drive angle sender 2 for electric throttle

J338 Throttle valve module

J623 Engine control unit

T6h 6-pin connector

T6x 6-pin connector

T80 80-pin connector

AGdoesnotguaranteeoracceptanyliabilitywi

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Hall sender, Knock sensor 1, Coolant temperature sender, Engine control unit

G40 Hall sender

G61 Knock sensor 1

G62 Coolant temperature sender

J623 Engine control unit

T2dp 2-pin connector

T2ex 2-pin connector

T3b 3-pin connector

T80 80-pin connector

220 Earth connection (sender earth), in engine wiring harness

Jetta Rusia

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

= red

= red

= brown

= green

= blue

= grey

= purple

= purple

= yellow

= orange

= pink

Enginespeedsender,Intakeairtemperaturesender,Intake manifold pressure sender, Engine control unit, Activated charcoal filter solenoid valve 1

G28 Engine speed sender

G42 Intake air temperature sender

G71 Intake manifold pressure sender

J623 Engine control unit

N80 Activated charcoal filter solenoid valve 1

T2dt 2-pin connector

T3ag 3-pin connector

T4ax 4-pin connector

T4x 4-pin connector

T14 14-pin connector, near battery

T80 80-pin connector

220 Earth connection (sender earth), in engine wiring harness

D101 Connection 1 in engine compartment wiring harness

* Radiator fan connection

Jetta Rusia

Engine control unit, Injector, cylinder 1, Injector, cylinder 2, Injector, cylinder 3, Injector, cylinder 4

J623 Engine control unit

N30 Injector, cylinder 1

N31 Injector, cylinder 2

N32 Injector, cylinder 3

N33 Injector, cylinder 4

T2cg 2-pin connector

T2ch 2-pin connector

T2ci 2-pin connector

T2cj 2-pin connector

T14 14-pin connector, near battery

T80 80-pin connector

D95 Connection (injectors), in engine compartment wiring harness

* Only models with "High" equipment (AW1)

*2 Only models with "Low" equipment (AW0)

Jetta Rusia

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

= red

= brown

= green

= blue

= purple

purple

yellow

Lambda probe, Lambda probe after catalytic converter, Engine control unit, Lambda probe heater, Lambda probe 1 heater after catalytic converter

G39 Lambda probe

G130 Lambda probe after catalytic converter

J623 Engine control unit

T4 4-pin connector

T4ao 4-pin connector

T80 80-pin connector

Z19 Lambda probe heater

Z29 Lambda probe 1 heater after catalytic converter

D103 Connection 3 in engine compartment wiring harness

E30 Connection (87a), in engine wiring harness

Rusia

rup op s e s , i n p a r t o r in w hole,

Brake light switch, Brake pedal switch, Onboard supply control unit, Engine control unit

F Brake light switch

F47 Brake pedal switch

J519 Onboard supply control unit

J623 Engine control unit

T4al 4-pin connector

T52c 52-pin connector

T73a 73-pin connector

T80 80-pin connector

B131 Connection (54), in interior wiring harness

* Only models with "High" equipment (AW1)

*2 Only models with "Low" equipment (AW0)

Jetta Rusia

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

Clutchpositionsender,Onboardsupplycontrolunit,Engine control unit

G476 Clutch position sender

J104 ABS control unit

J519 Onboard supply control unit

J623 Engine control unit

T5m 5-pin connector

T26 26-pin connector

T47 47-pin connector

T52c 52-pin connector

T73b 73-pin connector

T80 80-pin connector

* Only models with anti-lock brake system (ABS) and electronic stabilisation program (ESP)

*2 Only models with ABS and no ESP

*3 Only models with "High" equipment (AW1)

*4 Only models with "Low" equipment (AW0)

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Radiator outlet coolant temperature sender, Onboard supply control unit, Engine control unit

G83 Radiator outlet coolant temperature sender

J519 Onboard supply control unit

J623 Engine control unit

T2r 2-pin connector

T80 80-pin connector

A76 Connection (K-diagnosis wire), in dash panel wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

* gradual introduction

Jetta Rusia Current Flow Diagram

Control unit in dash panel insert, Onboard supply control

Data bus diagnostic interface

J285 Control unit in dash panel insert

J519 Onboard supply control unit

J533 Data bus diagnostic interface

T16 16-pin connector

T20 20-pin connector

T32 32-pin connector

T52c 52-pin connector

T73b 73-pin connector

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

B397 Connection 1 (convenience CAN bus, high), in main wiring harness

B406 Connection 1 (convenience CAN bus, low), in main wiring harness

* Diagnostic connection

*2 Only models with "Low" equipment (AW0)

*3 Only models with "High" equipment (AW1)

Jetta Rusia Current Flow Diagram

Fuel gauge, Coolant temperature gauge, Rev. counter, Speedometer, Control unit in dash panel insert, Onboard supply control unit, Alternator warning lamp, Coolant temperature and coolant shortage warning lamp, Cruise control system warning lamp, Reserve fuel warning lamp, Electronic power control fault lamp

G1 Fuel gauge

G3 Coolant temperature gauge

G5 Rev. counter

G21 Speedometer

G32 Coolant shortage indicator sender

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K2 Alternator warning lamp

K28 Coolant temperature and coolant shortage warning lamp

K31 Cruise control system warning lamp

K83 Exhaust emissions warning lamp

K105 Reserve fuel warning lamp

K132 Electronic power control fault lamp

T32 32-pin connector

132 Earth connection 3, in engine compartment wiring harness

269 Earth connection (sender earth) 1, in dash panel wiring harness

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

* gradual introduction

*2 Gradually discontinued

*3 Only models with cruise control system (CCS)

Jetta Rusia Current Flow Diagram

Oil pressure switch, Control unit in dash panel insert, Onboard supply control unit

F1 Oil pressure switch

G266 Oil level and oil temperature sender

H3 Buzzer and gong

J285 Control unit in dash panel insert

J519 Onboard supply control unit

K3 Oil pressure warning lamp

T6z 6-pin connector

T14 14-pin connector

T32 32-pin connector

T52b 52-pin connector

T52c 52-pin connector

T73a 73-pin connector

T73b 73-pin connector

367 Earth connection 2, in main wiring harness

605 Earth point, on top end of steering column

* Only models with extended servicing intervals (ESI)

Electromechanical steering

From April 2011

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia Current Flow Diagram

Steering angle sender, Steering moment sender, Power steering control unit, Data bus diagnostic interface, Fuse 3 in fuse holder A, Fuse 14 on fuse holder C, Electromechanical power steering motor

A Battery

G85 Steering angle sender

G269 Steering moment sender

J500 Power steering control unit, in rear left side panel

J533 Data bus diagnostic interface, on left under dash panel

SA3 Fuse 3 in fuse holder A

SC14 Fuse 14 on fuse holder C

T2a 2-pin connector

T3 3-pin connector

T5al 5-pin connector

T5g 5-pin connector

T6z 6-pin connector, near left headlight

T20 20-pin connector

T73b 73-pin connector

V187 Electromechanical power steering motor

= black

508 Threaded connection (30) on E-box

640 Earth point 2, left in engine compartment

A199 Positive connection 4 (15a) in dash panel wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

* see applicable current flow diagram for basic equipment

*2 Only models with "High" equipment (AW1)

*3 Only models with "Low" equipment (AW0)

Rusia

Dual clutch gearbox 02E

From November 2010

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen AGdoesnotguaranteeoracceptanyliabilitywith respect t o t h e c o r r e c t n e ss o f ni

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

Jetta Rusia

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

AGdoesnotguaranteeoracceptanyliabilitywi

Mechatronic unit for dual clutch gearbox

G193 Automatic gearbox hydraulic pressure sender 1

G194 Automatic gearbox hydraulic pressure sender 2

J519 Onboard supply control unit

J623 Engine control unit

J743 Mechatronic unit for dual clutch gearbox

N88 Solenoid valve 1

N89 Solenoid valve 2

N90 Solenoid valve 3

N91 Solenoid valve 4

N92 Solenoid valve 5

SB17 Fuse 17 on fuse holder B

SC25 Fuse 25 on fuse holder C

T20e 20-pin connector

T52c 52-pin connector

T73b 73-pin connector

T94 94-pin connector

85 Earth connection 1, in engine compartment wiring harness

655 Earth point, on left headlight

D104 Positive connection 2 (30a), in engine compartment wiring harness

D109 Connection 7 in engine compartment wiring harness

U8 Positive connection (15a), in automatic gearbox wiring harness

* see applicable current flow diagram for engine

*2 Only models with "High" equipment (AW1)

*3 Only models with "Low" equipment (AW0)

*4 Cross section depends on equipment

*5 Up to May 2012

Jetta Rusia

Gearbox input speed sender, Clutch temperature sender, Mechatronic unit for dual clutch gearbox

G182 Gearbox input speed sender

G195 Gearbox output speed sender

G196 Gearbox output speed sender 2

G487 Gear selector movement sensor 1

G488 Gear selector movement sensor 2

G489 Gear selector movement sensor 3

G490 Gear selector movement sensor 4

G501 Input shaft speed sender 1

G502 Input shaft speed sender 2

G509 Clutch temperature sender

J743 Mechatronic unit for dual clutch gearbox

N215 Automatic gearbox pressure regulating valve 1

N216 Automatic gearbox pressure regulating valve 2

N217 Automatic gearbox pressure regulating valve 3

N218 Automatic gearbox pressure regulating valve 4

N233 Automatic gearbox pressure regulating valve 5

N371 Automatic gearbox pressure regulating valve 6

T4 4-pin connector

Jetta Rusia

Selectorleversensorscontrolunit,Mechatronicunitfordual clutch gearbox

D Ignition/starter switch

F319 Selector lever locked in position P switch

G93 Gearbox oil temperature sender

G510 Temperature sender in control unit

J527 Steering column electronics control unit

J587 Selector lever sensors control unit

J743 Mechatronic unit for dual clutch gearbox

J764 Control unit for electronic steering column lock

T10 10-pin connector

T10s 10-pin connector

T16l 16-pin connector

T16v 16-pin connector

T20e 20-pin connector

43 Earth point, lower part of right A-pillar

366 Earth connection 1, in main wiring harness

388 Earth connection 23, in main wiring harness

B114 Connection (inhibitor switch), in interior wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

* Only models with entry and start authorisation

*2 According to equipment

*3 Only models with no entry and start authorisation

Jetta Rusia

. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w ho

Selector lever sensors control unit, Selector lever display illuminationbulb,Selectorleverlocksolenoid,Selectorlever position display

E313 Selector lever

J519 Onboard supply control unit

J587 Selector lever sensors control unit

L101 Selector lever display illumination bulb

N110 Selector lever lock solenoid

SC14 Fuse 14 on fuse holder C

SC20 Fuse 20 on fuse holder C

T1fa Single connector

T2p 2-pin connector

T10s 10-pin connector

T10v 10-pin connector

T52b 52-pin connector

T73b 73-pin connector

Y6 Selector lever position display

A189 Positive connection 5 (30a) in dash panel wiring harness

A199 Positive connection 4 (15a) in dash panel wiring harness

B340 Connection 1 (58d), in main wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

* Only models with "Low" equipment (AW0)

*2 Only models with "High" equipment (AW1)

*3 Up to May 2012

*4 From June 2012

Jetta Rusia

icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

grey

purple

purple

yellow

orange

= pink

Control unit in dash panel insert, Data bus diagnostic interface

J285 Control unit in dash panel insert

J519 Onboard supply control unit

J533 Data bus diagnostic interface

T16 16-pin connector

T20 20-pin connector

T32 32-pin connector

T73b 73-pin connector

A76 Connection (K-diagnosis wire), in dash panel wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

B590 K-diagnosis wire connection, in interior wiring harness

* Only models with "Low" equipment (AW0)

*2 Diagnostic connection

*3 Only models with "High" equipment (AW1)

Jetta Rusia

Dual clutch gearbox 0AM

From November 2010

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen AGdoesnotguaranteeoracceptanyliabilitywi

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

Jetta Rusia

Enginecontrolunit,Mechatronicunitfordualclutchgearbox

G182 Gearbox input speed sender

G487 Gear selector movement sensor 1

G488 Gear selector movement sensor 2

G510 Temperature sender in control unit

J623 Engine control unit

J743 Mechatronic unit for dual clutch gearbox

SB17 Fuse 17 on fuse holder B

SB18 Fuse 18 on fuse holder B

SC25 Fuse 25 on fuse holder C

T25 25-pin connector

T94 94-pin connector

V401 Hydraulic pump motor

85 Earth connection 1, in engine compartment wiring harness

655 Earth point, on left headlight

U8 Positive connection (15a), in automatic gearbox wiring harness

* Only models with Euro 6 emission standard *2 Only for American markets

Jetta Rusia Current Flow Diagram

Selectorleversensorscontrolunit,Mechatronicunitfordual clutch gearbox

F319 Selector lever locked in position P switch

G270 Gearbox hydraulic pressure sender

G641 Gearbox input speed sender 3

J527 Steering column electronics control unit

J587 Selector lever sensors control unit

J743 Mechatronic unit for dual clutch gearbox

J764 Control unit for electronic steering column lock

N110 Selector lever lock solenoid

SC14 Fuse 14 on fuse holder C

SC20 Fuse 20 on fuse holder C

T2p 2-pin connector

T10s 10-pin connector, under selector lever

T16l 16-pin connector

T16v 16-pin connector

43 Earth point, lower part of right A-pillar

366 Earth connection 1, in main wiring harness

388 Earth connection 23, in main wiring harness

A189 Positive connection 5 (30a) in dash panel wiring harness

A199 Positive connection 4 (15a) in dash panel wiring harness

B114 Connection (inhibitor switch), in interior wiring harness

* Only models with entry and start authorisation

*2 According to equipment

*3 Only models with no entry and start authorisation

Jetta Rusia

Selectorleversensorscontrolunit,Mechatronicunitfordual clutch gearbox, Selector lever display illumination bulb, Selector lever position display

E313 Selector lever

G489 Gear selector movement sensor 3

G490 Gear selector movement sensor 4

G617 Clutch travel sender 1

G618 Clutch travel sender 2

J519 Onboard supply control unit

J587 Selector lever sensors control unit

J743 Mechatronic unit for dual clutch gearbox

L101 Selector lever display illumination bulb

N433 Valve 1 in sub-gearbox 1

N434 Valve 2 in sub-gearbox 1

N435 Valve 3 in sub-gearbox 1

N440 Valve 4 in sub-gearbox 2

T10s 10-pin connector, under selector lever

T10v 10-pin connector

T25 25-pin connector

T52b 52-pin connector

Y6 Selector lever position display

B340 Connection 1 (58d), in main wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

Jetta Rusia

Power and control electronics for electric drive, Control unit in dash panel insert, Data bus diagnostic interface, Mechatronic unit for dual clutch gearbox

G612 Gearbox input speed sender 2

G632 Gearbox input speed sender 1

JX1 Power and control electronics for electric drive

J285 Control unit in dash panel insert

J533 Data bus diagnostic interface

J743 Mechatronic unit for dual clutch gearbox

N436 Valve 4 in sub-gearbox 1

N437 Valve 1 in sub-gearbox 2

N438 Valve 2 in sub-gearbox 2

N439 Valve 3 in sub-gearbox 2

T16 16-pin connector, on diagnostic connection

T20 20-pin connector

T25 25-pin connector

T28jx 28-pin connector

T32 32-pin connector

A76 Connection (K-diagnosis wire), in dash panel wiring harness

B383 Connection1(powertrainCANbus,high),inmainwiringharness

B390 Connection 1 (powertrain CAN bus, low), in main wiring harness

B708 Connection 1 (dash panel insert CAN bus high) in main wiring harness

B709 Connection 1 (dash panel insert CAN bus low) in main wiring harness

* From June 2013

Air conditioning system , (9AP),(KH6)

From April 2010

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen

Jetta Rusia

High-pressure sender, Air conditioning system control unit

G65 High-pressure sender

J301 Air conditioning system control unit

J680 Terminal 75 voltage supply relay 1

J681 Terminal 15 voltage supply relay 2

SA4 Fuse 4 in fuse holder A

SC13 Fuse 13 on fuse holder C

SC20 Fuse 20 on fuse holder C

SC33 Fuse 33 on fuse holder C

T3c 3-pin connector

T9f 9-pin connector

T9x 9-pin connector

T20c 20-pin connector

44 Earth point, lower part of left A-pillar

367 Earth connection 2, in main wiring harness

389 Earth connection 24, in main wiring harness

A189 Positive connection 5 (30a) in dash panel wiring harness

A217 Positive connection 8 (15a) in dash panel wiring harness

B111 Positive connection 1 (30a), in interior wiring harness

B163 Positive connection 1 (15), in interior wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

* see applicable current flow diagram for basic equipment

*2 Gradually discontinued

*3 Cross-section 16.0 possible

*4 Wiring colour depends on equipment

*5 Cross-section 6.0 possible

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE

Jetta Rusia Current Flow Diagram

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,

Footwell vent temperature sender, Potentiometer for left temperature flap control motor, Evaporator output temperature sender, Air conditioning system control unit, Temperature flap control motor

E159 Fresh air and air recirculation flap switch

G192 Footwell vent temperature sender

G220 Potentiometer for left temperature flap control motor

G263 Evaporator output temperature sender

G267 Potentiometer for temperature selection rotary knob

J301 Air conditioning system control unit

K10 Heated rear window warning lamp

K114 Fresh air and air recirculation warning lamp

T6k 6-pin connector

T6m 6-pin connector

T16e 16-pin connector

V68 Temperature flap control motor

V113 Air recirculation flap control motor

L2 Connection in air conditioning system wiring harness

L10 Connection 2, in air conditioning system wiring harness

* Only models with Climatic

Jetta Rusia

Centre vent temperature sender, Potentiometer for air distribution flap control motor, Air conditioning system

controlunit,Airconditionercompressorregulatingvalve,Air distribution flap control motor

E30 Air conditioning system switch

E94 Heated driver seat regulator

E95 Heated front passenger seat regulator

E230 Heated rear window button

G191 Centre vent temperature sender

G645 Potentiometer for air distribution flap control motor

J301 Air conditioning system control unit

J774 Heated front seats control unit

N280 Air conditioner compressor regulating valve

T4t 4-pin connector

T6aj 6-pin connector

T8z 8-pin connector

T10c 10-pin connector, under driver seat

T16e 16-pin connector

T20c 20-pin connector

V428 Air distribution flap control motor

132 Earth connection 3, in engine compartment wiring harness

376 Earth connection 11, in main wiring harness

655 Earth point, on left headlight

B431 Connection (seat heating), in main wiring harness

L2 Connection in air conditioning system wiring

L10 Connection 2, in air conditioning system wiring harness

M45 Connection 5, in driver seat wiring harness

* Only models with Climatic

*2 Only models with seat heating

*3 Wiring colour depends on equipment

Jetta Rusia

AGdoesnotguaranteeoracceptanyliabilitywi

Freshairblowerswitch,Airconditioningsystemcontrolunit, Freshairblowerseriesresistorwithoverheatingfuse,Fresh air blower

E9 Fresh air blower switch

J301 Air conditioning system control unit

J485 Auxiliary heater operation relay

J533 Data bus diagnostic interface

N24 Fresh air blower series resistor with overheating fuse

T4f 4-pin connector

T5 5-pin connector

T10a 10-pin connector, on heater unit

T20 20-pin connector

T20c 20-pin connector

T73b 73-pin connector

V2 Fresh air blower

43 Earth point, lower part of right A-pillar

366 Earth connection 1, in main wiring harness

388 Earth connection 23, in main wiring harness

602 Earth point, in front left footwell

B397 Connection 1 (convenience CAN bus, high), in main wiring harness

B406 Connection 1 (convenience CAN bus, low), in main wiring harness

L5 Connection 1, in evaporator housing unit wiring harness

L6 Connection 2, in evaporator housing unit wiring harness

* Only models with auxiliary coolant heater

*2 Only models with "High" equipment (AW1)

*3 Only models with "Low" equipment (AW0)

Climatronic , (9AK),(AW1)

From October 2010

.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof

thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen AGdoesnotguaranteeoracceptanyliabilitywith respect

Jetta Rusia Current Flow Diagram

Battery, Terminal 15 voltage supply relay 2

A Battery

C Alternator

J681 Terminal 15 voltage supply relay 2

SA1 Fuse 1 in fuse holder A

SA4 Fuse 4 in fuse holder A

SB Fuse holder B

SC Fuse holder C

SC13 Fuse 13 on fuse holder C

SC20 Fuse 20 on fuse holder C

SC24 Fuse 24 on fuse holder C

SC49 Fuse 49 on fuse holder C

T9f 9-pin connector

1 Earth strap, battery - body

508 Threaded connection (30) on E-box

B111 Positive connection 1 (30a), in interior wiring harness

B163 Positive connection 1 (15), in interior wiring harness

B169 Positive connection 1 (30), in interior wiring harness

B170 Positive connection 2 (30), in interior wiring harness

* Gradually discontinued

*2 see applicable current flow diagram for basic equipment

*3 Cross-section 16.0 possible

Jetta Rusia Current Flow Diagram

High-pressure sender, Climatronic control unit

G65 High-pressure sender

J255 Climatronic control unit

J681 Terminal 15 voltage supply relay 2

J774 Heated front seats control unit

T3c 3-pin connector

T6g 6-pin connector

T9f 9-pin connector

T10c 10-pin connector

T10d 10-pin connector

T20c 20-pin connector 43 Earth point,

Earth connection 2, in

harness 388 Earth connection 23, in main wiring harness 389 Earth connection 24, in main wiring harness

A189 Positive connection 5 (30a) in dash panel wiring harness

A217 Positive connection 8 (15a) in dash panel wiring harness

B431 Connection (seat heating), in main wiring harness

M45 Connection 5, in driver seat wiring harness

* Only models with seat heating

*2 see applicable current flow diagram for seat heating

*3 see applicable current flow diagram for basic equipment

*4 Wiring colour depends on equipment

Jetta Rusia Current Flow Diagram

Sunlight penetration photosensor, Left vent temperature sender, Right vent temperature sender, Left footwell vent temperature sender, Evaporator temperature sensor, Climatronic control unit

G107 Sunlight penetration photosensor

G134 Sunlight penetration photosensor 2

G150 Left vent temperature sender

G151 Right vent temperature sender

G238 Air quality sensor

G261 Left footwell vent temperature sender

G308 Evaporator temperature sensor

J255 Climatronic control unit

T2bh 2-pin connector

T2bq 2-pin connector

T2da 2-pin connector

T2j 2-pin connector

T3aw 3-pin connector

T4n 4-pin connector

T16g 16-pin connector

T20c 20-pin connector

80 Earth connection 1, in dash panel wiring harness

L7 Connection 3, in evaporator housing unit wiring harness

L9 Connection 1, in air conditioning system wiring harness

* According to equipment

*2 Wiring colour depends on equipment

Jetta Rusia

Potentiometer for defroster flap control motor, Potentiometer for left temperature flap control motor, Right footwell vent temperature sender, Climatronic control unit, Defroster flap control motor, Left temperature flap control motor

G135 Potentiometer for defroster flap control motor

G220 Potentiometer for left temperature flap control motor

G262 Right footwell vent temperature sender

J255 Climatronic control unit

T2db 2-pin connector

T6p 6-pin connector

T6q 6-pin connector

T16e 16-pin connector

T16g 16-pin connector

V107 Defroster flap control motor

V158 Left temperature flap control motor

L7 Connection 3, in evaporator housing unit wiring harness

L8 Connection 4, in evaporator housing unit wiring harness

= white

= red

= red

= brown

= green

= blue

= grey

= purple

= purple

= yellow

= orange

= pink

Jetta Rusia

purple

yellow

Potentiometer for centre flap servomotor, Potentiometer for righttemperatureflapcontrolmotor,Potentiometerforfresh air/recirculated air, air flow flap control motor, Climatronic control unit, Centre flap control motor, Right temperature flap control motor, Fresh air/recirculated air, air flow flap control motor

G112 Potentiometer for centre flap servomotor

G221 Potentiometer for right temperature flap control motor

G644 Potentiometer for fresh air/recirculated air, air flow flap control motor

J255 Climatronic control unit

T6n 6-pin connector

T6r 6-pin connector

T6t 6-pin connector

T16e 16-pin connector

T16g 16-pin connector

V70 Centre flap control motor

V159 Right temperature flap control motor

V425 Fresh air/recirculated air, air flow flap control motor

L7 Connection 3, in evaporator housing unit wiring harness

L8 Connection 4, in evaporator housing unit wiring harness

Jetta Rusia

icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen

thgirypocybdetcetorP

Fresh air blower control unit, Climatronic control unit, Onboard supply control unit, Air conditioner compressor regulating valve, Fresh air blower

J126 Fresh air blower control unit

J255 Climatronic control unit

J519 Onboard supply control unit

J533 Data bus diagnostic interface

N280 Air conditioner compressor regulating valve

T2m 2-pin connector

T4t 4-pin connector

T6t 6-pin connector

T10a 10-pin connector

T14hy 14-pin connector

T16e 16-pin connector

T20 20-pin connector

T20c 20-pin connector

T52c 52-pin connector

V2 Fresh air blower

132 Earth connection 3, in engine compartment wiring harness

376 Earth connection 11, in main wiring harness

602 Earth point, in front left footwell

655 Earth point, on left headlight

B397 Connection 1 (convenience CAN bus, high), in main wiring harness

B406 Connection 1 (convenience CAN bus, low), in main wiring harness

* Only models with hybrid drive system

*2 Wiring colour depends on equipment

CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL

• Thank you very much for reading the preview of the manual.

• You can download the complete manual from: www.heydownloads.com by clicking the link below

• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.

CLICK HERE TO DOWNLOAD THE
