ws = white sw = black ro = red rt = red br = brown
gn = green bl = blue gr = grey li = purple vi = purple
ge = yellow or = orange
rs = pink
Battery, Starter, Starter motor relay, Fuse 2 on fuse holder
A Battery
B Starter
J53 Starter motor relay
SA2 Fuse 2 on fuse holder A
T18 18-pin connector, black, near engine/motor control unit
T18a 18-pin connector, grey, near engine/motor control unit
1 Earth strap, battery - body
B322 Positive connection 8 (30a) in main wiring harness
B729 Connection 1 (50), in main wiring harness
D78 Positive connection 1 (30a), in engine compartment wiring harness
* For models with diesel engine
*2 For models with petrol engine
Terminal 58b relief relay, Voltage supply relay 2
J374 Terminal 58b relief relay
J710 Voltage supply relay 2
T6d 6-pin connector, grey, on relay carrier
366 Earth connection 1, in main wiring harness
B315 Positive connection 1 (30a) in main wiring harness
B476 Connection 12, in main wiring harness
purple
yellow
orange
= pink
Alternatorwithvoltageregulator,Terminal15voltagesupply relay, Onboard supply control unit, Engine/motor control unit, Fuse 4 on fuse holder B
CX1 Alternator with voltage regulator
J329 Terminal 15 voltage supply relay
J519 Onboard supply control unit
J623 Engine/motor control unit
SA1 Fuse 1 on fuse holder A
SB4 Fuse 4 on fuse holder B
T18 18-pin connector, black, near engine/motor control unit
T73b 73-pin connector, colourless
T94a 94-pin connector, black
12 Earth point, on left in engine compartment
B569 Connection 36, in main wiring harness
* see applicable current flow diagram for engine
*2 For models with diesel engine
*3 For models with petrol engine
Ignition/starter switch, Onboard supply control unit
D Ignition/starter switch
J16 Current supply relay
J519 Onboard supply control unit
SC8 Fuse 8 on fuse holder C
T6f 6-pin connector, black
T73a 73-pin connector, black
T73b 73-pin connector, colourless
B273 Positive connection (15), in main wiring harness
B276 Positive connection (50), in main wiring harness
B318 Positive connection 4 (30a) in main wiring harness
B490 Connection 26, in main wiring harness
B518 Connection (86s), in main wiring harness
Light switch, Light switch illumination bulb, Fuse 26 on fuse holder C, Fuse 27 on fuse holder C
E1 Light switch
L9 Light switch illumination bulb
SC26 Fuse 26 on fuse holder C
SC27 Fuse 27 on fuse holder C
T17 17-pin connector, black
B489 Connection 25, in main wiring harness
* For models with daytime running lights
= red
red
brown
= blue
purple
purple ge = yellow
orange
Light switch, Fuse 16 on fuse holder C, Fuse 53 on fuse holder C
E1 Light switch
SC16 Fuse 16 on fuse holder C
SC53 Fuse 53 on fuse holder C
T17 17-pin connector, black
B485 Connection 21, in main wiring harness
B522 Connection (FL), in main wiring harness
B626 Positive connection 2 (15), in main wiring harness
* For models with no fog lights and with multifunction display
*2 For models with fog lights
orange
Light switch, Switch and instrument illumination regulator, Headlight range control regulator, Fuse 28 on fuse holder C
E1 Light switch
E20 Switch and instrument illumination regulator
E102 Headlight range control regulator
SC17 Fuse 17 on fuse holder C
SC28 Fuse 28 on fuse holder C
T6c 6-pin connector, black
T17 17-pin connector, black B472 Connection 8, in main wiring harness
N2 Connection 1, in headlight range control wiring harness
N3 Connection 2, in headlight range control wiring harness
* For models with headlight range control
*2 For models with dimmable instrument illumination
*3 For models with Highline equipment
*4 For models with no dimmable instrument illumination
*5 For models with Trendline equipment
*6 For models with basic equipment
= white
= black
= red
= red
Front left headlight
J519 Onboard supply control unit
MX1 Front left headlight
M1 Left side light bulb
M29 Left headlight dipped beam bulb
M30 Left headlight main beam bulb
SC29 Fuse 29 on fuse holder C
SC30 Fuse 30 on fuse holder C
T10 10-pin connector, black
T73a 73-pin connector, black
T73b 73-pin connector, colourless
V48 Left headlight range control motor
B455 Connection (HRC), in main wiring harness
B474 Connection 10, in main wiring harness
B478 Connection 14, in main wiring harness
B486 Connection 22, in main wiring harness
* For models with headlight range control
*2 For models with Highline equipment
= brown
= green
= blue
= purple
= purple
= yellow
= orange
= pink
ws = white sw = black ro = red rt = red br = brown gn = green bl = blue gr = grey li = purple vi = purple
ge = yellow or = orange
rs = pink
Left fog light bulb, Front left headlight, Left turn signal repeater bulb
J519 Onboard supply control unit
L22 Left fog light bulb
L174 Left daytime running light bulb
MX1 Front left headlight
M5 Front left turn signal bulb
M18 Left turn signal repeater bulb
T3e 3-pin connector, black, in rear left of engine compartment
T10 10-pin connector, black
T73b 73-pin connector, colourless
368 Earth connection 3, in main wiring harness
655 Earth point, on left headlight, on left on bulkhead
B469 Connection 5, in main wiring harness
B484 Connection 20, in main wiring harness
CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL
• Thank you very much for reading the preview of the manual.
• You can download the complete manual from: www.heydownloads.com by clicking the link below
• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.
CLICK HERE TO DOWNLOAD THE
Right fog light bulb, Front right headlight, Right turn signal repeater bulb
J519 Onboard supply control unit
L23 Right fog light bulb
L175 Right daytime running light bulb
MX2 Front right headlight
M3 Right side light bulb
M7 Front right turn signal bulb
M19 Right turn signal repeater bulb
T8f 8-pin connector, black, in rear right of engine compartment
T10c 10-pin connector, black
T73a 73-pin connector, black
T73b 73-pin connector, colourless
369 Earth connection 4, in main wiring harness
656 Earth point, on right headlight, on right on bulkhead
B470 Connection 6, in main wiring harness
B473 Connection 9, in main wiring harness
* For models with basic equipment
*2 For models with headlight range control
ws = white sw = black
= red rt = red br = brown gn = green bl = blue gr = grey li = purple
vi = purple
Front right headlight, Fuse 32 on fuse holder C, Fuse 55 on fuse holder C
MX2 Front right headlight
M31 Right headlight dipped beam bulb
M32 Right headlight main beam bulb
SC32 Fuse 32 on fuse holder C
SC55 Fuse 55 on fuse holder C
T10c 10-pin connector, black
V49 Right headlight range control motor
376 Earth connection 11, in main wiring harness
B487 Connection 23, in main wiring harness
* For models with headlight range control
ge = yellow or = orange rs = pink
Left tail light cluster, Left number plate light
L46 Rear left fog light bulb
MX3 Left tail light cluster
M4 Left tail light bulb
M6 Rear left turn signal bulb
M9 Left brake light bulb
M16 Left reversing light bulb
T5i 5-pin connector, black
T14 14-pin connector, black, behind rear bumper on left
T18a 18-pin connector, grey, near engine/motor control unit
T42 42-pin connector, black, near handbrake lever
X4 Left number plate light
68 Earth point, on left of rear cross member
86 Earth connection 1, in rear wiring harness
196 Earth connection 3, in rear wiring harness
624 Earth point, starter battery
W1 Positive connection 1 (54), in rear wiring harness
W70 Positive connection 2 (58), in number plate wiring harness
* For models with rear fog light
*2 see applicable current flow diagram for preparation for trailer coupling
*3 For models with no rear fog light
*4 For models with no towing bracket
*5 For models with Highline equipment
*6 For models with Trendline equipment
*7 For models with basic equipment
Reversing light switch, Right tail light cluster, Right number plate light
F4 Reversing light switch
M2 Right tail light bulb
MX4 Right tail light cluster
M8 Rear right turn signal bulb
M10 Right brake light bulb
M17 Right reversing light bulb
SC3 Fuse 3 on fuse holder C
T5k 5-pin connector, black
T18a 18-pin connector, grey, near engine/motor control unit
T42 42-pin connector, black, near handbrake lever
X5 Right number plate light
86 Earth connection 1, in rear wiring harness
196 Earth connection 3, in rear wiring harness
197 Earth connection 4, in rear wiring harness
W3 Connection in rear wiring harness
W70 Positive connection 2 (58), in number plate wiring harness
* For models with headlight range control
*2 For models with Highline equipment
*3 For models with diesel engine
*4 For models with no rear fog light
Brake light switch
F Brake light switch
SC42 Fuse 42 on fuse holder C
T4c 4-pin connector, black
B283 Positive connection 7 (15a) in main wiring harness
B335 Connection 1 (54), in main wiring harness
* For models with cruise control system (CCS)
*2 Country specific
*3 If fitted
*4 For models with Euro 5 emission standard
*5 see applicable current flow diagram for engine
Load area illumination switch, High-level brake light bulb, Load area illumination bulb
E481 Load area illumination switch, near radio
M25 High-level brake light bulb
M53 Load area illumination bulb
SC63 Fuse 63 on fuse holder C
T6a 6-pin connector, black
T6al 6-pin connector, blue
T6d 6-pin connector, grey, on relay carrier
B283 Positive connection 7 (15a) in main wiring harness
B336 Connection 2 (54), in main wiring harness
* For models with headlight range control
thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,
Steering column combination switch, Coil connector, Steering angle sender, Horn plate, Airbag control unit, Multifunction steering wheel control unit
E595 Steering column combination switch
F350 Coil connector, on steering wheel
G85 Steering angle sender
H Horn plate
J234 Airbag control unit
J453 Multifunction steering wheel control unit, in steering wheel
J519 Onboard supply control unit
N95 Airbag igniter on driver side
SC45 Fuse 45 on fuse holder C
T5p 5-pin connector, black
T12b 12-pin connector, yellow
T41 41-pin connector, grey
T50 50-pin connector, yellow
T73a 73-pin connector, black
T73b 73-pin connector, colourless
B316 Positive connection 2 (30a) in main wiring harness
B383 Connection1(powertrainCANbus,high),inmainwiringharness
B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
* For models with anti-lock brake system (ABS) and electronic stabilisation program (ESP)
*2 For models with no multifunction steering wheel
*3 For models with multifunction steering wheel
Turn signal switch, Intermittent wiper switch, Washer pump switch(automaticwash/wipeandheadlightwashersystem), Steering column combination switch, Washer pump
E Windscreen wiper switch
E2 Turn signal switch
E19 Parking light switch
E22 Intermittent wiper switch
E44 Washer pump switch (automatic wash/wipe and headlight washer system)
E595 Steering column combination switch
J519 Onboard supply control unit
SC2 Fuse 2 on fuse holder C
SC18 Fuse 18 on fuse holder C
T6d 6-pin connector, grey, on relay carrier
T8f 8-pin connector, black, in rear right of engine compartment
T41 41-pin connector, grey
T73a 73-pin connector, black
T73b 73-pin connector, colourless
V5 Washer pump
42 Earth point, next to steering column
371 Earth connection 6, in main wiring harness
605 Earth point, on top end of steering column
B480 Connection 16, in main wiring harness
Headlight dipper and flasher switch, Cruise control system switch, Multifunction display call-up button, Multifunction display memory switch, Steering column combination switch
E4 Headlight dipper and flasher switch
E45 Cruise control system switch
E86 Multifunction display call-up button
E109 Multifunction display memory switch
E227 Cruise control system (CCS) SET button
E595 Steering column combination switch
J29 Blocking diode, near steering column
J519 Onboard supply control unit
T1d 1-pin connector, red T1e 1-pin connector, red
T41 41-pin connector, grey
T73b 73-pin connector, colourless
B441 Connection (CCS), in main wiring harness
B475 Connection 11, in main wiring harness
* For models with cruise control system (CCS)
*2 For models with petrol engine
*3 For models with diesel engine
*4 For models with multifunction display
CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL
• Thank you very much for reading the preview of the manual.
• You can download the complete manual from: www.heydownloads.com by clicking the link below
• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.
CLICK HERE TO DOWNLOAD THE
Heated rear window button, Heated rear window
E230 Heated rear window button
J519 Onboard supply control unit
SC4 Fuse 4 on fuse holder C
SC44 Fuse 44 on fuse holder C
T1a 1-pin connector, black
T1c 1-pin connector, black
T6ah 6-pin connector, near radio
T18a 18-pin connector, grey, near engine/motor control unit
T21a 21-pin connector, brown, on relay carrier
T73a 73-pin connector, black
T73b 73-pin connector, colourless
Z1 Heated rear window
81 Earth connection 1, in dash panel wiring harness
* For models with no air conditioning system/Climatronic
Front interior light, Centre interior light
J519 Onboard supply control unit
SC21 Fuse 21 on fuse holder C
T3a 3-pin connector, black
T3b 3-pin connector, black
T73a 73-pin connector, black
W1 Front interior light
W7 Centre interior light
61 Earth point, left C-pillar
79 Earth point on left B-pillar
= white
= black
= red
= red
= brown
= green
= blue
= grey
= purple
= purple
= yellow
= orange
= pink
370 Earth connection 5, in main wiring harness
B559 Positive connection 1 (30g), in main wiring harness
B758 Connection 1 (Dct), in main wiring harness
* For models with double cab
*2 For models with Highline equipment
*3 For models with basic equipment
*4 For models with single cab
Hazard warning lights button, Treble horn, Bass horn
E229 Hazard warning lights button
H2 Treble horn
H7 Bass horn
J519 Onboard supply control unit
SC47 Fuse 47 on fuse holder C
T6ai 6-pin connector, red, near radio
T21a 21-pin connector, brown, on relay carrier
T73a 73-pin connector, black
129 Earth connection, in dual tone horn wiring harness
* For models with Highline equipment
*2 For models with Trendline equipment
*3 For models with basic equipment
Dash panel insert, Windscreen wiper motor
J285 Control unit in dash panel insert
J400 Wiper motor control unit
J519 Onboard supply control unit
K Dash panel insert
K13 Rear fog light warning lamp
SC43 Fuse 43 on fuse holder C
T4e 4-pin connector, black
T32 32-pin connector, blue
T73a 73-pin connector, black
T73b 73-pin connector, colourless
V Windscreen wiper motor
44 Earth point, lower part of left A-pillar 372 Earth connection 7,
Driver side belt switch, Brake fluid level warning contact, Coolant temperature gauge, Ambient temperature sensor, Coolant shortage indicator sender, Ambient temperature indicator, Multifunction indicator, Dash panel insert, Brake fluid level warning lamp, Warning lamp for airbag deactivated on driver side
E24 Driver side belt switch
F34 Brake fluid level warning contact
G3 Coolant temperature gauge
G17 Ambient temperature sensor
G32 Coolant shortage indicator sender
G106 Ambient temperature indicator
J119 Multifunction indicator
J285 Control unit in dash panel insert
K Dash panel insert
K33 Brake fluid level warning lamp
K144 Warning lamp for airbag deactivated on driver side
T32 32-pin connector, blue
374 Earth connection 9, in main wiring harness
* For models with multifunction display
*2 For models with no airbags
Fuel gauge, Fuel pump, Fuel pump control unit, Dash panel insert, Reserve fuel warning lamp
G Fuel gauge sender
G1 Fuel gauge
G23 Fuel pump
J285 Control unit in dash panel insert
J538 Fuel pump control unit
K Dash panel insert
K105 Reserve fuel warning lamp
T5g 5-pin connector, black
T5h 5-pin connector, black
T32 32-pin connector, blue
T42 42-pin connector, black, near handbrake lever
* see applicable current flow diagram for engine
*2 For models with diesel engine
*3 For models with petrol engine
. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen
Clutch pedal switch, Fuel pump relay, Terminal 30 voltage supply relay, Engine/motor control unit
F36 Clutch pedal switch
J17 Fuel pump relay
J317 Terminal 30 voltage supply relay
J623 Engine/motor control unit
SB2 Fuse 2 on fuse holder B
SC15 Fuse 15 on fuse holder C
SC36 Fuse 36 on fuse holder C
T94 94-pin connector, black
T94a 94-pin connector, black
V55 Circulation pump
purple
yellow
orange
= pink
B564 Connection 31, in main wiring harness
* see applicable current flow diagram for engine
*2 For models with petrol engine
*3 For models with cruise control system (CCS)
*4 For models with diesel engine
*5 For models with no air conditioning system/Climatronic
*6 see applicable current flow diagram for air conditioning
*7 seeapplicablecurrentflowdiagramforautomaticairconditioning system
Immobiliser reader coil, Oil pressure switch, Oil level and oil
temperaturesender,Ignitionandstarterkeywarningsystem
buzzer and gong, Dash panel insert, Oil pressure warning lamp, Oil level warning lamp, Radio
D2 Immobiliser reader coil, on ignition/starter switch
F1 Oil pressure switch
G266 Oil level and oil temperature sender
H5 Ignition and starter key warning system buzzer and gong
J285 Control unit in dash panel insert
K Dash panel insert
K3 Oil pressure warning lamp
K38 Oil level warning lamp
R Radio
T3m 3-pin connector, black
T8c 8-pin connector, black
T18 18-pin connector, black, near engine/motor control unit
T21 21-pin connector, blue, on relay carrier
T32 32-pin connector, blue
T42 42-pin connector, black, near handbrake lever
* see applicable current flow diagram for engine
*2 For models with Euro 5 emission standard
*3 Country specific
*4 If fitted
Parkingbrakecontactswitch,Dashpanelinsert,Handbrake warning lamp, Light 1 for front centre console background
lighting, Electric socket, Cigarette lighter, 12 V socket, 12 V socket 2
F321 Parking brake contact switch
J285 Control unit in dash panel insert
K Dash panel insert
K139 Handbrake warning lamp
L193 Light 1 for front centre console background lighting
SC38 Fuse 38 on fuse holder C
SC52 Fuse 52 on fuse holder C
SC54 Fuse 54 on fuse holder C
SC59 Fuse 59 on fuse holder C
T2al 2-pin connector, black, Interface for rear left socket, on wheel housing
T3g 3-pin connector, transparent
T3h 3-pin connector, transparent
T6d 6-pin connector, grey, on relay carrier
T21a 21-pin connector, brown, on relay carrier
T32 32-pin connector, blue
T42 42-pin connector, black, near handbrake lever
U Electric socket
U1 Cigarette lighter
U5 12 V socket
U18 12 V socket 2
373 Earth connection 8, in main wiring harness
A7 Positive connection (58 D1), in dash panel wiring harness
* Special equipment
*2 For models with Highline equipment
*3 For models with multifunction display
CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL
• Thank you very much for reading the preview of the manual.
• You can download the complete manual from: www.heydownloads.com by clicking the link below
• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.
CLICK HERE TO DOWNLOAD THE
Fuel tank filler flap central locking actuator, Bonnet contact switch, Onboard supply control unit, Driver door lock unit,
Frontpassengerdoorlockunit,Rearleftdoorlockunit,Rear right door lock unit
F219 Fuel tank filler flap central locking actuator
F266 Bonnet contact switch
J519 Onboard supply control unit
T2xz 2-pin connector, black, on lock carrier
T6af 6-pin connector, black
T6ar 6-pin connector, black
T6as 6-pin connector, black
T8e 8-pin connector, black
T28 28-pin connector, black, on left B-pillar
T28a 28-pin connector, black, on left A-pillar
T28b 28-pin connector, black, on right A-pillar
T28c 28-pin connector, black, on right B-pillar
T42 42-pin connector, black, near handbrake lever
T73a 73-pin connector, black
VX21 Driver door lock unit
VX22 Front passenger door lock unit
VX23 Rear left door lock unit
VX24 Rear right door lock unit
43 Earth point, lower part of right A-pillar
205 Earth connection, in driver door wiring harness
206 Earth connection, in front passenger door wiring harness
367 Earth connection 2, in main wiring harness
B214 Connection 1 (central locking), in interior wiring harness
B466 Connection 2, in main wiring harness
* For models with no central locking
*2 According to equipment
Central locking, window regulators and mirror adjustment , (L0L)
From December 2009
thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen
Onboard supply control unit, Central locking SAFELOCK function warning lamp, Fuse 20 on fuse holder C, Fuse 66 on fuse holder C
J519 Onboard supply control unit
K133 Central locking SAFELOCK function warning lamp
SC20 Fuse 20 on fuse holder C
SC66 Fuse 66 on fuse holder C
T28a 28-pin connector, black, on left A-pillar
T73a 73-pin connector, black
T73b 73-pin connector, colourless
44 Earth point, lower part of left A-pillar
366 Earth connection 1, in main wiring harness
372 Earth connection 7, in main wiring harness
377 Earth connection 12, in main wiring harness
734 Earth point in front left door
* From July 2011
*2 From November 2011
*3 Only models with double cab
*4 Up to January 2012
*5 Up to October 2011
*6 From January 2012
*7 Up to July 2011
Central locking button, Fuel tank filler flap central locking actuator, Onboard supply control unit
E600 Central locking button, in driver door
F219 Fuel tank filler flap central locking actuator
J519 Onboard supply control unit
T2am 2-pin connector, black, on left wheel housing
T4v 4-pin connector, black
T28a 28-pin connector, black, on left A-pillar
T42 42-pin connector, black, near handbrake lever
T73a 73-pin connector, black
ws = white sw = black ro = red rt = red br = brown gn = green bl = blue gr = grey
li = purple vi = purple ge = yellow or = orange
rs = pink
205 Earth connection, in driver door wiring harness
B214 Connection 1 (central locking), in interior wiring harness
B466 Connection 2, in main wiring harness
* From November 2011
*2 Up to October 2011
Onboard supply control unit, Driver door lock unit, Front passenger door lock unit
J519 Onboard supply control unit
T6af 6-pin connector, black
T8e 8-pin connector, black
T28a 28-pin connector, black, on left A-pillar
T28b 28-pin connector, black, on right A-pillar
T73a 73-pin connector, black
VX21 Driver door lock unit
VX22 Front passenger door lock unit
B214 Connection 1 (central locking), in interior wiring harness
B215 Connection 2 (central locking), in interior wiring harness
B466 Connection 2, in main wiring harness
B467 Connection 3, in main wiring harness
* Only models with double cab
*2 Only models with single cab
Onboard supply control unit, Rear left door lock unit, Rear right door lock unit
J519 Onboard supply control unit
T6ar 6-pin connector, black
T6as 6-pin connector, black
T28 28-pin connector, black, on left B-pillar
T28c 28-pin connector, black, on right B-pillar
T73a 73-pin connector, black
VX23 Rear left door lock unit
VX24 Rear right door lock unit
purple
purple
= yellow
orange
B215 Connection 2 (central locking), in interior wiring harness
B466 Connection 2, in main wiring harness
B467 Connection 3, in main wiring harness
* Only models with double cab
*2 Only models with SAFELOCK function
*3 Up to October 2011
*4 From November 2011
Mirroradjustmentswitch,Onboardsupplycontrolunit,Fuse 19 on fuse holder C, Fuse 33 on fuse holder C
E43 Mirror adjustment switch, in driver door
J519 Onboard supply control unit
SC19 Fuse 19 on fuse holder C
SC33 Fuse 33 on fuse holder C
T10d 10-pin connector, black
T28a 28-pin connector, black, on left A-pillar
T73a 73-pin connector, black
T73b 73-pin connector, colourless
R14 Connection 1 (open), in driver door wiring harness
R95 Connection 2 in driver side door wiring harness
R96 Connection 3 in driver side door wiring harness
Z2 Connection 2, in mirror adjustment/heating wiring harness
* Up to October 2011
*2 From November 2011
thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen
Suppression filter, Onboard supply control unit, Driver side exterior mirror
C10 Suppression filter, in left door
J519 Onboard supply control unit
T6ae 6-pin connector, blue, in left door, near exterior mirror
T10o 10-pin connector, black, in left door, near exterior mirror
T28a 28-pin connector, black, on left A-pillar
T73a 73-pin connector, black
VX4 Driver side exterior mirror
V17 Driver side mirror adjustment motor 2
V149 Driver side mirror adjustment motor
Z4 Heated exterior mirror on driver side
B471 Connection 7, in main wiring harness
R95 Connection 2 in driver side door wiring harness
R96 Connection 3 in driver side door wiring harness
Z1 Connection 1, in mirror adjustment/heating wiring harness
Z2 Connection 2, in mirror adjustment/heating wiring harness
* According to equipment
*2 Adapter wire
Front driver side window regulator button, Rear driver side window regulator button, in driver door, Rear passenger side window regulator button, in driver door, Front passenger side window regulator button, in driver door,
Driver door control unit, Onboard supply control unit, Fuse
48 on fuse holder C, Driver side window regulator motor
E318 Childproof lock button
E710 Front driver side window regulator button
E712 Rear driver side window regulator button, in driver door
E714 Rear passenger side window regulator button, in driver door
E715 Front passenger side window regulator button, in driver door
J386 Driver door control unit
J519 Onboard supply control unit
K236 Warning light for activated childproof lock
L76 Button illumination bulb
SC48 Fuse 48 on fuse holder C
T4bk 4-pin connector, black
T10e 10-pin connector, black
T16e 16-pin connector, black
T28a 28-pin connector, black, on left A-pillar
T73b 73-pin connector, colourless
V147 Driver side window regulator motor
B528 Connection 1 (LIN bus) in main wiring harness
R94 Connection 1 in driver side door wiring harness
* Only models with double cab
*2 Only models with single cab
*3 According to equipment
*4 see applicable current flow diagram for exterior lighting
*5 Up to October 2011
*6 From November 2011
CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL
• Thank you very much for reading the preview of the manual.
• You can download the complete manual from: www.heydownloads.com by clicking the link below
• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.
CLICK HERE TO DOWNLOAD THE
= white
Front passenger side window regulator button, Front passengerdoorcontrolunit,Fuse49onfuseholderC,Front passenger side window regulator motor
E716 Front passenger side window regulator button
J387 Front passenger door control unit
SC49 Fuse 49 on fuse holder C
T4ab 4-pin connector, black
T16f 16-pin connector, black
T28b 28-pin connector, black, on right A-pillar
V148 Front passenger side window regulator motor
43 Earth point, lower part of right A-pillar
green
purple
orange
206 Earth connection, in front passenger door wiring harness
367 Earth connection 2, in main wiring harness
735 Earth point in front right door
B528 Connection 1 (LIN bus) in main wiring harness
* Only models with double cab
*2 From July 2011
*3 Up to July 2011
. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen
Switch and instrument illumination regulator, Fuse 28 on fuse holder C, Front passenger side exterior mirror
E20 Switch and instrument illumination regulator
SC28 Fuse 28 on fuse holder C
T6aa 6-pin connector, blue, in right door, near exterior mirror
T10p 10-pin connector, black, in right door, near exterior mirror
T28b 28-pin connector, black, on right A-pillar
VX5 Front passenger side exterior mirror
V25 Front passenger side mirror adjustment motor 2
V150 Front passenger side mirror adjustment motor
Z5 Heated exterior mirror on front passenger side
B340 Connection 1 (58d), in main wiring harness
B472 Connection 8, in main wiring harness
B528 Connection 1 (LIN bus) in main wiring harness
* Up to October 2011
*2 Only models with double cab
*3 From November 2011
*4 According to equipment
*5 Adapter wire
*6 see applicable current flow diagram for exterior lighting
Rear driver side window regulator button, Rear passenger side window regulator button, Rear left door control unit, Rear right door control unit, Fuse 50 on fuse holder C, Fuse 51 on fuse holder C, Rear left window regulator motor, Rear right window regulator motor
E711 Rear driver side window regulator button, in rear left door
E713 Rear passenger side window regulator button, in rear right door
J388 Rear left door control unit
J389 Rear right door control unit
SC50 Fuse 50 on fuse holder C
SC51 Fuse 51 on fuse holder C
T4ae 4-pin connector, black
T4ag 4-pin connector, black
T16h 16-pin connector, black
T16i 16-pin connector, black
T28 28-pin connector, black, on left B-pillar
T28c 28-pin connector, black, on right B-pillar
V26 Rear left window regulator motor
V27 Rear right window regulator motor
B528 Connection 1 (LIN bus) in main wiring harness
* Only models with double cab
*2 Up to January 2012
*3 Up to October 2011
*4 From November 2011
*5 From January 2012
purple
purple
yellow
orange
= pink
Climatic
From December 2009
thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen AGdoesnotguaranteeoracceptanyliabilitywith respect t o t h e c o r r e c t n e ss o f ni.GAnegawskloVybthgirypoC.tnemucodsihtninoitamrof
thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen
Battery, Fuse 2 on fuse holder A, Fuse 42 on fuse holder C, Fuse 45 on fuse holder C
A Battery
D Ignition/starter switch
J329 Terminal 15 voltage supply relay
SA2 Fuse 2 on fuse holder A
SC42 Fuse 42 on fuse holder C
SC45 Fuse 45 on fuse holder C
1 Earth strap, battery - body
379 Earth connection 14, in main wiring harness
B273 Positive connection (15), in main wiring harness
B315 Positive connection 1 (30a) in main wiring harness
B316 Positive connection 2 (30a) in main wiring harness
B322 Positive connection 8 (30a) in main wiring harness
B626 Positive connection 2 (15), in main wiring harness
D78 Positive connection 1 (30a), in engine compartment wiring harness
* From November 2011
orange
Auxiliary coolant heater relay, Fuse 62 on fuse holder C, Circulation pump
J493 Auxiliary coolant heater relay
SC62 Fuse 62 on fuse holder C
V55 Circulation pump
43 Earth point, lower part of right A-pillar
368 Earth connection 3, in main wiring harness
372 Earth connection 7, in main wiring harness
380 Earth connection 15, in main wiring harness
655 Earth point, on left headlight
B317 Positive connection 3 (30a) in main wiring harness
D78 Positive connection 1 (30a), in engine compartment wiring harness
L62 Positive connection (30a), in auxiliary heater wiring harness
* For models with diesel engine
*2 Up to November 2011
*3 Up to July 2011
*4 From November 2011
*5 From July 2011
= black
= red
red
= brown
= green
= blue
= grey
purple
= purple
yellow
= orange rs = pink
Fuse 15 on fuse holder C, Circulation pump
J317 Terminal 30 voltage supply relay
J623 Engine/motor control unit
SC15 Fuse 15 on fuse holder C
SC36 Fuse 36 on fuse holder C
T18 18-pin connector, black
T94 94-pin connector, black
T94a 94-pin connector, black
V55 Circulation pump
375 Earth connection 10, in main wiring harness
B564 Connection 31, in main wiring harness
* For models with diesel engine
*2 For models with petrol engine
. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole,
= green
= blue
= purple
= purple
= yellow
= orange
= pink
Air conditioning system control unit, Fresh air blower series resistor with overheating fuse, Fuse 64 on fuse holder C, Fresh air blower
J16 Current supply relay
J301 Air conditioning system control unit
N24 Fresh air blower series resistor with overheating fuse
SC64 Fuse 64 on fuse holder C
T2bp 2-pin connector, on relay carrier, black
T4ah 4-pin connector
T5n 5-pin connector, black
T17a 17-pin connector, behind glove compartment, black
T20 20-pin connector, black
V2 Fresh air blower
80 Earth connection 1, in dash panel wiring harness
377 Earth connection 12, in main wiring harness
B491 Positive connection (75), in interior wiring harness
L9 Connection 1, in air conditioning system wiring harness
High-pressure sender, Air conditioning system control unit, Onboard supply control unit
G65 High-pressure sender
J301 Air conditioning system control unit
J519 Onboard supply control unit
T3v 3-pin connector
T16 16-pin connector, black
T17a 17-pin connector, behind glove compartment, black
T20 20-pin connector, black
T21 21-pin connector, on relay carrier, blue
T73b 73-pin connector
U31 Diagnostic connection
44 Earth point, lower part of left A-pillar
366 Earth connection 1, in main wiring harness
371 Earth connection 6, in main wiring harness
B283 Positive connection 7 (15a) in main wiring harness
B398 Connection 2 (convenience CAN bus, high), in main wiring harness
B407 Connection 2 (convenience CAN bus, low), in main wiring harness
* Up to July 2011
*2 For models with diesel engine
*3 From November 2011
CLICK HERE TO DOWNLOAD THE COMPLETE MANUAL
• Thank you very much for reading the preview of the manual.
• You can download the complete manual from: www.heydownloads.com by clicking the link below
• Please note: If there is no response to CLICKING the link, please download this PDF first and then click on it.
CLICK HERE TO DOWNLOAD THE
= white
= red
= brown
Potentiometer for defroster flap control motor, Air conditioningsystemcontrolunit,Airconditionercompressor regulating valve, Defroster flap control motor, Air recirculation flap control motor
G135 Potentiometer for defroster flap control motor
J301 Air conditioning system control unit
N280 Air conditioner compressor regulating valve
T6au 6-pin connector
T6ay 6-pin connector
T16k 16-pin connector, black
T17a 17-pin connector, behind glove compartment, black
T20 20-pin connector, black
T21 21-pin connector, on relay carrier, blue
T42 42-pin connector, near handbrake lever, black
V107 Defroster flap control motor
V113 Air recirculation flap control motor
68 Earth point, on left of rear cross member
86 Earth connection 1, in rear wiring harness
112 Earth connection 2, in air conditioning system wiring harness
196 Earth connection 3, in rear wiring harness
L31 Connection (5V), in air conditioning system wiring harness
Potentiometer for temperature flap control motor, Potentiometer for footwell vent control motor, Air conditioning system control unit, Temperature flap control motor, Footwell flap control motor
G92 Potentiometer for temperature flap control motor
G468 Potentiometer for footwell vent control motor
J301 Air conditioning system control unit
T6aw 6-pin connector
T6ax 6-pin connector
T16k 16-pin connector, black
T20 20-pin connector, black
V68 Temperature flap control motor
V261 Footwell flap control motor
112 Earth connection 2, in air conditioning system wiring harness
L31 Connection (5V), in air conditioning system wiring harness
Centreventtemperaturesender,Footwellventtemperature sender, Evaporator temperature sensor, Potentiometer for air distribution flap control motor, Air conditioning system control unit, Air distribution flap control motor
G191 Centre vent temperature sender
G192 Footwell vent temperature sender
G308 Evaporator temperature sensor
G645 Potentiometer for air distribution flap control motor
J301 Air conditioning system control unit
T6av 6-pin connector
T16k 16-pin connector, black
T20 20-pin connector, black
V428 Air distribution flap control motor 97 Earth connection 1,
L31 Connection (5V), in air conditioning system wiring harness
Anti-lock brake system (ABS) with electronic differential lock (EDL) and traction control system (TCS)
From December 2009
thgirypocybdetcetorP . icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen AG. Volkswagen
Battery,ABScontrolunit,Onboardsupplycontrolunit,Fuse 1 on fuse holder B, Fuse 2 in fuse holder A, Fuse 4 on fuse holder B, Fuse 20 on fuse holder C
A Battery
J104 ABS control unit
J519 Onboard supply control unit
SB1 Fuse 1 on fuse holder B
SA2 Fuse 2 in fuse holder A
SB3 Fuse 3 on fuse holder B
SB4 Fuse 4 on fuse holder B
SC20 Fuse 20 on fuse holder C, black
T18a 18-pin connector, grey, near engine control unit
T47 47-pin connector, black
T73b 73-pin connector, colourless
1 Earth strap, battery - body
12 Earth point, on left in engine compartment
purple
yellow
orange
508 Threaded connection (30) on E-box
B317 Positive connection 3 (30a) in main wiring harness
D78 Positive connection 1 (30a), in engine compartment wiring harness
Brakelightswitch,ABScontrolunit,Onboardsupplycontrol unit, Fuse 1 on fuse holder C
F Brake light switch
J104 ABS control unit
J329 Terminal 15 voltage supply relay
J519 Onboard supply control unit
J623 Engine control unit
M25 High-level brake light bulb
SC1 Fuse 1 on fuse holder C
SC42 Fuse 42 on fuse holder C
T4c 4-pin connector, black
T6a 6-pin connector, black
T42 42-pin connector, black, near handbrake lever
T47 47-pin connector, black
T73a 73-pin connector, black
T73b 73-pin connector, colourless
T94 94-pin connector, black
T94a 94-pin connector, black
44 Earth point, lower part of left A-pillar
372 Earth connection 7, in main wiring harness
380 Earth connection 15, in main wiring harness
B279 Positive connection 3 (15a) in main wiring harness
B283 Positive connection 7 (15a) in main wiring harness
B335 Connection 1 (54), in main wiring harness
B626 Positive connection 2 (15), in main wiring harness
* Only models with electronic stabilisation program (ESP)
*2 Up to July 2011
*3 Only models with diesel engine
*4 Only models with petrol engine
*5 From July 2011
*6 Only left-hand drive models
. icremmocroetavirprofgniypoCla rup op s e s , i n p a r t o r in w hole, isnotpermittedunlessauthorisedbyVolkswagen
