Massey Ferguson
353570X1 4 Bolt (7/16 x 2-3/8" NF, Hex.)
31731515 2 Washer (Special)
31731516 2 Washer (Special)
330811 1 Spacer 16 410132 1 Gear, Crankshaft
33176137 1 Washer, Oil Thrower
31147788 1 Pulley, Crankshaft (4 Holes)
36271704 1 Key, Pulley
32162312 1 Bolt, Crankshaft Pulley
33125112 1 Washer
31137212 AR Washer (Upper)(+.007")
31137222 AR Washer (Lower)(+.007")
41112797 1 Flywheel Assembly
410236 1 Ring Gear
353595X1 6 Bolt (1/2 x 1-1/2" NF, Hex.)
33117121 6 Washer, Flat (33/64 x 15/16 x 7/64")
(Order 68084C)
Massey Ferguson
240 TRACTOR (PRIOR TO 522354)
CYLINDER BLOCK
Item Part Number Qty Description
1
1688286M91 1 (A) Engine Assembly (Complete)
1683696M91 1 (B) Engine Assembly (Complete)
ZZ050045 1 (C) Block Assembly, Cylinder (Stripped) (Incls. Items 2 Thru 7)
ZZ050033 1 (D) Block Assembly, Cylinder (Stripped)
2 31358345 3 Liner (Cast Iron)
3 33137408 8 Thimble
4 32181441 6 Bolt (9/16 x 3-19/32" NF, Hex.)
32181442 2 Bolt (9/16 x 4-19/32" NF, Hex.)
5 650710 4 Plug (1-1/4" Cup Type)
2485A204 1 Plug, Cylinder Block
7 1447053M1 2 "O" Ring (3/4" I.D. x .070" Thk., Spl.)
1 64573 1 (E) Block Assembly, Cylinder (Stripped)
2 31358345 3 Liner (Cast Iron)
3 33137408 8 Thimble
4 32181441 6 Bolt (9/16 x 3-19/32" NF, Hex.)
32181442 2 Bolt (9/16 x 4-19/32" NF, Hex.)
5 650710 5 Plug (1-1/4" Cup Type)
6 650692 1 Plug (57/64" Cup Type)
7 1447053M1 2 "O" Ring (3/4" I.D. x .070" Thk., Spl.)
8 32417115 2 Plug (13/32" Cup Type)
9 33141124 1 Plug (13/16" Dia. W/1/8" Dia. Hole)
10 650566 2 Plug (11/16" Cup Type) 11 33127107 AR Shim, Cylinder Liner (.005") 12 32114471 1 Plug (1/2" NF, Phillips Head) 355547X1 1 Plug (1/8" N.P.T.) (Not Illustrated) 16 32181447 4 Bolt (7/16 x 3-1/4" NF, Hex.)
17 32181446 9 Bolt (7/16 x 3-7/8" NF, Hex.) 18 32524132 2 Stud (7/16 x 3-5/8") 365333X1 1 Plug (1/4" P.T. Hex. Sckt. Hd.)
20 3681E006 1 Gasket, Cylinder Head
21 31419 1 Drain, Cylinder Block
22 33221315 2 Nut (7/16" NF, Hex.)
23 350015 5 Dowel (3/8 x 9/16")
24 4142V002 1 Housing, Rear Oil Seal
25 2418F475 1 Seal, Rear Housing
26 33826111 1 Gasket, Oil Seal Housing
27 353518X1 9 Bolt (5/16 x 7/8" NF, Hex.)
28 353770X1 9 Washer (11/32 x 11/16 x 3/32" Flat)
29 37416751 1 Housing, Tractormeter Drive
30 36862511 1 Gasket, Housing
31 636762M1 1 Seal, Housing to Block (7/8 x 1-3/8 x 1/4")
32 33473106 1 Connection, Tractormeter Drive
33 32813106 1 Washer Seal
34 32811104 1 Washer, Seal
35 37147974 1 Plate, Flywheel Housing Adapter
36 37813113 1 Grommet, Rubber
37 354074X1 1 Pin (3/16 x 3/4" Cotter)
47 32526512 1 Stud (5/8 x 5-7/8" NC - NF Special)
48 33121417 2 Shim (21/32 x 1-1/4 x .036") 33121416 3 Shim (21/32 x 1-1/4 x .010") 760050 1 Shim (21/32 x 1-1/4 x .005") 33121415 4 Shim (21/32 x 1-1/4 x .002")
49 826201 3 Stud (5/16 NF x 1-1/4")
50 353446X1 3 Washer (5/16" Lock)
51 353916X1 3 Nut (5/16" NF, Hex.)
52 353538X1 AR Bolt (3/8 x 1" NF, Hex.)
53 720798 AR Bolt (3/8 x 1" NF, Sckt. Hd.)
54 353434X1 AR Washer (3/8" Lock)
61 1260A AR Pin, Dowel
62
AR Screw (M12 - 1.75 x 35MM 12 PT. Flange Hd.) 63 391198X1 AR Bolt (M12 - 1.75 x 55MM Hex.) 64 391955X1 AR Bolt (M12 - 1.75 x 70MM Lg. Hex., Hd.)
65 3009794X1 AR Screw (M12 - 1.75 x 70MM 12 PT. Flange 66 3019857X1 AR Bolt (M12 - 1.75 x 90MM Hex. Hd.)
67 339369X1 AR Washer (M12 Lock)
68 1440204X1 AR Nut (M12 - 1.75 Hex.)
Massey Ferguson 240 TRACTOR (PRIOR TO 522354)
Item Part Number Qty Description
(A) - Used Late Production Tractor.
(B) - Used Early Production Tractor. For Repair Order 1688286M91 Engine Assembly.
(C) - Used Late Production For Tractors Equipped w/4 Hole Mounted Fuel Pump.
(D) - Used Early Production Tractors Equipped w/2 Hole Mounted Fuel Pump.
(E) - Used Early Production Tractors.
