D39E-1/P-1 S/N 95872-96337
BRAKE CONTROLS ITEM NO. 1 2
3
4
5
6 7
8 9
10
11 12 13 14 15 16 17 18 19
20
PART NO.
DESCRIPTION
Q'TY REF
(1308 102 H91) BRAKES AND CONTROLS SHOES AND LEVERS (SEE PG 04-014) BRAKE PAD (SEE PG 04-006) 25 274 R1 BOLT, HEX - 1/2NCx1-1/8 116 121 WASHER, LOCK - 1/2 1258 315 H91 ROD, FINAL BRAKE 16 619 R1 PIN, CLEVIS - 1/2x1-23/64 103 385 PIN, COTTER - 1/8x1 25 527 R1 NUT, HEX - 1/2NF 144 256 CLEVIS, ROD END 25 527 R1 NUT, HEX - 1/2NF 16 619 R1 PIN, CLEVIS - 1/2x1-23/64 103 385 PIN, COTTER - 1/8x1 BRACKET, BRAKE SUPPORT (SEE PG 04-008) 26 316 R1 BOLT, HEX - 1/2NCx1 25 555 R1 WASHER, FLAT - 1/2 1258 312 H1 ROD, MAIN BRAKE PEDAL, BRAKE/DECELERATOR (SEE PG 04-010) 24 861 R1 BOLT, HEX - 1/2NCx1-1/4 25 536 R1 WASHER, FLAT - 1/2 1287 522 H1 ROD, TURNBUCKLE 19 457 R1 YOKE, LH THREAD 145 406 NUT, JAM - 1/2NF 16 619 R1 PIN, CLEVIS - 1/2x1-23/64 103 385 PIN, COTTER - 1/8x1 652 827 C1 CLEVIS, BRAKE ROD 25 527 R1 NUT, JAM - 1/2NF 103 499 R1 PIN, CLEVIS - 5/8x1-39/64 103 385 PIN, COTTER - 1/8x1 652 829 C1 BOOT, CONTROL ROD 122 316 R91 CLAMP, BOOT 1286 903 H1 SPRING, RETURN 621 318 C1 SUPPORT, BRAKE ACTUATOR 621 319 C1 PIN, PIVOT 21 853 H PIN, CLEVIS - 1/2x1-1/2 103 385 PIN, COTTER - 1/8x1 621 310 C2 SUPPORT, BRAKE EQUALIZER PEDAL, SECONDARY BRAKE (SEE PG 04-012) CYLINDER, BRAKE (SEE PG 04-020) 24 861 R1 BOLT, HEX - 1/2NCx1-1/4 - FRONT 24 866 R1 BOLT, HEX - 1/2NCx2-1/2 - REAR 25 546 R1 WASHER, FLAT - 1/2 CONNECTOR, PORT (SEE PG 07-084) F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.
