Structuraldamage,anoverturn,modification,alteration,or improperrepaircanimpairthisstructure'sprotectioncapability therebyvoidingthiscertification.Donotweldordrillholesin thisstructure.ConsultanElphinstonedealertodeterminethis structure'slimitationswithoutvoidingitscertification.
Noclearanceforpersoninthisareawhenmachineturns.Severe injuryordeathfromcrushingcouldoccur.
Connectsteeringframelockbetweenfrontandrearframes beforelifting,transporting,orservicingmachineinarticulation area.
Disconnectlockandsecurebeforeresumingoperation.
Usegrabhandlenotsteeringwheelwhenenteringorleaving operator'sstation.Severeinjuryordeathmaybecausedby crushingwhenmachineturns.
HIGHPRESSURECYLINDER.Donotremoveanyvalve,
hydraulicfittingorvalvecore,ordisassembleanypartsuntil pressurehasbeenrelieved,orpersonalinjurymayoccur.
Torelievepressure:
1.RefertotheServiceManualforthecorrectmethodof dissipatinghydraulicsystempressure.
2.Relievegaspressureintheaccumulatorcylinderbyopening thechargevalveoneturnonly.
Chargecylinderwithdrynitrogengas.
PrechargepressurekPaPSI
Servicepressure(Operating-Loaded)kPaPSI
MinimumburstingpressurekPaPSI
SeeyourElphinstonedealerfortoolsanddetailedinformation requiredforchargingcylinders.
Improperjumpercableconnectionscancauseanexplosion resultinginpersonalinjury.
ELECTRICALSHOCKHAZARDUNITINJECTORSYSTEM90-120 VOLTS.
FireExtinguisher
Lines,TubesandHoses
