Product: TRACK-TYPE TRACTOR
Model: D6T TRACK-TYPE TRACTOR LAE
Configuration: D6T TRACK-TYPE TRACTOR STD, XL Differential Steering LAE00001-UP (MACHINE) POWERED BY C9 Engine
Operation and Maintenance Manual
D6T Track-Type Tractor
Media Number -SEBU8146-12
Foreword
Date -01/12/2013 Date Updated -18/03/2019
California Proposition 65 Warning
Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm.
WARNING - This product can expose you to chemicals including ethylene glycol, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to:
www.P65Warnings.ca.gov
Do not ingest this chemical. Wash hands after handling to avoid incidental ingestion.
WARNING - This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to:
www.P65Warnings.ca.gov
Wash hands after handling components that may contain lead.
Literature Information
This manual should be stored in the operator's compartment in the literature holder or seat back literature storage area.
This manual contains safety information, operation instructions, transportation information, lubrication information, and maintenance information.
Some photographs or illustrations in this publication show details or attachments that can be different from your machine. Guards and covers might have been removed for illustrative purposes.
Continuing improvement and advancement of product design might have caused changes to your machine which are not included in this publication. Read, study, and keep this manual with the machine.
Whenever a question arises regarding your machine, or this publication, please consult your Cat dealer for the latest available information.
Safety
The safety section lists basic safety precautions. In addition, this section identifies the text and locations of warning signs and labels used on the machine.
Read and understand the basic precautions listed in the safety section before operating or performing lubrication, maintenance, and repair on this machine.
Operation
The operation section is a reference for the new operator and a refresher for the experienced operator. This section includes a discussion of gauges, switches, machine controls, attachment controls, transportation, and towing information.
Photographs and illustrations guide the operator through correct procedures of checking, starting, operating, and stopping the machine.
Operating techniques outlined in this publication are basic. Skill and techniques develop as the operator gains knowledge of the machine and its capabilities.
Maintenance
The maintenance section is a guide to equipment care. The Maintenance Interval Schedule (MIS) lists the items to be maintained at a specific service interval. Items without specific intervals are listed under the "When Required" service interval. The Maintenance Interval Schedule lists the page number for the step-by-step instructions required to accomplish the scheduled maintenance. Use the Maintenance Interval Schedule as an index or "one safe source" for all maintenance procedures.
Maintenance Intervals
Use the service hour meter to determine servicing intervals. Calendar intervals shown (daily, weekly, monthly, etc.) can be used instead of service hour meter intervals if the calendar intervals
provide more convenient servicing schedules and approximate the indicated service hour meter reading. Perform the recommended service at the interval that occurs first.
Under severe, dusty, or wet operating conditions, more frequent lubrication than is specified in the maintenance intervals chart might be necessary.
Perform service on items at multiples of the original requirement. For example, at every 500 service hours or 3 months, also service those items listed under every 250 service hours or monthly and every 10 service hours or daily.
Certified Engine Maintenance
Proper maintenance and repair are essential to keep the engine and machine systems operating correctly. As the heavy-duty off-road diesel engine owner, you are responsible for the performance of the required maintenance listed in the Owner Manual, Operation and Maintenance Manual, and Service Manual.
It is prohibited for any person engaged in the business of repairing, servicing, selling, leasing, or trading engines or machines to remove, alter, or to render inoperative, any emission-related device or element of design installed on or in an engine or machine that is in compliance with all applicable regulations of the intended country to which it has been shipped. Certain elements of the machine and engine such as the exhaust system, fuel system, electrical system, intake air system, and cooling system may be emission-related and should not be altered unless approved by Caterpillar.
Machine Capacity
Additional attachments or modifications may exceed machine design capacity which can adversely affect performance characteristics. Included would be stability and system certifications such as brakes, steering, and rollover protective structures (ROPS). Contact your Cat dealer for further information.
Product Identification Number
Effective First Quarter 2001 the Product Identification Number (PIN) has changed from 8 to 17 characters. To provide uniform equipment identification, construction equipment manufacturers are moving to comply with the latest version of the product identification numbering standard. Non-road machine PINs are defined by ISO 10261. The new PIN format will apply to all machines and generator sets. The PIN plates and frame marking will display the 17 character PIN. The new format will look like the following:
This is the sample of the manual click on the download link for complete manual
DOWNLOAD LINK
For some reason if link does not work download this pdf and then click
Illustration 1 g03891925
Where:
1. World Manufacturing Code (characters 1-3)
2. Machine Descriptor (characters 4-8)
3. Check Character (character 9)
4. Machine Indicator Section (MIS) or Product Sequence Number (characters 10-17). These were previously referred to as the Serial Number.
Machines and generator sets produced before First Quarter 2001 will maintain their 8 character PIN format.
Components such as engines, transmissions, axles, and work tools will continue to use an 8 character Serial Number (S/N).
Copyright 1993 - 2024 Caterpillar Inc. All Rights Reserved. Private Network For SIS Licensees. Thu Jul 11 11:00:15 UTC+0530 2024
Product: TRACK-TYPE TRACTOR
Model: D6T TRACK-TYPE TRACTOR LAE
Configuration: D6T TRACK-TYPE TRACTOR STD, XL Differential Steering LAE00001-UP (MACHINE) POWERED BY C9 Engine
Operation and Maintenance Manual
D6T Track-Type Tractor
Media Number -SEBU8146-12 Publication Date -01/12/2013 Date Updated -18/03/2019
Angle Blade Manual Tilt Brace - Lubricate
SMCS - 6074-086
If equipped:
Illustration 1 g00103702
i01034553
Lubricate the two fittings. Use Multipurpose Lithium Complex Grease with Molybdenum (MPGM).
Product: TRACK-TYPE TRACTOR
Model: D6T TRACK-TYPE TRACTOR LAE
Configuration: D6T TRACK-TYPE TRACTOR STD, XL Differential Steering LAE00001-UP (MACHINE) POWERED BY C9 Engine
Operation and Maintenance Manual
D6T Track-Type Tractor
Media Number -SEBU8146-12 Publication Date -01/12/2013 Date Updated -18/03/2019
Backup Alarm - Test
SMCS - 7406-081
The backup alarm is on the rear of the machine.
i02712816
In order to test the alarm for proper functioning, turn the engine start switch to the ON position.
Apply the service brake. Release the parking brake. Move the speed range selector to the REVERSE position.
The backup alarm should start to sound immediately. The backup alarm will continue to sound until the speed range selector is moved to the NEUTRAL position or to the FORWARD position.
Copyright 1993 - 2024 Caterpillar Inc. All Rights Reserved. Private Network For SIS Licensees.
Thu Jul 11 11:23:45 UTC+0530 2024
Product: TRACK-TYPE TRACTOR
Model: D6T TRACK-TYPE TRACTOR LAE
Configuration: D6T TRACK-TYPE TRACTOR STD, XL Differential Steering LAE00001-UP (MACHINE) POWERED BY C9 Engine
Operation and Maintenance Manual
D6T Track-Type Tractor
Media Number -SEBU8146-12
Battery - Inspect
SMCS - 1401-040
Publication Date -01/12/2013 Date Updated -18/03/2019
i01376996
1. Open the battery access covers. The battery access covers are located on the left side of the machine outside the operator compartment.
2. Tighten the battery retainers. Clean the top of the batteries with a clean cloth. Keep the terminals clean and coated with petroleum jelly. Install the terminal covers after you coat the terminals.
3. Close the battery access covers.
