CP-433C VIBRATORY COMPACTOR

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

i05663146

MID 122 - CID 1251 - FMI 03

SMCS - 1406-038

Conditions Which Generate This Code:

The Product Link module tracks the machine operating hours for reporting to the office. The Alternator R-Terminal signal is used to detect when the machine is operating. If the input continually receives a voltage signal that is above normal, then machine operation cannot be detected. If the input continually receives a voltage signal that is above normal, the reported Service Meter Hours (SMU) would be inaccurate.

Test Step 1. CHECK THE R-TERMINAL CABLING FOR SHORT TO BATTERY.

A. Disconnect the Product Link cable (P1) from the Product Link module.

B. Measure the resistance from the Alternator R-terminal input J1-4 (403MC9-GN-18 to battery (J1-1).

Expected Result:

The resistance should be greater than 5000 ohms.

Results:

• OK - The Product Link harness is likely correct. Proceed to Test Step 2.

• NOT OK - The Product Link cable has a probable short to battery. Repair: Repair the cable and verify that the fault has been removed.

STOP

Test Step 2. CHECK THE PRODUCT LINK HARNESS FOR A SHORT TO A VOLTAGE SOURCE.

A. Disconnect the Product Link cable (P1) from the Product Link module.

B. Start the engine.

C. Measure the Alternator R-Terminal input (J1-4) to verify that there is an 11 VDC to 32 VDC square-wave from 0 kHz to 2 kHz. Also, a steady DC voltage equivalent to the battery should be present.

Expected Result:

The Alternator R-Terminal input does not measure at a steady DC voltage equivalent to the battery voltage.

Results:

• OK - The signal is an 11 VDC to 32 VDC square-wave from 0kHz to 2 kHz or a steady DC voltage equivalent to the battery present. The Product Link harness is likely not faulty. Proceed to Test Step 3.

• NOT OK - The Product Link cable has a possible short to a DC voltage source other than battery voltage.

Repair: Repair the cable and verify that the fault has been removed.

STOP

Test Step

3. CHECK THE MACHINE ALTERNATOR.

A. Disconnect the Product Link machine cable from the alternator.

B. Start the engine.

C. Measure the Alternator R-Terminal to verify that there is 11 VDC to 32 VDC square-wave from 0 kHz to 2 kHz. There should not be a steady DC voltage equivalent to the battery present.

Expected Result:

The alternator R-Terminal should be an 11 VDC to 32 VDC square-wave from 0 kHz to 2 kHz.

Results:

• OK - The alternator R-Terminal is an 11 VDC to 32 VDC square-wave from 0 kHz to 2 kHz. Proceed to Test Step 4.

• NOT OK - The alternator R-Terminal is not an 11 VDC to 32 VDC square-wave from 0 kHz to 2 kHz.

Repair: Repair the alternator or replace the alternator.

STOP

Test Step 4. CHECK IF THE DIAGNOSTIC CODE IS STILL ACTIVE.

This is the sample of the manual click on the download link for complete manual

DOWNLOAD LINK

For some reason if link does not work download this pdf and then click

A. Clean the contacts of the harness connectors.

B. Reconnect all harness connectors.

C. Turn the key start switch to the ON position and operate the machine.

D. Determine if "CID 1251 FMI 03" diagnostic code is present by using the Caterpillar Electronic Technician (Cat ET).

Expected Result:

A "CID 1251 FMI 03" diagnostic code is present.

Results:

• YES - The problem has not been corrected. It is unlikely that the ECM is faulty.

Repair: Perform this diagnostic test procedure again. If the cause of the diagnostic code is not found, replace the Product Link ECM. Before replacing the Product Link, contact your Caterpillar Technical Communicator. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM) - Replace".

STOP

• NO - The diagnostic code is NOT present. The problem does not exist at this time. The initial problem was probably caused by a poor electrical connection or a short at one of the harness connectors that was disconnected and reconnected. Resume normal machine operation.STOP

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

Media Number -RENR7911-15

MID 122 - CID 1250 - FMI 09

SMCS - 7606-038

Conditions Which Generate This Code:

This code signals a lack of communication between the PL300 and the PL121. The lack of communication can be caused by the following actions:

• "Sub-Module Flashing" of the PL121 with old software (prior to v3.0) on the PL300

• A failure in the harness between the PL300 and the PL121

• A failure of the hardware of the PL121 and the PL300

-05/04/2019

i05663141

Note: In versions of software prior tov3.1, if the code clears following a power cycle, verify that the GPS Receiver is shown as "Functional". If the status for the GPS Receiver is shown as "Not Present", the lack of communication still exists.

Test Step 1. CHECK THE VERSION OF SOFTWARE ON THE PL300.

By using Caterpillar Electronic Technician (Cat ET), check the version of software on the PL300. Click "Service" and then click "Submodule Programming".

Expected Result:

The version of software should be version 3.0 or a later version.

Results:

• OK - The version of software is version 3.0 or a later version. Proceed to Test Step 2.

• NOT OK - The version of software is not version 3.0 or a later version.

Repair: Flash the PL300 with the latest version of software. The version of software should be version 3.0 or a later version. Clear the diagnostic code.

STOP

Test Step 2. VERIFY POWER FROM THE PL300 TO THE PL121.

A. Use a multimeter in order to verify power from the PL300 to the PL121.

B. Disconnect the 12-pin connector from the PL121.

C. Check the voltage on pin 1 and pin 2.

Expected Result:

The voltage should be between 11 VDC and 32 VDC.

Results:

• OK - The voltage is 11 VDC to 32 VDC. Proceed to Test Step 3.

• NOT OK - The voltage is not 11 VDC to 32 VDC.

Repair: Check the harness for damage. Repair the harness or replace the harness. Clear the diagnostic code.

STOP

Test Step 3. EXCHANGE THE PL121 WITH A "KNOWN GOOD UNIT".

Replace the PL121 with a second PL121. Before replacing the Product Link, contact your Caterpillar Technical Communicator. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM) - Replace".

Expected Result:

The diagnostic code should be cleared.

Results:

• OK - The diagnostic code was cleared.

Repair: The Product Link should be replaced. Before replacing the Product Link, contact your Caterpillar Technical Communicator. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM) - Replace".

STOP

• NOT OK - The diagnostic code was not cleared. Proceed to Test Step 4.

Test Step 4. REPLACE THE PL300.

Replace the PL300.

Expected Result:

The diagnostic code should be cleared.

Results:

• OK - The diagnostic code was cleared.

Repair: Replace the PL300. Before replacing the Product Link, contact your Caterpillar Technical Communicator. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM) - Replace".

STOP

• NOT OK - The diagnostic code was not cleared.

Repair: Repeat the diagnostic procedure. If the diagnostic code still exists, contact your Caterpillar Technical Communicator for additional assistance.

STOP

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

i05663140

MID 122 - CID 0269 - FMI 04

SMCS - 1408-038

Conditions Which Generate This Code:

This diagnostic code is recorded when the voltage of the sensor supply circuit (T930-WH-18) is below the normal range (nominal 8.3 VDC). Any sensor that is connected to this supply will not operate. If there is not a sensor connected, then this fault can be considered a nuisance fault. The possible causes of this diagnostic code are listed below:

• The sensor supply circuit (T930-WH-18) is shorted to ground.

• The sensor is faulty.

• The ECM is faulty, however ECM failure is unlikely.

Test Step 1. CHECK THE SENSOR SUPPLY OUTPUT.

A. Disconnect the Product Link Input or Output cable (J2) from the sensor cable for the machine.

B. Turn the key start switch to the ON position.

C. Measure the sensor supply output (J2-1) to verify that it is above 7.5 VDC.

Expected Result:

The sensor supply output measures above 7.5 VDC.

Results:

• OK - The voltage is above 7.5 VDC when on. The Product Link Sensor Supply and Product Link harness are likely not faulty. The machine harness or the external sensor may be faulty. Proceed to Test Step 3.

• NOT OK - The Product Link cable has a possible short to ground. Proceed to Test Step 2.

Test Step 2. CHECK THE PRODUCT LINK HARNESS FOR A SHORT TO GROUND.

A. Turn the key start switch to the OFF position.

B. Keep the Product Link Input or Output cable disconnected from the sensor cable for the machine.

C. At the Product Link harness, measure the resistance from sensor supply contact J2-1 (+V) to frame ground and the Product Link cable J1-2.

Expected Result:

Each resistance should be greater than 5000 ohms.

Results:

• OK - The Product Link harness is correct. Proceed to Test Step 3.

• NOT OK - There is a short in the Product Link harness J2-1 (T930-WH-18) and a ground source. The possible ground sources are J1-2 (202-BK), and frame ground.

Repair: Repair the Product Link harness or replace the Product Link harness. STOP

Test Step 3. CHECK THE SENSOR CABLE FOR A SHORT TO GROUND.

A. Keep the Product Link Input or Output cable disconnected from the sensor cable for the machine.

B. At the sensor machine harness, measure the resistance from sensor supply contact J2-1 (+V) to frame ground and the Product Link cable J1-2.

Expected Result:

Each resistance should be greater than 5000 ohms.

Results:

• OK - The sensor and the sensor harness are correct. The sensor and the sensor harness are not shorted to ground. Proceed to Test Step 4.

• NOT OK - There is a short in the sensor harness J2-1 (T930-WH-18) and a ground source or the sensor has failed resulting in a short to ground. The possible ground sources are J1-2(202BK), and frame ground.

Repair: Replace the sensor or correct the short to ground. If necessary, replace the sensor harness.

STOP

Test Step 4. CHECK IF THE DIAGNOSTIC CODE IS STILL ACTIVE.

A. Clean the contacts of the harness connectors.

B. Reconnect all harness connectors.

C. Turn the key start switch to the ON position.

D. Operate the machine.

E. Determine if "CID 0269 FMI 04" diagnostic code is present utilizing Caterpillar Electronic Technician (Cat ET).

Expected Result:

A "CID 0269 FMI 04" diagnostic code is present.

Results:

• YES - The problem has not been corrected. However, ECM failure is unlikely.

STOP

Mar 10 13:13:36 UTC+0530

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

i05663136

MID 122 - CID 0269 - FMI 03

SMCS - 1408-038

Conditions Which Generate This Code:

This diagnostic code is recorded when the voltage of the sensor supply circuit (T930-WH-18) is above the normal range (nominal 8.3 VDC). Any sensor that is connected to this supply may not operate properly or the sensor may be damaged. If there is not a sensor connected, then this fault can be considered a nuisance fault. The possible causes of this diagnostic code are listed below:

• The circuit for +V (T930-WH-18) to the sensor is shorted to the battery.

• The sensor is faulty.

• The ECM is faulty, however ECM failure is unlikely.

Test Step 1. CHECK THE SUPPLY

OUTPUT FOR THE SENSOR.

A. Disconnect the Product Link Input or Output cable (J2) from the sensor cable for the machine.

B. Turn the key start switch to the ON position.

C. Measure the sensor supply output (J2-1) to verify that it is less than 9 VDC when on and less than 4 VDC when off.

Expected Result:

The sensor supply output measures above less than 4 VDC in the off state and less than 9 VDC in the on state.

Results:

• OK - The voltage is in the required voltage range. The Product Link Sensor Supply and Product Link harness are likely not faulty. The machine harness or the external sensor may be faulty. Proceed to Test Step 3.

• NOT OK - The voltage is not in the required voltage range. The Product Link cable has a possible short to the battery. Proceed to Test Step 2.

Test Step 2. CHECK THE PRODUCT LINK HARNESS FOR A SHORT TO BATTERY.

A. Turn the key start switch to the OFF position.

B. Keep the Product Link Input or Output cable disconnected from the cable for the sensor for the machine.

C. At the Product Link harness, measure the resistance from sensor supply contact J2-1 (+V) to the Product Link cable J1-1.

Expected Result:

The resistance should be greater than 5000 ohms.

Results:

• OK - The Product Link harness is correct. Proceed to Test Step 3.

• NOT OK - There is a short in the Product Link harness J2-1 (T930-WH-18) and a battery source (J1-1).

Repair: Repair the Product Link harness or replace the Product Link harness.

STOP

Test Step 3. CHECK THE CABLE FOR THE SENSOR FOR A SHORT TO BATTERY.

A. Keep the Product Link harness Input or Output cable that is disconnected from the sensor cable for the machine.

B. At the sensor machine harness, measure the resistance from sensor supply contact J2-1 (+V) to battery power.

Expected Result:

The resistance should be greater than 5000 ohms.

Results:

• OK - The sensor or the sensor harness are not shorted to the battery. Proceed to Test Step 4.

• NOT OK - There is a short between the sensor harness "J2-1" (T930-WH-18) and the source for the battery, or the sensor has failed resulting in a short to the battery.

Repair: Replace the wiring harness or repair the wiring harness.

STOP

Test Step 4. CHECK IF THE DIAGNOSTIC CODE IS STILL ACTIVE.

A. Clean the contacts of the harness connectors.

B. Reconnect all harness connectors.

C. Turn the key start switch to the ON position.

D. Operate the machine.

E. Determine if CID 0269 FMI 03 diagnostic code is present by using Cat ET.

Expected Result:

The "CID 0269 FMI 03" diagnostic code is present.

Results:

• OK - The problem has not been corrected. However, ECM failure is unlikely.

STOP

• NOT OK - The diagnostic code is not present. The problem does not exist at this time. The initial problem was probably caused by a poor electrical connection or a short at one of the harness connectors that was disconnected and reconnected. Resume normal machine operation.STOP

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

i05663117

MID 122 - CID 0254 - FMI 12

SMCS - 7610-038

Conditions Which Generate This Code:

This diagnostic code is recorded when the Product Link detects a problem that is internal to the control module. This diagnostic code can only be caused if the ECM for Product Link is faulty. There are no serviceable parts within the control module.

Test Step 1. CHECK THE HARNESS CONNECTIONS.

A. Disconnect the contacts and clean the contacts of the harness connectors.

B. Reconnect all harness connectors.

C. Turn the key start switch to the ON position.

D. Operate the machine.

E. Determine if "CID 0254 FMI 12" diagnostic code is present by using Cat ET.

Expected Result:

The "CID 0254 FMI 12" diagnostic code is present.

Results:

• OK - The "CID 0254 FMI 12" diagnostic code is present.

Repair: The problem has not been corrected. It is unlikely that the ECM is faulty. Perform this diagnostic test procedure again. If the cause of the diagnostic code is not found, replace the ECM for Product Link. Before replacing the Product Link, contact your Caterpillar Technical Communicator. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM) - Replace".

• NOT OK - The "CID 0254 FMI 12" diagnostic code is not present. The problem does not exist at this time. The initial problem was probably caused by a poor electrical connection or a short at one of the harness connectors that was disconnected and reconnected. Resume normal machine operation.STOP

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300 Media

MID 122 - CID 0254 - FMI 04

SMCS - 7610-038

Conditions Which Generate This Code:

i05663113

Communication with the satellite will not occur when power to the Product Link is below 10.5 VDC. The Product Link will still communicate with Caterpillar Electronic Technician (Cat ET) when power to the module is down to 9 VDC. A diagnostic code of "CID 168 FMI 01" will occur when the system voltage drops below 11 VDC. A diagnostic code of "CID 254 FMI 04" will occur when the system voltage drops below 9 VDC. This CID code is logged so that no messages will be communicated from the machine to the office.

Test Step 1. CHECK THE SYSTEM VOLTAGE AT THE PRODUCT LINK.

A. Start the engine and operate the engine at a high idle for 5 to 10 minutes.

B. Measure the system voltage between the "Unswitched Power" and the "Ground" contacts. Pin 52 is the terminal for "Unswitched Power" and pin 65 is the terminal for "Ground".

Expected Result:

The voltage is 11 VDC to 32 VDC.

Results:

• OK - The voltage is 11 VDC to 32 VDC. The Product Link should not be logging this diagnostic code.

Repair: Use Cat ET in order to clear the diagnostic code from the Product Link. If the voltage is correct and the Product Link records the diagnostic code again, the Product Link may need replaced. Before replacing the Product Link, contact your Caterpillar Technical Communicator.

STOP

• NOT OK - The voltage is not 11 VDC to 32 VDC. Proceed to Test Step 2.

Test Step 2. CHECK THE ALTERNATOR.

A. Run the engine at high idle for 5 to 10 minutes.

B. Measure the voltage output at the battery posts.

Expected Result:

The voltage should be below 32 VDC.

Results:

• OK - The voltage is below 32 VDC. The battery could be faulty. Proceed to Test Step 3.

• NOT OK - The voltage is above 32 VDC. Repair the alternator or replace the alternator. The voltage regulator could be faulty. If conditions are not resolved, proceed to Test Step 3.

Test Step 3. CHECK THE BATTERY VOLTAGE.

Turn the key start switch to the OFF position. Measure the battery voltage at the battery posts.

Expected Result:

The voltage should be below 32 VDC.

Results:

• OK - The voltage is below 32 VDC. Proceed to Test Step 4.

• NOT OK - The voltage is above 32 VDC.

Repair: See Special Instruction, REHS0354, "Charging System Troubleshooting".

If conditions are not resolved, proceed to Test Step 4.

Test Step 4. CHECK EVERY ECM ON THE MACHINE.

Check the logged diagnostics of any other ECM that is installed on the machine. Compare each ECM that has logged the"CID 168 FMI 00" code in the same time period.

Note: The Diagnostic Clock Hours (DCH) on the logs may be different. The difference between the current DCH and the logged DCH is important.

Expected Result:

Other "CID 168 FMI 00" diagnostic codes can be found on other Electronic Control Modules (ECM).

Results:

• YES - "CID 168 FMI 00" diagnostic codes are found on other Electronic Control Modules (ECM).

Repair: Clear the fault if all the following conditions occur:

A problem is not found with the charging system.

A problem is not found with the wiring.

The fault has occurred a few times.

Monitor the module and the machine for further occurrences. If the fault occurs again, the Product Link module has not failed as other electronic control modules are displaying the same fault. Recheck the system voltage.

STOP

• NO - No other "CID 168 FMI 00" diagnostic codes can be found on other electronic control modules.

Repair: Clear the fault if all the following conditions occur:

A problem is not found with the charging system.

A problem is not found with the wiring.

The fault has occurred a few times.

Monitor the module and the machine for further occurrences. If the fault occurs again, then the Product Link module is possibly faulty. The Product Link should be replaced. Refer to Systems operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM)Replace". If the Product Link has been replaced, recheck the system and check the status of the diagnostic code.

STOP

Mar 10 13:12:55 UTC+0530 2024

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

i05663106

MID 122 - CID 0168 - FMI 01

SMCS - 1406-038

Conditions Which Generate This Code:

This diagnostic code is recorded when the Product Link detects a battery voltage of less than 11 VDC.

Test Step 1. CHECK THE SYSTEM VOLTAGE AT THE PRODUCT LINK MODULE.

Start the engine and operate the engine at a high idle for 5 to 10 minutes. Measure the system voltage between the "Unswitched Power" and the "Ground" contacts. Pin 52 is the terminal for "Unswitched Power" and pin 65 is the terminal for "Ground".

Expected Result:

The voltage is 27 VDC to 29 VDC for a 24 VDC system. The voltage is 13 VDC to 15 VDC for a 12 VDC system.

Results:

• OK - The voltage is correct. Clear the diagnostic code and check for another occurrence of the diagnostic code.STOP

• NOT OK - The voltage is incorrect. Proceed to Test Step 2.

Test Step 2. CHECK THE ALTERNATOR.

Run the engine at a high idle for 5 to 10 minutes. Measure the voltage output at the battery posts.

Expected Result:

For a 24 VDC system, the voltage range should be 27 VDC to 29 VDC. The voltage range should be 13 VDC to 15 VDC for a 12 VDC system.

Results:

• OK - The voltage is correct. Proceed to Test Step 3.

• NOT OK - The voltage is incorrect.

Repair: Repair the alternator or replace the alternator.

STOP

Test Step 3. CHECK THE BATTERY VOLTAGE.

Turn the key start switch to the OFF position. Measure the battery voltage at the battery posts.

Expected Result:

The voltage should be 12 VDC to 15 VDC for a 12 VDC system. The voltage should be 24 VDC to 27 VDC for a 24 VDC system.

Results:

• OK - The voltage is between 12 VDC and 15 VDC or the voltage is between 24 VDC and 27 VDC.

Repair: The Product Link could be faulty. Recheck the system before replacing the Product Link. The Product Link is seldom the cause of a diagnostic code. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM) - Replace". If the Product Link has been replaced, recheck the system and check the status of the diagnostic code.

STOP

• NOT OK - The voltage is not between 12 VDC and 15 VDC or the voltage is not between 24 VDC and 27 VDC.

Repair: See Special Instruction, REHS0354, "Charging System Troubleshooting". If conditions are not resolved, the Product Link could be faulty. Recheck the system before replacing the Product Link. The Product Link is seldom the cause of a diagnostic code. Refer to Systems Operation, Troubleshooting, Testing and Adjusting, "Electronic Control Module (ECM)Replace". If the Product Link has been replaced, recheck the system and check the status of the diagnostic code.

STOP

Private Network For SIS Licensees.

Sun Mar 10 13:12:41 UTC+0530 2024

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

i05662656

MID 122 - CID 0168 - FMI 00

SMCS - 1406-038

MID 122 CID 0168 FMI 00

Conditions Which Generate This Code:

This diagnostic code is recorded when the diagnostic circuit in the Product Link identifies a system voltage that is above 32 VDC.

The possible causes of this fault are listed below:

• A charging system component is faulty.

• The harness wiring is faulty.

• The Product Link is faulty, however a faulty Product Link is unlikely.

Note: Determine if a battery charger or a welder is being used on the machine. Disconnect the charger or the welder if one is used. Recheck for the diagnostic code.

Test Step 1. CHECK THE SYSTEM VOLTAGE AT THE PRODUCT LINK.

A. Start the engine and operate the engine at a high idle for 5 to 10 minutes.

B. Measure the system voltage between the "Unswitched Power" and the "Ground" contacts. Pin 52 is the terminal for "Unswitched Power" and pin 65 is the terminal for "Ground".

Expected Result:

The voltage is 11 VDC to 32 VDC.

Results:

• OK - The voltage is 11 VDC to 32 VDC. The Product Link should not be logging this diagnostic code.

Repair: Use the Caterpillar Electronic Technician (Cat ET) in order to clear the diagnostic code from the Product Link. If the voltage is correct and the Product Link records the diagnostic code again, the Product Link may need to be replaced. Before replacing the Product Link, contact your Caterpillar Technical Communicator.

STOP

• NOT OK - The voltage is not 11 VDC to 32 VDC. Proceed to Test Step 2.

Test Step 2. CHECK THE ALTERNATOR.

A. Run the engine at high idle for 5 to 10 minutes.

B. Measure the voltage output at the battery posts.

Expected Result:

The voltage should be below 32 VDC.

Results:

• OK - The voltage is below 32 VDC. The battery could be faulty. Proceed to Test Step 3.

• NOT OK - The voltage is above 32 VDC. Troubleshoot the alternator. The voltage regulator could be faulty. If conditions are not resolved, proceed to Test Step 3.

Test Step 3. CHECK THE BATTERY VOLTAGE.

Turn the key start switch to the OFF position. Measure the battery voltage at the battery posts.

Expected Result:

The voltage should be below 32 VDC.

Results:

• OK - The voltage is below 32 DCV. Proceed to Test Step 4.

• NOT OK - The voltage is above 32 VDC.

Repair: Refer to Special Instruction, REHS0354, "Charging System Troubleshooting".

If conditions are not resolved, proceed to Test Step 4.

Test Step 4. CHECK EVERY ECM ON THE MACHINE.

Check the logged diagnostics of any other ECM that is installed on the machine. Compare each ECM that has logged the "CID 168 FMI 00" code in the same time period.

Note: The Service Meter Hours (SMH) on the logs may be different. The difference between the current SMH and the logged SMH is important.

Expected Result:

Other "CID 168 FMI 00" diagnostic codes can be found on other Electronic Control Modules (ECM).

Results:

• YES - "CID 168 FMI 00" diagnostic codes are found on other Electronic Control Modules (ECM).

Repair: Clear the fault if all the following conditions occur:

A problem is not found with the charging system.

A problem is not found with the wiring.

The fault has occurred a few times.

STOP

• NO - No other "CID 168 FMI 00" diagnostic codes can be found on other electronic control modules.

Repair: Clear the fault if all the following conditions occur:

A problem is not found with the charging system.

A problem is not found with the wiring.

The fault has occurred a few times.

STOP

Private Network For SIS Licensees.

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300 Media Number -RENR7911-15

Diagnostic Code List

SMCS - 7569

Table 1

Module Identifier 122 Diagnostic Codes(1)

CID 0168 Electrical System

FMI 03 for PLVIMS and PL GSM Voltage above normal

FMI 04 for PLVIMS and PL GSM Voltage below normal

CID 0254 Electronic Control Module

FMI 04

FMI 12

FMI 03

FMI 04

FMI 09

FMI 03

-05/04/2019

i05662649

Voltage below normal

Failed Module

CID 0269 Sensor Power Supply

Voltage above normal

Voltage below normal

CID 1250 Remote Communication Module

Unable to establish communication

CID 1251 Alternator R-Terminal

Voltage above normal

(1) For troubleshooting, see the procedure with the same CID FMI.

Note: A machine ECM will self-erase a diagnostic if the diagnostic does not reappear after 100 operating hours. When this event happens, the event history screen in the EquipmentManager

application will show a code that occurred 100 hours in the past that no longer shows up in Cat ET because the diagnostic has not reoccurred.

Sun Mar 10 13:12:12 UTC+0530 2024

Product: VIBRATORY COMPACTOR

Model: CP-433C VIBRATORY COMPACTOR 2JM

Configuration: CS-433C CP-433C Vibratory Compactor 2JM00001-UP (MACHINE) POWERED BY 3054 Engine

Troubleshooting

Product Link 121S/300

Media Number -RENR7911-15

Event Code List

SMCS - 7569

i05662643

Event codes alert the operator or the technician that an abnormal operating condition exists in one of the machine systems.

When an Electronic Control Module (ECM) activates an event code, the operator or the technician will be alerted by the Messenger. Most active events will be logged by the ECM. Some events are active only. Active only events are not logged. The events that are active and the events that are logged can be viewed with the following equipment:

• Messenger

• Caterpillar Electronic Technician (Cat ET)

Warning Levels

The ECM will assign a warning level to an active event code. Event codes are one of three levels. The level is according to the severity of the abnormal condition. Each warning level requires a specific response from the operator. The warning levels and the required operator response are listed below.

Warning Level 1

Warning level 1 alerts the operator that a machine system requires attention. The operator should check that the involved system condition or the operator should perform maintenance on the involved system at the earliest possible time.

Warning Level 2

Warning level 2 requires changing the operation of the machine or performing a maintenance procedure. Failure to correct a problem that caused this warning may result in damage to the components involved in the system.

Warning Level 2S

Warning level 2S requires an immediate change in machine operation in order to avoid possible damage to the system.

Warning Level 3

Warning level 3 requires an immediate safe shutdown of the machine in order to avoid damage to the machine or injury to personnel around the machine. The problem that caused the event must be corrected before machine operation can resume.

Indications and System Response

Caterpillar Electronic Technician (Cat ET) Service Tool

When an abnormal operating condition occurs, the status screen on the Cat ET indicates that there is an active event.

Event codes are displayed on Cat ET in the following format:

EXXXX Description of the code

The "E" means that the code is an event code. The "XXXX" is a numeric identifier. The numeric identifier is followed by a description of the code.

Active event codes are listed in ascending numerical order. The code with the lowest number is listed first. The active event code is removed from the list when the condition is no longer present.

Logged Event Codes

Some event codes are logged in the ECM memory. Some event codes are active only. The logged event codes are listed in chronological order. The most recent code is listed first.

A logged code is cleared from memory when one of the following conditions occur:

• The service technician manually clears the code.

• The code does not reoccur for 1000 hours.

• A new code is logged and there are already ten logged codes in memory. In this case, the oldest logged code is cleared.

Note: Always clear logged event codes after investigating and correcting the problem which generated the code.

This is the sample of the manual click on the download link for complete manual

DOWNLOAD LINK

For some reason if link does not work download this pdf and then click
