NEW CERVUS CVT SERIES
Engineering excellence, peak performance, STEYR power The new CERVUS CVT marks STEYR’s bold entry into the high-horsepower market, blending Austrian engineering with advanced CVT tech for unmatched productivity, precision, and power. Ideal for transport and heavy-duty tasks, it’s built for today’s professional users.
TAKEN FURTHER
THAN EVER BEFORE
3 MODELS FROM 360 HP UP TO 435 HP MAX. POWER
FPT Cursor 9 engine with 6-cylinder with 8,700 cm3 capacity for high performance in tough tasks
S-Control™ CVT continuously variable transmission up to 60 kph for faster transport and top efficiency
2-speed rear PTO and 2-speed front PTO for multiple implements capability
Base weight of 12,450 kg; GVW up to 18,000 kg (19,000 kg technical) for optimal payload capacity
Up to 11,760 kg rear lift capacity and 5,800 kg at the front for optimal implement performance
Dual hydraulic pumps deliver up to 360 l/min total flow with improved efficiency
Extended 750 h engine service interval, reducing downtime and costs
ENGINEERING EXCELLENCE
Electronic Front Hitch (EFH) featuring pressure control, 2-speed front PTO, and automatic engagement options
Fully integrated Central Tyre Inflation System (CTIS); increased traction and reduced soil compaction
Oil-cooled inboard front brakes deliver top-tier braking power, exhaust decompression brake for best braking power without wear
Independent front axle-suspension with double wishbone design, roll control and anti pitch functionality for top safety and stability at high speeds
Semi-active cab suspension with double panhard rod and angled damper design improves control of lateral movement for stable and comfortable driving experience
With advanced insulation and an ergonomic design, the cab delivers one of the quietest work environments in its class at only 68 dBA
Up to 26 work lights turn night into day for uninterrupted operation during peak season
Integrated hitch and step illumination makes implements coupling and cab access at night much more easier and safer
Removable cool box and external storage compartment with hand wash tank take care of operator’s needs
STEYR TECHNOLOGY
Factory-fitted Connectivity Included for subscription free access to FieldOps™ to efficiently track your STEYR equipment location and view machine parameters in real time
Monitor and operate your CERVUS CVT through the Infomat 1200 touchscreen monitor
ISOBUS & Tractor Implement Management (TIM) enabling seamless connection between tractor and implement, including implement operation by configurable tractor controls
STEYR Turn II and EasyTronic II with GPS trigger for easy, hands-free, full automated headland turns with implement control and improved field efficiency
ENGINEERED AND BUILT IN AUSTRIA
The smoothest ride ever
The standard, brand new independent front axle suspension greatly improves comfort, control, and drivability.
Featuring a robust double wishbone architecture and hydro-pneumatic suspension, it delivers exceptional load-carrying capacity and ride quality, making the CERVUS CVT ideal for demanding field and transport operations.
Outstanding ergonomics
The cab offers one of the quietest workplace in its class (68 dBA) and sets new standards in operator’s working environment thanks to enhanced ergonomics. Features like step illumination, expanded storage, all-round visibility, effective insulation and advanced climate control support efficient, low-fatigue operation.
Performance redefined
Powerful Cursor 9 engine, delivering up to 435 hp. High-performance, dual pumps, hydraulic system providing 360 l/min total flow. Electronic Front Hitch (EFH), 2-speed front PTO, oil-cooled inboard front brakes and 60 kph transport speed. CERVUS CVT has it all to do it all, better.
TECHNOLOGY-CENTERED CAPABILITY
Precision technology packages
All CERVUS CVT models come with Connectivity Included, enabling subscription-free access to our full range of connectivity features. In addition, three configurable technology packages are available – each tailored to meet the full spectrum of precision farming needs. These packages include features such as ISOBUS compatibility, EasyTronic II with GPS trigger, and STEYR Turn II for full seamless, automated headland turns.
Infomat 1200 and ISOBUS
The Infomat 1200 touchscreen monitor offers an effective control and precision guidance system for arable farming. TIM compatible attachments can easily be connected and controlled with one or optionally 2 monitors.
Keep an eye on your farm
Crop and weather monitoring
Operation control in real time
One simplified, comprehensive solution
The new all-in-one mobile app and web platform stores machines’ information, providing one streamlined platform for all STEYR machines, equipment brands and users.
Keep an eye on your data
Access to real time data and insights, precise location and duty status, estimated job completion time, and more.
Both front and rear wheel ballasts of up to 2,000 kg make the CERVUS CVT ready for heavy pulling applications and are easy to install
STEYR-branded tail lights with integrated drawbar illumination, rear reflectors, and standard reversing lights deliver the perfect combination of style and visibility
With its laminated front screen for reduced noise and greater impact protection, and a 260° front wiper for superior visibility, the CERVUS CVT delivers a safer, quieter, and more comfortable driving experience
The premium leather seat with active suspension, heating, and ventilation takes care of operator’s wellbeing
Front and rear mounted cameras for improved visibility when working with implements
FACTS
Connectivity Included in base
User-friendly interface
Time-saving management
Data visualisation enhancing decision making
Efficiently track your equipment‘s location and view machine parameters in real time
FieldOps is your destination for STEYR product support
Solutions for mixed fleets – DataConnect
TRANSMISSION
Type
[kph]
/ 60 kph [rpm]
Rear PTO engine speed at 540E / 1,000 [rpm]
Rear PTO engine speed at 1,000 / 1,000E [rpm]
Front PTO engine speed at 1,000 / 1,000E [rpm]
LINKAGE
Rear linkage category
Maximum rear lift capacity at ball ends [kg]
Front linkage category IIIN
Maximum front lift capacity at ball ends [kg]
AXLES
Independent front axle suspension Double wishbone design for comfort and high load capacity
Turning radius measured at the drawbar pin [mm] 6,100
DIMENSION
Length – Rear lower links horizontal to front top link [mm]
Height Middle of rear axle to top of roof [mm]
Middle of rear axle to top of GPS Antenna [mm]
Width – Over rear fenders without extension [mm]
WEIGHT Weight base specification [kg]
You drive better when you are safe. Before using this vehicle, please read the Operating Manual and become familiar with the use of each of the controls. Note the contents of the instruction panels and use the safety equipment for your own personal safety. This brochure is intended for use internationally. The availability of a few models and of standard and special equipment items may vary from one country to another.
STEYR reserves the right at any time and without prior announcement to make changes to the design and technical version without this in any way obliging STEYR to transfer these to units already sold.
Details, descriptions and pictorial material reflect the current status at the date of publication, but can be amended without prior announcement and at any time. Pictorial materials may show certain national versions, items of special equipment as well as non-complete standard versions.
