Matterport & Interactive Closeouts
INTERNALTRAINING
VDC Lunch & Learn · Martin Horn
Presented
by
Habiba Elnagdy, VDC Coordinator
What We're Covering Today
Why We Scan, and When
PHASE 1
PHASE 2
Framing Scan
Captures what's inside the walls before drywall goes up
Final Scan
As-built record at substantial completion: the official model
Lets the team find MEP, blocking & structure later without guessing
Owner receives a navigable digital twin, not flat PDFs
Cool for clients to see the build progress in real time
FM team can measure spaces & access O&M tags from any browser
Permanent reference for future renovation or service work
Feeds directly into the closeout package (Procore, BIM 360, etc.)
Tools Inside the Model
Floor Plans
Auto-generated 2D floor plan from the scan. Shareable, zoomable, and downloadable. Great for a quick spatial overview.
Dimensions
Click any two points in the model to get an instant measurement, useful for owners checking furniture fit or contractors verifying rough-in.
Mattertags
Pin a note, document, photo, or link to any point in space.This is the core of the tagged closeout: equipment manuals, warranty info, and more.
Dollhouse View
The iconic 3D dollhouse gives owners a full building overview. Great for orientation before diving into individual spaces.
The Tagging Standard
A standardized tagging sheet keeps closeouts cohesive across every project.
Equipment Name: Consistent naming from the submittal / O&M binder
Tag Color /Type: Category-coded: mechanical, electrical, plumbing, etc.
Attached Docs: Cut sheets, warranty cards, serial numbers, manuals
Location Note: Brief plain-language description for the FM team
Last Updated: Date stamped so the client knows the record is current
The sheet lives in the project folder. Use it as your tagging checklist before every closeout scan.
Merging Models & Multi-Floor Setup
1 Scan Each Floor Separately
Each floor is processed as its own Matterport model. Keep naming consistent: Floor 1, Floor 2, etc. Use the tagging sheet to tag as you go.
2 Merge in Matterport Cloud
Open both models, use the 'Link Spaces' feature to connect floors.Align overlapping scans at stairwells or elevators for a seamless walk-through.
3 Floor Switcher for Owners
The finished model shows a floor selector UI. Owners and FM team can jump between levels without losing orientation. No app needed.
We'll walk through this live, so feel free to ask questions as we go.
The Camera & iPad Workflow
CAMERASETUP
IPAD EDITING
1 Review the scan coverage map as you go (red = needs more) 2 Add Mattertags on-site while the space is fresh in your head
Review final model on the app before sharing with the client
Client Handoff Package
We send a simple how-to guide alongside the model link so owners know exactly what they have and how to use it.
The Model Link
The How-To Guide
What's Tagged
No login required, just a URL
Navigation basics (walk, dollhouse, floor plan)
All major mechanical equipment
Works on phone, tablet, or desktop
How to take measurements
Electrical panels + breaker IDs
Include in Procore closeout docs
How to open Mattertags & download docs
Plumbing shutoffs & access panels
Stays live in Matterport Cloud
Who to call for access questions
Special items per the standard tagging sheet
Quick Reference: Keep This Handy
✔ DO
Scan framing before drywall. Don't skip it
30–40% overlap between scan positions
Tag equipment on-site while it's fresh
Use the tagging sheet on every project, every time
Save the model link in Procore at closeout
Charge the camera the night before a full-day shoot
✘
DON'T
Don't scan with trades actively working in the space
Use the Pro2 or Pro3, not your phone
Don't skip mechanical rooms (owners need them most) Don't leave Mattertag labels blank
Don't upload on LTE. Wait for WiFi
Don't share the link before reviewing the model yourself
