Exclusive decorative glass Technical data sheet
Fluido
Base product: patterned glass to EN 572-5. Description and performance: the printed side is chemically satin-finished, opaque, very smooth, velvety to the touch. Effective visual obscuration and optimal light diffusion are the key properties. Thanks to its low porosity, it ensures greater resistance to fingerprints and easier cleaning than traditional sand-blasted glass. Internal and external applications: building (façades, parapets... ), windows & doors, partitions, furniture, shower-screens etc. Fluido can also be supplied in the finishes: Fluido-T (transparent finish) - Art. 401011 Fluido-M - Art. 401243 Sheet size: Fluido-T: 3350 x 1610 mm Fluido-M: 3210 x 1610 mm Maximum possible dimensions: Fluido-T: 3300 x 1560 mm Fluido-M: 3300 x 1560 mm Pattern direction: parallel to 3210 mm side. Lines size: 12.5 ± 0.3 mm
Thickness 4 mm 6 mm 8 mm
Colour float float float extrawhite
-M
Compatible processing: Cutting, grinding, drilling, notching, varnishing, etc. Processing such as tempering, layering and assembly in insulating glass are to be agreed. Cleaning: care must be taken when installing the glass not to get putty, resin, sealants, etc., on the treated side. Each of these substances requires a specific solvent for removing traces from glass. For routine maintenance, use water and/or any of the commonly marketed glass detergents. Dry immediately with a clean cloth, preferably micro fibre. Colours and finishings in the photographs may look slightly different from those of the real products: we recommend that customers examine sample glass before choosing products. Galvolux SA Via Strecce 1, 6934 Bioggio Tel. +41 91 610 55 11 info@galvolux.com www.galvolux.com
