RAILINGS

CONTAINS THE NINFA 106, 116, 56, 176, 186, 6, 50-N, NINFA 6 STADIO MODELS 2026 UPDATE

Take care of the people you love. With the latest generation of Ninfa balustrades.

faraone.it

NINFA THE SERIES 6

In 2008, the first metres of what would later become a reference system for glass balustrades in Italy were shipped: the Ninfa system. At the time, this system was relegated to the last pages of the balustrade catalogue, after the stainless steel systems, occupying a small space with a single article. Five series later, after setting one record after another, the Ninfa balustrade system has definitely conquered designers and operators of the Italian sector, becoming a best-selling item with over 1,600,000 metres (994 miles) installed since 2009. Today, more than 2,000 km (1,243 miles) of Faraone balustrades have been installed in Italy and abroad since 2009. Now in its sixth generation, the Ninfa 6 series has new records to break, which we see as a natural evolution of the design inherited from the previous series. The entire range stems from our desire to always look forward, pursuing continuous innovation, improving performance, aesthetics, functionality, ease of installation and much more. Among the main new records you will find the simplicity of the management of glass thicknesses and the possibility of using taller glass panels, meeting today’s design requirements, with calculation verifications and laboratory tests in full compliance with the regulations. We do all this not because the market requires it, but because we strongly believe in what we do and always want to raise the level of the category. Welcome to our new innovation.

Flavio Faraone CEO Faraone Architetture Trasparenti

faraone.it

INDEX P. WHY USE THE NEW NINFA FARAONE BALUSTRADE SYSTEM.

A RECORD THAT IS STILL UNDEFEATED: INSTALLATION ON THE INSIDE ONLY

THE NEW NINFA PROJECT

P. ASSEMBLY INSTRUCTIONS NINFA THE SERIES 6

114

CUSTOMER CARE

115

NINFA TECHNICAL SPECIFICATIONS

116

THE IDEAL TECHNOLOGICAL PACKAGE

GENERAL CONDITIONS OF SALE

118

OUR STRENGTH: THE QUICK ASSEMBLY

ALUMINIUM FINISHES

OPTIONAL

NINFA THE SERIES 6 AND ITS POTENTIAL

MAINTENANCE

WE ARE GREEN

INTENDED USE

NINFA 106

NINFA 116

NINFA 56

NINFA 176

NINFA 186

NINFA 6

NINFA 50-N

NINFA 6 STADIO

NINFA LED OUTSIDE THE PROFILE

NINFA LED INSIDE THE PROFILE

DEDICATED SOLUTIONS FOR WATER DRAINAGE

NINFA176/186 SOLUTIONS FOR WATER DRAINAGE AND COVER PROFILES

COVER CLADDING

ACHIEVEMENTS WITH NINFA BALUSTRADES OVER THE YEARS

100

NINFA THE SERIES 6

WHY USE THE NEW NINFA FARAONE BALUSTRADE SYSTEM? After more than 50 years in the world of Transparent Architecture, Ninfa is still the best-selling "all-glass" balustrade in Italy. Sabatino Faraone

The Ninfa glass balustrades by Faraone are synonymous with experience, comfort and safety for outdoor environments such as balconies, terraces, poolside fencing, fences; and for indoor environments such as stairways, galleries and walkways. The reason for using the new Ninfa series 6 balustrades by Faraone can be found in some of the following records achieved to date:

PRESIDENT

Flavio Faraone CHIEF EXECUTIVE OFFICER / CEO

1. The Ninfa system by Faraone was the first industrialized all-glass balustrade to arrive on the market in Italy since 2009, previously there were mainly handcrafted or ‘do-it-yourself’ solutions; 2. To date, more than 2,000 km (1,243 miles) of Ninfa balustrades have been installed in Italy with total customer satisfaction; 3. Ninfa was the first balustrade to use the “only from the inside” assembly methodology since 2016 and today it reduces assembly times by 40% compared to the market average; 4. Ninfa 6th series is the first glass balustrade system that fully complies with static calculations verified by our technical department, offering unmatched performance; 5. Ninfa the 6th series is the first to present its technology package with the "RS system"; 6. Ninfa series 6 offers high customisation and prestigious finishes for the profile and for the glass; 7. NINFA 116, the profile with mounting flush with the wall and/or for solutions with floating floors. Ninfa the 6th series is not just a product. faraone.it

Pamela Faraone ADMINISTRATIVE MANAGEMENT

Federico Vallese ORGANIZATIONAL MANAGEMENT

These are some numbers related to the world of Ninfa: over 60,000 orders processed tofor direct customers; 2,000 km (1,243 miles) installed equal to 160,000 homes with Ninfa balustrades (about 10 metres/10.93 yd per home). A network of consultants throughout Italy is ready to offer maximum assistance for every need, starting from simple technical or commercial advice to the definition of the design. The internal department is also able to guide you in choosing the most suitable product for you or to respond to your emergencies. Below we have tried to answer the main FAQs (frequently asked questions), to illustrate how Faraone resolves the main technical issues, whether on the construction site or regarding customer support. In the final part there is a section related to Ninfa's references.

Faraone Headquarter. Watch the video.

PLAY

Faraone Headquarter. Watch the video.

NINFA THE SERIES 6

A RECORD THAT IS STILL UNDEFEATED: INSTALLATION FROM THE INSIDE ONLY Install-time optimization

OPTIMIZED ASSEMBLY TIMES

When the Faraone R&D department designs a balustrade, it also considers the installation phases. That's why all the NINFA series 6 technology is even easier and quicker to install. The glass is assembled exclusively from the inside to offer a better installation experience and greater safety for the installer, who is not forced to work from the outside.

PLAY

Also for the Ninfa 186 profile, which is fascia mounted, the glass is mounted only from the inside. It is advisable to contact qualified specialists to be sure to get a “state-of-the-art” installation.

faraone.it

Watch the installation video of Ninfa 106

INSTALLATION OF THE RAILING ONLY FROM ABOVE THE BALCONY, NO EXTERNAL SCAFFOLDING

Adjustment and vertical alignment

Internal cladding assembly

Glass assembly

MAXIMUM ATTENTION TO SAFETY

FOLLOW THE INSTRUCTIONS OF THE SITE SAFETY OFFICER

Drilling of the floor and fixing of the aluminium profile. External cladding pre-installed.

NINFA THE SERIES 6

THE NEW NINFA PROJECT The new NINFA Series 6 project further improves the previous series with a more practical and faster glass adjustment system.

PATENTED AND CERTIFIED SYSTEM New range with resistance from 200 kg/m (tested to 300 kg/m) up to 500 kg/m (tested to 750 kg/m). 134 lb/ft (tested at 202 lb/ft) up to 336 lb/ft (tested at 504 lb/ft). THE SYSTEM GUARANTEES THE STANDARD SAFETY LEVEL.

Types of fixing New RS system TOP-MOUNTED

Glazing support block FASCIA-MOUNTED

Fixing bush

EMBEDDED

faraone.it

Adhesive gasket

TOP-MOUNTED ON UPSTAND

-2°

+2°

With NINFA THE SERIES 6 the adjustment and alignment of the glass are even faster from the inside of the balustrade.

6.6, 8.8, 10.10 and 12.12 glass

(1/4”+1/4”, 5/16”+5/16”, 3/8”+3/8”, 1/2”+1/2” glass)

Vertically adjustable external LED

The use of extra-clear glass is recommended for LED lighting

LED strip inside profile

NINFA THE SERIES 6

THE IDEAL TECHNOLOGICAL PACKAGE 1 - NINFA system 2 - Safety glass

Only with the NINFA system and the appropriate safety glass can outstanding performance be achieved in full compliance with regulations. The knowledge of the materials used such as aluminium and glass combined with their technological capabilities has allowed Faraone to develop increasingly high-performance systems. This is thanks to the Technology Package consisting of the NINFA system (profile, RS, base, fixing) and the suitable structural glass. Why are they both essential? The NINFA system concerns Faraone’s know-how: from resistance performance (based on the intended use and the glass used) to installation needs and ease of assembly. The Structural Glass, on the other hand, concerns the production technique of the glass sheets, the hardening and processing methods that make this material, basically fragile, into a resistant and high-performing one. The performance of a glass balustrade depends mainly on the number of panes that make up the balustrade, their thickness and the type of interlayer that is inserted inside.

faraone.it

ADVANCED TECHNOLOGY

2 SAFETY GLASS

B C

1 NINFA SYSTEM A Aluminium profile B New “RS” system C Base + support D Fixing

NINFA SYSTEM

SAFETY GLASS

(SUPPLIED BY FARAONE)

(SPECIFIED BY FARAONE)

The advantages of the NINFA system

Follow Faraone’s specifications for the glass panels

TESTING IN COMPLIANCE WITH REGULATIONS

TEMPERING AND HARDENING PROCESSES

INTENDED USE

CORRECT LAMINATION

SPEED OF ASSEMBLY

TYPES OF INTERLAYER

One of the main steps in glass processing to increase its resistance fourfold.

We calculate and test the resistance levels of Ninfa balustrades in compliance with current regulatory standards.

In addition to the thickness of the glass panes, it is important to insert the Tempered-Hardened glass on the outside and the Tempered glass on the inside.

Each NINFA glass balustrade is designed for specific uses.

The assembly and plumb alignment of the glass are faster and easier.

It is an essential element that determines the behaviour of the glass even after breaking. Use “hard” plastic interlayer for superior resistance.

GUARANTEED GLASS HEIGHT

Thanks to the data of our tests, in addition to the types of glass, we are able to indicate the maximum height of each glass relative to the intended use.

NINFA THE SERIES 6

OUR STRENGTH: THE QUICK ASSEMBLY 4 simple steps, and that's it!

STEP01

STEP02

> PREPARATION a) Position the pre-drilled bar (with external gasket already fitted) as a template b) Mark the holes and then drill the floor c) Thoroughly clean the holes d) Apply the resin e) Insert the rods

> GLASS HOUSING a) Insert the glazing support block inside the profile b) Prepare the RS system by inserting the correct shims according to the glass thickness to be inserted (6.6, 8.8, 10.10, 12.12) (1/4”.1/4”,5/16”. 5/16”, 3/8”.3/8”,1/2”.1/2”)

> START OF ASSEMBLY a) Fasten the profile to the floor

YOU ONLY NEED TO Place: 1. Adhesive gasket 2. Profile 3. Fixing bush 4. Plain washer 5. M12 nut

faraone.it

YOU ONLY NEED TO Distribute the glazing support blocks (4 for each metre)

OPTIMIZED ASSEMBLY TIMES

STEP03

STEP04

> POSITIONING OF THE GLASS a) Insert the glass inclined inwards

> FINAL PHASE a) Insert the upper snap-fit cladding b) Fasten the side caps with the supplied screws

> RS system Installation a) Insert the adjusters (RS system) b) Adjust the inclination c) Tighten both rows of adjusters

YOU ONLY NEED TO Insert 4 adjusters (RS system) per metre. Make sure the glass panels are plumb. Make sure the glass panels are spaced 2 cm (0.78”) apart.

YOU ONLY NEED TO Make sure you have performed a professional installation.

NINFA THE SERIES 6

ALUMINIUM FINISHES Customise your balustrade

CUSTOMIZATIONS AND QUALITY FINISHES

Customise your profile with trendy finishes for INDOOR and OUTDOOR use, or choose a colour on request from more than 2,000 RAL colours.

PROFILE FINISHES BASE

SILVER ANODISED 20 micron (raw on request)

PROFILE FINISHES: RAL FINISHES AND SPECIAL COATINGS BASE

ON REQUEST

WHITE RAL 9010 MATT

2000 RAL COLOURS

BLACK RAL 9005 MATT

faraone.it

Illustrative reproduction of the available finishes

OPTIONAL HANDRAIL

MINIMALIST HANDRAIL

32 (1.26”) 32

39 (1.53”) 39 26,5

26.5 (1”) 26,5

22.5 (0.9”) 22,5

OTHER COLOURS

BASE

ON REQUEST

Safety handrail, aluminium profile (structural adhesive fixing EXCLUDED). Recommended technical solution. Check applicable regulations

2000 RAL COLOURS

WHITE RAL 9010 MATT

22,5

PROFILE FINISHES

SILVER ANODISED 20 μm (raw on request)

BLACK RAL 9005 MATT

2 LED PACK:

INTERNAL LED PACK

14 EXTERNAL LED PACK

TYPES OF LIGHT

WHITE LIGHT UNIQUE LIGHT EFFECT

MULTICOLOUR LIGHT CUSTOMIZE THE TYPE OF LIGHT WITH THE RGB LED VERSION.

LED EFFECTS Get the most out of the light and the effect you want.

LED not supplied by Faraone

Illustrative reproduction of the available finishes

DISCOVER THE NEW LED EFFECTS FROM PAGES 84 TO 89

NINFA THE SERIES 6

NINFA SERIES 6 AND ITS POTENTIAL The secret of the new glass balustrades is in the details.

THE IMPORTANCE OF THE ALUMINIUM SHOCK ABSORBER PROFILE

What is important to know is that you have to choose the right materials for the intended uses. This is true for aluminium, too: there are different alloys and different hardness levels that determine its characteristics depending on the use; consequently, this aspect also applies to the balustrades. Ninfa series 6 was born from a deep knowledge of how materials behave, which made it possible to develop a system with the right stiffness and elasticity to achieve an optimal shock-absorbing effect. It is easy to design a “heavy profile” (rigid and resistant) that is not optimized for glass. It is difficult, very difficult, to create a “shock-absorbing profile” (elastic and resistant) designed to work together with the glass. In the following pages you will discover the surprising results achieved by Ninfa series 6.

Sabatino Faraone

Founder and President of the company with over 50 years of experience in the sector.

faraone.it

THE FUNDAMENTAL ROLE OF ACCESSORIES: THE RS SYSTEM Immediately after the profile, we find the heart of the new NINFA technology: the RS system of internal accessories. Having a profile with exceptional performance is not enough, if it is not accompanied by a system of accessories that are equally high-performing. The new RS system, an unprecedented glass clamping and adjustment system, allows you to set the glass plumb and tighten it in just a few quick steps, achieving a complete composite system. Furthermore, the glass thickness change system is also new; it is done simply by replacing the pressure blocks with a single click.

The Ninfa 6 series has left nothing to chance, thanks to the gasket made with a special compound that allows it not to shrink over time, not to yellow and always remain under pressure on the glass. FIXING: CHEMICAL OR MECHANICAL? This is the question that designers and installers ask us most often: which fastening do you recommend? Fastening is a fundamental element in any application. Whether it's a window, an awning, a canopy, each product must have a fixing suitable to hold its weight under certain conditions. I can assure you that the fixing for the balustrades is of fundamental importance. Since as far back as 2008, with the first Ninfa systems, floor fixing has always been a primary element — so much so that throughout the design of the various Ninfa systems over the years, it has always been the first element to be taken into consideration.

THE GASKETS: ADVANTAGES OF THE NEW DESIGN AND COMPOUND Have you ever thought of gaskets as an important element for a glass balustrade? They are not needed only to avoid contact of the glass with aluminium, but also to limit the passage of water. Here too, a simple gasket that merely plays a minor role is not enough — it must take on a truly leading role. The compound must be designed in such a way as not to expand or shrink, and to maintain its colour over time despite its exposure to different weather conditions and atmospheric agents. On the technical side, it must be easy to insert and must adhere to the glass in the various conditions of inclination.

NINFA THE SERIES 6

The fixing system indicated by Faraone is the only one able to guarantee a perfect fastening strength, which is verified by calculation and carried out in several tests performed both in our test laboratory and at the certification bodies. - threaded rod certified according to the applicable standard - a corresponding CERTIFIED chemical anchor recommended by the manufacturer, not just any chemical resin! Is the mechanical fixing not up to standard? Let me be clear, even the mechanical fixing offers the necessary guarantees if you are sure that you have a “guaranteed” concrete. This is why fixing with a chemical resin offers all the guarantees needed for those who do not want to have problems after the installation.

proper installation, water infiltration can be avoided. However, we wanted to go further with two important technical measures: - the use of epoxy resin to limit water ingress (waterproof) - external drainage outlets on the entire new Ninfa 6 series

WATER DRAINAGE ON THE PROFILE The first question that is asked by the designer and the customer is: where does the water go? Water has always been a hassle for all those dealing with outdoor balustrades. You never know where it comes from. Even when everything is planned and well-designed, water can sometimes seep through any micro-crack and become a problem.

This prevents water from infiltrating the fixing points, while any excess water drains through the drainage outlets (just as in window systems).

When it comes to the balustrade, the utmost attention must be paid during outdoor installation to: - the gasket along the glass - the seal between glass panels - fixing - water stagnating near the profile due to the inclination and the lack of drainage provisions. - do not use polyester resins, they are not suitable for the required loads. By paying attention to all these points, and with a

faraone.it

TESTS 1

Faraone Laboratory Test

The creation of every product goes through laboratory tests. The Ninfa Series 6 was also subjected to numerous tests at the Faraone LAB during its development process.

Politecnico di Milano Test

After passing the tests at the Faraone LAB, the certifications are also obtained at the Politecnico di Milano.

LAB

MORE THAN 100 TEST CYCLES CARRIED OUT ON THE PROFILES 100 QUINTALS OF GLASS USED

NINFA THE SERIES 6

MAINTENANCE

In general, classic iron or masonry balustrades require continuous routine and major maintenance, with repainting needed every 6 to 10 years.

profile painted according to QUALICOAT and SEASIDE system and anodised according to QUALANOD. The main components of a balustrade system are: - Painted or anodised aluminium profile (supporting structure); - Floor fixing bolts; - Laminated tempered/tempered or tempered/ hardened glass 8.8 or 10.10 (5/16”. 5/16” or 3/8”. 3/8”) + interlayer; - Gaskets;

The more you live in areas affected by atmospheric agents, such as near the sea, the more maintenance you will need to do. With an aluminium and glass balustrade (with suitable anodising or painting) you can rest assured for many years. These materials are widely used in architecture to last over time. This type of balustrade consists of an aluminium

Maintenance with specific antirust treatments for common metal balustrades is recommended, to prevent them from being corroded by time, losing beauty and safety.

faraone.it

WE ARE GREEN Faraone chooses sustainable and recyclable raw materials for its products and their packaging. The management of its own special waste is accomplished according to the Italian legislation. GLASS . Glass is the sustainable material par excellence. Glass can be reused an unlimited number of times, while keeping its properties intact. In addition, at the production level, re-melting the waste material implies a lower waste of energy and raw materials. It is also an energy-efficient material for its applications in architecture and design. (Such as, for example, the application of glass with photovoltaic cells for the balustrades). ALUMINIUM . Aluminium is today one of the most common materials in the construction sector, both because it is optimal for countless uses and, from an environmental point of view, for its quality, thanks also to the new carbon-free production methods. To date, aluminium is one of the best choices in terms of sustainability, as it is a 100% recyclable material and significantly reduces energy consumption during production, while maintaining its qualitative performance intact. STEEL . Steel is thought to be the most recycled material in the world, of which Italy holds the record in Europe with about 80%. High strength and durability make it an essential material in the construction world, as well as beneficial for the environment and the economy.

PACKAGING . All our packaging is made from recyclable materials, starting with the cardboard used to make the product packaging.

Certifications:

Members of:

NINFA THE SERIES 6

INTENDED USE For new builds or refurbishments

01RESIDENTIAL

02RESIDENTIAL COMPLEXES

- private house

indoors / outdoors

- balconies - terraces

05HOSPITALITY

06INFRASTRUCTURE

- hotels - restaurants - chalets - poolside fencing

- airports - train stations

faraone.it

03FENCES

04WORKING ENVIRONMENTS

- residential - public

- offices - conference rooms

07HISTORICAL BUILDINGS

08SHOPPING CENTRES

- Churches and places of worship - redevelopment of historic centres

- halls - external terraces

NINFA THE SERIES 6

INTENDED USE For new builds or refurbishments

09HEALTHCARE FACILITIES

10SCHOOL BUILDINGS

- hospitals - private clinics - socio-health structures - nursing homes

- schools - campus and university

faraone.it

11SPORTS FACILITIES - stadiums - sports halls - swimming pools - racetracks

NINFA THE SERIES 6

THE MINIMAL & HIGH-PERFORMANCE GLASS BALUSTRADE

faraone.it

NINFA 106

INIMITABLE PERFORMANCE

THE MINIMAL & HIGH-PERFORMANCE GLASS BALUSTRADE

The NINFA 106 glass balustrade was created to increase the safety level of balconies, terraces, stairs, galleries and poolside fencing. It’s ideal for private and public spaces. NINFA 106 is the first system to simultaneously meet engineering software calculation requirements and pass all static load and dynamic impact tests required by the standards. The profile accommodates both 8.8 and 10.10 (5/16” .5/16” and 3/8”.3/8”) glass thanks to the new RS system for adjusting and tightening the glass. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H For uncrowded environments: Tested to 300 kg/m 202 lb/ft Dynamic impact resistance up to 350 J 258 ft-lb

P For very crowded environments: Tested to 450 kg/m 302 lb/ft Dynamic impact resistance up to 600 J 440 ft-lb Ninfa 106 H (Home) Ninfa 106 P (Professional)

faraone.it

NINFA 106

TECHNICAL DETAILS

internal

This page shows the complete list of the main components. Some accessories, such as the adjusting block, the gaskets and the cladding can vary to accommodate different thicknesses of glass panels, such as the "compensator shim" shown in the drawing alongside.

external

SAFETY GLASS 8.8 or 10.10 (5/16”.5/16” or 3/8”. 3/8”)

1.25”

GASKET SLIDE-IN

3.18”

COMPENSATION SHIMS

111

4.37”

CAP FIXING HOUSING NEW “RS” SYSTEM (Adjustment and Tightening)

BASE + GLASS SUPPORT

FIXING BUSH ADHESIVE GASKET

1.33”

scale 1:1

faraone.it

2.91”

M12 ROD (1/2” ROD)

GLASS THICKNESS VARIATIONS:

The thickness of the glass can vary from a minimum of 8.8 (5/16”.5/16”) to a maximum of 10.10 (3/8”.3/8”) using the appropriate compensation shims inserted in the “RS System”.

On the left, the two variants with glass thickness change (highlighted in red).

ASSEMBLY OF THE RS SYSTEM - GLASS 8.8 (5/16”.5/16”)

MAIN APPLICATIONS

TOP-MOUNTED

8.8

(5/16”.5/16”)

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 10.10 (3/8”.3/8”)

EMBEDDED 1

10.10

(3/8”.3/8”)

WITHOUT SHIMS

Embedded 1 recommended for indoor use only

NINFA 106

THE GLASS BALUSTRADE FOR EXTERNAL FLUSH MOUNTING

faraone.it

NINFA 116

INIMITABLE PERFORMANCE

THE GLASS BALUSTRADE FOR EXTERNAL FLUSH MOUNTING

The NINFA 116 glass balustrade was created to increase the safety level of balconies, terraces, stairs, galleries and poolside fencing. It’s ideal for private and public spaces. NINFA 116, like the entire new series, has been verified through engineering software calculations and laboratory tests, including static load and dynamic impact tests, as required by Italian regulations. The profile accommodates both 8.8 and 10.10 (5/16” .5/16” and 3/8”.3/8”) glass thanks to the new RS system for adjusting and tightening the glass. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H For uncrowded environments: Tested to 300 kg/m 202 lb/ft Dynamic impact resistance up to 350 J 258 ft-lb

P For very crowded environments: Tested to 450 kg/m 302 lb/ft Dynamic impact resistance up to 600 J 440 ft-lb Ninfa 116 H (Home) Ninfa 116 P (Professional)

faraone.it

NINFA 116

TECHNICAL DETAILS

internal

external

SAFETY GLASS 8.8 or 10.10 (5/16”.5/16” or 3/8”.3/8”) 28

1.10”

SLIDE-IN GASKET

COMPENSATION SHIMS CAP FIXING HOUSING

114

4.48”

3.62”

NEW “RS” SYSTEM (Adjustment and Tightening)

BASE + GLASS SUPPORT

FIXING BUSH ADHESIVE GASKET

1.25”

122

scale 1:1

4.80”

M12 ROD (1/2” ROD)

faraone.it

GLASS THICKNESS VARIATIONS:

The thickness of the glass can vary from a minimum of 8.8 (5/16".5/16") to a maximum of 10.10 (3/8".3/8") using the appropriate compensator shims

inserted in the “RS System”. On the left, the two variants with glass thickness change (highlighted in red).

ASSEMBLY OF THE RS SYSTEM - GLASS 8.8 (5/16”.5/16”)

8.8

(5/16”.5/16”)

MAIN APPLICATIONS

TOP-MOUNTED flush with the exterior wall

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 10.10 (3/8”.3/8”)

10.10

(3/8”.3/8”)

EMBEDDED 1

solution indicated for external use

WITHOUT SHIMS

NINFA 116

THE GLASS BALUSTRADE WITH ULTRA SLIM DESIGN

faraone.it faraone.it

NINFA LA SERIE 6 56 NINFA

INIMITABLE PERFORMANCE

THE GLASS BALUSTRADE WITH ULTRA SLIM DESIGN

The NINFA 56 glass balustrade is the smallest of the series, in height and width (recommended for private spaces) it can be used in the following ways: 1) on a low reinforced concrete wall, the glass can have a variable height up to a maximum of 90 cm. (example 20 cm wall + 90 cm glass = H 110 cm, height now required in general) (wall 7.87” + glass 35.43” = H 43.31”). The use of the anti-climbing cladding for children is essential. 2) It can be top-mounted with the normal cladding and with the 8.8 (5/16”.5/16”) glass 100 cm (39.37”) high only if there is no risk of falling from height. (example: internal partition, ground floor, or similar). The profile accommodates 6.6 and 8.8 glass panels (1/4” . 1/4” and 5/16”. 5/16”), thanks to the new RS system for adjusting and tightening the glass. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H For uncrowded environments: Tested to 300 kg/m 202 lb/ft Dynamic impact resistance up to 350 J 258 ft-lb

P For very crowded environments: Tested to 450 kg/m 302 lb/ft Dynamic impact resistance up to 600 J 440 ft-lb Ninfa 56 H (Home) Ninfa 56 P (Professional)

faraone.it

NINFA 56

TECHNICAL DETAILS

internal

external

SAFETY GLASS 6.6 or 8.8 (1/4”.1/4” or 5/16”.5/16”)

0.86”

SLIDE-IN GASKET

2.20”

COMPENSATION SHIMS CAP FIXING HOUSING

3.26”

NEW “RS” SYSTEM (Adjustment and Tightening) BASE + GLASS SUPPORT

FIXING BUSH ADHESIVE GASKET

1.25”

scale 1:1

faraone.it

2.51”

M10 ROD (3/8” ROD)

GLASS THICKNESS VARIATIONS:

The thickness of the glass can vary from a minimum of 6.6 (1/4".1/4") to a maximum of 8.8 (5/16".5/16") using the appropriate compensator shims

inserted in the “RS System”. On the left, the two variants with glass thickness change (highlighted in red).

ASSEMBLY OF THE RS SYSTEM - GLASS 6.6 (1/4”.1/4”)

6.6 (1/4”.1/4”)

MAIN APPLICATIONS

TOP-MOUNTED Without risk of falling

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 8.8 (5/16”.5/16”)

8.8

(5/16”.5/16”)

TOP-MOUNTED ON UPSTAND With risk of falling

WITHOUT SHIMS

NINFA 56

THE GLASS BALUSTRADE WITH INTERNAL LATERAL FIXING

faraone.it

NINFA 176

INIMITABLE PERFORMANCE

THE GLASS BALUSTRADE WITH INTERNAL LATERAL FIXING

The NINFA 176 glass balustrade is the technology for internal side mounting, ideal for private and public spaces thanks to its performance. NINFA 176, like the whole new series, has been verified through engineering calculations and laboratory tests, including static load and dynamic impact tests, as required by Italian regulations. The profile accommodates 8.8, 10.10 and 12.12 (5/16” .5/16”, 3/8”.3/8” and 1/2”.1/2”) glass thanks to the new RS system for adjusting and tightening the glass. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H For uncrowded environments: Tested to 300 kg/m 202 lb/ft Dynamic impact resistance up to 350 J 258 ft-lb

P For very crowded environments: Tested to 450 kg/m 302 lb/ft Dynamic impact resistance up to 600 J 440 ft-lb Ninfa 176 H (Home) Ninfa 176 P (Professional)

faraone.it

NINFA 176

TECHNICAL DETAILS

internal SAFETY GLASS 8.8, 10.10 or 12.12 (5/16”.5/16”, 3/8”.3/8” or 1/2”.1/2”) GASKET SLIDE-IN COMPENSATION SHIMS

NEW “RS” SYSTEM (Adjustment and Tightening)

173

6.81”

112

4.40”

Some accessories, such as the adjusting block, the gaskets and the cladding can vary to accommodate different thicknesses of glass panels, such as the "compensator shims" shown in the drawing alongside.

2.20”

3.62”

This page shows the complete list of the main components.

external

BASE + GLASS SUPPORT

FIXING BUSH

scale 1:1

1.96”

CAP FIXING HOUSING

M12 ROD (1/2” ROD) 80

3.14”

faraone.it

GLASS THICKNESS VARIATIONS:

The thickness of the glass can vary from a minimum of 8.8 (5/16".5/16"), 10.10 (3/8”.3/8”) to a maximum of 12.12 (1/2".1/2") using the appropriate compen-

sator shims inserted in the “RS System”. On the left, the two variants with glass thickness change (highlighted in red).

ASSEMBLY OF THE RS SYSTEM - GLASS 8.8 (5/16”.5/16”)

8.8

MAIN APPLICATIONS

SIDE MOUNTED

(5/16”.5/16”)

SHIMS 8 mm (0.31”)

ASSEMBLY OF THE RS SYSTEM - GLASS 10.10 (3/8”.3/8”)

10.10

EMBEDDED 1

(3/8”.3/8”)

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 12.12 (1/2”.1/2”)

EMBEDDED 2

12.12

(1/2”.1/2”)

WITHOUT SHIMS

NINFA 176

THE GLASS BALUSTRADE WITH EXTERNAL LATERAL FIXING

faraone.it

NINFA 186

INIMITABLE PERFORMANCE

THE GLASS BALUSTRADE WITH EXTERNAL LATERAL FIXING

The NINFA 186 glass balustrade is designed for external side mounting, ideal for private and public spaces thanks to its performance. NINFA 186, like the whole new series, has been verified through engineering calculations and laboratory tests, including static load and dynamic impact tests, as required by Italian regulations. The profile accommodates 8.8, 10.10 and 12.12 (5/16” .5/16”, 3/8”.3/8” and 1/2”.1/2”) glass thanks to the new RS system for adjusting and tightening the glass. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H For uncrowded environments: Tested to 300 kg/m 202 lb/ft Dynamic impact resistance up to 350 J 258 ft-lb

P For very crowded environments: Tested to 450 kg/m 302 lb/ft Dynamic impact resistance up to 600 J 440 ft-lb Ninfa 186 H (Home) Ninfa 186 P (Professional)

faraone.it

The profile can also be installed flush with the edge of the step.

NINFA 186

TECHNICAL DETAILS

internal

external

SAFETY GLASS 8.8, 10.10, 12.12 (5/16”.5/16”, 3/8”.3/8” or 1/2”.1/2”)

1.25”

GASKET SLIDE-IN

3.62”

112

COMPENSATION SHIMS

4.40”

This page shows the complete list of the main components.

173

6.81”

NEW “RS” SYSTEM (Adjustment and Tightening) BASE + GLASS SUPPORT M12 ROD (1/2” ROD)

CAP FIXING HOUSING

1.96”

FIXING BUSH

scale 1:1

3.14”

faraone.it

GLASS THICKNESS VARIATIONS:

The thickness of the glass can vary from a minimum of 8.8 (5/16".5/16") to a maximum of 12.12 (1/2".1/2") using the appropriate compensator shims

inserted in the “RS System”. On the left, the two variants with glass thickness change (highlighted in red).

ASSEMBLY OF THE RS SYSTEM - GLASS 8.8 (5/16”.5/16”)

8.8

MAIN APPLICATIONS

FASCIA MOUNTED

(5/16”.5/16”)

SHIMS 8 mm (0.31”)

ASSEMBLY OF THE RS SYSTEM - GLASS 10.10 (3/8”.3/8”)

10.10

(3/8”.3/8”)

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 12.12 (1/2”.1/2”) 12.12

(1/2”.1/2”)

WITHOUT SHIMS

NINFA 186

faraone.it

NINFA 6

INIMITABLE PERFORMANCE

The NINFA 6 glass balustrade represents the new technology of the Faraone company with very high performance levels. It’s ideal for public and crowded places. NINFA 6, like the whole new series, has been verified through engineering calculations and laboratory tests, including static load and dynamic impact tests, as required by Italian regulations. The profile accommodates both 10.10 and 12.12 (3/8”.3/8” and 1/2”.1/2”) glass thanks to the new RS system for adjusting and tightening the glass. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H For uncrowded environments: Tested to 300 kg/m 202 lb/ft Dynamic impact resistance up to 350 J 258 ft-lb

P For very crowded environments: Tested to 450 kg/m 302 lb/ft Dynamic impact resistance up to 600 J 440 ft-lb Ninfa 6 H (Home) Ninfa 6 P (Professional)

faraone.it

NINFA 6

TECHNICAL DETAILS

internal

1.41”

GASKET SLIDE-IN COMPENSATION SHIMS

SAFETY GLASS 10.10 or 12.12 (3/8”.3/8” or 1/2”.1/2”)

3.62”

This page shows the complete list of the main components.

external

5.35”

CAP FIXING HOUSING 136

NEW “RS” SYSTEM (Adjustment and Tightening)

BASE + GLASS SUPPORT

FIXING BUSH ADHESIVE GASKET

1.57”

scale 1:1

faraone.it

3.38”

M12 ROD (1/2” ROD)

GLASS THICKNESS VARIATIONS:

The thickness of the glass can vary from a minimum of 10.10 (3/8".3/8") to a maximum of 12.12 (1/2".1/2") using the appropriate compensator

shims inserted in the “RS System”. On the left, the two variants with glass thickness change (highlighted in red).

ASSEMBLY OF THE RS SYSTEM - GLASS 10.10 (3/8”.3/8”)

10.10

MAIN APPLICATIONS

TOP-MOUNTED

(3/8”.3/8”)

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 12.12 (1/2”.1/2”)

EMBEDDED 1

12.12

(1/2”.1/2”)

WITHOUT SHIMS Embedded 1 recommended for indoor use only

NINFA 6

THE IDEAL COMPACT GLASS BALUSTRADE FOR LOW WALLS

faraone.it

NINFA 50 N

INIMITABLE PERFORMANCE

THE IDEAL COMPACT GLASS BALUSTRADE FOR LOW WALLS

The NINFA 50-N glass balustrade is the new technology from Faraone, ideal for residential and low wall installations. It passes all static load tests required by regulations.

SINGLE IUM L A UMIN , E IL F O PR UT WITHO ING CLADD

Glass thickness: 8.8 only (5/16".5/16"). Glass height: max. 600 mm (23.62“) from wall Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

H IL PARAPETTO IN VETRO COMPATTO IDEALE PER MURETTI

For uncrowded environments: Tested to 300 kg/m 202 lb/ft

Ninfa 50-N H (Home)

faraone.it

NINFA 50 N

TECHNICAL DETAILS

internal

external

This page shows the complete list of the main components. Unlike the other profiles in the Ninfa 6 series, the Ninfa 50-N profile does not use the RS system to adjust the glass, but rather an adjuster with a presser.

SAFETY GLASS 8.8 (5/16”.5/16”)

GASKET EXTERNAL SLIDE-IN

46,9 1.84”

INTERNAL GASKET PRESS-FIT

67,9 2.67“

PRESSURE GASKET NINFA 50-N PROFILE L-SHAPED GLASS-HOLDING PLASTIC ALUMINIUM MAX 20 mm

(0.79”)

FIXING BUSH

41,7 1.64“ 68 2.67“

scale 1:1 ADHESIVE GASKET M8X130 GALVANISED ROD (5/16”X5-1/8” GALVANISED ROD)

faraone.it

hh wall 800 800 (31.50“) muretto

hhwall 700 (27.56“) muretto 700

hhwall 500 (19.69“) muretto 500

h glass 600600 (23.62“) h vetro

h glass 600 600 (23.62“) h vetro

hh glass 600 (23.62“) vetro 600

INSTALLATION TYPES

With risk of falling from height

NINFA 50 N

6 STADIO

Bergamo Stadium

faraone.it

NINFA 6 STADIO

INIMITABLE PERFORMANCE

6 STADIO Sport is pure fun. People go to stadiums and sports centres to admire the champions, and this balustrade is up to the greatest sporting performances. Maximum safety for highly crowded places. Optional: External LED pack and handrail. Finishes: Standard and on request customisations.

6 STADIO P

IL PARAPETTO IN VETRO COMPATTO IDEALE PER MURETTI

For very crowded environments: – Sports facilities – Dividers – Barriers – Large-height glass panels

Ninfa 6 STADIO P (Professional)

faraone.it

Albinoleffe Stadium, Bergamo

NINFA 6 STADIO

STRUCTURAL INNOVATION Key features of the NINFA 6 STADIO profile The Ninfa 6 Stadio profile is a glass balustrade system designed by Faraone engineers for sports facilities and spectator stands (stadiums, arenas, school gyms, swimming pools, racetracks).

h 3 metres

The first thing that strikes you about the Ninfa Stadio system is its extraordinary dimensional capacity, reaching up to three metres in height. Achieving this maximum height means the balustrade can serve as a true transparent protective barrier. It is a testament to the structural stability of the aluminium profile which, combined with specifically engineered adjustment components and dedicated laminated safety glass, is able to safely anchor and stabilise such a tall element, maximising uninterrupted views. For heights of 3 metres (9’-10”) the use of a handrail is recommended

Bergamo Stadium

faraone.it

(h 9’-10”)

1. VERTICALITY BEYOND LIMITS: BALUSTRADES WITH HEIGHTS UP TO 3 METRES

Udine Stadium

2. SYMMETRICAL SAFETY: A COMBINATION OF INSTALLATION EFFICIENCY AND STRUCTURAL INTEGRITY WITHOUT EQUAL This is the crucial characteristic that differentiates the Ninfa 6 Stadio profile and defines its reliability in crowded public spaces: guaranteeing exceptional resistance performance to horizontal static linear loads in a perfectly symmetrical manner. This bidirectional resistance at maximum load is essential to ensure the balustrade maintains its structural properties. At the same time, the Ninfa 6 Stadio profile features a patented adjustment system that allows correction of glass alignment and inclination operated exclusively from the inside of the balustrade. Its internal architecture ensures that the fixing system and gaskets do not suffer differential settlements.

NINFA 6 STADIO

3. CERTIFICATION FOR THE EXTREME: PERFORMANCE UNDER "STADIUM-LEVEL" LOADS Top-load and wind-load tests verify the resistance and stability of glass balustrades.

The name itself, “Stadio”, derives from its extremely high-level certification. This profile has passed the most stringent tests required by the UNI EN 13200-3, specific to spectator structures in sports facilities.

The top load (1) simulates the horizontal thrust on the upper edge, while the wind load (2) reproduces the pressures and depressions due to wind action. These tests guarantee the structural safety and fall-prevention function of the system.

The performance level: The EN 13200-3 standard simulates extreme loads and the profile has been verified by calculation for the 500 kg/m class (336 lb/ft). Laboratory tests have demonstrated the capacity to resist loads of up to 900 kg/m (605 lb/ft). This level of robustness is the ultimate guarantee of a product that makes no compromises on safety in public spaces.

1: TOP-LOAD

faraone.it

2: WIND LOAD

Felice Scandone Swimming Pool, Naples

NINFA 6 STADIO

TECHNICAL DETAILS

internal

external

SAFETY GLASS 12.12 (1/2”.1/2”)

This page shows the complete list of the main components.

(1.49”)

GASKET SLIDE-IN

145

(5.70”)

108

(4.25”)

COMPENSATION SHIMS

NEW “RS” SYSTEM (Adjustment and Tightening)

(1.45”)

BASE + GLASS SUPPORT

FIXING BUSH

RUBBER WASHER 48

(1.88”) M12 ROD (1/2” ROD)

faraone.it

(3.81”)

GLASS THICKNESS:

MAIN APPLICATIONS

ASSEMBLY OF THE RS SYSTEM - GLASS 10.10 (3/8”.3/8”)

TOP-MOUNTED

The glass thickness is 12.12

10.10

(3/8”.3/8”)

SHIMS 4 mm (0.15”)

ASSEMBLY OF THE RS SYSTEM - GLASS 12.12 (1/2”.1/2”) 12.12

(1/2”.1/2”)

WITHOUT SHIMS

NINFA 6 STADIO

Philippe Chatrier, Roland Garros, Paris (Photo: Ercole Salinari)

faraone.it

Udine stadium

Left: Qemal Stafa Stadium, Tirana Right: Albinoleffe Stadium, Bergamo

NINFA 6 STADIO

Nereo Rocco stadium, Trieste

Mugello Circuit

faraone.it

U-Power stadium, Monza

NINFA 6 STADIO

NINFA LED: OUTSIDE THE PROFILE LED Housing on the internal side of the profile

Opzioni posizionamento led > ac

LED profile screwed to the Ninfa aluminium profile. Inclined projection of light downwards creating a ‘step-light’ effect. (LED not supplied by Faraone) Valid for models: Ninfa 6 Stadio, 6, 106, 56

LED POSITIONING OPTIONS - NEW INTERNAL ACCESSORY internal

external

Variable vertical positioning

6 STADIO

IL PARAPETTO IN VETRO SICURO IDEATO PER IMPIANTI SPORTIVI

internal

faraone.it

external

internal

external

internal

external

internal

external

NINFA LED: OUTSIDE THE PROFILE LED Housing on the external side of the profile

mento led > accessorio nuovo esterno LED profile screwed to the Ninfa aluminium profile. Inclined projection of light downwards. Ideal for creating a lighting effect on the outside of the balcony, making each one clearly visible and producing a unique effect together with the building’s lighting. (LED not supplied by Faraone) Valid for models: Ninfa 6 Stadio, 6, 106, 56, 116 LED POSITIONING OPTIONS - NEW EXTERNAL ACCESSORY

Led Led Led Led Montaggio Montaggio Montaggio Montaggio in ininin basso basso basso basso external

internal

Variable vertical positioning

Led Led Led montaggio montaggio montaggio montaggio esterno esterno esterno esterno profilo profilo profilo profilo 6Led STADIO

IL PARAPETTO IN VETRO SICURO IDEATO PER IMPIANTI SPORTIVI

internal

external

internal

external

internal

external

internal

external

internal

external

NINFA THE SERIES 6

NINFA LED: OUTSIDE THE PROFILE LED Housing on the internal and external sides of the profile

sorio nuovo esterno

LED profile screwed to the Ninfa aluminium profile. Inclined projection of light downwards. Dual use internal/external lighting. (LED not supplied by Faraone) Valid for models: Ninfa 6 Stadio, 6, 106, 56

LED POSITIONING OPTIONS - INTERNAL/EXTERNAL ACCESSORY

Variable vertical positioning

internal

external

Variable vertical positioning

6 STADIO

IL PARAPETTO IN VETRO SICURO IDEATO PER IMPIANTI SPORTIVI

internal

faraone.it

external

internal

external

Led LedMontaggio Montaggioinin inbasso basso Led Montaggio basso

internal

external

internal

external

Opzioni posizionamento led > accessorio nuovo esterno

NINFA LED: OUTSIDE THE PROFILE Bottom LED housing for fascia-mounted aluminium profiles LED profile screwed to the bottom of the Ninfa aluminium profile. Inclined projection of light downwards. The new LED system can also be used with the fascia-mounted profiles, which can be oriented as preferred. (LED not supplied by Faraone) Valid for models: Ninfa 176, 186 LED POSITIONING OPTIONS - BOTTOM ACCESSORY

Variable horizontal positioning

Led LedMontaggio Montaggio Led Montaggio ininbasso basso in basso internal

external

internal

external

internal

external

internal

external

Opzioni posizionamento led carter e fissaggio

NINFA THE SERIES 6

NINFA LED: INSIDE THE PROFILE Installation of the LED strip in the cladding To optimize installation processes and ensure faster, more convenient maintenance, the new LED position has been moved inside the cladding. This upgrade offers several benefits and corresponding adaptations: - Total Accessibility: In the event of servicing or replacing the LED strip, restoration work can be carried out directly by removing the cladding, without needing to remove the glass. - Cost Efficiency and Standardization: Enables the use of standard fixings (threaded rod, nut, and washer) on the Ninfa 106 and Ninfa 56 profiles as well. - RS Component Update: Following this geometric transition, all L-shaped components of the RS adjustment system will no longer be transparent, but will be produced in a colour coordinated with the corresponding T-piece.

Technical Specifications for the LED Strip: For geometric reasons and to ensure proper mechanical installation within the profile, the LED strip used must meet the following requirements: Fixing: The strip must be equipped with an adhesive backing on the rear to allow perfect anchoring and alignment within the dedicated channel inside the aluminium cladding. Maximum Width: 10 mm Maximum Height: 7 mm It is recommended to use LED strips with a protection rating of at least IP65/68 and with heat resistance ratings certified according to the MS CG-12 and GM6073 tests.

Adhesive backing Banda adesiva

faraone.it

TECHNICAL DETAILS LED POSITIONING OPTIONS

Light diffusion on the glass

internal

external

6 STADIO

IL PARAPETTO IN VETRO SICURO IDEATO PER IMPIANTI SPORTIVI

internal

external

internal

external

internal

external

internal

external

internal

external

internal

external

internal

external

NINFA THE SERIES 6

DEDICATED SOLUTIONS FOR WATER DRAINAGE

ALUMINIUM SHIMS

The Ninfa profile remains raised to allow water to run off. Consult the designer and/or Works Supervisor to determine the water load on the balcony. > ADVANTAGES: – Made to fit perfectly with the Ninfa profile – Double hole for greater stability – Same finish as aluminium profile – 20 micron (0.79 mil) anodising, after processing

faraone.it

TECHNICAL DETAILS DISTRIBUTION OF ALUMINIUM SHIMS Standard layout

Double shims

Set up with odd numbered holes and custom cut

Single shims Individual accessories are also available for odd-numbered holes and custom cut.

0 30

”)

.81

”)

.81

(11

11 0(

3”)

3.9

( 00

3”)

3.9

( 00

”)

.74

15 0(

”)

3. 0(

NINFA THE SERIES 6

DEDICATED SOLUTIONS FOR WATER DRAINAGE TYPES OF PROFILE PROCESSING: Processing and accessories that allow water to drain away. A) Profile with through milling Solution for draining water without the use of shims. Static load tests were carried out in the laboratory with the processed profile (minimum 600 mm / 23.62” in centre distance). In order to determine the number of through holes in a given context/project, we recommend that you rely on your designer and/ or structural engineer, who will have to consider the possible design water load and thus determine the optimal spacing. Valid for models: Ninfa 6,106 B) Profile with side hole Solution for draining any water present in the profile (minimum of 3 holes per 6 m / 19’ 8” profile).

faraone.it

TECHNICAL DETAILS PROFILE WITH THROUGH MILLING FOR WATER DRAINAGE A

O FORO INTERNO FORO ESTERNO FORO INTERNO FORO ESTERNO FORO ESTERNO

minimum centre-to-centre spacing 600 mm (23.62”)

Black or grey polycarbonate square hole trim accessory. Profile milling: 40.5x20 mm (1.59x0.79”)

FORO INTERNO FORO INTERNO

PROFILE WITH SIDE HOLE FOR INTERNAL WATER DRAINAGE

FORO ESTERNO FORO ESTERNO

B Profile with a minimum of 3 Ø 9 mm (0.35”) holes per 6 metre (19’ 8”) profile.

Hole Ø 9 mm (0.35”)

NINFA THE SERIES 6

NINFA176/186 SOLUTIONS FOR WATER DRAINAGE AND COVER PROFILES 8+8 (5/16”+5/16”)

0 / -- 50

(0/ -1.96”)

0 / -- 50

(0/ -1.96”)

0 / -- 50

Example valid for models: Ninfa 176/186 with 8+8 (5/16"+5/16") glass

(0/ -1.96”)

CONNECTION BETWEEN FLOOR AND PROFILE

10+10 (3/8”+3/8”)

CONNECTION BETWEEN FLOOR AND PROFILE Example valid for models: Ninfa 176/186 with 10+10 (3/8"+3/8") glass

12+12 (1/2”+1/2”)

CONNECTION BETWEEN FLOOR AND PROFILE Example valid for models: Ninfa 176/186 with 12+12 (1/2"+1/2") glass

faraone.it

(5.66”)

TECHNICAL DETAILS

144

APPLICATIONS WATER DRAINAGE / SPACER WITH LATERAL FIXING Example valid for models: Ninfa 176/186

(3.15”)

(1.18”)

STEP01

STEP02

a) Fix the lateral spacer/water drainage to the profile

a) Fix the profile to the wall following the installation instructions for NINFA 176/186

b) Prepare the fixing screws

STEP03

STEP04

a) Prepare the accessories inside the profile, following the installation instructions for NINFA 176/186

a) Insert, adjust, and lock the glass using the RS system b) Insert the internal and external cover.

NINFA THE SERIES 6

COVER CLADDING External cover cladding

For a perfect finish and connection between floor and glass, with no visible screws; snap-fit only.

faraone.it

TECHNICAL DETAILS 8+8

APPLICATIONS ON FLOATING FLOOR Example valid for models: Ninfa 6,106,56,116

10+10

CONNECTION BETWEEN FLOOR AND PROFILE Example valid for models: Ninfa 176

10+10

CONNECTION BETWEEN FLOOR AND PROFILE Example valid for models: Ninfa 186

NINFA THE SERIES 6

Carter coprifilo serie 6 Carter coprifilo serie 6 55

Carter Carter Cartercoprifilo coprifilo coprifiloserie serie serie666 55

TYPES

62 62 62 28(2.44”)

55 55 55 (2.16”)

28 28 28 (1.10”)

40 40 40 (1.57”)

NINFA 6

28 28 28 (1.10”)

GASKETS

black colour

10+10

12+12 (1/2”.1/2”)

Example of cover cladding and gasket combination with Ninfa 6 and 12+12 (1/2"+1/2") glass 2) External cover cladding A) Slide-in gasket

faraone.it

TECHNICAL DETAILS

With 10+10 (3/8"+3/8") glass: Cover 1 + gasket B

With 8+8 (5/16"+5/16") glass: Cover 2 + gasket A

With 12+12 (1/2”+1/2”) glass: Cover 2 + gasket A

With 10+10 (3/8”+3/8”) glass: Cover 2 + gasket B

With 8+8 (5/16"+5/16") glass: Cover 3 + gasket B

With 8+8 (5/16"+5/16") glass: Cover 1 + gasket A

With 10+10 (3/8”+3/8”) glass: Cover 3 + gasket B

With 10+10 (3/8”+3/8”) glass: Cover 2 + gasket A

With 12+12 (1/2”+1/2”) glass: Cover 3 + gasket B

With 12+12 (1/2”+1/2”) glass: Cover 2 + gasket B

NINFA THE SERIES 6

ACHIEVEMENTS WITH NINFA BALUSTRADES OVER THE YEARS.

faraone.it

100

NINFA, Maritime Station, Salerno, IT

101

NINFA THE SERIES 6

NINFA, Maritime Station, Salerno, IT

faraone.it

102

Curved glass in private residence, Marcianise (CE), Partner: Idea Vetro

Enzo Ferrari Museum, Maranello (MO)

Redevelopment of the Malgrate lakeside promenade, Malgrate (LC), IT, Partner: Vetreria Colombo

103

NINFA THE SERIES 6

NINFA, Shopping centre Berlin, DE

NINFA, Rome Fiumicino Airport, IT

faraone.it

104

NINFA WITH LED, Bridge of Peace, Tbilisi, Georgia

Convention Centre, Rome

105

NINFA THE SERIES 6

Ninfa balustrades, Residential building, Milan area

Multifunctional building, Cuneo, IT

faraone.it

106

Multifunctional building, Cuneo, IT

107

NINFA THE SERIES 6

Baldoria (ex Velvet) Rimini Partner: Vetreria Nuova Romagnola

Bergamo stadium

faraone.it

108

Felice Scandone Swimming Pool, Naples

Ninfa balustrades, Residential building, Milan area

Residential building, Jesolo

109

NINFA THE SERIES 6

Residential building, Milan

Residential building, Pescara

faraone.it

110

Residential building, Milan

111

NINFA THE SERIES 6

Hotel in Riccione, Partner: Vetreria Nuova Romagnola

faraone.it

112

Residential building, Pescara

113

NINFA THE SERIES 6

ASSEMBLY INSTRUCTIONS NINFA THE SERIES 6 Download the assembly instructions in PDF format

IL PARAPETTO IN VETRO COMPATTO IDEALE PER MURETTI

faraone.it

114

6 STADIO

IL PARAPETTO IN VETRO SICURO IDEATO PER IMPIANTI SPORTIVI

CUSTOMER CARE Our experience is at your service. We guide you in choosing the best solution for your needs.

EXPERT GUIDE

INSTALLATION

Managing a project through all its phases can be challenging. That is why we provide comprehensive support, from technical consultation through to after-sales service.

We carefully select the experts who carry out the installation of our products to ensure our quality standards. During this phase, tests are carried out on site to ensure that the installation has been performed in a competent manner and that everything is safe.

How to contact us: email: faraone@faraone.it web: faraone.it Contact us now

Watch the installation video

115

NINFA THE SERIES 6

TECHNICAL SPECIFICATIONS Ninfa glass balustrade system (or similar), 10+10 (3/8"+3/8"), 12+12 (1/2"+1/2") up to a C25/30. Special attention is recommended compliant with current standards, with glass height of 1400 mm (55.118”); when drilling through the waterproofing relevant test report including: membrane; in this case, epoxy resins 1/F) Model NINFA 116 profile size of capable of restoring the seal between the Static load test with horizontal static linear 122x114 mm (4.80"x 4.48") (base x height), rod and the drilled membrane are advised load of 2 kN/m (137 lb/ft) or 3 kN/m (206 lb/ft). linear horizontal load from 2 to 3 kN/m (e.g. Hilti HIT-Re 500 V4, or similar). Dynamic load test with variable pendulum (137 to 206 lb/ft) for laminated glass* 8+8 Standard fixing span: 20 cm (7.87”). height depending on the intended use and (5/16"+5/16"), 10+10 (3/8"+3/8") up to a possible breakage of glass. glass height of 1400 mm (55.118”); a.5) WATER DRAINAGE HOLES: any water Technical drawings with the heights and present inside the profile can be drained dimensions of each component of the 1/G) Model NINFA 50-N profile size of 68x68 through appropriate drainage holes in the balustrade. In addition, the type of glass mm (2.68x2.68”) (base x height), linear Ninfa profile. panes and interlayer of the laminated horizontal load from 2 kN/m (137 lb/ft) for package must be defined in order to meet laminated glass* 8+8 (5/16”+5/16”) up to a a.6) ALUMINIUM FINISHES. Exposed the PR “post-breakage” requirement. glass height of 600 mm (23.622”); aluminium profiles shall be anodised in silver or other anodised-range colours on 1. CHARACTERIZATION OF NINFA SERIES 6 1/H) Ninfa 6 Stadio - 5 kN (343 lb/ft) request. Anodising thickness: 20 microns BALUSTRADES a.1) BASE PROFILE suitable for floor (0.79 mil) (Qualanod mark). Alternatively Ninfa glass balustrade system or railing installation, made with 6063 T66 aluminium powder coated in RAL colours (Qualicoat (or similar) made with 6060 T66 or 6063 alloy extruded profiles, for positioning mark) or other colours upon request. T66 aluminium alloy profile of the model and adjustment of the glass panel. The chosen by the Works Supervisor, based on profile geometry is specifically engineered a.7) LABORATORY TEST REPORTS: the intended use and the resistance class; to guarantee both stiffness under static The complete balustrade system must be suitable for floor mounting, embedded, or load and the flexibility required to absorb supported by laboratory test reports carried fascia mounting, to be chosen from the accidental impacts. out in the laboratory in full compliance with following models (or similar): the following regulations: a.2) GLASS consisting of 2 toughened glass • UNI EN 13200-3:2018 separation elements 1/A) NINFA 6 model, profile size 86x136 mm panes 12 mm (1/2”) thick each, laminated for spectators in stadiums and grandstands; (3.39x5.35”) (base x height), linear horizontal with rigid interlayer (SentryGlas type or Additional indications on laboratory tests: load from 2 to 5 kN/m (137 to 343 lb/ft) for similar belonging to family 2 according to • The report must include technical drawings laminated glass* 10+10 3/8”+3/8”), 12+12 EN 16613:2019) with a minimum height of with the dimensions and thickness of (1/2”+1/2”) up to a glass height of 1500 mm 1100 mm (43.30”) or as required. the glass, the type of interlayer used for (59.06”). lamination; a.2A) Glass panels used as separators • The certificate must include all photos 1/B) Model NINFA 106 profile size of 74x111 between spectators with heights up to 2.3 of the sample during the test phases, also mm (2.91"x 4.37") (base x height), linear metres (7’ 6.54”) without connection, and up illustrating the type of assembly with the horizontal load from 2 to 3 kN/m (137 to 206 to 3 metres (9’ 10.11”) but connected by an balustrade free from any lateral constraint. lb/ft) for laminated glass* 8+8 (5/16"+5/16"), aluminium top rail profile properly fixed to Individual pages must be stamped by the 10+10 (3/8"+3/8") up to a glass height of the glass panels. certification body; 1400 mm (55.118”); • The Designer or Works Supervisor reserves a.3) ACCESSORIES: glass fixing to the the right to request an experimental test 1/C) Model NINFA 56 profile size 64x83 aluminium profile is achieved through directly on site (with the same system and mm (2.51"x 3.26") (base x height), linear special accessories with adjusters that allow standards used in the laboratory) in order to horizontal load from 2 to 3 kN/m (137 to 206 plumb alignment, levelling and tightening of assess the quality of the balustrade system lb/ft) for laminated glass* 6+6 (1/4"+1/4"), the glass panels — operations carried out and above all the resistance of the fixing in use. 8+8 (5/16"+5/16") up to a glass height of 900 exclusively from the inside of the balustrade mm (35.433”); (4 kits per metre of profile are provided). 2. FUNCTIONALITY AND AESTHETICS OF The glass, both on the external and internal THE NINFA BALUSTRADES 1/D) Model NINFA 186 profile size of 80x173 side, comes into contact only with the The aluminium profile of the balustrade will mm (3.14"x 6.81") (base x height), linear plastic adjusters. be equipped with special accessories that horizontal load from 2 to 3 kN/m (137 to 206 The gaskets inserted in the profile grooves allow adjustment for the alignment and lb/ft) for laminated glass* 8+8 (5/16"+5/16"), complete the upper seal between the glass plumb alignment of the glass sheets. 10+10 (3/8"+3/8"), 12+12 (1/2"+1/2");* up to and the aluminium profile. The type and quantity of floor/slab/wall a glass height of 1500 mm (59.06”); fixings for the profiles will vary according to a.4) FIXING: the profile is fixed to the floor the resistance class requested by the Works 1/E) Model NINFA 176 profile size of 80x173 with M12 (1/2”) threaded rods and chemical Supervisor and the nature of the support. mm (3.14"x 6.81") (base x height), linear resin anchor. Fixing must be carried out Where fixing is carried out on a reinforced horizontal load from 2 to 3 kN/m (137 to 206 on reinforced concrete beam or slab, concrete beam or slab, the concrete must be lb/ft) for laminated glass* 8+8 (5/16"+5/16"), ensuring the concrete is of minimum class of minimum class C25/30.

faraone.it

116

Exposed aluminium profiles shall be type of project and the requirements of the anodised in silver, 15 micron (0.60 mil) designer and Works Supervisor. class (or other colours upon request), or The use of rigid interlayers belonging alternatively powder coated with epoxy to Family 2 (EN 16613), combined with powder in RAL colours or other colours upon adequate thicknesses of toughened request. glass, allows for improved resistance and stiffness of the glazed panel. 3. PERFORMANCE IN POST-BREAKAGE Experimentally, residual resistance to static CONDITIONS and dynamic loads can be guaranteed For the NINFA system profiles it is sufficient even with one or both panes broken. to use tempered-hardened laminated glass to obtain residual post-breakage resistance. Test reports on balustrades are prepared by It is advisable to pay extreme attention to laboratories authorised by the Ministry of the installation of the hardened sheet, which Infrastructure and Transport. must be placed in the compressed part of For the tests to be considered valid, the laminate, i.e. externally to the horizontal any handrail or the upper part of the static linear load and impacts. balustrade must not have any fixings to walls and/or columns. The floor 4. ADDITIONAL SAFETY GUARANTEES IN anchorage of the balustrade must POST-BREAKAGE OF GLASS AND HANDRAIL reproduce the most unfavourable To ensure “system redundancy” and satisfy fixing conditions; therefore a cracked the post-breakage criterion, the Works reinforced concrete substrate of maximum Supervisor may also require an upper strength class C25/30 is recommended. handrail anchored and bonded to the individual glass panes in order to ensure, in The certificate must also include photos of case of breakage of the sheets, the transfer the assembled sample to demonstrate the of linear loads to the adjacent intact sheets type of test carried out. and the reduction of the risk of collapse of the laminate glass with both sheets broken. TO LEARN MORE Note that this solution involves a price Consult the document “Guide to designing increase due only to the cost of the handrail. glass balustrades” on the www.faraone.it website. RIGID INTERLAYER To ensure “system redundancy” and achieve This documentation is the result of a the satisfaction of the post-breakage long and careful experimental campaign criterion, without the use of the upper combined with Faraone’s experience, and handrail, it is possible to improve the makes available to all interested parties the performance of the plastic interlayer. many tests carried out and the behaviour/ * In this case the glass panes will be both performance of the various glass solutions tempered-hardened and combined with rigid (all valid with Faraone systems only). plastic interlayers belonging to family 2, as Ing. Gabriele Romagnoli defined in EN 16613. Such systems must guarantee a load resistance of 1 kN/m (69 lb/ft) even with one pane broken, and prevent immediate collapse of the laminated unit in the event of both panes breaking. Note that this solution involves a price increase due to the cost of lamination with rigid interlayer. Paragraph to be used according to the

117

NINFA THE SERIES 6

GENERAL CONDITIONS OF SALE Transportation costs shall be evaluated with NB. The information, technical data, conevery offer, according to volume, weight and figurations, drawings, photographs, renderings, graphic simulations and images destination. generated with artificial intelligence tools contained in this catalogue/document are COMPLAINTS: Any complaint must be sent to Faraone for illustrative and informational purposes within a strict deadline of 8 days from receipt only and do not constitute a public offer or of goods. Unless previously authorised by contractual commitment. Faraone, returns sent carriage collect will The images do not necessarily represent not be accepted. real installations, real contexts or configuAny returned products that should arrive at rations actually supplied. Faraone without prior authorization will be Faraone reserves the right to make chanrefused without exception and returned to ges to products for technical, manufacturing, regulatory or improvement the sender by carriage collect. reasons, without prejudice to what is expressly stated in the offer, order confirPAYMENT METHOD: For foreign countries, payment for goods mation and technical and commercial domust be made by bank transfer in advance. cumentation in force at the time of supply. Other payment methods will be agreed Unless otherwise indicated, the contents of this material are proprietary and used by Fasubject to credit insurance approval. - VAT: all prices listed in the price lists are raone within the scope of the relevant rights. Reproduction, even partial, by any means, exclusive of VAT. without prior written authorisation is prohibited, except for uses permitted by law. Prices, where indicated in materials intended for customers, are understood to be exclusive of VAT, transport, installation and any other ancillary charges, unless otherwise agreed in writing.

We thank our partners for the shared photographic material. - Idea Vetro - Vetreria Colombo - Vetreria Nuova Romagnola

faraone.it

118

Certifications:

Memberships:

119

NINFA THE SERIES 6

With the latest generation of Ninfa balustrades.

faraone.it

mcomunicare.it/marcoceci CAT-NINFA6R-EN 09/2026-R06

Take care of the people you love.
