NO PARKING FIRE LANE 12"X 18�)°1/ (7
BUILDING
NO PARKING FIRE LANE 12"X 18�)°1/ (7
4" YELLOW LINE @ 45° - 5• o.c. (TYP.)
NOTES:
1. The pavement shall be painted with parallel four-inch-wide yellow strip lines every 5' on center extending at lest 3' from edge of the pavement. FIRE LANE DETAIL
