TOP QUALITY – MADE BY KLAUKE

Always a secure connection...

... and that's our promise to you.

Since 1960, we've been the go-to partner for electrical connection materials. "Made by Klauke" means more than just a slogan: we do our own development, we are passionate about design, we manufacture the products ourselves and we have the highest expectations when it comes to the perfect connection. We perform testing regularly, both in our in-house laboratory and at independent test centers. This is how we ensure that all products we offer you are of outstanding quality, fully compatible and combined into a perfect system.

Our extensive portfolio is a proof of our expertise. We offer solutions in electrical connection technology from 0.14 to 1,000 mm², for almost every challenge in electrical installation. As a trendsetter, we've created our own cable lug series (the R-Series), and work closely with key customers when it comes to customized individual solutions for various applications.

In our cable lug manufacturing, we always go for the best materials, using high-purity copper and aluminum, which ensure a perfect electrical connection. The soft copper ensures an optimized material flow during crimping and reduces the effort required.

OUR PROMISE

Klauke takes your needs seriously. For us, "Made by Klauke" means that all products are manufactured with the highest quality.

ALWAYS ON THE SAFE SIDE, WITH KLAUKE

Safety and reliability through quality

Our products are tested by authorized inspection agencies certified to ISO 17025 so that we're able to offer our customers – and thereby your customers, too – the highest safety and reliability possible. This ensures accurate and reliable test results. The scope of testing ranges from the connection materials we use to the tools we make. This serves to firmly

CERTIFICATES

Company

– ISO 14001

– ISO 9001

Quality of the connection

– IEC 61238-1 (Class A)

– UL468A-468B

– DNV

Merely meeting the standards' requirements is not enough for us. When it comes to safety and reliability, usability and robustness, Klauke's products fulfill the highest demands and deliver more than the standards require.

establish the prerequisites for market entry and guarantees quality assurance, because the conformity assessment includes performance and qualification testing ranging from drop tests, flammability tests and functional safety tests to screw tear-out tests and much more.

Safety of the tools

– IEC 62841-1

– VDE nach REG. F647

Certified quality management systems of the Klauke companies

– ISO 9001:2015 - Customer- and process-oriented quality management system

– IATF 16949:2016 - The IATF 16949 standard goes beyond the DIN ISO 9001-series standards, and is the internationally recognized standard for quality management systems in the automotive industry.

– ISO 14001:2015 - Environmental management systems for continuously improving environmental performance

Solar power systems are an essential green energy source for the present and future generations. But if we talk about the optimal efficiency of the solar panels, a factor that is often underestimated is the quality and reliability of the electrical connection elements.

When it comes to safe and reliable cable connections, Klauke has proven expertise for over 60 years. From engineering and design, to customized solutions, manufacturing and services, Klauke is the industry leader in connecting materials and electrical tools.

In a solar park you will find Klauke products every time when you connect a combiner box, an inverter or a transformer.

A COMPLETE SOLUTION FOR QUALITY

When connecting a combiner box, it is important to establish a safe connection.

Combiner Box

QUALITY SOLAR INSTALLATIONS

Inverter

With the mostly prefabricated inverters, professional cable processing and connection is a must-have.

EKM6022 ESM50

Tubular cable lugs, Cu EK30IDML

EKWF120ML Wire ferrules

Compression cable lugs, Al/Cu

COMBINER BOX INSTALLATION

EKM 60 ID

Battery powered hydraulic crimping tool 10 - 240 mm²

• Extra large crimping area due to innovative 2-stage telescopic cylinder

• Indent crimping - no change of crimping dies required

EK 50 ML

Electromechanical crimping tool

0,5 - 50 mm²

• With the multitude of available crimping dies, the Klauke micro offers a very wide range of applications

• Excellent crimping results with minimum effort

EKM 60/22

Battery powered hydraulic crimping tool 6 - 300 mm²

• The EKM6022 has a very large crimping range of up to 300 mm²

• Interchangeable crimping dies of the 22 series can be used

ESM 50

Battery powered hydraulic cutting tool

50 mm dia. for copper and aluminium cable

• High cutting power for cutting copper and aluminium cables (fine-stranded also)

• Saves time with multiple cuts thanks to the manual retract stop (MRS)

• Very low weight (3kg)

• Optimum center of gravity

ES 32 F ML / ES 32 ML

Battery powered hydraulic cutting tools

32 mm dia.

• The ES32FML is ideally suited for cutting fine and superfine stranded copper cables

• The ES32ML is designed for cutting multi-stranded copper and aluminium cables

• Both tools have a slim cutting headideal when space is critical

Compression cable lugs, Al/Cu and aluminum, tinned

Al/Cu: 16 - 400 mm2 , Aluminum: 16 - 500 mm2

• For non-tension connections of Al conductors to DIN EN 60228

• Tube dimension to DIN 46329

Tubular cable lugs, Cu, standard type

6 - 400 mm2 , R-Series

• For multi-stranded round conductors, e.g. to DIN EN 60228 Cl. 2

• In combination with the EKM 60 ID suitable for fine wired conductors

• For pre-rounded multi-stranded sector shaped conductors

• Also available as a connector

Insulated

cable end-sleeve according to DIN with Easy-Entry

• For fine and superfine stranded conductors, e.g. according to DIN EN 60228 Cl. 5 and 6

• Easy-Entry Insulation for splice-free cable entry

• Alternative color codings available

K 507 WF

Crimping tool with interchangeable crimping dies for wire ferrules, 0,5 - 50 mm²

• Changing crimping dies on the K507WF is quick and easy (dies easily stowed in the handle)

• Due to the optimum width, fewer pressings are required
