Chapter1
SolutionstoExerciseswithintheChapter
Ex:1.1 Whenoutputterminalsare open-circuited,asinFig.1.1a:
Forcircuita. v oc = v s (t )
Forcircuitb. v oc = is (t ) × Rs
Whenoutputterminalsareshort-circuited,asin Fig.1.1b:
Forcircuita. isc = v s (t ) Rs
Forcircuitb. isc = is (t )
Forequivalency
Rs is (t ) = v s (t )
vs (t) Figure1.1a is (t)
Figure1.1b
Ex:1.2
voc vs Rs isc
v oc = 10mV
isc = 10 µA
Rs = v oc isc = 10mV 10 µA = 1k
Ex:1.3 Usingvoltagedivider:
v o (t ) = v s (t ) × RL Rs + RL
vs (t) vo Rs RL
Given v s (t ) = 10mVand Rs = 1k
If RL = 100k
v o = 10mV × 100 100 + 1 = 9.9mV
If RL = 10k
v o = 10mV × 10 10 + 1 9.1mV
If RL = 1k
v o = 10mV × 1 1 + 1 = 5mV
If RL = 100
v o = 10mV × 100 100 + 1K 0.91mV
For v o = 0.8v s , RL RL + Rs = 0.8
Since Rs = 1k , RL = 4k
Ex:1.4 Usingcurrentdivider: Rs is 10 A RL io
io = is × Rs Rs + RL
Given is = 10 µA, Rs = 100k For RL = 1k , io = 10 µA × 100 100 + 1 = 9.9 µA For RL = 10k , io = 10 µA × 100
+ 10 9.1 µA For RL = 100k , io = 10 µA × 100 100 + 100 = 5 µA
For RL = 1M , io = 10 µA × 100K 100K + 1M
0.9 µA
For io = 0.8is , 100 100 + RL = 0.8
⇒ RL = 25k
Ex:1.5 f = 1 T = 1 10 3 = 1000Hz
ω = 2π f = 2π × 103 rad/s
Ex:1.6 (a) T = 1 f = 1 60 s = 16.7ms
(b) T = 1 f = 1 10 3 = 1000s
(c) T = 1 f = 1 106 s = 1 µs
Ex:1.7 If6MHzisallocatedforeachchannel, then470MHzto608MHzwillaccommodate
806 470 6 = 23channels
Sincethebroadcastbandstartswithchannel14,it willgofromchannel14tochannel36.
Ex:1.8 P = 1 T T 0 v 2 R dt
= 1 T × V 2 R × T = V 2 R
Alternatively, P = P1 + P3 + P5 +··· = 4V
Itcanbeshownbydirectcalculationthatthe infiniteseriesintheparentheseshasasumthat approaches π 2 /8;thus P becomes V 2 /R asfound fromdirectcalculation.
Fractionofenergyinfundamental
= 8/π 2 = 0.81
Fractionofenergyinfirstfiveharmonics
= 8 π 2 1 + 1 9 + 1 25 = 0.93
Fractionofenergyinfirstsevenharmonics
= 8 π 2 1 + 1 9 + 1 25 + 1 49 = 0.95
Fractionofenergyinfirstnineharmonics
= 8 π 2 1 + 1 9 + 1 25 + 1 49 + 1 81 = 0.96
Notethat90%oftheenergyofthesquarewaveis inthefirstthreeharmonics,thatis,inthe fundamentalandthethirdharmonic.
Ex:1.9 (a) D canrepresent15equally-spaced valuesbetween0and3.75V.Thus,thevaluesare spaced0.25Vapart.
v A = 0V ⇒ D = 0000
v A = 0.25V ⇒ D = 0000
v A = 1V ⇒ D = 0000
v A = 3.75V ⇒ D = 0000
(b)(i)1levelspacing:20 ×+0.25 =+0.25V
(ii)2levelspacings:21 ×+0.25 =+0.5V
(iii)4levelspacings:22 ×+0.25 =+1.0V
(iv)8levelspacings:23 ×+0.25 =+2.0V
(c)Theclosestdiscretevaluerepresentedby D is +1.25V;thus D = 0101.Theerroris-0.05V,or 0.05/1.3 × 100 =−4%.
Ex:1.10 Voltagegain = 20log100 = 40dB
Currentgain = 20log1000 = 60dB
Powergain = 10log Ap = 10log (Av Ai ) = 10log105 = 50dB
Ex:1.11 Pdc = 15 × 8 = 120mW
PL = (6/√2)2 1 = 18mW
Pdissipated = 120 18 = 102mW
η = PL Pdc × 100 = 18 120 × 100 = 15%
Ex:1.12 v o = 1 × 10 106 + 10 10 5 V = 10 µV
PL = v 2 o /RL = (10 × 10 6 )2 10 = 10 11 W
Withthebufferamplifier:
v o = 1 × Ri Ri + Rs × Av o × RL RL + Ro = 1 × 1 1 + 1 × 1 × 10 10 + 10 = 0.25V
PL = v 2 o RL = 0.252 10 = 6.25mW
Voltagegain= v o v s = 0.25V 1V = 0.25V/V
=−12dB
Powergain (Ap ) ≡ PL Pi where PL =6.25mWand Pi = v i i1 ,
v i = 0.5Vand
ii = 1V 1M + 1M = 0.5 µA
Thus, Pi = 0.5 × 0.5 = 0.25 µW and
Ap = 6.25 × 10 3 0.25 × 10 6 = 25 × 103
10log Ap = 44dB
Ex:1.13 Open-circuit(noload)outputvoltage=
Av o v i
Outputvoltagewithloadconnected
= Av o v i RL RL + Ro
0.8 = 1 Ro + 1 ⇒ Ro = 0.25k = 250
Ex:1.14 Av o = 40dB = 100V/V
PL = v 2 o RL = Av o v i RL RL + Ro 2 RL
= v 2 i × 100 × 1 1 + 1 2 1000 = 2.5 v 2 i
Pi = v 2 i Ri = v 2 i 10,000
Ap ≡ PL Pi = 2.5v 2 i 10 4 v 2 i = 2.5 × 104 W/W
10log Ap = 44dB
Ex:1.15 Withoutstage3(seefigure)
v L
v s = 1M 100k + 1M (10) 100k 100k + 1k
×(100) 100 100 + 1k
v L v s = (0.909)(10)(0.9901)(100)(0.0909) = 81.8V/V
ThisfigurebelongstoExercise1.15.
Ex:1.16 ReferthesolutiontoExample1.3inthe text.
v i1 v s = 0.909V/V
v i1 = 0.909 v s = 0.909 × 1 = 0.909mV
v i2 v s = v i2 v i1 × v i1 v s = 9.9 × 0.909 = 9V/V
v i2 = 9 × v S = 9 × 1 = 9mV v
× 9.9 × 0.909
= 818V/V
v i3 = 818 v s = 818 × 1 = 818mV
v L v s = v L v i3 × v i3 v i2 × v i2 v i1 × v i1 v s = 0.909 × 90.9 × 9.9 × 0.909 744V/V
v L = 744 × 1mV = 744mV
Ex:1.17 Usingvoltageamplifiermodel,the three-stageamplifiercanberepresentedas
vi Ri Ro Avovi
Ri = 1M
Ro = 10
Av o = Av 1 × Av 2 × Av 3 = 9.9 × 90.9 × 1 = 900V/V Theoverallvoltagegain
v o v s = Ri Ri + Rs × Av o × RL RL + Ro
For RL = 10 :
Overallvoltagegain = 1M 1M + 100K × 900 × 10 10 + 10 = 409V/V
For RL = 1000 :
Overallvoltagegain = 1M 1M + 100K × 900 × 1000 1000 + 10 = 810V/V
∴ Rangeofvoltagegainisfrom409V/Vto 810V/V.
Ex:1.18 ii io Ais ii RL Ro Rs Ri is ii = is Rs Rs + Ri
io = Ais ii Ro Ro + RL = Ais is Rs Rs + Ri Ro Ro + RL
Thus, io is = Ais Rs Rs + Ri Ro Ro + RL
Ex:1.19 Ri Ro Gmvi RL Ri vi vo vs v i = v s Ri Ri + Rs
v o = Gm v i (Ro RL )
= Gm v s Ri Ri + Rs (Ro RL ) Thus,
v o v s = Gm Ri Ri + Rs (Ro RL )
Ex:1.20 Usingthetransresistancecircuitmodel, thecircuitwillbe Ri Rs is ii Ro RL vo Rmii
ii is = Rs Ri + Rs
v o = Rm ii × RL RL + Ro
v o ii = Rm RL RL + Ro Now v o is = v o ii × ii is = Rm RL RL + Ro × Rs Ri + Rs = Rm Rs Rs + Ri × RL RL + Ro
Ex:1.21
v b = ib rπ + (β + 1)ib Re = ib [rπ + (β + 1)Re ]
But v b = v x and ib = ix ,thus Rin ≡ v x ix = v b ib = rπ + (β + 1)Re
Ex:1.22 f Gain 10Hz60dB 10kHz40dB 100kHz20dB 1MHz0dB
110 10 10 10 10 10 10 f (Hz)
Ex:1.23
Gain (dB) 20 dB/decade 3 dB frequency
RL Ro Ri Vi Vi Gm Vo CL
V2 Vs = Ri Rs + 1 sC + Ri = Ri Rs + Ri s s + 1 C (Rs + Ri ) whichisanHPSTCfunction.
f3dB = 1 2π C (Rs + Ri ) ≤ 100Hz
C ≥ 1 2π(1 + 9)103 × 100 = 0.16 µF
Ex:1.25 T = 50K
ni = BT 3/2 e Eg/(2kT )
= 7.3 × 1015 (50)3/2 e 1.12/(2×8.62×10 5 ×50) 9.6 × 10 39 /cm3
T = 350K
ni = BT 3/2 e Eg/(2kT )
= 7.3 × 1015 (350)3/2 e 1.12/(2×8.62×10 5 ×350)
= 4.15 × 1011 /cm3
Vo = Gm Vi [Ro RL CL ] = Gm Vi 1 Ro + 1 RL + sCL
Thus, Vo Vi = Gm 1 Ro + 1 RL × 1 1 + sCL 1 Ro + 1 RL
Vo Vi = Gm (RL Ro ) 1 + sCL (RL Ro ) whichisoftheSTCLPtype.
ω0 = 1 CL (RL Ro ) = 1 4.5 × 10 9 (103 Ro )
For ω0 tobeatleast wπ × 40 × 103 ,thehighest valueallowedfor Ro is
Ro = 103 2π × 40 × 103 × 103 × 4.5 × 10 9 1 = 103 1.131 1 = 7.64k
Thedcgainis
Gm (RL Ro )
Toensureadcgainofatleast40dB(i.e.,100), theminimumvalueof Gm is
⇒ RL ≥ 100/(103 7.64 × 103 ) = 113.1mA/V
Ex:1.24 RefertoFig.E1.24
Ex:1.26 ND = 1017 /cm3
FromExercise1.26, ni at T = 350K = 4.15 × 1011 /cm3
nn = ND = 1017 /cm3
pn ∼ = ni2 ND
= (4.15 × 1011 )2 1017 = 1.72 × 106 /cm3
Ex:1.27 At300K, ni = 1.5 × 1010 /cm3
pp = NA
Wantelectronconcentration
= np = 1.5 × 1010 106 = 1.5 × 104 /cm3
∴ NA = pp = ni2 np
= (1.5 × 1010 )2 1.5 × 104
= 1.5 × 1016 /cm3
Ex:1.28 (a) νn drift =−μn E
Herenegativesignindicatesthatelectronsmove inadirectionoppositeto E Weuse Sedra,Smith,Carusone,GaudetMicroelectronicCircuits,8thInternationalEdition©OxfordUniversityPress2021
νn-drift = 1350 × 1 2 × 10 4 ∵ 1 µm = 10 4 cm
= 6.75 × 106 cm/s = 6.75 × 104 m/s
(b)Timetakentocross2-µm
length = 2 × 10 6 6.75 × 104 30ps
(c)In n-typesilicon,driftcurrentdensity Jn is
Jn = qnμn E
= 1.6 × 10 19 × 1016 × 1350 × 1V 2 × 10 4
= 1.08 × 104 A/cm 2
(d)Driftcurrent In = AJn
= 0.25 × 10 8 × 1.08 × 104
= 27 µA
Theresistanceofthebaris
R = ρ × L A
= qnμn × L A
= 1.6 × 10 19 × 1016 × 1350 × 2 × 10 4 0.25 × 10 8
= 37.0k
Alternatively,wemaysimplyusethepreceding resultforcurrentandwrite
R = V /In = 1V/27 µA = 37.0k
Notethat0.25 µm2 = 0.25 × 10 8 cm2
Ex:1.29 Jn = qDn dn(x) dx
FromFig.E1.29,
n0 = 1017 /cm3 = 105 /(µm)3
Dn = 35cm2 /s = 35 × (104 )2 (µm)2 /s
= 35 × 108 (µm)2 /s
dn dx = 105 0 0.5 = 2 × 105 µm 4
Jn = qDn dn(x) dx
= 1.6 × 10 19 × 35 × 108 × 2 × 105
= 112 × 10 6 A/µm2
= 112 µA/µm2
For In = 1mA = Jn × A
⇒ A = 1mA Jn = 103 µA 112 µA/(µm)2 9 µm2
Ex:1.30 UsingEq.(1.44), Dn μn = Dp μp = VT
Dn = μn VT = 1350 × 25.9 × 10 3
∼ = 35cm2 /s
Dp = μp VT = 480 × 25.9 × 10 3
∼ = 12.4cm2 /s
Ex:1.31 Equation(1.49)
W = 2 s q 1 NA + 1 ND V0
= 2 s q NA + ND NA ND V0
W 2 = 2 s q NA + ND NA ND V0
V0 = 1 2 q s NA ND NA + ND W 2
Ex:1.32 Ina p+ n diode NA ND
Equation(1.49) W = 2 s q 1 NA + 1 ND V0
Wecanneglecttheterm 1 NA ascomparedto 1 ND , thus
W 2 s qND · V0
Equation(1.50) xn = W NA NA + ND W NA NA
= W
Equation(1.51), xp = W ND NA + ND since NA ND W ND NA = W NA ND
Equation(1.52), QJ = Aq NA ND NA + ND W Aq NA ND NA W = AqND W
Equation(1.53), QJ = A 2 s q NA ND NA + ND V0
A 2 s q NA ND NA V0 since NA ND
= A 2 s qND V0
Ex:1.33 InExample1.10, NA = 1018 /cm3 and ND = 1016 /cm3
Inthe n-regionofthis pn junction
nn = ND = 1016 /cm3
pn = n2 i nn = (1.5 × 1010 )2 1016 = 2.25 × 104 /cm3
Asonecanseefromaboveequation,toincrease minority-carrierconcentration (pn ) byafactorof 2,onemustlower ND (= nn )byafactorof2.
Ex:1.34
Equation(1.64) IS = Aqn2 i Dp Lp ND + Dn Ln NA since Dp Lp and Dn Ln haveapproximately
similarvalues,if NA ND ,thentheterm Dn Ln NA
canbeneglectedascomparedto Dp Lp ND
∴ IS ∼ = Aqn2 i Dp Lp ND
Ex:1.35 IS = Aqn2 i Dp Lp ND + Dn Ln NA
= 10 4 × 1.6 × 10 19 × (1.5 × 1010 )2 × ⎛ ⎜ ⎜ ⎝ 10 5 × 10 4 × 1016 2 + 18 10 × 10 4 × 1018
= 1.46 × 10 14 A
I = IS (e V /V T 1) IS e V /V T = 1.45 × 10 14 e 0.605/(25.9×10 3 )
= 0.2mA
Ex:1.36 W = 2 s q 1 NA + 1 ND (V0 VF )
= 2 × 1.04 × 10 12 1.6 × 10 19 1 1018 + 1 1016 (0.814 0.605)
= 1.66 × 10 5 cm = 0.166 µm
Ex:1.37 W = 2 s q 1 NA + 1 ND (V0 + VR ) = 2 × 1.04 × 10 12 1.6 × 10 19 1 1018 + 1 1016 (0.814 + 2)
= 6.08 × 10 5 cm = 0.608 µm
UsingEq.(1.52),
QJ = Aq NA ND NA + ND W
= 10 4 × 1.6 × 10 19 1018 × 1016 1018 + 1016 × 6.08 × 10 5 cm
= 9.63pC
Reversecurrent I = IS = Aqn2 i Dp Lp ND + Dn Ln NA
= 10 14 × 1.6 × 10 19 × (1.5 × 1010 )2 × 10 5 × 10 4 × 1016 + 18 10 × 10 4 × 1018
= 7.3 × 10 15 A
Ex:1.38 Equation(1.69),
Cj0 = A s q 2 NA ND NA + ND 1 V0
= 10 4 1.04 × 10 12 × 1.6 × 10 19 2 1018 × 1016 1018 + 1016 1 0.814
= 3.2pF
Equation(1.70),
Cj = Cj0 1 + VR V0 = 3.2 × 10 12 1 + 2 0.814
= 1.72pF
Ex:1.39 Cd = dQ dV = d dV (τ T I )
= d dV [τ T × IS (e V /V T 1)]
= τ T IS d dV (e V /V T 1)
= τ T IS 1 VT e V /V T
= τ T VT × IS e V /V T
∼ = τ T VT I
Ex:1.40 Equation(1.73),
τ p = L2 p Dp = (5 × 10 4 )2 10 = 25ns
Equation(3.57),
Cd = τ T VT I
InExample1.6, NA = 1018 /cm3 , ND = 1016 /cm3
Assuming NA ND ,
τ T τ p = 25ns
∴ Cd = 25 × 10 9 25.9 × 10 3 0.1 × 10 3
= 96.5pF
SolutionstoEnd-of-ChapterProblems
1.1 (a) V = IR = 5mA × 1k = 5V
P = I 2 R = (5mA)2 × 1k = 25mW
(b) R = V /I = 5V/1mA = 5k
P = VI = 5V × 1mA = 5mW
(c) I = P/V = 100mW/10V = 10mA
R = V /I = 10V/10mA = 1k
(d) V = P/I = 1mW/0.1mA = 10V
R = V /I = 10V/0.1mA = 100k
(e) P = I 2 R ⇒ I = P/R
I = 1000mW/1k = 31.6mA
V = IR = 31.6mA × 1k = 31.6V
Note: V,mA,k ,andmWconstitutea consistentsetofunits.
1.2 (a) I = V R = 5V 1k = 5mA
(b) R = V I = 5V 1mA = 5k
(c) V = IR = 0.1mA × 10k = 1V
(d) I = V R = 1V 100 = 0.01A = 10mA
Note: Volts,milliamps,andkilohmsconstitutea consistentsetofunits.
1.3 (a) P = I 2 R = (20 × 10 3 )2 × 1 × 103 = 0.4W
Thus, R shouldhavea 1 2 -Wrating.
(b) P = I 2 R = (40 × 10 3 )2 × 1 × 103 = 1.6W
Thus,theresistorshouldhavea2-Wrating.
(c) P = I 2 R = (1 × 10 3 )2 × 100 × 103 = 0.1W
Thus,theresistorshouldhavea 1 8 -Wrating.
(d) P = I 2 R = (4 × 10 3 )2 × 10 × 103 = 0.16W
Thus,theresistorshouldhavea 1 4 -Wrating.
(e) P = V 2 /R = 202 /(1 × 103 ) = 0.4W
Thus,theresistorshouldhavea 1 2 -Wrating.
(f) P = V 2 /R = 112 /(1 × 103 ) = 0.121W
Thus,aratingof 1 8 Wshouldtheoretically suffice,though 1 4 Wwouldbeprudenttoallow forinevitabletolerancesandmeasurementerrors.
1.4 Seefigureonnextpage,whichshowshowto realizetherequiredresistancevalues.
1.5 Shuntingthe10k byaresistorofvalueof R resultsinthecombinationhavingaresistance
Req ,
Req = 10R R + 10
Thus,fora1%reduction,
R R + 10 = 0.99 ⇒ R = 990k
Fora5%reduction,
R R + 10 = 0.95 ⇒ R = 190k
Fora10%reduction,
R R + 10 = 0.90 ⇒ R = 90k
Fora50%reduction,
R
R + 10 = 0.50 ⇒ R = 10k
Shuntingthe10k by (a)1M resultsin
Req = 10 × 1000 1000 + 10 = 10 1.01 = 9.9k a1%reduction;
(b)100k resultsin
Req = 10 × 100 100 + 10 = 10 1.1 = 9.09k
a9.1%reduction;
(c)10k resultsin
Req = 10 10 + 10 = 5k
a50%reduction.
1.6 Usevoltagedividertofind VO VO = 5 2 2 + 3 = 2V
Equivalentoutputresistance RO is RO = (2k 3k ) = 1.2k
ThisfigurebelongstoProblem 1.4 Allresistorsare5k
Theextremevaluesof VO for ±5%tolerance resistorare
VOmin = 5 2(1 0.05) 2(1 0.05) + 3(1 + 0.05) = 1.88V
VOmax = 5 2(1 + 0.05) 2(1 + 0.05) + 3(1 0.05) = 2.12V
Theextremevaluesof RO for ±5%tolerance resistorsare1.2 × 1.05 = 1.26k and 1.2 × 0.95 = 1.14k
1.7 VO = VDD R2 R1 + R2 Tofind RO ,weshort-circuit VDD andlookback intonodeX,
10 // 10 // 10 3.33 k
Voltagegenerated:
+3V[twoways:(a)and(c)with(c)havinglower outputresistance]
+4.5V(b)
+6V[twoways:(a)and(d)with(d)havinga loweroutputresistance]
Tomake RO = 3.33,weaddaseriesresistanceof approximately200 ,asshownbelow,
Toincrease VO to10.00V,weshuntthe10-k resistorbyaresistor R whosevalueissuchthat 10 R = 2 × 4.7.
1.11 Connectaresistor R inparallelwith RL
Tomake IL = I /4(andthusthecurrentthrough R,3 I /4), R shouldbesuchthat
6 I /4 = 3 IR/4
⇒ R = 2k
4
1.12 Theparallelcombinationoftheresistorsis
R where 1 R = N i=1 1/Ri
Thevoltageacrossthemis
V = I × R = I N i=1 1/Ri
Thus,thecurrentinresistor Rk is
Ik = V /Rk = I /Rk N i=1 1/Ri
Tomakethecurrentthrough R equalto0.2 I ,we shunt R byaresistance R1 havingavaluesuch thatthecurrentthroughitwillbe0.8 I ;thus
0.2 IR = 0.8 IR1 ⇒ R1 = R 4
Theinputresistanceofthedivider, Rin ,is
Rin = R R1 = R R 4 = 1 5 R
Nowif R1 is10%toohigh,thatis,if
R1 = 1.1 R 4
theproblemcanbesolvedintwoways:
(a)Connectaresistor R2 across R1 ofvaluesuch that R2 R1 = R/4,thus
R2 (1.1R/4)
R2 + (1.1R/4) = R 4
+ 1.1R 4 ⇒ R2 = 11R 4 = 2.75R
R
=
(b)Connectaresistorinserieswiththeload resistor R soastoraisetheresistanceoftheload branchby10%,therebyrestoringthecurrent divisionratiotoitsdesiredvalue.Theadded seriesresistancemustbe10%of R (i.e.,0.1R). 0.1R 1.1R 4 Rin R 0.8 I 0.2 I I
Rin = 1.1R 1.1R 4 = 1.1R 5 thatis,10%higherthanincase(a).
1.14 For RL = 10k ,whensignalsource generates0 0.5mA,avoltageof0 2Vmay appearacrossthesource
Tolimit v s ≤ 1V,thenetresistancehastobe ≤ 2k .Toachievethiswehavetoshunt RL with aresistorRsothat (R RL ) ≤ 2k
R RL ≤ 2k
RRL R + RL ≤ 2k
For RL = 10k
R ≤ 2.5k
Theresultingcircuitneedsonlyoneadditional resistanceof2k inparallelwith RL sothat
v s ≤ 1V.Thecircuitisacurrentdivider,andthe currentthrough RL isnow0–0.1mA.
0 0.5 mA is vs RL
1.15 (a)Betweenterminals1and2:
(b)Sameprocedureisusedfor(b)toobtain
(c)Betweenterminals1and3,theopen-circuit voltageis1.5V.Whenweshortcircuitthe voltagesource,weseethattheThévenin resistancewillbezero.Theequivalentcircuitis then
Now,whenaresistanceof3k isconnected betweennode4andground, Sedra,Smith,Carusone,GaudetMicroelectronicCircuits,8thInternationalEdition©OxfordUniversityPress2021
I = 0.77 12.31 + 3 = 0.05mA 1.17
V
1
3 I2 I1 I3 V
(a)Nodeequationatthecommonmodeyields
I3 = I1 + I2
Usingthefactthatthesumofthevoltagedrops across R1 and R3 equals10V,wewrite
10 = I1 R1 + I3 R3
= 10 I1 + (I1 + I2 ) × 2
= 12 I1 + 2 I2
Thatis,
12 I1 + 2 I2 = 10 (1)
Similarly,thevoltagedropsacross R2 and R3 add upto5V,thus
5 = I2 R2 + I3 R3
= 5 I2 + (I1 + I2 ) × 2
whichyields
2 I1 + 7 I2 = 5 (2)
Equations(1)and(2)canbesolvedtogetherby multiplyingEq.(2)by6:
12 I1 + 42 I2 = 30 (3)
Now,subtractingEq.(1)fromEq.(3)yields
40 I2 = 20
⇒ I2 = 0.5mA
SubstitutinginEq.(2)gives
2 I1 = 5 7 × 0.5mA
⇒ I1 = 0.75mA
I3 = I1 + I2
= 0.75 + 0.5 = 1.25mA
V = I3 R3
= 1.25 × 2 = 2.5V
Tosummarize:
I1 = 0.75mA I2 = 0.5mA
I3 = 1.25mA V = 2.5V
(b)Anodeequationatthecommonnodecanbe writtenintermsof V as 10 V R1 + 5 V R2 = V R3
Thus, 10 V 10 + 5 V 5 = V 2
⇒ 0.8V = 2
⇒ V = 2.5V
Now, I1 , I2 ,and I3 canbeeasilyfoundas I1 = 10 V 10 = 10 2.5 10 = 0.75mA I2 = 5 V 5 = 5 2.5 5 = 0.5mA I3 = V R3 = 2.5 2 = 1.25mA
Method(b)ismuchpreferred,beingfaster,more insightful,andlesspronetoerrors.Ingeneral, oneattemptstoidentifythelowestpossible numberofvariablesandwritethecorresponding minimumnumberofequations.
1.18 FindtheThéveninequivalentofthecircuit totheleftofnode1.
Betweennode1andground, RTh = (1k 1.2k ) = 0.545k
VTh = 10 × 1.2 1 + 1.2 = 5.45V
FindtheThéveninequivalentofthecircuittothe rightofnode2.
Betweennode2andground, RTh = 9.1k 11k = 4.98k
VTh = 10 × 11 11 + 9.1 = 5.47V
Theresultingsimplifiedcircuitis
5 0.545 k 4.98 k
V 5.47 V
I5 = 5.47 5.45 4.98 + 2 + 0.545 = 2.66 µA
V5 = 2.66 µA × 2k = 5.32mV
1.19 WefirstfindtheThéveninequivalentofthe sourcetotherightof v O .
V = 4 × 1 = 4V
Then,wemayredrawthecircuitinFig.P1.19as shownbelow 5 V 4 V 3 k1 k vo
Then,thevoltageat v O isfoundfromasimple voltagedivision.
v O = 4 + (5 4) × 1 3 + 1 = 4.25V
1.20 RefertoFig.P1.20.Usingthevoltage dividerruleattheinputside,weobtain
v π v s = rπ rπ + Rs (1)
Attheoutputside,wefind v o bymultiplyingthe current gm v π bytheparallelequivalentof ro and RL ,
v o =−gm v π (ro RL )(2)
Finally, v o /v s canbeobtainedbycombiningEqs. (1)and(2)as
v o v s =− rπ rπ + Rs gm (ro RL )
1.21 (a) T = 10 4 ms = 10 7 s
f = 1 T = 107 Hz
ω = 2π f = 6.28 × 107 rad/s
(b) f = 1GHz = 109 Hz
T = 1 f = 10 9 s
ω = 2π f = 6.28 × 109 rad/s
(c) ω = 6.28 × 102 rad/s
f = ω 2π = 102 Hz
T = 1 f = 10 2 s
(d) T = 10s
f = 1 T = 10 1 Hz
ω = 2π f = 6.28 × 10 1 rad/s
(e) f = 60Hz
T = 1 f = 1.67 × 10 2 s
ω = 2π f = 3.77 × 102 rad/s
(f) ω = 1krad/s = 103 rad/s
f = ω 2π = 1.59 × 102 Hz
T = 1 f = 6.28 × 10 3 s
(g) f = 1900MHz = 1.9 × 109 Hz
T = 1 f = 5.26 × 10 10 s
ω = 2π f = 1.194 × 1010 rad/s
1.22 (a) Z = R + 1 jω C = 103 + 1 j2π × 10 × 103 × 10 × 10 9
= (1 j1.59) k
(b) Y = 1 R + jω C
= 1 104 + j2π × 10 × 103 × 0.01 × 10 6
= 10 4 (1 + j6.28)
Z = 1 Y = 104 1 + j6.28
= 104 (1 j6.28) 1 + 6.282
= (247.3 j1553)
(c) Y = 1 R + jω C = 1 100 × 103 + j2π × 10 × 103 × 100 × 10 12
= 10 5 (1 + j0.628)
Z = 105 1 + j0.628
= (71.72 j45.04) k
(d) Z = R + jω L
= 100 + j2π × 10 × 103 × 10 × 10 3
= 100 + j6.28 × 100
= (100 + j628), 1.23 (a) Z = 1k atallfrequencies
(b) Z = 1 /jω C =− j 1 2π f × 10 × 10 9
At f = 60Hz, Z =− j265k
At f = 100kHz, Z =− j159
At f = 1GHz, Z =− j0.016
(c) Z = 1 /jω C =− j 1 2π f × 10 × 10 12
At f = 60Hz, Z =− j0.265G
At f = 100kHz, Z =− j0.16M
At f = 1GHz, Z =− j15.9
(d) Z = jω L = j2π fL = j2π f × 10 × 10 3
At f = 60Hz, Z = j3.77
At f = 100kHz, Z = j6.28k
At f = 1GHz, Z = j62.8M
(e) Z = jω L = j2π fL = j2π f (1 × 10 6 )
f = 60Hz, Z = j0.377m
f = 100kHz, Z = j0.628
f = 1GHz, Z = j6.28k
1.24 Y = 1 jω L + jω C = 1 ω 2 LC jω L
⇒ Z = 1 Y = jω L 1 ω 2 LC
Thefrequencyatwhich |Z | =∞ isfoundletting thedenominatorequalzero:
1 ω 2 LC = 0 ⇒ ω = 1 √LC
Atfrequenciesjustbelowthis, ∠Z =+90◦ . Atfrequenciesjustabovethis, ∠Z =−90◦
Sincetheimpedanceisinfiniteatthisfrequency, thecurrentdrawnfromanidealvoltagesourceis zero.
1.25 is Rs Rs vs Thévenin equivalent Norton equivalent
v oc = v s isc = is v s = is Rs
Thus, Rs = v oc isc (a) v s = v oc = 1V is = isc = 0.1mA
Rs = v oc isc = 1V 0.1mA = 10k (b) v s = v oc = 0.1V is = isc = 1 µA
Rs = v oc isc = 0.1V 1 µA = 0.1M = 100k
v o
vs vo
v s = RL RL + Rs
v o = v s 1 + Rs RL
Thus, v s 1 + Rs 100 = 40 (1) and v s 1 + Rs 10 = 10 (2)
DividingEq.(1)byEq.(2)gives
1 + (Rs /10)
1 + (Rs /100) = 4
⇒ RS = 50k
SubstitutinginEq.(2)gives
v s = 60mV
TheNortoncurrent is canbefoundas
is = v s Rs = 60mV 50k = 1.2 µA
1.27 Thenominalvaluesof VL and IL are givenby
VL = RL RS + RL VS IL = VS RS + RL
Aftera10%increasein RL ,thenewvalueswillbe
VL = 1.1RL RS + 1.1RL VS
IL = VS RS + 1.1RL
(a)Thenominalvaluesare
VL = 200 5 + 200 × 1 = 0.976V
IL = 1 5 + 200 = 4.88µA
Aftera10%increasein RL ,thenewvalueswillbe
VL = 1.1 × 200 5 + 1.1 × 200 = 0.978V
IL = 1 5 + 1.1 × 200 = 4.44µA
Thesevaluesrepresenta0.2%and9%change, respectively.Sincetheloadvoltageremains relativelymoreconstantthantheloadcurrent,a Théveninsourceismoreappropriatehere.
(b)Thenominalvaluesare
VL = 50 5 + 50 × 1 = 0.909V
IL = 1 5 + 50 = 18.18mA
Aftera10%increasein RL ,thenewvalueswillbe
VL = 1.1 × 50 5 + 1.1 × 50 = 0.917V
IL = 1 5 + 1.1 × 50 = 16.67mA
Thesevaluesrepresenta1%and8%change, respectively.Sincetheloadvoltageremains relativelymoreconstantthantheloadcurrent,a Théveninsourceismoreappropriatehere.
(c)Thenominalvaluesare
VL = 0.1 2 + 0.1 × 1 = 47.6mV
IL = 1 2 + 0.1 = 0.476mA
Aftera10%increasein RL ,thenewvalueswillbe
VL = 1.1 × 0.1 2 + 1.1 × 0.1 = 52.1mV
IL = 1 2 + 1.1 × 0.1 = 0.474mA
Thesevaluesrepresenta9%and0.4%change, respectively.Sincetheloadcurrentremains relativelymoreconstantthantheloadvoltage,a Nortonsourceismoreappropriatehere.The Nortonequivalentcurrentsourceis
IS = VS RS = 1 2 = 0.5mA
(d)Thenominalvaluesare
VL = 16 150 + 16 × 1 = 96.4mV
IL = 1
150 + 16 = 6.02mA
Aftera10%increasein RL ,thenewvalueswillbe
VL = 1.1 × 16
150 + 1.1 × 16 = 105mV
IL = 1
150 + 1.1 × 16 = 5.97mA
Thesevaluesrepresenta9%and1%change, respectively.Sincetheloadcurrentremains relativelymoreconstantthantheloadvoltage,a Nortonsourceismoreappropriatehere.The Nortonequivalentcurrentsourceis
= VS RS = 1 150 = 6.67mA
v 2 S R2 L (RL + RS )2 × 1 RL
v 2 S RL (RL + RS )2
Sincewearetoldthatthepowerdeliveredtoa 16 speakerloadis75%ofthepowerdelivered toa32 speakerload, PL (RL = 16 ) = 0.75 × PL (RL = 32 ) 16 (RS + 32)2 = 0.75 × 32 (RS + 32)2 √16 RS + 32 = √24 RS + 32
(√24 = √16)RS = √16 × 32 √24 × 16 0.9RS = 49.6
Open-circuit (io 0) voltage 0 Rs vs vs vo is io Slope Rs Short-circuit (vo 0) current 1.31 Rs RL RL is vs vo vo Rs io io
RL representstheinputresistanceoftheprocessor
For v o = 0.95v s 0.95 = RL RL + Rs ⇒ RL = 19Rs For io = 0.95is 0.95 = Rs Rs + RL ⇒ RL = RS /19 1.32
Case ω (rad/s) f (Hz) T (s)
a 3.14 × 1010 5 × 109 0.2 × 10 9
b 2 × 109 3.18 × 108 3.14 × 10 9
c 6.28 × 1010 1 × 1010 1 × 10 10
d 3.77 × 102 60 1.67 × 10 2
e 6.28 × 104 1 × 104 1 × 10 4
f 6.28 × 105 1 × 105 1 × 10 5
1.29 Theobservedoutputvoltageis1mV/ ◦ C, whichisonehalfthevoltagespecifiedbythe sensor,presumablyunderopen-circuitconditions: thatis,withoutaloadconnected.Itfollowsthat thatsensorinternalresistancemustbeequalto RL ,thatis,5k 1.30 vs vo Rs Rs io is vo io v o = v s io Rs
1.33 (a) v = 10sin(2π × 103 t ),V
(b) v = 120√2sin(2π × 60),V
(c) v = 0.1sin(2000t ),V
(d) v = 0.1sin(2π × 103 t ),V
1.34 Comparingthegivenwaveformtothat describedbyEq.(1.2),weobservethatthegiven waveformhasanamplitudeof0.5V(1V peak-to-peak)anditslevelisshiftedupby0.5V (thefirsttermintheequation).Thusthe waveformlooksasfollows:
1.37 Thermsvalueofasymmetricalsquare wavewithpeakamplitude ˆ V issimply ˆ V .Taking theroot-mean-squareofthefirst5sinusoidal termsinEq.(1.2)givesanrmsvalueof, 4
= 0.980 ˆ V whichis2%lowerthanthermsvalueofthe squarewave.
1.38 Iftheamplitudeofthesquarewaveis Vsq , thenthepowerdeliveredbythesquarewavetoa resistance R willbe V 2 sq /R .Ifthispoweristobe equaltothatdeliveredbyasinewaveofpeak amplitude V ,then
Averagevalue = 0.5V
Peak-to-peakvalue = 1V
Lowestvalue = 0V
Highestvalue = 1V
Period T = 1 f0 = 2π ω0 = 10 3 s
Frequency f = 1 I = 1kHz
1.35 (a) Vpeak = 117 × √2 = 165V
(b) Vrms = 33.9/√2 = 24V
(c) Vpeak = 220 × √2 = 311V
(d) Vpeak = 220 × √2 = 311kV
1.36 Thetwoharmonicshavetheratio 126/98 = 9/7.Thus,thesearethe7thand9th harmonics.FromEq.(1.2),wenotethatthe amplitudesofthesetwoharmonicswillhavethe ratio7to9,whichisconfirmedbythe measurementreported.Thusthefundamentalwill haveafrequencyof98/7,or14kHz,andpeak amplitudeof63 × 7 = 441mV.Thermsvalueof thefundamentalwillbe441/√2 = 312mV.To findthepeak-to-peakamplitudeofthesquare wave,wenotethat4V/π = 441mV.Thus,
Peak-to-peakamplitude
= 2V = 441 × π 2 = 693mV
Period T = 1 f = 1 14 × 103 = 71.4 µs
Thus, Vsq = ˆ V /√2.Thisresultisindependentof frequency. 1.39 Decimal Binary 0 0
1.40 (a)For N bitstherewillbe2N possible levels,from0to VFS .Thustherewillbe(2N 1) discretestepsfrom0to VFS withthestepsize givenby
Stepsize = VFS 2N 1
Thisistheanalogchangecorrespondingtoa changeintheLSB.Itisthevalueofthe resolutionoftheADC.
(b)Themaximumerrorinconversionoccurs whentheanalogsignalvalueisatthemiddleofa step.Thusthemaximumerroris
1 2 × stepsize = 1 2 VFS 2N 1
Thisisknownasthequantizationerror.
(c) 5V 2N 1 ≤ 2mV
2N 1 ≥ 2500
2N ≥ 2501 ⇒ N = 12, For N = 12,
Resolution = 5 212 1 = 1.2mV
=
=
Notethattherearetwopossiblerepresentations ofzero:0000and1000.Fora0.5-Vstepsize, analogsignalsintherange ±3.5Vcanbe represented.
Input Steps Code
+5 0101
0101
6 1110
1.42 (a)When bi = 1,the ithswitchisin position1andacurrent(Vref /2i R)flowstothe output.Thus iO willbethesumofallthecurrents correspondingto“1”bits,thatis,
iO = Vref R b1 21 + b2 22 +···+ bN 2N
(b) bN istheLSB
b1 istheMSB
(c) iOmax = 10V 10k 1 21 + 1 22 + 1 23 + 1 24 + 1 25 + 1 26 + 1 27 + 1 28
= 0.99609375mA
CorrespondingtotheLSBchangingfrom0to1 theoutputchangesby (10/10) × 1/28 = 3.91 µA.
1.43 Therewillbe44,100samplespersecond witheachsamplerepresentedby16bits.Thusthe throughputorspeedwillbe44,100 × 16 = 7.056 × 105 bitspersecond.
1.44 Eachpixelrequires8 + 8 + 8 = 24bitsto representit.Wewillapproximateamegapixelas 106 pixels,andaGbitas109 bits.Thus,each imagerequires24 × 10 × 106 = 2.4 × 108 bits. Thenumberofsuchimagesthatfitin16Gbitsof memoryis
2.4 × 108 16 × 109 = 66.7 = 66
1.45 (a) Av = v O v I = 10V 100mV = 100V/V
or20log100 = 40dB
Ai = iO iI = v O /RL iI = 10V/100 100 µA = 0.1A 100 µA
= 1000A/A
or20log1000 = 60dB
Ap = v O iO v I iI = v O v I × iO iI = 100 × 1000
= 105 W/W
or10log105 = 50dB
(b) Av = v O v I = 1V 10 µV = 1 × 105 V/V
or20log1 × 105 = 100dB
Ai = iO iI = v O /RL iI = 1V/10k 100nA
= 0.1mA 100nA = 0.1 × 10 3 100 × 10 9 = 1000A/A
or20log Ai = 60dB
Ap = v O iO v I iI = v O v I × iO iI
= 1 × 105 × 1000
= 1 × 108 W/W
or10log AP = 80dB
(c) Av = v O v i = 5V 1V = 5V/V
or20log5 = 14dB
Ai = iO iI = v O /RL iI = 5V/10 1mA = 0.5A 1mA = 500A/A
or20log500 = 54dB
Ap = v O iO v I iI = v O v I × iO iI
= 5 × 500 = 2500W/W
or10log Ap = 34dB
1.46 For ±5Vsupplies:
Thelargestundistortedsine-waveoutputisof 4-Vpeakamplitudeor4/√2 = 2.8Vrms .Input neededis14mVrms .
For ±10-Vsupplies,thelargestundistorted sine-waveoutputisof9-Vpeakamplitudeor 6.4Vrms .Inputneededis32mVrms
For ±15-Vsupplies,thelargestundistorted sine-waveoutputisof14-Vpeakamplitudeor
9.9Vrms .Theinputneededis9.9V/200 = 49.5mVrms
Av = v o v i = 2.2 0.2 = 11V/V
or20log11=20.8dB
Ai = io ii = 2.2V/100 1mA = 22mA 1mA = 22A/A
or20log Ai = 26.8dB
Ap = po pi = (2.2/√2)2 /100 0.2 √2 × 10 3 √2
= 242W/W
or10log AP = 23.8dB
Supplypower = 2 × 3V ×20mA = 120mW
Outputpower = v 2 orms RL = (2.2/√2)2 100 = 24.2mW
Inputpower = 24.2 242 = 0.1mW(negligible)
Amplifierdissipation Supplypower Output power
= 120 24.2 = 95.8mW
Amplifierefficiency = Outputpower supplypower × 100 = 24.2 120 × 100 = 20.2%
1.48 v o = Av o v i RL RL + Ro = Av o v s Ri Ri + Rs RL RL + Ro vi vi vs Ri Rs RL Av ovi Ro
Thus,
v o v s = Av o Ri Ri + Rs RL RL + Ro
(a) Av o = 100, Ri = 10Rs , RL = 10Ro :
v o v s = 100 × 10Rs 10Rs + Rs × 10Ro 10Ro + Ro = 82.6V/Vor20log82.6 = 38.3dB
(b) Av o = 100, Ri = Rs , RL = Ro :
v o v s = 100 × 1 2 × 1 2 = 25V/Vor20log25 = 28dB
(c) Av o = 100V/V, Ri = Rs /10, RL = Ro /10:
v o v s = 100 Rs /10 (Rs /10) + Rs Ro /10 (Ro /10) + Ro = 0.826V/Vor20log0.826 =−1.7dB
1.49 (a)
v o v s = v i v s × v o v i
ThisfigurebelongstoProblem 1.49.
= 1 5 + 1 × 100 × 100 200 + 100 = 5.56V/V
Muchoftheamplifier’s100V/Vgainislostin thesourceresistanceandamplifier’soutput resistance.Ifthesourcewereconnecteddirectly totheload,thegainwouldbe
v o v s = 0.1 5 + 0.1 = 0.0196V/V
Thisisafactorof284× smallerthanthegain withtheamplifierinplace!
(b)
Theequivalentcurrentamplifierhasadependent currentsourcewithavalueof 100V/V 200 × ii = 100V/V 200 × 1000 × v i = 500 × ii
Thus, io is = ii is × io ii = 5 5 + 1 × 500 × 200 200 + 100 = 277.8A/A
Usingthevoltageamplifiermodel,thecurrent gaincanbefoundasfollows, io is = ii is × v i ii × io v i = 5 5 + 1 × 1000 × 100V/V 200 + 100 = 277.8A/A
1.50 InExample1.3,whenthefirstandthe secondstagesareinterchanged,thecircuitlooks likethefigureabove,and
v i1 v s = 100k 100k + 100k = 0.5V/V
io
Figure1
Figure2
ThisfigurebelongstoProblem 1.50
Av 1 = v i2 v i1 = 100 × 1M 1M + 1k = 99.9V/V
Av 2 = v i3 v i2 = 10 × 10k 10k + 1k = 9.09V/V
Av 3 = v L v i3 = 1 × 100 100 + 10 = 0.909V/V
Totalgain = Av = v L v i1 = Av 1 × Av 2 × Av 3
= 99.9 × 9.09 × 0.909 = 825.5V/V
Thevoltagegainfromsourcetoloadis
v L v s = v L v i1 × v i1 v S = Av v i1 v S
= 825.5 × 0.5
= 412.7V/V
Theoverallvoltagehasreducedappreciably.This isbecausetheinputresistanceofthefirststage, Rin ,iscomparabletothesourceresistance Rs .In Example1.3theinputresistanceofthefirststage ismuchlargerthanthesourceresistance.
1.51 Theequivalentcircuitattheoutputsideofa currentamplifierloadedwitharesistance RL is shown.Since
io = (Ais ii ) Ro Ro + RL wecanwrite
1 = (Ais ii ) Ro Ro + 1 (1) and
0.5 = (Ais ii ) Ro Ro + 12 (2)
DividingEq.(1)byEq.(2),wehave RL Ro Aisii io
2 = Ro + 12 Ro + 1 ⇒ Ro = 10k
Ais ii = 1 × 10 + 1 10 = 1.1mA
1.52
Thecurrentgainis
io ii = Rm Ro + RL
= 5000 10 + 1000
= 4.95A/A = 13.9dB
Thevoltagegainis
v o v s = ii v s × io ii × v o io
= 1 Rs + Ri × io ii × RL
= 1 1000 + 100 × 4.95 × 1000
= 4.90V/V = 13.8dB
Thepowergainis
v o io
v s ii = 4.95 × 4.90
= 24.3W/W = 27.7dB
1.53
Gm = 60mA/V
Ro = 20k
RL = 1k
v i = v s Ri Rs + Ri
= v s 2 1 + 2 = 2 3 v s
v o = Gm v i (RL Ro )
= 60 20 × 1 20 + 1 v i
= 60 20 21 × 2 3 v s
Overallvoltagegain ≡ v o v s = 38.1V/V
ThisfigurebelongstoProblem 1.52
10 k vs vi
o ii Ri 5-mV peak
Av ovi 1 k
1.54 vi vo 100 500 1 M 100vi
20log Av o = 40dB ⇒ Av o = 100V/V
Av = v o v i
= 100 × 500 500 + 100 = 83.3V/V
or20log83.3 = 38.4dB
Ap = v 2 o /500 v 2 i /1M = A2 v × 104 = 1.39 × 107 W/W
or10log (1.39 × 107 ) = 71.4dB.
Forapeakoutputsine-wavecurrentof20mA, thepeakoutputvoltagewillbe20mA × 500 = 10V.Correspondingly v i willbeasinewave withapeakvalueof10V/Av = 10/83.3,oran rmsvalueof10/(83.3 × √2) = 0.085V. Correspondingoutputpower = (10/√2)2 /500 = 0.1W
1.55 vi 200 k 1 M 1 V vo 20 100 1 vi
v o = 1V ×
× 1 ×
= 1 1.2 × 100 120 = 0.69V
Voltagegain = v o v s = 0.69V/Vor 3.2dB
Currentgain = v o /100 v s /1.2M = 0.69 × 1.2 × 104 = 8280A/Aor78.4dB
Powergain = v 2 o /100 v 2 s /1.2M = 5713W/W
or10log5713 = 37.6dB (Thistakesintoaccountthepowerdissipatedin theinternalresistanceofthesource.)
1.56 (a)CaseS-A-B-L(seefigureonnextpage):
v o v s = v o v ib × v ib v ia × v ia v s = 10 × 100 100 + 1000 × 100 × 10 10 + 10 × 100 100 + 100
v o v s = 22.7V/VandgainindB20log22.7 = 27.1dB
(b)CaseS-B-A-L(seefigureonnextpage):
v o v s = v o v ia v ia v ib v ib v s = 100 × 100 100 + 10K × 10 × 100K 100K + 1K × 10K
10K + 100K
v o v s = 0.89V/VandgainindBis20log0.89 = 1dB.Obviously,caseaispreferredbecauseit provideshighervoltagegain.
1.57 Eachofstages#1,2,..., (n 1) canbe representedbytheequivalentcircuit:
v o v s = v i1 v s × v i2 v i1 × v i3 v i2 ×···× v in v i(n 1) × v o v in where
Thisfigurebelongsto 1.56,part(a).
Thisfigurebelongsto 1.56,part(b).
v i1
v s = 10k 10k + 10k = 0.5V/V
v o v in = 10 × 200 1k + 200 = 1.67V/V
v i2 v i1 = v i3 v i2 =···= v in v i(n 1) = 10 × 10k 10k + 10k = 9.09V/V
Thus,
v o v s = 0.5 × (9.09)n 1 × 1.67 = 0.833 × (9.09)n 1
For v s = 5mVand v o = 3V,thegain v o v s must be ≥ 600,thus
0.833 × (9.09)n 1 ≥ 600
⇒ n = 4
Thusfouramplifierstagesareneeded,resultingin
v o v s = 0.833 × (9.09)3 = 625.7V/V andcorrespondingly
v o = 625.7 × 5mV = 3.13V
Thisfigurebelongsto 1.57.
1.58 Deliver0.5Wtoa100- load. Sourceis30mVrmswith0.5-M source resistance.Choosefromthesethreeamplifier types:
Chooseordertoeliminateloadingoninputand output:
A,first,tominimizeloadingon0.5-M source
B,second,toboostgain
C ,third,tominimizeloadingat100- output.
Wefirstattemptacascadeofthethreestagesin theorder A, B, C (seefigureabove),andobtain
v i1 v s = 1M 1M + 0.5M = 1 1.5
