that a negative ion had been caught from the air. The next time recorded under , namely, 34.8, indicates that another negative ion had been caught. The next time, 84.5, indicates the capture of still another negative ion. This charge was held for two trips, when the speed changed back again to 34.6, showing that a positive ion had now been caught which carried precisely the same charge as the negative ion which before caused the inverse change in time, i.e., that from 34.8 to 84.5.
In order to obtain some of the most important consequences of this and other similar experiments we need make no assumption further than this, that the velocity with which the drop moves is proportional to the force acting upon it and is independent of the electrical charge which it carries. Fortunately this assumption can be put to very delicate experimental test, as will presently be shown, but introducing it for the time being as a mere assumption, as Townsend, Thomson, and Wilson had done before, we get
The negative sign is used in the denominator because will for convenience be taken as positive when the drop is going up in the direction of , while will be taken as positive when it is going down in the direction of . denotes the charge on the drop, and must not be confused with the charge on an ion. If now by the capture of an ion the drop changes its charge from to , then the value of the captured charge is and since constant for this drop, any charge which it may capture will always be proportional to ( ) that is, to the change produced in the velocity in the field by the captured ion. The successive values of and of ( ), these latter being obtained by subtracting successive values of the velocities given under , are shown in Table V.
It will be seen from the last column that within the limits of error of a stop-watch measurement, all the charges captured have exactly the same value save in three cases. In all of these three the captured charges were just twice as large as those appearing in the other changes. Relationships of exactly this sort have been found to hold absolutely without exception, no matter in what gas the drops have been suspended or what sort of droplets were used upon which to catch the ions. In many cases a given drop has been held under observation for five or six hours at a time and has been seen to catch not eight or ten ions, as in the experiment above, but hundreds of them. Indeed, I have observed, all told, the capture of many thousands of ions in this way, and in no case have I ever found one the charge of which, when tested as above, did not have either exactly the value of the smallest charge ever captured or else a very small multiple of that value. Here, then, is direct, unimpeachable proof that the electron is not a “statistical mean,” but that rather the electrical charges found on ions all have either exactly the same value or else small exact multiples of that value.
II. PROOF THAT ALL STATIC CHARGES BOTH ON CONDUCTORS AND INSULATORS ARE BUILT UP OF ELECTRONS
The foregoing experiment leads, however, to results of much more fundamental importance than that mentioned in the preceding section. The charge which the droplet had when it first came under observation had been acquired, not by the capture of ions from the air, but by the ordinary frictional process involved in blowing the spray If then ordinary static charges are built up of electrons, this charge should be found to be an exact multiple of the ionic charge which had been found from the
most reliable measurement shown in Table V to be proportional to the velocity .00891. This initial charge on the drop is seen from equations (9) and (10) to bear the same relation to ( ) which the ionic charge bears to ( ). Now, , hence . Dividing this by 9 we obtain .008931, which is within about one-fifth of 1 per cent of the value found in the last column of Table V as the smallest charge carried by an ion. Our experiment has then given us for the first time a means of comparing a frictional charge with the ionic charge, and the frictional charge has in this instance been found to contain exactly 9 electrons. A more exact means of making this comparison will be given presently, but suffice it to say here that experiments like the foregoing have now been tried on thousands of drops in different media, some of the drops being made of non-conductors like oil, some of semi-conductors like glycerin, some of excellent metallic conductors like mercury. In every case, without a single exception, the initial charge placed upon the drop by the frictional process, and all of the dozen or more charges which have resulted from the capture by the drop of a larger or smaller number of ions, have been found to be exact multiples of the smallest charge caught from the air Some of these drops have started with no charge at all, and one, two, three, four, five, and six elementary charges or electrons have been picked up. Others have started with seven or eight units, others with twenty, others with fifty, others with a hundred, others with a hundred and fifty elementary units, and have picked up in each case a dozen or two of elementary charges on either side of the startingpoint, so that, in all, drops containing every possible number of electrons between one and one hundred and fifty have been observed and the number of electrons which each drop carried has been accurately counted by the method described. When the number is less than fifty there is not a whit more uncertainty about this count than there is in counting one’s own fingers and toes. It is not found possible to determine with certainty the number of electrons in a charge containing more than one hundred or two hundred of them, for the simple reason that the method of measurement used fails to detect the difference between 200 and 201, that is, we cannot measure with an accuracy greater than one-half of 1 per cent. But it is quite inconceivable that large charges such as are dealt with in commercial applications of electricity can be built up in an essentially different way from that in
which the small charges whose electrons we are able to count are found to be. Furthermore, since it has been definitely proved that an electrical current is nothing but the motion of an electrical charge over or through a conductor, it is evident that the experiments under consideration furnish not only the most direct and convincing of evidence that all electrical charges are built up out of these very units which we have been dealing with as individuals in these experiments, but that all electrical currents consist merely in the transport of these electrons through the conducting bodies.
In order to show the beauty and precision with which these multiple relationships stand out in all experiments of this kind, a table corresponding to much more precise measurements than those given heretofore is here introduced (Table VI). The time of fall and rise shown in the first and second columns were taken with a Hipp chronoscope reading to one-thousandth of a second. The third column gives the reciprocals of these times. These are used in place of the velocities in the field, since distance of fall and rise is always the same. The fourth column gives the successive changes in speed due to the capture of ions. These also are expressed merely as time reciprocals. For reasons which will be explained in the next section, each one of these changes may correspond to the capture of not merely one but of several distinct ions.
The numbers in the fifth column represent simply the small integer by which it is found that the numbers in the fourth column must be divided in order to obtain the numbers in the sixth column. These will be seen to be exactly alike within the limits of error of the experiment. The mean value at the bottom of the sixth column represents, then, the smallest charge ever caught from the air, that is, it is the elementary ionic charge. The seventh column gives the successive values of expressed as reciprocal times. These numbers, then, represent the successive values of the total charge carried by the droplet. The eighth column gives the integers by which the numbers in the seventh column must be divided to obtain the numbers in the last column. These also will be seen to be invariable. The mean at the bottom of the last column represents, then, the electrical unit out of which the frictional charge on the droplet was built up, and it is seen to be identical with the ionic charge represented by the number at the bottom of the sixth column
It may be of interest to introduce one further table (Table VII) arranged in a slightly different way to show how infallibly the atomic structure of electricity follows from experiments like those under consideration.
TABLE VII
In this table 4.917 is merely a number obtained precisely as above from the change in speed due to the capture of ions and one which is proportional in this experiment to the ionic charge. The column headed contains simply the whole series of exact multiples of this number from 1 to 18. The column headed “Observed Charge” gives the successive observed values of ( ). It will be seen that during the time of observation, about four hours, this drop carried all possible multiples of the elementary charge from 4 to 18, save only 15. No more exact or more consistent multiple relationship is found in the data which chemists have amassed on the combining powers of the elements and on which the atomic theory of matter rests than is found in the foregoing numbers
Such tables as these—and scores of them could be given—place beyond all question the view that an electrical charge wherever it is found, whether on an insulator or a conductor, whether in electrolytes or in metals, has a definite granular structure, that it consists of an exact number of specks of electricity (electrons) all exactly alike, which in static
phenomena are scattered over the surface of the charged body and in current phenomena are drifting along the conductor. Instead of giving up, as Maxwell thought we should some day do, the “provisional hypothesis of molecular charges,” we find ourselves obliged to make all our interpretations of electrical phenomena, metallic as well as electrolytic, in terms of it.
III. MECHANISM OF CHANGE OF CHARGE OF A DROP
All of the changes of charge shown in Table IV were spontaneous changes, and it has been assumed that all of these changes were produced by the capture of ions from the air When a negative drop suddenly increases its speed in the field, that is, takes on a larger charge of its own kind than it has been carrying, there seems to be no other conceivable way in which the change can be produced. But when the charge suddenly decreases there is no a priori reason for thinking that the change may not be due as well to the direct loss of a portion of the charge as to the neutralization of this same amount of electricity by the capture of a charge of opposite sign. That, however, the changes do actually occur, when no X-rays or radioactive rays are passing between the plates, only by the capture of ions from the air, was rendered probable by the fact that drops not too heavily charged showed the same tendency on the whole to increase as to decrease in charge. This should not have been the case if there were two causes tending to decrease the charge, namely, direct loss and the capture of opposite ions, as against one tending to increase it, namely, capture of like ions. The matter was very convincingly settled, however, by making observations when the gas pressures were as low as 2 or 3 mm. of mercury. Since the number of ions present in a gas is in general directly proportional to the pressure, spontaneous changes in charge should almost never occur at these low pressures; in fact, it was found that drops could be held for hours at a time without changing. The frequency with which the changes occur decreases regularly with the pressure, as it should if the changes are due to the capture of ions. For the number of ions formed by a given ionizing agent must vary directly as the pressure.
Again, the changes do not, in general, occur when the electrical field is on, for then the ions are driven instantly to the plates as soon as formed, at a speed of, say, 10,000 cm. per second, and so do not have
any opportunity to accumulate in the space between them. When the field is off, however, they do so accumulate, until, in ordinary air, they reach the number of, say, 20,000 per cubic centimeter. These ions, being endowed with the kinetic energy of agitation characteristic of the temperature, wander rapidly through the gas and become a part of the drop as soon as they impinge upon it. It was thus that all the changes recorded in Table IV took place.
It is possible, however, so to control the changes as to place electrons of just such sign as one wishes, and of just such number as one wishes, within limits, upon a given drop. If, for example, it is desired to place a positive electron upon a given drop the latter is held with the aid of the field fairly close to the negative plate, say the upper plate; then an ionizing agent—X-rays or radium—is arranged to produce uniform ionization in the gas between the plates. Since now all the positive ions move up while the negatives move down, the drop is in a shower of positive ions, and if the ionization is intense enough the drop is sure to be hit. In this way a positive charge of almost any desired strength may be placed upon the drop.
Similarly, in order to throw a negative ion or ions upon the drop it is held by the field close to the lower, i.e., to the positive, plate in a shower of negative ions produced by the X-rays. It was in this way that most of the changes shown in Table VI were brought about. This accounts for the fact that they correspond in some instances to the capture of as many as six electrons.
When X-rays are allowed to fall directly upon the drop itself the change in charge may occur, not merely because of the capture of ions, but also because the rays eject beta particles, i.e., negative electrons, from the molecules of the drop. That changes in charge were actually produced in this way in our experiments was proved conclusively in 1910 by the fact that when the pressure was reduced to a very low value and X-rays were allowed to pass through the air containing the drop, the latter would change readily in the direction of increasing positive or decreasing negative charge, but it could almost never be made to change in the opposite direction. This is because at these low pressures the rays can find very few gas molecules to ionize, while they detach negative electrons from the drop as easily as at atmospheric pressure. This experiment proved directly that the charge carried by an ion in gases is the same as the charge on the beta or cathode-ray particle.
When it was desired to avoid the direct loss of negative electrons by the drop, we arranged lead screens so that the drop itself would not be illuminated by the rays, although the gas underneath it was ionized by them.[41]
IV. DIRECT OBSERVATION OF THE KINETIC ENERGY OF AGITATION OF A MOLECULE
I have already remarked that when a drop carries but a small number of electrons it appears to catch ions of its own sign as rapidly as those of opposite signs—a result which seems strange at first, since the ions of opposite sign must be attracted, while those of like sign must be repelled. Whence, then, does the ion obtain the energy which enables it to push itself up against this electrostatic repulsion and attach itself to a drop already strongly charged with its own kind of electricity? It cannot obtain it from the field, since the phenomenon of capture occurs when the field is not on. It cannot obtain it from any explosive process which frees the ion from the molecule at the instant of ionization, since in this case, too, ions would be caught as well, or nearly as well, when the field is on as when it is off. Here, then, is an absolutely direct proof that the ion must be endowed with a kinetic energy of agitation which is sufficient to push it up to the surface of the drop against the electrostatic repulsion of the charge on the drop.
This energy may easily be computed as follows: Let us take a drop, such as was used in one of these experiments, of radius .000197 cm. The potential at the surface of a charged sphere can be shown to be the charge divided by the radius. The value of the elementary electrical charge obtained from the best observations of this type, is . Hence the energy required to drive an ion carrying the elementary charge up to the surface of a charged sphere of radius , carrying 16 elementary charges, is
Now, the kinetic energy of agitation of a molecule as deduced from the value of herewith obtained, and the kinetic theory equation,
, is . According to the MaxwellBoltzmann Law of the partition of energy, which certainly holds in gases, this should also be the kinetic energy of agitation of an ion. It will be seen that the value of this energy is approximately three times that required to push a single ion up to the surface of the drop in question. Hence the electrostatic forces due to 16 electrons on the drop are too weak to exert much influence upon the motion of an approaching ion. But if it were possible to load up a drop with negative electricity until the potential energy of its charge were about three times as great as that computed above for this drop, then the phenomenon here observed of the catching of new negative ions by such a negatively charged drop should not take place, save in the exceptional case in which an ion might acquire an energy of agitation considerably larger than the mean value. Now, as a matter of fact, it was regularly observed that the heavily charged drops had a very much smaller tendency to pick up new negative ions than the more lightly charged drops, and, in one instance, we watched for four hours another negatively charged drop of radius .000658 cm., which carried charges varying from 126 to 150 elementary units, and which therefore had a potential energy of charge (computed as above on the assumption of uniform distribution) varying from to . In all that time this drop picked up but one single negative ion when the field was off, and that despite the fact that the ionization was several times more intense than in the case of the drop of Table I. Positive ions too were being caught at almost every trip down under gravity (The strong negative charge on the drop was maintained by forcing on negative ions by the field as explained above.)
V. POSITIVE AND NEGATIVE ELECTRONS EXACTLY EQUAL
The idea has at various times been put forth in connection with attempts to explain chemical and cohesive forces from the standpoint of electrostatic attractions that the positive and negative charges in a socalled neutral atom may not after all be exactly equal, in other words, that there is really no such thing as an entirely neutral atom or molecule. As a matter of fact, it is difficult to find decisive tests of this hypothesis. The present experiments, however, make possible the following sort of test. I loaded a given drop first with negative electrons and took ten or twelve observations of rise and fall, then with the aid of X-rays, by the
method indicated in the last section, I reversed the sign of the charge on the drop and took a corresponding number of observations of rise and fall, and so continued observing first the value of the negative electron and then that of the positive. Table VIII shows a set of such observations taken in air with a view to subjecting this point to as rigorous a test as possible. Similar, though not quite so elaborate, observations have been made in hydrogen with the same result. The table shows in the first column the sign of the charge; in the second the successive values of the time of fall under gravity; in the third the successive times of rise in the field ; in the fourth the number of electrons carried by the drop for each value of ; and in the fifth the number, characteristic of this drop, which is proportional to the charge of one electron. This number is obtained precisely as in the two preceding tables by finding the greatest common divisor of the successive values of ( ) and then multiplying this by an arbitrary constant which has nothing to do with the present experiment and hence need not concern us here (see chap. V).
It will be seen that though the times of fall and of rise, even when the same number of electrons is carried by the drop, change a trifle because of a very slight evaporation and also because of the fall in the potential of the battery, yet the mean value of the positive electron, namely, 6.697, agrees with the mean value of the negative electron, namely, 6.700, to within less than 1 part in 2,000.
TABLE VIII
Sign of Drop Sec.
63.050 } 63.186 41.728} 8
63.332 41.590} - 63.328
62.728 25.740}
62.926 25.798 11
62.900 25.510
63.214 25.806} } Mean = 62.976 }
63.538 22.694} 12}
63.244 22.830}
63.114 25.870}
63.242 25.876 11 +
63.362 25.484}
63.136 10.830}
63.226 10.682
63.764 10.756 22
63.280 10.778
63.530 10.672
63.268 10.646} } Mean = 63.325 }
Sign of Drop Sec. Sec.
63.642 }
63.020 71.664} 6
62.820 71.248}
63.514 52.668} +
63.312 52.800 7
63.776 52.496
63.300 52.860}
63.156 71.708 6
63.126 Mean = 63.407 }
63.228 42.006} }
63.294 41.920 8
63.184 42.108}
63.260 53.210}
63.478 52.922 7 -
63.074 53.034
63.306 53.438}
63.414 12.888}
63.450 12.812 19
63.446 12.748
63.556 12.824} Mean = 63.335 }
Duration of experiment 1 hr. 40 min. Mean = 6.697
Initial volts = 1723.5 Mean = 6.700
Final volts = 1702.1
Pressure = 53.48 cm.
Since this is about the limit of the experimental error (the probable error by least squares is 1 part in 1,500), we may with certainty conclude that there are no differences of more than this amount between the values of the positive and negative electrons. This is the best evidence I am aware of for the exact neutrality of the ordinary molecules of gases. Such neutrality, if it is actually exact, would seem to preclude the possibility of explaining gravitation as a result of electrostatic forces of any kind. The electromagnetic effect of moving charges might, however, still be called upon for this purpose.
VI. RESISTANCE OF MEDIUM TO MOTION OF DROP THROUGH IT THE SAME WHEN DROP IS CHARGED AS WHEN UNCHARGED
A second and equally important conclusion can be drawn from Table VIII. It will be seen from the column headed “ ” that during the whole of the time corresponding to the observations in the third group from the top the drop carried either 6 or 7 electrons, while, during the last half of the time corresponding to the observations in the second group from the top, it carried three times as many, namely, 22 electrons. Yet the mean times of fall under gravity in the two groups agree to within about one part in one thousand. The time of fall corresponding to the heavier charge happens in this case to be the smaller of the two. We may conclude, therefore, that in these experiments the resistance which the medium offers to the motion of a body through it is not sensibly increased when the body becomes electrically charged. This demonstrates experimentally the exact validity for this work of the assumption made on p. 70 that the velocity of the drop is strictly proportional to the force acting upon it, whether it is charged or uncharged.
The result is at first somewhat surprising since, according to Sutherland’s theory of the small ion, the small mobility or diffusivity of charged molecules, as compared with uncharged, is due to the additional resistance which the medium offers to the motion through it of a charged molecule. This additional resistance is due to the fact that the charge on a molecule drags into collision with it more molecules than would otherwise hit it. But with oil drops of the sizes here used (
) the total number of molecular collisions against the surface of the drop is so huge that even though the small number of charges on it might produce a few more collisions, their number would be negligible in comparison with the total number At any rate the experiment demonstrates conclusively that the charges on our oil drops do not influence the resistance of the medium to the motion of the drop. This conclusion might also have been drawn from the data contained in Table VI. The evidence for its absolute correctness has been made more convincing still by a comparison of drops which carried but 1 charge and those which carried as many as 68 unit charges. Further, I have observed the rate of fall under gravity of droplets which were completely discharged, and in every case that I have ever tried I have found this rate precisely the same, within the limits of error of the time measurements, as when it carried 8 or 10 unit charges.
VII. DROPS ACT LIKE RIGID SPHERES
It was of very great importance for the work, an account of which will be given in the next chapter to determine whether the drops ever suffer —either because of their motion through a resisting medium, or because of the electrical field in which they are placed—any appreciable distortion from the spherical form which a freely suspended liquid drop must assume. The complete experimental answer to this query is contained in the agreement of the means at the bottom of the last and the third from the last columns in Table VI and in similar agreements shown in many other tables, which may be found in the original articles.
[42] Since is in this experiment large compared to , the value of
the greatest common divisor at the bottom of the last column of Table VI is determined almost wholly by the rate of fall of the particle under gravity when there is no field at all between the plates, while the velocity at the bottom of the third from the last column is a difference between two velocities in a strong electrical field. If, therefore, the drop were distorted by the electrical field, so that it exposed a larger surface to the resistance of the medium than when it had the spherical form, the velocity due to a given force, that is, the velocity given at the bottom of the third from the last column, would be less than that found at the
bottom of the last column, which corresponds to motions when the drop certainly was spherical.
Furthermore, if the drops were distorted by their motion through the medium, then this distortion would be greater for high speeds than for low, and consequently the numbers in the third from the last column would be consistently larger for high speeds than for low. No such variation of these numbers with speed is apparent either in Table VI or in other similar tables.
We have then in the exactness and invariableness of the multiple relations shown by successive differences in speed and the successive sums of the speeds in the third from the last and the last columns of Table VI complete experimental proof that in this work the droplets act under all circumstances like undeformed spheres. It is of interest that Professor Hadamard,[43] of the University of Paris, and Professor Lunn, [44] of the University of Chicago, have both shown from theoretical considerations that this would be the case with oil drops as minute as those with which these experiments deal, so that the conclusion may now be considered as very firmly established both by the experimentalist and the theorist.
CHAPTER V THE EXACT EVALUATION OF
I. DISCOVERY OF THE FAILURE OF STOKES’S LAW
Although complete evidence for the atomic nature of electricity is found in the fact that all of the charges which can be placed upon a body as measured by the sum of speeds , and all the changes of charge which this body can undergo as measured by the differences of speed ( ) are invariably found to be exact multiples of a particular speed, yet there is something still to be desired if we must express this greatest common divisor of all the observed series of speeds merely as a velocity which is a characteristic constant of each particular drop but which varies from drop to drop. We ought rather to be able to reduce this greatest common divisor to electrical terms by finding the proportionality factor between speed and charge, and, that done, we should, of course, expect to find that the charge came out a universal constant independent of the size or kind of drop experimented upon. The attempt to do this by the method which I had used in the case of the water drops (p. 55), namely, by the assumption of Stokes’s Law, heretofore taken for granted by all observers, led to the interesting discovery that this law is not valid.[45] According to this law the rate of fall of a spherical drop under gravity, namely, is given by
in which is the viscosity of the medium, the radius and the density of the drop, and the density of the medium. This last quantity was neglected in (6), p. 55, because, with the rough measurements there possible, it was useless to take it into account,
but with our oil drops in dry air all the other factors could be found with great precision.
When we assume the foregoing equation of Stokes and combine it with equation (5) on p. 55, an equation whose exact validity was proved experimentally in the last chapter, we obtain, after substitution of the purely geometrical relation , the following expression for the charge carried by a drop loaded with electrons which we will assume to have been counted by the method described:
According to this equation the elementary charge should be obtained by substituting in this the greatest common divisor of all the observed series of values of ( ) or ( ). Thus, if we call this ( we have
But when this equation was tested out upon different drops, although it yielded perfectly concordant results so long as the different drops all fell with about the same speed, when drops of different speeds, and, therefore, of different sizes, were used, the values of obtained were consistently larger the smaller the velocity under gravity. For example, ex for one drop for which per second came out , while for another of almost the same speed, namely, , it came out 5.482; but for two drops whose speeds were five times as large, namely, .0536 and .0553, came out 5.143 and 5.145, respectively. This could mean nothing save that Stokes’s Law did not hold for drops of the order of magnitude here used, something like cm. (see Section IV below), and it was surmised that the
