EBBSFLEET SUSTAINABILITY ASSESSMENT
// Public Realm+ Infrastructure
Engagement Draft// May 2024
One Page Design Guidance Public Realm & Infrastructure
Carbon & Energy
The primary focus is on the the delivery of Net Zero Carbon public realm and infrastructure. Such schemes should:
• Utilise renewable energy sources such as solar panels PV cells to ensure a low operational carbon demand
• Use low embodied carbon materials that are highly sustainable, renewable or made of high recycled content such as timber, GGBS concrete and recycled steel. Schemes should make reference to how materials are being manufactured, procured, transported and constructed onsite to reduce Upfront Carbon figures. Questions should be asked about what are the big ticket carbon saving materials being used, their specifications & strategies for repair, maintenance & replacement of the homes to reduce in-use embodied carbon
Water
The primary focus is to develop public realm and infrastructure to be climate resilience, and minimise water use. Schemes should demonstrate:
• Evidence of blue / green infrastructure and Sustainable Urban Drainage Systems (SuDS) that capture stormwater and mitigate flooding
• Connections to existing SuDS infrastructure, where possible
• Evidence of permeable hard landscape surfaces
• Provision of rainwater collection such as water butts to infrastructure buildings and Grey water recycling measures
Additional guidance can be found here:
• Susdrain, Delivering SuDS (including retrofitting SuDS)
• Kent County Council Drainage and Planning policy statement
• Susdrain, Water People Places
Waste & Materials
The primary focus is to construct infrastructure with circular economy sustainable and healthy materials minimise domestic waste streams. Schemes should evidence:
• Appropriately sized, easily storage provision for recycled waste streams
• Specify reused or recycled materials in dwellings and
• Demonstrate design for deconstruction or adaptability and Offsite Construction
Health & Wellbeing
The primary focus is to develop healthy neighbourhoods with active travel and low carbon and pollution infrastructure, that allow residents to be within a 5 minute walk of day to day amenities and good access to public open space.
• The public realm should be designed with a clear design hierarchy of pedestrian, cycle and public transport routes
Materials
construct public realm and economy principles, promote materials and opportunities to streams.
easily accessible and secure recycled food waste and general
recycled and responsibly sourced and landscape treatment material efficiency, high PMV, adaptability of homes with DfMA / MMC methods
• Align design proposals with the Design for Ebbsfleet Character Guide
• Align design proposals with the Ebbsfleet’s Park Design Criteria
• Align design proposals with the Ebbsfleet Public Realm Strategy
Natural Environment
The primary focus is to construct the public realm with green infrastructure that contributes to climate resilience and provides opportunities to enable residents and visitors to connect with nature and make sustainable lifestyle choices. Applicants should provide evidence of:
• Diversity of native and drought resistance species of planting
• Creation and provision of habitats in the landscape
• Soft landscaping and Tree Canopy Cover strategies in alignment with EDC’S Public Realm Strategy
• Connecting new public realm to existing
• Adoption of minimum 10% Biodiversity Net Gain and target 0.4 or greater Urban Greening Factor opportunities
Public realm + Infrastructure
Carbon and Energy
Sustainability Performance Assessment
Performance measure
Whole life carbon
CO2 emission from both embodied and operational stages- (modules A-C, excluding B6- B7)
CO2 e / m2 (GIA)
Operational: Renewables
Amount of on site renewable
Will not deliver Net-Zero Ebbsfleet
Net-zero best practice
Towards Net-Zero
Please attach Whole Life Carbon Assessment report
Net-zero best practice
Energy Management
Performance gap
(Soft Landings and Post Occupancy Evaluation)
<50% of infrastructure / public realm energy demand provided by onsite renewables
≥50% of infrastructure / public realm energy demand provided by onsite renewables
Net-zero best practice
Not included (Provide justification)
Energy positive 100% of infrastructure / public realm energy demand provided by onsite renewables
Soft Landings Stage 6-7 principles (Provide evidence)
Public realm + Infrastructure
Waste & Materials
Sustainability Performance Assessment * Referencing GLA CE Template v1.1 May 2023
Circular sourcing
% building materials by volume that are reused, recycled, secondary and renewable in construction
See glossary for definition.
Responsible sourcing
% construction materials by volume that are responsibly sourced
Construction waste
Waste to landfill and % incinerated volume/tonnage
Provide comprehensive justification
Provide Circular Economy Statement as a written summary. ≥50%
Provide Circular Economy statement and Table of results.*
<75% of key materials are responsibly sourced
≥75% of key materials are responsibly sourced
* Referencing GLA CE Template v1.1 May 2023
Waste to landfill and incineration
*Zero nonhazardous waste to landfill and ≤10% incinerated.
100% of key materials are responsibly sourced.
Provide Circular Economy statement
*Zero nonhazardous waste to landfill and 0% incinerated.
Public realm + Infrastructure
Health
&
Wellbeing
Sustainability Performance Assessment
Performance measure
Car club
Distance from car club and ratio of car/number of units
Transport connections
Distance to public transport stops and Mobility as a Service (MaaS) hubs
External daylight and sunlight
Compliance with BRE 209 standard for external daylight and sunlight
Wind comfort
Wind speed (m/s) sits within ‘comfortable’ level of Lawson Wind Comfort Criteria
Will not deliver a healthy Ebbsfleet
Towards a healthy Ebbsfleet
Net-zero best practice
Car club bays within 5 minute walking radius
≤400m to bus stops
Net-zero best practice
≤400m to mobility hubs (car share, bike share, bike hubs, bus stops)
< 2 hours direct sunlight on the ground to 50% of open space on 21st March
< 2 hours direct sunlight on the ground to 70% of open space on 21st March
≥ 2 hours direct sunlight on the ground to 70% of open spaces on 21st March
≥15m/s (Unsafe)
<15m/s - 8m/s (Uncomfortable to Fast walking)
< 8m/s (Comfortable)
Public realm + Infrastructure
Water
Sustainability Performance Assessment
Performance measure
SuDs
Sustainable Urban Drainage Systems
See glossary for definition.
Surface water run off Runoff volume
Water Use
Water usage per person / BREEAM criteria
Towards waterresilience Non water-resilient
No SuDs measures provided Provide justifcation
No control measures provided Provide justification
Water-resilient
SuDs measures provided 100% above ground attenuation
Control runoff to greenfield volume
Net-zero best practice
Irrigation systems fed by Potable water
Control runoff to greenfield volume and no net increase in volume from existing state
No permanent irrigation system used
Public realm + Infrastructure
Natural Environment
Sustainability Performance Assessment
Performance measure
Under-performing
Biodiversity Net Gain
% biodiversity net gain (BNG)
Tree Canopy cover
% tree canopy cover of amenity and public realm outdoor space
Food Growing
Proximity to community growing garden, orchard or allotment.
Drought resistance
% drought resistant species of trees, shrubs and ornamental planting specification
Ecological corridor
Compliance with Ebbsfleet Green Infrastructure Framework
Not Applicable
≥ 10.6% (Gravesham)
≥ 16% (Dartford)
Community Garden, Allotment or Orchard within 10mins walk or greater from the site
No Drought resistant planting provided.
(Provide justification)
Net-zero best practice
≥16.5% (Environmental Improvement Plan)
Community Garden, Allotment or Orchard within 5mins walk from the site
Garden City Best Practice
Net-zero best practice
≥20% of the site area ≥ 0.3 target score (UK Forestry Commission)
Community Garden, Allotment or Orchard provided on site.
≥80% planting to be drought tolerant
100% planting to be drought tolerant
Provide evidence report on number of connections to Ebbsfleet Green Infrastructure Framework ‘garden grid’ network.
Public realm + Infrastructure Inclusive growth + community development
Community Engagement
Community Engagement
Accessibility
Accessibility
Project has facilitated co-design events early in the design process to up-skill the community on design, and enable them to engage in the codesign of the project.`
Project has utilised a digital engagement platform throughout the design process to provide a portal for all briefing and community engagement activities, and to provide feedback on community proposals and ideas.
Project has included an access consultant to enable best practice accessibility within the project.
For Public Realm, the project has applied the public building section of the London Legacy Development Corporation’s Inclusive Design Standards.
Arts and Culture
Design teams has reviewed the Ebbsfleet Public Art Strategy, and integrated the Ebbsfleet public art principles into the project.
Application Assessment Summary
Project Name:
Sustainability Themes / Performance Measure
Carbon & Energy
Please select Sustainability Level achieved in each measure
Whole life Carbon N/A N/A
Renewables
Energy Management N/A
Waste & Materials
Circular sourcing
Responsible sourcing
Construction waste
Health & Wellbeing
Car club N/A
Transport connections N/A
External daylight and sunlight
Wind comfort
Water
Sustainable Urban Drainage Systems (SuDs)
Surface water run off
Water use
Natural Environment
Biodiversity Net Gain
Tree Canopy cover
Food growing
Drought resistance
