CAPITAL IMPROVEMENTS PROGRAM
WEST IRVING CREEK
Channel Improvements from W Pioneer Drive to Alan-a-Dale
COMMUNITY MEETING #2
OCTOBER 18, 2022
2 1
INTRODUCTIONS & BACKGROUND
PROJECT OVERVIEW
3
4
DESIGN UPDATES
MEETING AGENDA
Q&A AND BREAKOUT
1.
Existing Channel Upstream of Conflans
INTRODUCTIONS & BACKGROUND
PROJECT TEAM
Walter Thomas, PE City Engineer
Garry Fennell, PE, CFM
Floodplain Manager
Brent Redd MDU Programs Manager
Justin Oswald, PE, CFM
Project Manager
Freese and Nichols, Inc.
WHAT IS WEST IRVING CREEK?
▪ Drains 15%+ of the City south of SH-183- over 3 square miles!
▪ Runs for 3+ miles from Wyche Park at Pioneer Road to outfall south of Oakdale Road
▪ Constructed in the 1960s
▪ Inadequate to meet current standards for 100-year flood capacity
MUNICIPAL DRAINAGE UTILITY
▪ City reinvesting in the MDU
▪ Issuing bonds backed by fee increase
▪ #1 City Council priority for MDU
▪ Project expected to cost $90+ million
▪ MDU program provides opportunity for a long-term fix
▪ Comprehensive Study completed 2021
Current Project
Future Phase
Future Phase
PHASED CAPACITY IMPROVEMENTS
Future Phase
FLOOD INFRASTRUCTURE FUND
▪ City may be awarded grant and 0% loan from Texas Water Development Board (TWDB)
▪ Provides funding for the first 2 phases
▪ Application in progress
▪ May result in impacts to project schedule
PROJECT OVERVIEW 2.
Delaware Creek Construction
PROJECT BENEFITS
CAPACITY
▪ Improvements similar to recently completed Delaware Creek
▪ Provide 100-Year Capacity
▪ Increase Detention at Wyche Park
▪ Reconstruct Channel with Vertical Walls
▪ Increase Capacity with Minimal Footprint
▪ Replace or Add Fencing
▪ Improve Aesthetics
Delaware Creek
CHANNEL
BRIDGES
Single Span Bridge Delaware Creek
Existing Crossing
▪ 5 Bridge Replacements
▪ Replace Small Culverts with Large Single Span
▪ Improve Aesthetics
▪ Evaluate Traffic Impacts
WATER &
▪ Replacing 3400’ Wastewater Main Beneath/Parallel to Channel
▪ Adjusting 5 Water Line Locations
▪ Adjustments To Be Made Before Channel Work
▪ Minimize Service Disruption
▪ Provide Capacity for Future Needs
▪ Other Water, Wastewater, and Paving Work Between Conflans and Yorkshire Recently Completed
WASTEWATER
Wastewater Bore Delaware Creek
WYCHE PARK
▪ Deepen Park by approx. 8 feet
▪ Permanent Pond to Provide Water Quality
▪ Provide Forebay and Trash Collection
▪ Natural Edge to Provide Wetland Habitat
3.
DESIGN UPDATES
West Irving Creek Parallel to Elevated TRE Tracks
CHANNEL
SECTION
▪ Vertical Walls for Deeper Channel
▪ Fits In Narrow Easement Behind Residential Lots
▪ Construction Footprint Wider Than Finished Wall
▪ Relocation or Shoring May Be Necessary for Sheds, Storage Buildings, etc. Within or Adjacent to Easement
CHANNEL
FENCING
▪ Channel Area To Be Fully Fenced with Gates for City Maintenance
▪ Homeowner Fence To Be Replaced As-Is Along Property Line
▪ Safety Rail To Be Provided Along Channel
▪ Ornamental Rail To Be Provided At Public-Facing Locations
LICENSE
▪ Access To Properties Adjacent To Channel Will Be Required For Construction
▪ Shoring Will Be Implemented To Protect Structures
▪ Letters Have Been Sent To Affected Residents
▪ If you received a letter and haven’t responded yet, please speak with Real Estate Services (Cheryl Elgin)!
AGREEMENTS
WYCHE PARK
▪ Wyche Park Concept Has Been Developed
▪ Potential for Future Amenities: Trails, Trees, Lookout Area, etc.
SIDEWALK
▪ New Entrance To Wyche Park At Lawrence
▪ Potential Connection To Future Trail Extensions
Lawrence St
SIDEWALK CONNECTIONS
▪ New Connection To Rock Island Road Bike And Pedestrian Trail
Alan-A-Dale
PROJECT SCHEDULE
Community Meeting #1
Field Survey Work
Engineering Plans
Property Coordination
Community Meeting #2
Bid and Award
Community Meeting #3
Construction
▪ Design completed by Q1 2023
▪ Construction expected to begin Q3 2023
▪ Assumes no schedule impacts due to TWDB grant
4. QUESTIONS & ANSWERS
Sherwood Forest within Phase A
