CAPITAL IMPROVEMENTS PROGRAM
WEST IRVING CREEK
Channel Improvements from W Pioneer Drive to Alan-a-Dale
COMMUNITY MEETING #1
JANUARY 25, 2022
1
2
INTRODUCTIONS & BACKGROUND
3
PROJECT OVERVIEW Q&A AND BREAKOUT
MEETING AGENDA
1.
INTRODUCTIONS & BACKGROUND
Confluence Near Tipton Road
PROJECT TEAM
Walter Thomas, PE City Engineer
Garry Fennell, PE, CFM
Floodplain Manager
Brent Redd MDU Programs Manager
Justin Oswald, PE, CFM
Project Manager
Freese and Nichols, Inc.
WHAT IS WEST IRVING CREEK?
▪ Drains 3+ square miles – 15%+ of the City south of SH-183
▪ Runs for 3+ miles – from Wyche Park to outfall south of Oakdale Road
▪ Constructed in the 1960s
▪ Inadequate to meet current standards for conveyance of 100-year flood events
WEST IRVING
Channel Near Capacity at Bowman Street
▪ History of street and home flooding
▪ Portions not mapped by FEMA
▪ Urgent improvements underway:
▪ Wyche Park Detention
▪ Construction begins soon
▪ Hogbottoms Outfall Debris Collector
▪ Completed in 2021
MUNICIPAL DRAINAGE UTILITY
▪ City reinvesting in the MDU
▪ Issuing bonds backed by fee increase
▪ #1 City Council priority for MDU
▪ Project expected to cost $90+ million
▪ MDU program provides opportunity for a long term fix
▪ Comprehensive Study completed 2021
Current Project
Future Phase
Future Phase
PHASED CAPACITY IMPROVEMENTS
Future Phase
PROJECT OVERVIEW 2.
Delaware Creek Construction
PROJECT BENEFITS
CAPACITY
▪ Similar to recent Delaware Creek Project
▪ Additional Detention
▪ Reconstruct Channel with Vertical Walls
▪ Minimize Footprint
▪ Replace or Add Fencing
▪ Improve Aesthetics
▪ Provide 100-Year Capacity
Delaware Creek
CHANNEL
SECTION
▪ Narrow easement behind residential lots
▪ Vertical walls for deeper channel
▪ Construction footprint larger than the finished wall
▪ Private structures may be within or adjacent to easement
▪ Relocation or shoring may be necessary
CHANNEL
BRIDGES
Existing Crossing
▪ 4-5 Bridge Replacements
▪ Replace small pipes with large single span
▪ Improve aesthetics
▪ Evaluate traffic impacts
Single Span Bridge Delaware Creek
WATER &
▪ Approx. 15 conflicts
▪ Adjusted before channel work
▪ Minimize service disruption
▪ Provide capacity for future needs
▪ Other Water, Wastewater, and Paving work on-going between Conflans and Yorkshire
WASTEWATER
Wastewater Bore Delaware Creek
WYCHE PARK
▪ Deepen Park by approx. 8 feet
▪ Pond for water quality and amenity
▪ Provide forebay and trash collection
▪ Natural edge for water quality, erosion and safety
▪ Other amenities such as trails, trees etc.
SIDEWALK CONNECTIONS
▪ New entrance to Wyche Park at Lawrence may be considered
▪ New connection to Rock Island Road Bike and Pedestrian Trail may be considered
PROJECT SCHEDULE
Community Meeting #1
Field Survey Work
Engineering Plans
Property Coordination
Community Meeting #2
Bid and Award
Community Meeting #3
Construction
▪ Design completed by Q1 2023
▪ Construction expected to begin Q3 2023
3. QUESTIONS & ANSWERS
Before and After on Delaware Creek
