Silvercrest - Summit Series

SUMMIT SERIES

25020

Two Bed | Two Bath | 1,000 Sq. Ft.

25024

Two Bed | Two Bath | 1,183 Sq. Ft.

Two Bed | Two Bath | 1,325 Sq. Ft.

Two Bed | Two Bath | 1,333 Sq. Ft.

Three Bed | Two Bath | 1,493 Sq. Ft.

Three Bed | Two Bath | 1,600 Sq. Ft.

Three Bed | Two Bath | 1,780 Sq. Ft.

66’-8” x 26’-8”

Four Bed | Two Bath | 1,777 Sq. Ft.

Four Bed | Two Bath | 1,977 Sq. Ft.

Construction & Specifications

• California CARB II Compliant Home

• 20 lb Roof load

• R-11 Floor Insulation

• R-13 Wall Insulation

• R-22 Ceilings Insulation

• All Structural Lumber used is Kiln-Dried for Higher Quality

• 2” x 6” Transverse Floor Joists – 16” O.C.

• 2” x 4” Exterior Wall Studding – 16” O.C.

• White Vinyl Dual-Glazed Windows

• PEX Water Lines

• Water Shutoff Valves at all Sinks and Toilets

• Drywall Ceilings and Interior Walls

• 5/8” OSB Floor Decking

• 8’ Sidewall Height

• 100 Amp Electrical Panel

• 30-Gallon Gas Water Heater

• High-Efficiency Gas Furnace with Smart Thermostat

• Steel Outriggers on all Exterior Walls for Support – No Perimeter Blocking Required on Standard Plans without Modifications

• Silvershield 7-Year Warranty - Includes Structural Coverage (Deductibles Apply, Claims Processed by Cornerstone United Insurance Co.)

Exterior

• 30-Year Architectural Shingles

• (2) Exterior GFI Protected Patio Outlets (Locations Vary Per Plan)

• 16” Front Overhang / 2” Rear Overhang / 4” Eaves

• 36” Insulated 6-Panel Front Entry Door with Deadbolt Security Lock

• Cement Exterior Siding with Wood Grain Embossing

• 8” Fascia and 4” Hardboard Corner and Window Trim

• 2-Window Clerestory on Multi-Sections Only

• “Summit” Style Shutters (8” Trimmed Windows)

• 4” Trim Band with Accent Color Below

Interior Features

• Orange Peel Style Textured Finish on Walls and Ceilings

• PPG Interior Paint – White Walls Standard

• 8’ Flat Ceilings Throughout

• Passage and Wardrobe Doors Throughout –Flat Panel

• Mortised Hinges on Passage Doors – (3) Total

• Passage Door Locksets – Tulip Style

• Hidden Hinges on Cabinet Doors

• Side-Mounted Metal Drawer Guides

• Water Shutoff Valves at all Fixtures

• Rocker Style Light Switches with Matching Wall Outlets

• All Copper Wiring Throughout

• 1 ½” Square Baseboards, Window Casings & Crown Molding

Floor Coverings

• Carpet in Living Areas & Bedrooms

• 3/8” Rebond Carpet Pad

• Easy Care Linoleum Flooring in Kitchen, Baths, Utility, Nook & Dining Area (Per Plan)

Kitchen

• Summit Style Island (Per Plan)

• Whirlpool® Kitchen Appliances

• 30” Gas Freestanding Range & 30” Rangehood

• 18 Cu.Ft. Refrigerator with Top Freezer

• 8” Deep Stainless Steel Self-Rimming Sink

• Single Lever Faucet – Chrome

• Shelf in Overhead Cabinets with White Lined Finished Cabinet Interiors

• Corian® Countertops with 4” Backsplash

Bathrooms

• 60” Tub/Shower

• Corian® Countertops with 4” Backsplash

• China Self-Rimming Sink

• Dual-Handle Faucet

• Low-Flow Water Saving Toilets

• Towel Bar & Paper Holder

• Ceiling Vented Exhaust Fan

• Easy Care Vinyl Flooring

Optional Features

• 2” x 6” Exterior Walls with R-19 Fiberglass Insulation for Additional Energy Savings

• Energy-Saving Tankless Gas Water Heater

• ENERGY STAR® Construction with HighEfficiency Furnace

• Reflective Roof Sheathing for Cooler Roof Attic Areas – Saves Money on Heating and Cooling Costs

Lighting

• Switched Wall Outlet for Lamp Lighting in Living Room and all Bedrooms (Wall Outlet Installed Upside Down for Easy Identification)

• LED Can Lights in Selected Areas

• (2) Pendant Lights Over Island (Per Plan)

• Solar Tubes or Skylights that Light Home Interiors without Lighting During Daylight Hours – Saves Energy

• LED Can Lights for Energy Savings

• Prep Raceways for Wall Mounted Flat Screen Television

• WUI Compliant Structural Package

• Fire Sprinkler System

• And Much, Much More!

disclaimerDue to continuous product development and improvement, prices, specifications, and materials are subject to change without notice or obligation. Square footage and other dimensions are approximate. Exterior images may be artist renderings and are not intended to be an accurate representation of the home. Renderings, photos and floor plans may be shown with optional features or third-party additions.
