B2
NO FUNCTION - NF
VALVES
To be used when, on one of the two-way network, no pneumatic function is required. The flow conveys directly from the inlet to the output fitting without any variation.
TECHNICAL DATA
EB 80 - NO FUNCTION - NF
Ø of cartridge fitting Max. operating pressure
Flow rate at 6.3 bar ∆P 1 bar
DIMENSIONS
NOTES
B2.106
Ø 4 (5/32”) bar MPa psi Nl/min
Ø6
Ø 8 (5/16”)
Ø 1/4”
600
500
10 1 145 130
500
