CARLO GAVAZZI Automation Components
Inductive Proximity Sensors Carlo Gavazzi offers a comprehensive range of inductive sensors for detecting the presence of metal. These sensors are used extensively in packaging and plastics machinery, on assembly lines and conveyor Automation Components systems, and are available with a wide variety of styles and features. Carlo Gavazzi cylindrical inductive sensors are available in a wide variety of diameters and lengths, and configurations. Standard, extended and extra extended sensing ranges are available, providing up to 40mm sensing range. For particularly tough applications, Carlo Gavazzi offers IP69K-rated sensors for harsh wash-down applications, high temperature sensors, and full metal housed sensors. Flat-pack, fork-shaped and micro/ limit switch housings are also available for specialty applications.
CARLO GAVAZZI
CARLO GAVAZZI Automation Components USA Tel: 847.465.6100 Fax: 800.222.2659 Canada Tel: 888.575.2275 Fax: 905.542.2248 Mexico Tel and Fax: 52.55.5373.7042 www.GavazziOnline.com • Info@CarloGavazzi.com twitter.com/CarloGavazziNA facebook.com/CarloGavazziNA
For more detailed information, visit: www.GavazziOnline.com/Inductive
Visit our website for downloadable data sheets, Ø4,M5 M8 brochures and pricing: www.GavazziOnline.com
IBS, ICS
ICS, EI
M12 ICB, EI & IA
M18 ICB, EI & IA
M30 ICB, EI & IA
CARLO GAVAZZI Automation Components NEW
NEW
Miniature inductive proximity sensors with sensing ranges up to 1.3mm. 3 wire DC. M5 threaded, 4mm and 6.5mm smooth barrel. Stainless steel, IP67 housing. Flush or non-flush mounting. 6khz speed. IO-Link versions of these sensors are shown on page 11.
Inductive proximity sensors in M8 stainless steel IP67 housings. Standard and extended sensing ranges up to 4mm. NAMUR, 2 wire DC and 3 wire DC options. Flush or non-flush mounting. IO-Link versions of these sensors are shown on page 11.
Inductive proximity sensors in M12 stainless steel, nickel plated brass or plastic IP67 housings. Standard and extended ranges up to 8mm. NAMUR, 2 wire AC, 2 wire DC and 3 wire DC options. Flush, quasi-flush or non-flush mounting. Connection choice of 2m cable or M12 plug. IO-Link versions of these sensors are shown on page 11.
Inductive proximity sensors in M18 stainless steel, nickel plated brass or plastic IP67 housings. Standard and extended ranges up to 14mm. NAMUR, 2 wire AC, 2 wire DC and 3 wire DC options. Flush, quasi-flush or non-flush mounting. IO-Link versions of these sensors are shown on page 11.
Inductive proximity sensors in M30 stainless steel or nickel plated brass IP67 housings. Standard and extended sensing ranges up to 22mm. NAMUR, 2 wire AC, 2 wire DC and 3 wire DC options. Flush, quasi-flush or non-flush mounting. IO-Link versions of these sensors are shown on page 11.
Extra Extended Sensing Distance
Harsh Environment ICS
High Temperature IA..HT-K
Complementary Output ICB & ICS
Other Sensors and Amplifiers
NEW
ICB Series extra extended sensing distance in M12, M18 and M30 nickel plated brass IP67 housings. Extra extended range up to 10mm (M12), 20mm (M18) and 40mm (M30). 3 wire DC output. Quasi-flush or nonflush mounting.
4
Sensors
ICS Series harsh environment sensors in M12, M18 and M30 stainless steel IP69K ECOLAB certified housings rated from -40 to 80°C (-40 to 176°F). Sensing range up to 22mm. 3 wire DC. Flush or non-flush mounting. Connection via M12 plug and CONB Series IP69K cord set.
IA..HT-K Series high temperature sensors in M5, M8, M12, M18 and M30 stainless steel or nickel plated brass IP67 housings. Rated from -40 to 120°C (-40 to 248°F). Sensing range up to 15mm. 3 wire DC. Flush or non-flush mounting. Connection choice of 2m cable or M12 plug.
ICB and ICS Series with complementary output function provide high flexibility. Offered in M8 (stainless steel), M12, M18 and M30 (nickel plated brass) IP67 housings. Standard and extended sensing distances up to 22mm.
Carlo Gavazzi also offers non-cylindrical sensors and amplifier relays: DU Series fork shaped with various slot sizes; IG12 Series in microlimit switch housing; EI55 Series flat pack; IC40 Series with rotatable head in general purpose limit switch housing; and LDP Series loop detectors amplifiers.
CARLO GAVAZZI Automation Components. Specifications are subject to change without notice. Visit GavazziOnline.com for more details.
