Energy Meters, Data Loggers & Transducers Carlo Gavazzi supplies energy meters and power analyzers that provide information so that operators can identify consumption trends and take corrective actions. Analyzing the power profile, operators can aggregate Automation Components loads and negotiate favorable terms with the utility company. Carlo Gavazzi’s energy management program also includes hardware and software products for data-logging of instantaneous electrical and environmental variables and energy consumption profiles. VMUC or UDP platforms use industry standard communication protocols, can provide complete stand-alone, data-logging solution or function as data gateway to IoT servers. Also offered is a wide range of current transformers, that can be connected with all the existing wire terminals and installed either on DIN-rail, around busbars or directly onto back panels.
CARLO GAVAZZI
CARLO GAVAZZI Automation Components USA Tel: 847.465.6100 Fax: 800.222.2659 Canada Tel: 888.575.2275 Fax: 905.542.2248 Mexico Tel and Fax: 52.55.5373.7042 www.GavazziOnline.com • Info@CarloGavazzi.com twitter.com/CarloGavazziNA facebook.com/CarloGavazziNA
For more information, visit: www.GavazziOnline.com/EnergyManagement
Visit our website for downloadable data sheets, Modular Power Analyzer Modular Power Analyzerwww.GavazziOnline.com brochures and pricing:
WM30
WM20
Modular Power Analyzer WM40
Branch Circuit Analyzer WM50 & TCD12
Current Transformers CTD.X & CTD.S
CARLO GAVAZZI Automation Components NEW
Modular power analyzer for 3-phase systems with simplified user interface and LCD data display. Plug and play modules. Active and reactive energy. Optional modules for WM20: Modbus-RTU, TCP/IP, BACnet MS/TP or IP, Profibus, and dual relay output. Integrated optical port for OptoProg connectivity. Meter is rated up to 690VAC.
WM30 is a 3-phase smart power analyzer with built-in application configuration system and LCD data display. Plug and play modules. Total energy counting up to ten digits. Optional communication: same as WM20 plus EtherNet/IP, dual relay and analog outputs. WM30 is Go Solar California eligible. Meter is rated up to 690VAC.
3-phase smart power analyzer with an option for integrated data logging. WM40 measures instantaneous and min/max variables, fourquadrants of energy and harmonic analysis. Optional communication: same as WM30, relay and analog outputs, digital, process and temperature probe inputs. Meter is rated up to 690VAC.
Multichannel power analyzer. Using TCD12 split-core current sensors, WM50 can monitor any combination of single, two and three-phase loads for a maximum of 96 channels. Optional modules: Modbus-RTU or TCP/IP communication, I/O module or analog and temperature probe input module. Meter is rated up to 552VAC.
The CTD.X, the permanent core, cable/bus-bar type current transformer with DINrail/busbar and panel mounting facility. CTD.S, the split-core current transformer with similar mounting options. Rated maximum primary currents from 1 to 4,000AAC, with a secondary rating of either 1 or 5AAC.
Universal Web Platform UWP 3.0
Data-logging System VMUC-EM
Accessories for VMU-D, VMU-M,
Pulse Counter VMU-MC & VMU-OC
Server Software EM2 Server
NEW
The UWP 3.0 is a monitoring gateway and controller that allows the monitoring and controlling of installations where Energy Efficiency Management, Building Automation, and Car Park Guidance functions are needed. The UWP 3.0 can manage the complete lighting control system based on DALI actuators, and it can operate as a BACnet/IP gateway.
28
Controls
NEW
The VMU-C EM is a modular system that records, monitors and transmits analog and digital signals with a specific focus on energy efficiency. The system includes a web server used to set up and monitor the system. Furthermore, data can be transmitted using various protocols such as FTP, HTTP, and Modbus TCP/IP. Microsoft Azure Certified for IoT.
The VMU-D is an accessory module that provides reliable and cost-effective way to connect the VMU-C EM to the Internet by using mobile networks via dongle 3G modem. The VMU-M master module controls; VMU-O a module that manages two digital inputs and two relay outputs, and VMU-P, a module that manages environmental variables.
The VMU-MC is a pulse concentrator that makes totalizers available to master systems such as VMU-C EM. Furthermore, it controls up to three VMU-OC accessory modules via local bus to integrate from 2 to a maximum of 11 digital inputs. Each VMU-MC has two digital inputs, while the VMU-OC offers three digital
The Em2 Server software installed on a VMware server manages distributed installations. Each remote location is equipped with one VMU-C EM unit that is in charge of gathering data from connected devices, and transmitting it to the central Em2 Server. Such architecture centralizes the data base and web-server access for up to 20 locations per license.
