LATERAL DEFINITION AND DIRECTION OF TOP SHAPE
LATERAL DEFINITION AND DIRECTION OF TOP SHAPE
RE, NG
Visitor side (V)
User side (U) right side (R) left side (L)
Visitor side (V)
Visitor side laterally (VS) front (F)
User side (U) lateral (S)
Visitor side (V)
User side (U) front (F)
CONNECTION POSITION AND DIRECTION OF TOP SHAPE
Visitor side laterally (VS)
Visitor's side left (VL)
left side (L)
Visitor's side right (VR)
User side (U) right side (R)
OPTIONS TABLE TOP
CABLE OUTLET
Quick and easy to pass cabling through the table top. The outlet cover can be slip to one side so that the cable can pass though it.
· 1-3 units per table top possible Positions specified as fixed per desktop shape
Possible positions of the grommet hole
PLUG BOX
The plug box is milled flush into the table top and can be equipped with a connection plug board. Quick and easy access to the plug board is enabled by opening the aluminium flap.
2 unit per table top possible
· Position per desktop shape specified as fixed Position in the centre up to desk width of 1.400 mm
· Position left or right from desk width of 1.600 mm upwards
Cannot be combined with sliding top and cable flap.
Plug box and integral connection plug boards “Cable and media management” price list
Possible positions of the plug box
CABLE BOX
The cable box enables quick and easy access to the cable tray. The plastic frame and the metal flap are available in white, black or aluminum.
1 to maximum 2 pieces per desk top are possible
· position per desktop shape specified as fixed position in the centre up to desk width of 1.400 mm
· position left or right from desk width of 1.600 mm upwards
Cannot be combined with sliding top and cable flap.
Possible positions
