IT IS THE RESPONSIBILITY OF THE LESSEE TO COMPLY WITH THE BUILDING CODE OF AUSTRALIA INCLUDING WITHOUT LIMITATION THE CONDITIONS OF THE FIRE ENGINEERED DESIGN SOLUTION FOR THE CENTRE.
B.BAP (By MUN Korean Kitchen)
LESSEE TO OBTAIN ENGINEERS CERTIFICATE TO VERIFY STRUCTURAL ADEQUACY
Tenancy L02 2081 - Highpoint Shopping centre VIC 3032
LESSEE TO PROVIDE AND ENSURE SHOPFITTER RETAINS A COPY OF THESE GPT STAMPED APPROVED DRAWINGS ON SITE AT ALL TIMES. (ALL PREVIOUS ISSUED & ALL UNSTAMPED DRAWINGS TO BE DESTROYED.)
SUSPENDED ELEMENTS All suspended items such as canopies/ signage/ overhead structures and the like are required to have their supports and fixing details designed/ specified and certified by your appointed registered structural engineer with certification being provided to the lessor prior to handover of the premises.
DRW NO . A-01 A-02 A-03 A-04 A-05 A-06 A-07 A-08 A-09 A-10 A-11 A-12 A-13 A-14
APPROVED DESIGN CONCEPT Centre Highpoint Shop No. L02 2081 RDM Date Issue
LS 3 December 2021 REV B Conditional
TITLE
SCALE
DRW NO .
COVER PAGE
NOT TO SCALE
GENERAL NOTES
NOT TO SCALE
PERSPECTIVE VIEW -1
NOT TO SCALE
PERSPECTIVE VIEW -2
NOT TO SCALE
SCHEDULE -1
NOT TO SCALE
SCHEDULE -2
NOT TO SCALE
LOCATION PLAN
NOT TO SCALE
EXISTING PLANS EXISTING ELEVATIONS & SECTIONS PROPOSED FLOOR PLAN PROPOSED REFLECTED CEILING PLAN PROPOSED WALL & FLOOR FINISH PLAN ELECTRICAL PLAN HYDRAULIC PLAN
Consent of the concept is granted to the lessee for the Shopfront, shop layout and signage shown on these plans. GPT notations including comments & initialled handwritten changes must be complied with by the lessee. “GPT” includes GPT Management Holdings Limited (ABN 67 113 510 188), GPT RE Limited (ABN27 107 426 504) as responsible entity of the General Properties Trust, any of their subsidiaries and appointed agents.
A-15 A-16 A-17 A-18 A-19 A-20 A-21 A-22 A-23 A-24 A-25 A-26 A-27 A-28 A-29 A-30 A-31
SHOPFRONT Your shopfront is to comply with the NCC/ BCA 2019 ( and Section J – where applicable). Your shopfront is to be self-supporting and not impose any load to the base build structure. All door guides, tracks, lockdowns, trims, covers, mechanisms, access panels need to be recessed and set flush or concealed within surrounding planes and secured with mechanical fixings.
STRUCTURAL
Mechanical fixings are to be used as the primary method of installation for signage, linings, cladding and other embellishments. Adhesives may only be used as a secondary fixing to the primary ( mechanical ) method of installation.
Provide Structural Engineer’s documentation with details setting out structural intent for the bulkhead and shopfront support before handover of premises for lessor review.
Where adhesive fixings are the only suitable method of installation ( i.e. tile to masonry wall ), lessee’s consultants to issue details of the product including manufacturers recommendation for preparation and use, warranties etc.
Structural drawings must be submitted to the lessor during the design review process. All certification must be in place prior to open for trade.
All structural items to be designed and certified by a registered structural engineer.
CONSTRUCTION ISSUE
This drawing is the property of Roo op Building & Interior Studio, reproduc on in whole or part is strictly forbidden without wri en consent © 2020
REV.
Amendment
Date
Dwg Title:
Architecture and Design
COVER PAGE GSPublisherVersion 0.0.100.100
Tenancy specific conditions: Shopfront • RHSide Return wall to be treated as part of fit-out - please adjust and fully amend the junction - refer to the tenancy pans, the wall seems to have dropped off from the drawings. • Note that Lessor IT cappings to remain - provide junction detail of wall finishes to capping including return wall - provide detailed sketch for Lessor review and approval. • LHSide IT wall capping extends full height (refer to tenancy plans) ensure that the wall capping does not exceed the depth of the capping. Please provide sketch detail. • The wall bench (table) will need to stop 300mm short of the lease line, allowing the timber to be returned into the tenancy 300mm • The bench end will need to have a solid treatment installed confirm details of how the table will be fixed into position? 26/11/21 Outstanding. • Menu and overhead mirror to have the top plate fully concealed do not surface mount • Confirm if drinks fridge being installed and if so it will need to be built in and free of third party branding. Custom fridge required. 26/11/21 Outstanding. • Provide all counter details, sketch detail of all junction, lighting TITLE details to skirting (we would recommend these are deleted as they typically do not age well. Incorporate shadow detail (25mm angle to mall bulkhead and SHOPFRONT ELEVATION & ELEVATION -A1• tenancy bulkhead junction - confirm detail 26/11/21 Outstanding. 3/12/21 ELEVATION -A2 Outstanding. • Provide your engineer's structural design for shopfront, overhead ELEVATION -A3 & A4 features and any suspended elements. SECTION -B1 & B2 Flooring ELEVATION -B3 & B4 • To ensure the small amount of tenancy tile is not remaining between counter skirting and mall tile, we request that a 300mm threshold DETAIL - MAIN STATION tile is installed in a contrasting tone i.e. black please review and DETAIL - HANGING MIRROR & SIGHNAGE redocument. Seating (licensed area) DETAIL - BANQUETTE SEAT -1 • Provide updated details of the seating barrier - ensure to clad the DETAIL - BANQUETTE SEAT -2 top and sides with a black PC trim and introduce a recessed skirting (finished flushed to the cladding) DETAIL - WALLMOUNT HIGH TABLE • Please also provide fixing detail proposed (wall to be fixed into DETAIL - SIGNAGE position. 26/11/21 Outstanding. 3/12/21 Outstanding. DETAIL - WALLMOUNT NEON SIGN Finishes • Note that Corian finishes need to be fully finished off site and only DETAIL - CABINET-1 installed in tenancy (do not sand or cut on premises) 26/11/21 Outstanding. DETAIL - CABINET-2 3/12/21 Outstanding. • Provide sample finishes for Lessor review and approval. DETAIL - CABINET-3 Services DETAIL - MENU BOARDS • Note: Services are subject to base building consultant review DETAIL - WALL LED LETTER SIGNAGES • Exit sign to be single sided with fully recessed control gear - see Lessor standard requirements • Note that 800x800 access panels are required in this instance - see Lessor standard requirement for access hatches. Other • Please confirm that the drawings have been submitted to Maribyrnong Health Department for review. Refer to the Design Information pack for full details. 26/11/21 Outstanding. 3/12/21 Outstanding. • Signage and graphics package - Please provide a full signage and graphics package - ensure to nominate all proposed finishes, illumination and fixing methods proposed. 26/11/21 Outstanding. Please see separate reviews. 3/12/21 Please note that Lessor reserves the right to further assess signage and graphics requirements upon completion of fit-out, information provided being minimal.
