AIH Home Firefighting Sytems

Which home re ghting products are right for me?

Ultimately, only you can decide what equipment is best suited for your application. To assist you in that decision, we offer the following information:

https://forestry.alaska.gov/ Assets/pdfs/home/ rewise09.pdf

Fire Pump

Scan the QR code or follow the link to read “Firewise Alaska” from the State of Alaska Division of Forestry

This is the heart of your system. The pump must be designed for firefighting applications (not transfer, dewatering or trash pumps). It should be light in weight, able to produce water pressure of at least 80 psi and pump large volumes of water over the vertical and horizontal distance you require.

Suction Hose

This is the hose that goes from the water supply to the pump. It is different from the discharge hose in that it must be of a rigid construction to prevent it from collapsing from the suction generated by the pump. A strainer should be used on the suction hose to ensure only clean water is pulled into the pump.

Discharge Hose

Inadequate pressure can lead to ineffective firefighting. Sufficient discharge pressure ensures that hose lines can deliver water at the desired flow rate and pressure to the nozzle, maximizing the effectiveness of the firefighting stream. Ensure a snug fit to prevent leaks and for optimal pressure and flow. A charged hose does not like sharp turns, long gradual turns will prevent kinking and cutting off water flow. Do not use hoses that show signs of deterioration or damage.

Nozzle

Stream nozzles are good for penetration through a burning surface into the lower layers of a fire. These are most effective when you wish to kill the fire that is smoldering. Fog/Stream is ideal for attacking a brush or grass fire or knocking down a structure fire. An adjustable nozzle allows you to adapt to the fire and circumstance.

2" Fire ghting Pump Kit on Cart with 6.5 HP Honda Engine

196cc Honda GX200 engine with recoil start, low oil shutdown and a 0.95 gal. fuel capacity. Features centrifugal aluminum pump, heavy-duty aluminum impeller and foot valve. 126 gpm max flow rate. 197' total lift, 26' suction lift. Comes with 2" x 12' suction hose kit and 1-1/2" x 50' fire hose kit. BEP717137

2" Water Transfer Pump With Honda® GX200 Engine

GX200 196cc Honda engine with 0.82 gal. fuel tank capacity. Recoil start and low oil alert. Centrifugal aluminum pump with heavy-duty cast iron impeller. 2" MNPT intake and outlet connection. 85' total lift and 26' suction lift. 158 gpm/9480 gph.

BEPWP2065HL

2" PVC Discharge Hose

• Balanced polyester yarn spiral wrap

• Ultraviolet inhibitors reduce aging and weathering

2" x 25' HPS225D

2" x 100' HPS2100D

2" PVC Suction Hose

• For low temperature water suction & transfer

• Sub-zero, flexible HMWPVC

50' Fire Pump Discharge Kit

Includes –

• 50.015.007

reducing adapter 2" to 1.5"

• 50.015.0004

Connects adapter

• 50.015.001

Adapter

• 50.015.003

1.5" x 50' lay flat fire hose

• 50.015.002

1.5" fire nozzle

BEP359826

2" x 10' HPS210S

2" Centrifugal Strainer

• Protects pump from debris in suction hose HPS43307

2" FNPT Plastic Fogger Nozzle

• Adjustable spray

• Protective rubber bumper HPSJAHN

Quick Connect Discharge Hose Con guration

2" x 50' Hose With Quick Connect Ends HPS250DQD

Type "D"

Female x Female

NPT Thread HPS282888

Quick Connect Suction Hose Con guration

2" x 20' Hose With Quick Connect Ends HPS220SQD

Type "D"

Female x Female

NPT Thread HPS282888

Quick Connect Nozzle Con guration

2" x 1-1/2"

Galvanized

Bell Reducer GRI40596

1-1/2" x 2"

Galvanized Nipple GRI99178

1-1/2" Conical Fire Nozzle HPSPN15

Type "A"

Male x Female

NPT Thread HPS270380

Type "A"

Male x Female

NPT Thread HPS270380

1-1/2" Adjustable Fogger Nozzle HPSNB150

1" x 50' PVC Discharge Hose

• Premium water discharge hose featuring a balanced polyester yarn spiral wrap, longitudinal strength member and homogeneous PVC tube and cover

• Ultraviolet inhibitors reduce the aging and weathering process HPS150D

2" Fire ghting Pump Kit With 7.5 HP Gas Engine

Centrifugal aluminum pump with 225cc Powerease ® engine generates 40 PSI of pressure. Features recoil start and aluminum impeller. 0.95 gallon fuel tank capacity. 2" intake connection MNPT and outlet connection MNPT. 197' total lift and 26' suction lift. Includes 1-1/2" x 50' fire hose, 2" x 12' suction hose, fog/stream fire nozzle, fittings and foot valve. 7.5 HP and 126 gpm/7560 gph.

BEP16622

1" Centrifugal Water Pump With 4-Cycle 2.5 HP Engine

79cc Powerease ® engine with 0.15 gallon fuel capacity. Centrifugal aluminum pump with heavy-duty aluminum impeller. Recoil start and low oil shutdown. 1" intake and outlet connection MNPT. 85' total lift and 23' suction lift. 2.5 HP and 42 gpm/2040 gph.

BEPWP1020R

1" x 10'
