TBT HVAC Bi-Metal Thermometer
Description & Features:
• A durable and accurate thermometer with a rigid connection • Separable thermowell • Rugged steel case • Bi-metallic element • Dual scale (°F & °C) • Back or bottom connected • 1/2” NPT process connection • ASME B40.200 compliant • 5 year warranty
Advertisement
Applications:
• Hot water lines, boilers and hydronic heating
Dial Case Lens Ring Stem Thermowell Sensing Element Pointer Over Range Enclosure Rating Reset Ambient Temperature Process Temperature Accuracy Enclosure Rating
Warning
Specifi cations
3.5” (90mm), aluminum with black markings Steel Glass Steel, chrome plated Brass Brass, 1/2” NPT (standard), separable Bi-metallic coil Aluminum, painted black ±25% of full scale value Standard -22°F to 158°F (-30°C to 70°C) -22°F to 250°F (-30°C to 120°C) ±2% of full scale IP50 WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Order Codes (products in bold are normally stock in North America)
Range Bottom Back
30°F to 250°F & 0°C to 121°C TBT165 TBT160 0°F to 120°F - TBT161 Other ranges and connection sizes available upon request.
