Rigaku introduces new X-ray diffraction system with intelligent workflow automation EXCEPTIONAL
R
igaku Corporation, a world-leading provider of X-ray analytical instrumentation, is pleased to announce the release of a new X-ray diffractometer system with integrated sample-changing automation. The new diffractometer system features an integrated sample-changing automation platform, designed to improve the workflow. Rigaku XtaLAB Synergy diffractometers are known for high-performance X-ray sources and direct X-ray detection detectors, a combination designed for high throughput. The new XtaLAB Synergy Flow system incorporates a 6-axis UR3 Universal Robot into the popular XtaLAB Synergy diffractometer, enabling unattended data acquisition. By incorporating a unique X-ray safe dewar-drawer system that can be accessed from the side of the cabinet during data collection, the XtaLAB Synergy Flow system avoids the problem of having to halt data collection in order to open the enclosure and add more samples. Data collection can continue unimpeded. The XtaLAB Synergy Flow system is controlled by CrysAlisPro X-ray diffraction data collection and processing software for small molecule and protein crystallography, designed around an easy-to-use graphical user interface. The system utilises the Intelligent Goniometer Head (IGH), a motorised automated goniometer head with fast response and built in intelligence. On dual-camera systems, automated sample centring can be as fast as six seconds. As concerns about the spread of COVID-19 and other contagions grow, the XtaLAB Synergy Flow system can be used as part of a sample submission
protocol that minimises human contact. The XtaLAB Synergy Flow system was designed to take full advantage of the enhanced performance by minimising the time that an instrument might sit idle due to lack of human interaction. With automated sample mounting, potential contamination of the diffractometer by human contact is eliminated. A crystal capacity of 48 samples means that unattended data collection can be easily performed, minimising the time required to be in the X-ray laboratory.
The new XtaLAB Synergy Flow X-ray diffraction system from Rigaku Oxford Diffraction enables unattended data acquisition, enhanced productivity, and standardised workflow
VALUE IN
WIRSAM SCIENTIFIC Tel: (011) 482 1060 marketing@wirsam.com www.wirsam.com
PRECISION
WEIGHING
Fast and precise element analysis in organic sample materials
E
ltra‘s CS-580 is the ideal analyser for the simultaneous determination of carbon and sulphur in organic samples. Thanks to sample weights from 200mg or more, even inhomogeneous materials can be reliably analysed. The temperature of the powerful horizontal resistance furnace with ceramic combustion tube can be set to a maximum of 1 550°C with a working temperature of 1 350°C, ideal to burn any organic samples. The analyser can be equipped with a maximum of four independent infrared cells according to the user‘s requirements, allowing for a great variety of applications.
Application examples • Ashes, building materials, coal, coke, gypsum, limestone, oil, plant materials, rubber, sand, soils, soot, tobacco and waste. Product advantages • Simultaneous carbon and sulphur determination with minimal sample preparation • Wide range of organic materials can be analysed • Rapid, precise, accurate and reliable element determination • Resistance furnace can be set up to 1 550°C in steps of 1°C • Customised infrared cells provide wide, dynamic measuring range • A gold IR path that increases cell live time on all analysis of halogen or acid contents • Powerful software (multilingual, customised display, export of results) • Single and multipoint calibration • Simultaneous calibration of carbon and sulphur • Low maintenance • Robust design allows usage in production control and laboratory. VERDER SCIENTIFIC (PTY) LTD Tel: (010) 612 0141 sales@verder-scientific.co.za www.verder-scientific.com
