DEALING WITH FLOATING DEBRIS In this Q&A, GreenPort talks with Gregory Duquennois from Bolina Ltd, a company on a mission to clean up floating debris in the waterways Q
Why is the Bolina project so innovative?
In an effort to improve the water quality of Europe's rivers, Bolina Ltd, an Ecocoast company, has engineered the longest floating debris boom to catch plastic and other floating debris. The boom, installed on the Belgian tidal river of Scheldt, funnels 218kg a day into the plastic catcher, removing seven tonnes of debris and human pollutants a month from the river. An innovative design was required due to its tricky location on the river Scheldt near the Temse Bridge. Various factors came into play including the tidal effect of up to six metres, the alternating current directions and water speeds of up to two metres per second, as well as the river being a busy shipping route - a fitting challenge for both Bolina and DEME. The original design integrated the tried and tested Bolina floating debris booms that would rise and fall with the tide. Two giant 'arms' would form a funnel and guide the pollution towards the plastic collector to be trapped and then disposed of by means of a waste container and an autonomous vessel. Both arms are constructed from one full length, without intermediate pieces or other connections in order to maintain maximum tensile strength. The arms span 103 metres for the northern side of the funnel and the southern arm is 175 metres. Due to the extreme tidal effect, Bolina D-500 pile drivers were provided at the beginning of the booms, which followed the full height difference of six metres, four times a day. At the plastic collector, a special roller system was designed for the connection between the Bolina floating debris booms and the collector itself. The new roller system allows free movement between the dirt screen and the pontoon in the event of strong waves and tides, without losing any plastic or floating debris. The project utilised autonomous technology such as an installed pontoon, which is automatic and a collecting vessel to transport the debris onshore. Another innovative aspect of the project is the VR-technology, used to monitor and operate the installation remotely, which will identify the difference between a kayaker and a piece of timber that needs to be collected.
Q
How does the boom work?
DEME installed a litter trap in Temse, with a floating funnel, A made with Bolina Debris Booms that cover part of the river. Operational 24/7, it catches and collects drifting debris inside the Bolina floating debris boom. The booms guide the debris and plastic waste towards the litter trap, which collects everything from masks, to pieces of timber that would damage vessels on the river. Once the litter trap is full, everything is transferred into a CO2 neutral DEME vessel using VR technology. The debris is then transported to the riverbank, where DEME transfers once again the litter for collection and processing.
Q A
How can the system compliment the work that ports are doing to clean up their waters? If this DEME project was installed at strategic points, it would not interfere with ships, while creating an automatic
20 | SPRING 2021
Photo: Bolina Ltd
A
The boom funnels 218kg a day into the plastic catcher, removing seven tonnes of debris and human pollutants a month from the river
8 An innovative design was required due to the tricky location on the river Scheldt near the Temse Bridge
system for clean water, trapping the debris and human pollutants at the source and also protecting the vessels.
Q A Q
Could the installation be set up at a harbour/port entrance or is the aim to stop the litter from reaching the port? This project would work perfectly if the port is situated at a downstream river. Where could we see the system being used next?
This installation at Temse is currently the only one of its kind, and set to be a case study and example to waterway, government and environmental organisations who are looking for innovative products for their regions.
A
What further product solutions are in the pipeline to assist in cleaning up the rivers/waterways? Currently, Bolina Environment Booms are used for pollution A control in sensitive areas, such as industrial sites, nature reserves, harbours or marinas, pumping stations, water treatment works, dam spillways, just to mention a few. They are the toughest of their type, proudly designed and manufactured in the United
