Urban Canyon

Second fl oor plan with pool, boxing, offi ce, and basketball Third fl oor terrace with seating and activities such as badminton, ping pong, and long jump.

A B Fourth fl oor plan showing dance studios.

Ground fl oor plan which shows basketball, juice bar, front desk, changing rooms, interior/exterior seating for eating, studying, and etc., rock wall, glass wrapped staircase, and equipment area.

Zoomed in section axonometric illustrating the abundance of activity taking place in just a fraction of the project. From here, basketball, rock climbing, and badminton can all be seen.

Section A

Section B

Lane Avenue elevation

Lobby with studying space and reception desk.

Pool render illustrating the buildings many layers of transparency enabled by the trussed encasement of the grand stair.

Perspective from the intersection of Lane and Neil demonstrating building adjacencies with surrounding context as well as the energy created by perspectival distortion and directionality of the fenestration.
