PRODUCTION PRODUCTS Sponsored By
COMPACTION PRODUCTS HAMM GRW 280i Pneumatic Roller
Hyundai HR120C-9 Vibratory Roller The 26,455-lb. HR120C-9 single-drum vibratory roller features two-stage vibration system with dual amplitude, a centrifugal force of 240/140 kN (high/ low) & high/low frequency of 30/40 Hz. • Drum width of 6 ft. 10 in., drum diameter of 4 ft. 11 in. and a drum thickness of 1.18 in. • Gradeability up to 48% • 130-hp Deutz TCD 2012 L4 turbo, water-cooled diesel engine with optional ECO speed feature • HA control allows the traction drive to be automatically adjusted to different types of soil with no operator intervention ForConstructionPros. com/11351433
Road Widener Offset Vibratory Roller Attachment The Offset Vibe Roller Skid Steer Attachment offers interchangeable rollers in 2-, 3- and 4-ft. widths and includes an offset feature that allows the carrier and operator to stay on the road while rolling and compacting shoulders and ditches. • Can roll outside the shoulder’s slope (up to 30° drum pivot) and be dropped down into trenches with the drum positioned 30 in. below the mounting point • Produces 500 to 2,500 vpm with an amplitude of .02 in. for compaction of stone, asphalt, RAP and dirt • Remote control • Attaches via SAE quick-connector coupling and requires standard-flow hydraulics ForConstructionPros. com/20988103
52
ASPHALT CONTRACTOR AUGUST 2021
ACON0821_52-57_Compaction_JD.indd 52
The GRW 280i pneumatic roller updates its predecessor with subtle design changes and 114-hp Deutz Tier 4i engine. • 82 in. working width • Basic operating weight ratings available from 19,371 to 58,947 lbs. • Revised ballast compartment allows users to vary the operating weight • Includes a high-speed tire inflation system and standard oil service valve • Viewing channels in the frame structure offer a view of the edges and the tires of the outer wheels • Operator’s platform with movable, pivoting driver's seat rests on an asymmetrical frame ForConstructionPros.com/12039375
BOMAG BW 28 RH Pneumatic-Tired Roller
Dynapac CP2700 Pneumatic-Tired Roller
The BOMAG BW 28 RH pneumatictired roller features a large 106 cubic foot ballast compartment and efficient weight ballast changing system to boost wheel loads and improve compaction performance. • Designed for various applications from city streets and county roads to interstate highways and airports • Operating weights from 18,960 to 61,730 lbs. • Maximum wheel load of 7,715 lbs. for deep static compaction • Flexible ballast system offers the option of adding concrete, steel and/or underfloor weights plus water, dry sand or wet sand to quickly adapt machine weight to the application, resulting in optimum compaction performance
The Dynapac CP2700 pneumatic tired roller for soil compaction as well as asphalt finishing and sealing applications features a spacious platform, ergonomic controls and a rotating, sideway-sliding seat and steering assembly. • Tier 4i engine • Dual-circuit braking system maintains full braking effect even if one circuit is disabled • Compacting width of 7.55 ft. and a maximum operating weight of 59,000 lbs. • Optional temperature sensor and DCA-A analyzer can play back the rolling pattern and produce a printout of all relevant information
Co
The displ prog • At fe pr of LE lit th in st • De th m co (a ill no • It m w to
ForC com
Vin Ro
Muss Rolle indes
ForConstructionPros. com/12051951
ForConstructionPros. com/12312003
• Fi (o m th co • Th M th cu • If a
Volvo PT125C Pneumatic Roller The PT125C nine-wheeled pneumatic tire roller employs a kneading action for the compaction of hot and warm mix asphalt. • Heavy-duty 14-ply tires suited for chip seal applications • Central tire inflation system • 9,826 lb. operating weight (with ROPS) • 68.2 in. drum or rolling width • 74.3 hp Volvo D3.3 Tier 4 Final engine
ForC com
ForConstructionPros.com/12320053
www.ForConstructionPros.com/Asphalt
